Specifications

DescriptionNm
Front seat retaining bolts20
Front seat backrest retaining bolts25
Front seat cushion retaining nuts15
Front seat track motor retaining bolt10
Front seat cushion front height adjustment motor retaining bolt10
Front seat cushion rear height adjustment motor retaining bolts10
Front safety belt lower anchor retaining bolt55
Front seat safety belt pretensioner retaining bolt50
Fixed rear seat backrest retaining bolts55
Fixed rear seat retainer block bolt20
Folding rear seat backrest hinge retaining bolts - All vehicles55
Folding rear seat backrest center hinge plate retaining bolts - Wagon23
Folding rear seat latch retaining bolts - 4-door vehicles22
Folding rear seat latch retaining bolts - Wagon32
Rear center safety belt retractor retaining bolt - 4-door vehicles55
Rear center safety belt retractor retaining bolt - Wagon38
Rear center safety belt buckle retaining bolt - All vehicles55

Torque Specifications

Scheme 1

Scheme 1: Seats - Description & Operation
Item NumberDescription
1Front seat
2Front seat track and cushion front/rear height adjustment switch
3Front seat backrest recliner switch
4Front seat lumbar support switch

Scheme 2

Scheme 2
Item NumberDescription
1Front seat memory store switch
2Front seat memory switch
3Front seat backrest recliner switch
4Front seat lumbar support switch
5Front seat track and cushion front/rear height adjustment switch

Scheme 3

Scheme 3
Item NumberDescription
1Front seat track adjustment locking bar
2Front seat backrest recliner hand wheel
3Front seat cushion height adjustment switch (Driver side only)

Scheme 4

Scheme 4
Item NumberDescription
1Rear seat backrest bolster - RH
2Rear seat backrest
3Rear seat head restraints (Center rear seat head restraint is optional)
4Rear seat backrest
5Rear seat backrest bolster - LH
6Rear seat cushion
7Rear seat center arm rest

Scheme 5

Scheme 5
Item NumberDescription
1Rear seat backrest
2Rear seat head restraints (Center rear seat head restraint is optional)
3Rear seat cushion

Scheme 6

Scheme 6
Item NumberDescription
1Rear seat backrest bolster - RH
2Rear seat backrest
3Rear seat head restraints (Center rear seat head restraint is optional)
4Rear seat backrest
5Rear seat backrest bolster - LH
6Rear seat cushion
7Rear seat center arm rest

Scheme 7

Scheme 7
Item NumberDescription
1Front seat backrest recliner motor
2Front seat cushion front height adjustment motor
3Front seat track motor
4Front seat cushion rear height adjustment motor

Scheme 8

Scheme 8
Item NumberDescription
1Front seat cushion rear height adjustment motor
2Front seat cushion front height adjustment motor
3Front seat track motor

Scheme 9

Scheme 9
Item NumberDescription
1Front seat lumbar support bag
2Front seat lumbar motor

Scheme 10

Scheme 10
Item NumberDescription
1Front seat weight sensor
2Front seat weight sensor module

Scheme 11

Scheme 11
Item NumberDescription
1Seat Control Switch
2Heated Seat Module

Front Seats

All front seats are fitted with the following features as standard

  1. integral side air bags
  2. head restraints
  3. safety belt buckle/pretensioner

The driver and passenger seats, although almost identical, have some unique components fitted. The driver seat has a seat track position sensor and the passenger seat has a weight sensing system. In both instances the components form an integral part of the occupant restraint system. Refer to Seat Position Sensor . Refer to Occupant Classification Sensor .

The high option front seat has the following features

  1. electrically adjustable seat positioning
  2. electrically adjustable lumbar support (optional)
  3. heated seat (optional)

The basic option front seat has the following standard features

  1. electrically adjustable seat height positioning (driver seat only)
  2. heated seat (optional)

Seat Position Memory (Optional)

The seat position memory can be programmed for up to three different driver seat configurations and the seat memory switch, located in the seat control switch pack, can be used to store and retrieve the programmed configurations.

