Engine Ignition - 4.0L: Other Jaguar S-type I

Ignition System 6 illustrations ~192 words

A1: CHECK THE IGNITION COIL SUPPLY VOLTAGE CIRCUIT

Pinpoint Test A

A3 Is the voltage greater than 10.5 Volts?

A2: CHECK THE IGNITION COIL RESISTANCE

Pinpoint Test A

A2 Is the resistance between 0.50 and 1.00 Ohms?

A3: CHECK THE CONTINUITY BETWEEN THE PCM AND THE IGNITION COIL

Pinpoint Test A

A3 Is the resistance less than 0.5 Ohms?

Scheme 22

Scheme 22: Removal
Scheme 22: Removal

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Disconnect the battery ground cable.
  2. Remove the engine cover.
  3. Remove the evaporative emission canister purge valve. For additional information, refer to «EVAPORATIVE EMISSION CANISTER PURGE VALVE»(ref-199544-S02967808202005101900000) .
  4. Remove the oil level indicator.
  5. Detach the power assisted steering fluid reservoir.
  6. Unclip the engine breather hose.
  7. Remove the air intake tube. For additional information, refer to «AIR CLEANER OUTLET PIPE»(ref-199543-S00056862962005101900000) .
  8. Remove the ignition coil cover.
  9. Disconnect the ignition coil electrical connector.
  10. Remove the ignition coil.

Scheme 27

Scheme 27: Installation
Scheme 27: Installation
  1. To install, reverse the Removal procedure.
