Specifications
| CAUTION | Do not use brake fluid ITT Super Dot 4 on 2006my vehicles onwards. Failure to follow this instruction may result in damage to the vehicle. |
Note. Brake fluid ITT Super Dot 4 has now been superseded by Shell ESL Super Dot 4 which is the Jaguar recommended brake fluid. Shell ESL Super Dot 4 can be used on all model years.
| Item | Specification |
|---|---|
| Brake fluid | ITT Super Dot 4 |
| Brake fluid | Shell ESL Super Dot 4 |
| Brake caliper slide pin grease | Klueber GLK1 |
Lubricants, Fluids, Sealers and Adhesives
| Description | Nm |
|---|---|
| Brake pipe union | 15 |
| Brake caliper anchor plate retaining bolts | 133 |
| Brake caliper retaining bolts | 30 |
| Brake hose retaining bracket | 40 |
| Brake hose to brake caliper | 10 |
Torque Specifications
Scheme 13
| Item Number | Description |
|---|---|
| 1 | Brake hose |
| 2 | Brake caliper retaining bolts |
| 3 | Brake pads |
| 4 | Brake caliper anchor plate |
| 5 | Brake disc |
| 6 | Wheel hub |
| 7 | Wheel knuckle |
| 8 | Brake hose retaining bracket |
| 9 | Brake caliper |
| WARNING | Brake fluid contains polyglycol ethers and polyglycol. Avoid contact with the eyes. Wash hands thoroughly after handling. If brake fluid contacts the eyes, flush the eyes for 15 minutes with cold running water. Get medical attention if irritation persists. If taken internally, drink water and induce vomiting. Get medical attention immediately. Failure to follow these instructions can result in personal injury. |
Note. Brake system materials inherently generate heat in order to dissipate energy. As a result, occasional squeal is possible, which may be compounded by severe environmental conditions, such as cold, heat, rain, snow, salt and mud.
The front disc brake system consists of the following components
- Brake pads.
- Single piston, floating brake calipers.
- Brake discs.
- Brake caliper anchor plates.
- Brake hoses.
The brake caliper has two retaining bolts that attach it to the brake caliper anchor plate. The brake caliper anchor plate is attached to the wheel knuckle with two retaining bolts. The hydraulic system provides separate circuits for each pair of diagonally opposed wheels (i.e. left front, right rear and right front, left rear).
The brake disc is manufactured from cast iron and is of the vented type. It is retained on the wheel hub studs by the wheel and wheel nuts.
The brake calipers are mounted on the wheel knuckles. These are of single, sliding piston type which ensures that equal effort is applied through both brake pads.
For additional information, refer to Brake System - General Information article.
Caliper - Removal and Installation
Special Tools Tool Illustration Tool Name Tool Number Brake pedal hold-down tool JDS 9013
Scheme 14
Scheme 15
Scheme 16
- Remove the wheel and tire. For additional information, refer to «Wheels and Tires»(ref-311836) article.
- Detach the brake hose. Detach the brake pipe. Remove the retaining clip. Detach the brake hose.
- Detach the brake hose.
- Remove the brake caliper. Remove and discard the brake caliper retaining bolts.
Scheme 17
- Install the brake caliper. Tighten to 30 Nm.
- Attach the brake hose to the brake caliper. Tighten to 10 Nm.
- Attach the brake hose. Attach the brake hose. Install the retaining clip. Attach the brake pipe.
- Remove the brake pedal hold down tool.
- Bleed the brake system. For additional information, refer to «Brake System - General Information»(ref-311845) article.
- Install the wheel and tire. For additional information, refer to «Wheels and Tires»(ref-311836) article.
Scheme 18
Scheme 19
Scheme 20
- Remove the brake pads, refer to «Pads - Removal and Installation»(ref-311859-S01933560392009040700000) .
- Remove and discard the brake caliper anchor plate retaining bolts.
- Detach the brake caliper, brake caliper anchor plate assembly and secure to one side.
- Remove the brake disc.