The seat position memory front seat has the following features

  1. electrically adjustable seat positioning with three position memory
  2. electrically adjustable lumbar support
  3. heated seat (optional)

Heated Seats (Optional)

The heated seat system comprises

  1. heated seat module (incorporated in the seat control switch pack on vehicles with seat position memory)
  2. heated seat switches
  3. backrest heater element
  4. cushion heater element and thermostat

The heated seat function permits the electrical heating of the seat back and cushion on the driver and front passenger seats. The heating system of each seat is selected by separate switches located at the top of the center console.

Pressing the appropriate switch activates the first stage of a three stage operation of the heated seat function

  1. one press of the switch activates the high setting (providing a seat surface temperature of approximately 42°C).
  2. a second press of the switch activates the low setting (providing a seat surface temperature of approximately 37°C).
  3. a third press of the switch deactivates the heating function.

Once the heated seat function has been activated, it will persist until one of the following conditions have been satisfied

  1. A fixed period of time has expired (10 minutes).
  2. The engine is not running.
  3. The function is deactivated by pressing the switch for a third time.
  4. A malfunction is detected by the heated seat module.

Confirmation that the heated seat function is active is indicated by the illumination of the relevant switch, a yellow light indicates the low temperature setting and a red light indicates the high temperature setting.

Heated Seat Module

The heated seat module is located behind the outer side trim panel of the front seat on vehicles without seat position memory, and is incorporated in to the seat control switch pack on vehicles with seat position memory. The module controls the seat heating function by providing the appropriate response depending on the status of the heated seat switches.

Power Lumbar Support

The power lumbar is a self-contained unit controlled directly by the seat mounted power lumbar switch. On vehicles with seat position memory, the power lumbar switch is incorporated in to the recliner switch in the seat control switch pack.

Rear Seats - 4-Door

Depending on the market specification the rear seats will be one of the following

  1. fixed bench style seat
  2. folding 70/30 split seat

Folding Seatbacks (if equipped)

The rear seatbacks can be folded forward to provide additional luggage space if required. Release handles for each seat back are located in the luggage compartment under the parcel shelf on 4-door vehicles, and on the top of the each seatback on wagon.

Rear Seats - Wagon

The rear seats on wagon are of the folding type with a 70/30 split, fitted with a folding armrest in the left-hand seat backrest. The left-hand seat also incorporates the rear center safety belt retractor, which has a release cable connected to the rear seat backrest latch to prevent the safety belt from operating if the rear seat backrest is not in the fully latched position.

Head Restraints

The front seat head restraints are adjustable for height and forward and rearward tilt.

The rear seat head restraints can be set to one of two height positions. The optional center rear seat head restraint (excluding Federal specification vehicles) can also be set to one of two height positions.

Ski Hatch - 4-Door Vehicles only (if equipped)

Skis or similar objects can be stowed in the vehicle by utilizing the two door hatch fitted to the rear seat. The inner door is accessible after folding down the armrest, the second door is accessible from inside the luggage compartment. A sack complete with strap is provided for holding the stored items, the strap connects to the center rear seat belt buckle to secure the sack and contents.

Seats - Diagnostic Procedures

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of mechanical or electrical damage. Visual Inspection Chart Mechanical Electrical Seat base Seat backrest Seat track(s) Lumbar assembly bag Fuse(s) Wiring harness Electrical connector(s) Motor(s) Switch(es) Heated seat module Lumbar assembly pump
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the concern is not visually evident, verify the symptom and refer to «Symptom Chart»(ref-311873-S27642976302009040700000) .

