Auxiliary Climate Control: Removal & Installation Jaguar XF I

INSTALLATION

1. See figure.
2. See figure.
3. See figure.
4. See figure.
5. Lower the vehicle.
6. Remove the coolant expansion tank pressure cap.
7. Fill the cooling system up to the MAX mark on the coolant expansion tank using a fifty percent mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification WSS M97B44-D and fifty percent water.
8. Install the coolant expansion tank pressure cap.
9. Start and run the engine.
10. Set the heating system to MAX heat, the blower motor to MAX speed and the air distribution to the instrument panel registers.
11. Allow the engine to run until hot air is emitted from the instrument panel registers, while observing the engine temperature gauge.
12. Switch the engine off.
13. Allow the engine to cool.
14. Release the cooling system pressure.
15. Fill the cooling system up to the MAX mark on the coolant expansion tank using a fifty percent mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification WSS M97B44-D and fifty percent water.
16. Install the coolant expansion tank pressure cap.
17. Raise the vehicle.
18. Check all coolant hoses for visible signs of coolant leaks.
19. Install the air deflector. Refer to: «AIR DEFLECTOR»(ref-568406-S42840487662013072200000) .

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 62

1. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-568400-S03532047432013072200000) .
2. Refer to: «HEATER CORE AND EVAPORATOR CORE HOUSING»(ref-568412-S20808139432013072200000) .
3. Torque: 1.3 Nm
4. See figure.

1. To install, reverse the removal procedure.
