DCA System Service

CAUTIONTurn the MAIN switch OFF in conditions similar to driving, such as free rollers or a chassis dynamometer. Do not use or disassemble the ICC sensor removed from the vehicle. Erase DTC when replacing parts of DCA system, then check the operation of DCA system after performing radar beam alignment, if necessary.

Scheme 102

Scheme 102: Component Parts Location

Input Signal Item

Transmit unitSignal nameDescription
ECMCAN communicationClosed throttle position signalReceives idle position state (ON/OFF)
Accelerator pedal position signalReceives accelerator pedal position (angle)
ICC steering switch signalDynamic driver assistance switch signalReceives the operational state of the ICC steering switch
Engine speed signalReceives engine speed
Stop lamp switch signalReceives an operational state of the brake pedal
Snow mode switch signalReceives an operational state of the snow mode
TCMCAN communicationInput speed signalReceives the number of revolutions of input shaft
Current gear position signalReceives a current gear position
Shift position signalReceives a selector lever position
Output shaft revolution signalReceives the number of revolutions of output shaft
ABS actuator and electric unit (control unit)CAN communicationABS malfunction signalReceives a malfunction state of ABS
ABS operation signalReceives an operational state of ABS
ABS warning lamp signalReceives an ON/OFF state of ABS warning lamp
TCS malfunction signalReceives a malfunction state of TCS
TCS operation signalReceives an operational state of TCS
VDC OFF switch signalReceives an ON/OFF state of VDC
VDC malfunction signalReceives a malfunction state of VDC
VDC operation signalReceives an operational state of VDC
Vehicle speed signal (ABS)Receives wheel speeds of four wheels
Stop lamp switch signalReceives an operational state of the brake pedal
Yaw rate signalReceives yaw rate acting on the vehicle
Steering angle sensorCAN communicationSteering angle sensor malfunction signalReceives a malfunction state of steering angle sensor
Steering angle sensor signalReceives the number of revolutions, turning direction of the steering wheel
Steering angle speed signalReceives the turning angle speed of the steering wheel
Combination meterCAN communicationSystem selection signalReceives a selection state of each item in "Driving Aids" selected with the vehicle information display
ICC sensorITS communicationICC sensor signalReceives detection results, such as the presence or absence of a vehicle ahead and distance from the vehicle
Accelerator pedal actuatorITS communicationAccelerator pedal actuator operation status signalReceives an operational state of accelerator pedal actuator

Output Signal Item

Reception unitSignal nameDescription
ABS actuator and electric unit (control unit)CAN communicationBrake fluid pressure control signalTransmits a brake fluid pressure control signal to activates the brake
Combination meterCAN communicationMeter display signalVehicle ahead detection indicator signalTransmits a signal to display a state of the system on the information display
DCA system switch indicator signal
ICC warning lamp signalTransmits an ICC warning lamp signal to turn ON the ICC system warning lamp
Buzzer output signalTransmits a buzzer output signal to activate the buzzer
ICC sensorITS communicationVehicle speed signalTransmits a vehicle speed calculated by the ADAS control unit
Steering angle sensor signalTransmits a steering angle sensor signal received from the steering angle sensor
Accelerator pedal actuatorITS communicationAccelerator pedal position signalTransmits an accelerator pedal angle calculated by the ADAS control unit
Accelerator pedal feedback force control signalTransmits a target actuation force value calculated by the ADAS control unit
ICC brake hold relayICC brake hold relay drive signalActivates the brake hold relay and turns ON the stop lamp

When a vehicle is detected ahead

  1. The vehicle ahead detection indicator comes ON.

When vehicle approaches a vehicle ahead

  1. If the driver is not depressing the accelerator pedal, the system activates the brakes to decelerate smoothly as necessary. If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limitations of the system.
  2. If the driver is depressing the accelerator pedal, the system moves the accelerator pedal upward to assist the driver to release the accelerator pedal.

Fail-safe (ADAS Control Unit)

If a malfunction occurs in any system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp or warning message will display.

SystemBuzzerWarning lamp/Indicator lampDescription
Vehicle-to-vehicle distance control modeHigh-pitched toneICC system warning lampCancel
Conventional (fixed speed) cruise control modeHigh-pitched toneICC system warning lampCancel
Intelligent Brake Assist (IBA)High-pitched toneIBA OFF indicator lampCancel
Forward Collision Warning (FCW)High-pitched toneWarning messageCancel
Distance Control Assist (DCA)High-pitched toneICC system warning lampCancel
Lane Departure Warning (LDW)Lane Departure Warning lampCancel
Lane Departure Prevention (LDP)Low-pitched toneLane Departure Warning lampCancel
Blind Spot Warning (BSW)Blind Spot Warning/Blind Spot Intervention warning lampCancel
Blind Spot Intervention (BSI)Low-pitched toneBlind Spot Warning/Blind Spot Intervention warning lampCancel
Backup Collision Intervention (BCI)High-pitched toneBackup Collision Intervention warning indicatorCancel

Fail-safe (ICC Sensor)

If a malfunction occurs in the ICC sensor, ADAS control unit cancels control, sounds a beep, and turns ON the ICC system warning lamp in the combination meter.