Pinpoint Test A: THE POWER SEAT IS INOPERATIVE - HIGH SPECIFICATION SEAT

Pinpoint Test A

A1 CHECK THE FRONT SEAT OPERATION
  1. Operate the LH seat control switch
Is the LH seat inoperative?
YES Go to step 2 .. → A2
NO Go to step 4 .. → 4
A2 CHECK THE VOLTAGE TO THE SEAT CONTROL SWITCH
  1. Switch the ignition switch to the OFF position.
  2. Disconnect the seat control switch electrical connector LS1.
  3. Switch the ignition switch to the ON position.
  4. Measure the voltage between the seat control switch electrical connector LS1 pin 6, (OG), and ground.
Is the voltage greater than 10 volts?
YES Go to step 3 .. → A3
NO REPAIR the circuit. TEST the system for normal operation.
A3 CHECK THE SEAT CONTROL SWITCH GROUND CIRCUIT
  1. Measure the resistance between the seat control switch electrical connector LS1 pin 1, (B), and ground.
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
A4 CHECK THE VOLTAGE TO THE SEAT CONTROL SWITCH
  1. Switch the ignition switch to the OFF position.
  2. Disconnect the seat control switch electrical connector RS1.
  3. Switch the ignition switch to the ON position.
  4. Measure the voltage between the seat control switch electrical connector RS1 pin 6, (OY), and ground.
Is the voltage greater than 10 volts?
YES Go to step 5 .. → A5
NO REPAIR the circuit. TEST the system for normal operation.
A5 CHECK THE SEAT CONTROL SWITCH GROUND CIRCUIT
  1. Measure the resistance between the seat control switch electrical connector RS1 pin 1, (B), and ground.
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test B: THE POWER SEAT IS INOPERATIVE - LOW SPECIFICATION SEAT ONLY

Pinpoint Test B

B1 CHECK THE LH FRONT SEAT HEIGHT ADJUSTMENT MOTOR OPERATION
  1. Operate the LH seat control switch to the UP position.
Is the LH seat height adjustment inoperative?
YES Go to step 2 .. → B2
NO Go to step 8 .. → 8
B2 CHECK THE LH SEAT CONTROL SWITCH POWER SUPPLY
  1. Disconnect the seat control switch electrical connector LS16.
  2. Measure the voltage between the seat control switch electrical connector LS16 pin 2, (OG), and ground.
Is the voltage greater than 10 volts?
YES Go to step 3 .. → B3
NO REPAIR the circuit. TEST the system for normal operation.
B3 CHECK THE LH SEAT CONTROL SWITCH GROUND CIRCUIT
  1. Measure the resistance between the seat control switch electrical connector LS16 pin 3, (B), and ground and between LS16 pin 6, (B), and ground.
Are the resistances less than 5 ohms?
YES Go to step 4 .. → B4
NO REPAIR the circuit. TEST the system for normal operation.
B4 CHECK THE LH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUITS
  1. Disconnect the seat height motor electrical connector LS10.
  2. Operate the seat control switch to the UP position.
  3. Measure the voltage between the seat height motor electrical connector LS10 pin 1, (YG), and LS10 pin 2, (WG).
Is the voltage greater than 10 volts?
YES INSTALL a new front seat height motor. TEST the system for normal operation.
NO Go to step 5 .. → 5
B5 CHECK THE LH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUIT
  1. Operate the seat control switch to the UP position.
  2. Measure the voltage between the seat height motor electrical connector LS10 pin 1, (YG), and ground.
Is the voltage greater than 10 volts?
YES Go to step 6 .. → B6
NO Go to step 7 .. → 7
B6 CHECK THE LH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS16.
  2. Measure the resistance between the seat height motor electrical connector LS10 pin 2, (WG), and the seat control switch electrical connector LS16 pin 7, (WG).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. TEST the system for normal operation.
NO REPAIR the circuit. TEST the system for normal operation.
B7 CHECK THE LH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Measure the resistance between the seat height motor electrical connector LS10 pin 1, (YG), and the seat control switch electrical connector LS16 pin 1, (YG).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. TEST the system for normal operation.
NO REPAIR the circuit. TEST the system for normal operation.
B8 CHECK THE RH SEAT CONTROL SWITCH POWER SUPPLY
  1. Disconnect the seat control switch electrical connector RS16.
  2. Measure the voltage between the seat control switch electrical connector RS16 pin 2, (OY), and ground.
Is the voltage greater than 10 volts?
YES Go to step 9 .. → B9
NO REPAIR the circuit. TEST the system for normal operation.
B9 CHECK THE RH SEAT CONTROL SWITCH GROUND CIRCUIT
  1. Measure the resistance between the seat control switch electrical connector RS16 pin 3, (B), and ground and between RS16 pin 6, (B), and ground.
Are the resistances less than 5 ohms?
YES Go to step 10 .. → B10
NO REPAIR the circuit. TEST the system for normal operation.
B10 CHECK THE RH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUITS
  1. Disconnect the seat height motor electrical connector RS10.
  2. Operate the seat control switch to the UP position.
  3. Measure the voltage between the seat height motor electrical connector RS10 pin 1, (WG), and RS10 pin 2, (YG).
Is the voltage greater than 10 volts?
YES INSTALL a new front seat height motor. TEST the system for normal operation.
NO Go to step 11 .. → 11
B11 CHECK THE RH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUIT
  1. Operate the seat control switch to the UP position.
  2. Measure the voltage between the seat height motor electrical connector RS10 pin 1, (WG), and ground.
Is the voltage greater than 10 volts?
YES Go to step 12 .. → B12
NO Go to step 13 .. → 13
B12 CHECK THE RH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS16.
  2. Measure the resistance between the seat height motor electrical connector RS10 pin 2, (YG), and the seat control switch electrical connector RS16 pin 7, (YG).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. TEST the system for normal operation.
NO REPAIR the circuit. TEST the system for normal operation.
B13 CHECK THE RH SEAT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Measure the resistance between the seat height motor electrical connector RS10 pin 1, (WG), and the seat control switch electrical connector RS16 pin 1, (WG).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. TEST the system for normal operation.
NO REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test D: THE POWER SEAT DOES NOT MOVE VERTICALLY - HIGH SPECIFICATION SEAT

