Seating: Overhaul Jaguar X-type I рестайлинг

Assembly

1. To assemble, reverse the disassembly procedure.

Scheme 80

1. Remove the front seat cushion. For additional information, refer to «Front Seat Cushion - Removal and Installation»(ref-311873-S09024542932009040700000) .
2. Remove the seat cushion cover. Unclip the seat cushion from the seat base. Cut the hog rings.

1. To assemble, reverse the disassembly procedure.

Scheme 81

Scheme 82

Scheme 83

1. Remove the rear seat backrest - folding.
2. Remove the head restraint(s).
3. Detach the backrest cover from the backrest. Detach the retaining strip.
4. Remove the armrest.
5. Remove the head restraint guides. Using a suitable screwdriver, press the locking tangs. Remove the head restraint guides.
6. Remove the backrest cover. Cut the hog rings.

1. To assemble, reverse the disassembly procedure.

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

1. Remove the rear seat backrest. See «Rear Seat Backrest - Wagon, Vehicles With: 70/30 Split Seat»(ref-311873-S03852708492009040700000) .
2. Remove the rear seat head restraints (if equipped).
3. Remove the rear seat backrest hinge bracket.
4. Remove the armrest.
5. Remove the rear seat backrest latch finisher.
6. Detach the rear seat backrest cover from the backrest. Detach the retaining strip.
7. Detach the rear center safety belt guide finisher.
8. Remove the rear center safety belt guide finisher.
9. Detach the rear seat backrest cover. Remove and discard the hog rings.
10. Detach the rear seat backrest cover.
11. Detach the rear seat backrest cover.
12. Detach the rear seat backrest cover. Remove and discard the hog rings.
13. Detach the rear seat backrest cover. Remove and discard the hog rings.
14. Detach the rear seat backrest cover. Remove and discard the hog rings.
15. Detach the rear seat backrest cover from the backrest latch.
16. Remove the rear sear head restraint guides. Using a suitable tool, press the locking tangs. Remove the rear seat head restraint guides.
17. Remove the rear seat backrest cover. Pass the center safety belt through the rear seat backrest cover.

1. To assemble, reverse the disassembly procedure.

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

1. Remove the rear seat backrest - fixed. For additional information, refer to «Rear Seat Backrest - Assembly and Disassembly (Vehicles With: 70/30 Split Seat)»(ref-311873-S16764728602009040700000) .
2. Remove the head restraints.
3. Detach the backrest cover. Cut the hog rings.
4. Detach the backrest cover. Detach the retaining strips.
5. Remove the head restraint guides. Using a suitable screwdriver, press the locking tang. Remove the head restraint guide.
6. Remove the backrest frame from the backrest cushion and cover.
7. Detach the backrest cover from the cushion. Cut the hog rings.
8. Remove the backrest cover. Cut the hog rings.

1. To assemble, reverse the disassembly procedure.

Scheme 103

1. Remove the rear seat backrest - bolster. For additional information, refer to «Rear Seat Backrest - Removal and Installation (-Bolster)»(ref-311873-S05064319802009040700000) .
2. Remove the backrest bolster cover. Cut the hog rings.

1. To assemble, reverse the disassembly procedure.

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

1. Remove the rear seat cushion. For additional information, refer to «Rear Seat Cushion - Removal and Installation»(ref-311873-S21302990952009040700000) .
2. Detach the seat cushion cover. Cut the hog rings.
3. Cut the seat cushion cover tension cord retaining hog rings.
4. Detach the seat cushion cover tension cords from the seat cushion.
5. Detach the seat cushion cover from the seat cushion.
6. Detach the seat cushion cover. Cut the hog rings.
7. Remove the seat cushion cover. Cut the hog rings.

1. To assemble, reverse the disassembly procedure.
