OBD MONITOR OPERATION

Some OBD monitors are continuous, that is, they operate all the time the ignition is on.

Some OBD monitors have conditions that must be satisfied before the monitor is allowed to operate, for example: engine speed 1000-4000 RPM; engine airflow 10 - 100 g/sec; intake air temperature -10°C - +50°C. These conditions ensure the vehicle is operating in such a manner that the failure may be correctly diagnosed. If the conditions are not met, it may be possible for a failure to be present on the vehicle but remain undetected by the module.

Most OBD monitors use 2-trip detection: on the first occasion the failure is detected, a pending DTC is recorded. If on the subsequent drive cycle, the failure is again detected, then a confirmed DTC is logged and the MIL may be illuminated.

A few OBD monitors operate on a single trip basis where the MIL is illuminated as soon as the failure is diagnosed.

Detection of a failure may inhibit the operation of other OBD monitors to ensure that multiple DTCs are not logged due to a single fault being present.

Note. The system is not infallible and a single fault may result in two or more failures being detected and hence the recording of two or more DTCs.

Scheme 1

DTC DESCRIPTIONS & POSSIBLE CAUSES

Note. It is recommended that the applicable WIRING DIAGRAMS be referenced when using the information contained in (Scheme 4) - (Scheme 92).

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89