Pinpoint Test D

D1 CHECK THE LH FRONT SEAT CUSHION HEIGHT ADJUSTMENT MOTORS FOR CORRECT OPERATION
  1. Operate the LH seat control switch to the seat cushion front/rear height adjustment position.
Is the LH seat cushion height adjustment inoperative?
YES Go to step 2 .. → D2
NO Go to step 11 .. → 11
D2 CHECK THE LH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR OPERATION
  1. Operate the LH seat control switch to the seat cushion front height adjustment position.
Is the LH seat cushion front height adjustment inoperative?
YES Go to step 3 .. → D3
NO Go to step 7 .. → 7
D3 CHECK THE LH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUITS
  1. Disconnect the seat cushion front height adjustment motor electrical connector LS5.
  2. Operate the seat control switch to the FRONT HEIGHT adjustment UP position.
  3. Measure the voltage between the seat cushion front height adjustment motor electrical connector LS5 pin 1, (YB), and LS5 pin 2, (WB).
Is the voltage greater than 10 volts?
YES INSTALL a new seat cushion front height adjustment motor. For additional information, refer to «Front Seat Front Height Adjustment Motor - Removal and Installation»(ref-311873-S27083760162009040700000) .
NO Go to step 4 .. → 4
D4 CHECK THE LH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUIT
  1. Operate the seat control switch to the FRONT HEIGHT adjustment UP position.
  2. Measure the voltage between the seat cushion front height adjustment motor electrical connector LS5 pin 1, (YB), and ground.
Is the voltage greater than 10 volts?
YES Go to step 5 .. → D5
NO Go to step 6 .. → 6
D5 CHECK THE LH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS1.
  2. Measure the resistance between the seat cushion front height adjustment motor electrical connector LS5 pin 2, (WB), and the seat control switch electrical connector LS1 pin 5, (WB).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D6 CHECK THE LH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS1.
  2. Measure the resistance between the seat cushion front height adjustment motor electrical connector LS5 pin 1, (YB), and the seat control switch electrical connector LS1 pin 4, (YB).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D7 CHECK THE LH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUITS
  1. Disconnect the seat cushion rear height adjustment motor electrical connector LS2.
  2. Operate the seat control switch to the REAR HEIGHT adjustment UP position.
  3. Measure the voltage between the seat cushion rear height adjustment motor electrical connector LS2 pin 1, (YU), and LS2 pin 2, (WR).
Is the voltage greater than 10 volts?
YES INSTALL a new seat cushion rear height adjustment motor. For additional information, refer to «Front Seat Front Height Adjustment Motor - Removal and Installation»(ref-311873-S27083760162009040700000) .
NO Go to step 8 .. → 8
D8 CHECK THE LH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUIT
  1. Operate the seat control switch to the REAR HEIGHT adjustment UP position.
  2. Measure the voltage between the seat cushion rear height adjustment motor electrical connector LS2 pin 1, (YU), and ground.
Is the voltage greater than 10 volts?
YES Go to step 9 .. → D9
NO Go to step 10 .. → 10
D9 CHECK THE LH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS1.
  2. Measure the resistance between the seat cushion rear height adjustment motor electrical connector LS5 pin 2, (WR), and the seat control switch electrical connector LS1 pin 8, (WR).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D10 CHECK THE LH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS1.
  2. Measure the resistance between the seat cushion rear height adjustment motor electrical connector LS2 pin 1, (YU), and the seat control switch electrical connector LS1 pin 9, (YU).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D11 CHECK THE RH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR OPERATION
  1. Operate the RH seat control switch to the seat cushion front height adjustment position.
Is the RH seat cushion front height adjustment inoperative?
YES Go to step 12 .. → D12
NO Go to step 16 .. → 16
D12 CHECK THE RH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUITS
  1. Disconnect the seat cushion front height adjustment motor electrical connector RS5.
  2. Operate the seat control switch to the FRONT HEIGHT adjustment UP position.
  3. Measure the voltage between the seat cushion front height adjustment motor electrical connector RS5 pin 1, (WB), and RS5 pin 2, (YB).
Is the voltage greater than 10 volts?
YES INSTALL a new seat cushion front height adjustment motor. For additional information, refer to «Front Seat Front Height Adjustment Motor - Removal and Installation»(ref-311873-S27083760162009040700000) .
NO Go to step 13 .. → 13
D13 CHECK THE RH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUIT
  1. Operate the seat control switch to the FRONT HEIGHT adjustment UP position.
  2. Measure the voltage between the seat cushion front height adjustment motor electrical connector RS5 pin 1, (WB), and ground.
Is the voltage greater than 10 volts?
YES Go to step 14 .. → D14
NO Go to step 15 .. → 15
D14 CHECK THE RH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS1.
  2. Measure the resistance between the seat cushion front height adjustment motor electrical connector RS5 pin 2, (YB), and the seat control switch electrical connector RS1 pin 5, (YB).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D15 CHECK THE RH FRONT SEAT CUSHION FRONT HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS1.
  2. Measure the resistance between the seat cushion front height adjustment motor electrical connector RS5 pin 1, (WB), and the seat control switch electrical connector RS1 pin 4, (WB).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D16 CHECK THE RH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUITS
  1. Disconnect the seat cushion rear height adjustment motor electrical connector RS2.
  2. Operate the seat control switch to the REAR HEIGHT adjustment UP position.
  3. Measure the voltage between the seat cushion rear height adjustment motor electrical connector RS2 pin 1, (WR), and RS2 pin 2, (YU).
Is the voltage greater than 10 volts?
YES INSTALL a new seat cushion rear height adjustment motor. For additional information, refer to «Front Seat Front Height Adjustment Motor - Removal and Installation»(ref-311873-S27083760162009040700000) .
NO Go to step 17 .. → 17
D17 CHECK THE RH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUIT
  1. Operate the seat control switch to the REAR HEIGHT adjustment UP position.
  2. Measure the voltage between the seat cushion rear height adjustment motor electrical connector RS2 pin 1, (WR), and ground.
Is the voltage greater than 10 volts?
YES Go to step 18 .. → D18
NO Go to step 19 .. → 19
D18 CHECK THE RH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS1.
  2. Measure the resistance between the seat cushion rear height adjustment motor electrical connector RS2 pin 2, (YU), and the seat control switch electrical connector RS1 pin 8, (YU).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
D19 CHECK THE RH FRONT SEAT CUSHION REAR HEIGHT ADJUSTMENT MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS1.
  2. Measure the resistance between the seat cushion rear height adjustment motor electrical connector RS2 pin 1, (WR), and the seat control switch electrical connector RS1 pin 9, (WR).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test E: THE POWER SEAT DOES NOT RECLINE - HIGH SPECIFICATION SEAT ONLY

Pinpoint Test E

E1 CHECK THE LH FRONT SEAT BACKREST MOTOR FOR CORRECT OPERATION
  1. Operate the LH seat control switch to the REARWARD RECLINE position.
Is the LH seat recline adjustment inoperative?
YES Go to step 2 .. → E2
NO Go to step 6 .. → 6
E2 CHECK THE LH FRONT SEAT BACKREST MOTOR CIRCUITS
  1. Disconnect the seat backrest motor electrical connector LS6.
  2. Operate the seat control switch to the REARWARD RECLINE position.
  3. Measure the voltage between the seat backrest motor electrical connector LS6 pin 2, (WR), and LS6 pin 1, (YR).
Is the voltage greater than 10 volts?
YES INSTALL a new seat backrest motor. For additional information, refer to «Front Seat Recliner Motor - Removal and Installation»(ref-311873-S42533331822009040700000) .
NO Go to step 3 .. → 3
E3 CHECK THE LH FRONT SEAT BACKREST MOTOR CIRCUIT
  1. Operate the seat control switch to the REARWARD RECLINE position.
  2. Measure the voltage between the seat backrest motor electrical connector LS6 pin 2, (WR), and ground.
Is the voltage greater than 10 volts?
YES Go to step 4 .. → E4
NO Go to step 5 .. → 5
E4 CHECK THE LH FRONT SEAT BACKREST MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS1.
  2. Measure the resistance between the seat backrest motor electrical connector LS6 pin 1, (YR), and the seat control switch electrical connector LS1 pin 7, (YR).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
E5 CHECK THE LH FRONT SEAT BACKREST MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector LS1.
  2. Measure the resistance between the seat backrest motor electrical connector LS6 pin 2, (WR), and the seat control switch electrical connector LS1 pin 12, (WR).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
E6 CHECK THE RH FRONT SEAT BACKREST MOTOR CIRCUITS
  1. Disconnect the seat backrest motor electrical connector RS6.
  2. Operate the seat control switch to the REARWARD RECLINE position.
  3. Measure the voltage between the seat backrest motor electrical connector RS6 pin 2, (YR), and RS6 pin 1, (WR).
Is the voltage greater than 10 volts?
YES INSTALL a new seat backrest motor. For additional information, refer to «Front Seat Recliner Motor - Removal and Installation»(ref-311873-S42533331822009040700000) .
NO Go to step 7 .. → 7
E7 CHECK THE RH FRONT SEAT BACKREST MOTOR CIRCUIT
  1. Operate the seat control switch to the REARWARD RECLINE position.
  2. Measure the voltage between the seat backrest motor electrical connector RS6 pin 2, (YR), and ground.
Is the voltage greater than 10 volts?
YES Go to step 8 .. → E8
NO Go to step 9 .. → 9
E8 CHECK THE RH FRONT SEAT BACKREST MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS1.
  2. Measure the resistance between the seat backrest motor electrical connector RS6 pin 1, (WR), and the seat control switch electrical connector RS1 pin 7, (WR).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
E9 CHECK THE RH FRONT SEAT BACKREST MOTOR CIRCUIT FOR OPEN
  1. Disconnect the seat control switch electrical connector RS1.
  2. Measure the resistance between the seat backrest motor electrical connector RS6 pin 2, (YR), and the seat control switch electrical connector RS1 pin 12, (YR).
Is the resistance less than 5 ohms?
YES INSTALL a new seat control switch. For additional information, refer to «Seat Control Switch - Removal and Installation»(ref-311873-S16224770012009040700000) .
NO REPAIR the circuit. TEST the system for normal operation.