Scheme 103

Scheme 103: Switch Name and Function
No.Switch nameDescription
1Dynamic driver assistance switchTurns the DCA system ON/OFF (When the setting of the DCA system in the vehicle information display is ON)
2DCA system setting screen (in the vehicle information display)DCA system settings can be switched between ON and OFF

Scheme 104

Scheme 104: SYSTEM DISPLAY
No.Switch nameDescription
1Dynamic driver assistance switch OFFIndicates that DCA system is OFF.
2Dynamic driver assistance switch ON (DCA set)Indicates that DCA system is ON with no vehicle ahead

System Control Condition Display

The DCA system indicator on the vehicle information display illuminates when the system is turned ON by pressing the dynamic driver assistance switch.

Condition Display on combination meter Operation status System set display with vehicle ahead System set display with out vehicle ahead

Approach Warning Display

  1. If own vehicle comes closer to the vehicle ahead due to rapid deceleration of that vehicle or if another vehicle cuts in, the system warns the driver with the chime and DCA system display. Decelerate by depressing the brake pedal to maintain a safe vehicle distance if: The chime sounds. The vehicle ahead detection indicator blinks.
  2. The warning chime may not sound in some cases when there is a short distance between vehicles. Some examples are: When the vehicles are traveling at the same speed and the distance between vehicles is not changing When the vehicle ahead is traveling faster and the distance between vehicles is increasing When a vehicle cuts in near own vehicle
  3. The warning chime will not sound when own vehicle approaches vehicles that are parked or moving slowly.

Warning Lamp Display

Condition Description Display on combination meter Warning display When the dynamic driver assistance switch is turned ON with settings of DCA system, LDP system and Blind Spot Intervention system OFF The DCA system is not activated. The DCA system switch indicator blinks. When the road is slippery and VDC or ABS (including the TCS) operates When the VDC is turned OFF When the SNOW mode switch is turned ON The DCA system is automatically canceled. The chime will sound and the DCA system switch indicator will blink. NOTE: The system operates if the dynamic driver assistance switch is turned OFF-->ON after the condition improves. When the sensor window is dirty, making it impossible to detect a vehicle ahead The DCA system is automatically canceled. The chime sounds and the ICC system warning lamp will come on and the "Sensor Blocked" indicator will appear. NOTE: Stop the vehicle in a safe location and turn the ignition switch OFF. Clean the dirty area. The system returns to normal condition when turning the ignition switch ON again. When the DCA system is not operating properly The chime sounds and the DCA system warning indicator (orange) will come on. NOTE: Turn the ignition switch OFF, and then turn the ignition switch ON again. If there is no malfunction, the system returns to the normal condition. NOTE: When the DCA system is automatically canceled, the cancellation condition can be displayed on "WORK SUPPORT" of CONSULT (ICC/ADAS)

Scheme 105

Scheme 105: Warning Lamp Display

Scheme 106

Scheme 106: Precautions for Distance Control Assist

Scheme 107

Scheme 107
  1. If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limitations of the system. The system will cancel once it judges that the vehicle has come to a standstill with a warning chime. To prevent the vehicle from moving, the driver must depress the brake pedal.
  2. The DCA system will not apply brake control while the driver is depressing the accelerator pedal.
  3. This system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the driver's responsibility to stay alert, drive safely and be in control of the vehicle at all times.
  4. This system will not adapt automatically to road conditions. Do not use the system on roads with sharp curves, or on icy roads, in heavy rain or in fog.
  5. The distance sensor will not detect under most conditions. Stationary and slow moving vehicles Pedestrians or objects in the roadway Oncoming vehicles in the same lane Motorcycles traveling offset in the travel lane
  6. As there is a performance limit to the distance control function, never rely solely on the DCA system. This system does not correct careless, inattentive or absent-minded driving, or overcome poor visibility in rain, fog, or other bad weather. Decelerate the vehicle speed by depressing the brake pedal, depending on the distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance between vehicles.
  7. The system may not detect the vehicle in front of own vehicle in certain road or weather conditions. To avoid accidents, never use the DCA system under the following conditions. On roads with sharp curves On slippery road surfaces such as on ice or snow, etc. On off-road surfaces such as on sand or rock, etc. During bad weather (rain, fog, snow, etc.) When rain, snow or dirt on system sensor On steep downhill roads (frequent braking may result in overheating the brakes) On repeated uphill and downhill roads When towing a trailer or other vehicle
  8. In some road or traffic conditions, a vehicle or object can unexpectedly come into the sensor detection zone and cause automatic braking. Driver may need to control the distance from other vehicles using the accelerator pedal. Always stay alert and avoid using the DCA system when it is not recommended in this article.
  9. The following are some conditions in which the sensor cannot detect the signals. When the snow or road spray from traveling vehicles reduces the sensor's visibility When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle
  10. The DCA system is designed to automatically check the sensor's operation. When the front bumper area of the distance sensor is covered with dirt or is obstructed, the system will automatically be cancelled. If the front bumper area of the distance sensor is covered with ice, a transparent or translucent vinyl bag, etc., the DCA system may not detect them. In these instances, the DCA system may not be able to decelerate the vehicle properly. Be sure to check and clean the sensor regularly.
  11. The DCA system is designed to help assist the driver to maintain a following distance from the vehicle ahead. The system will decelerate as necessary and if the vehicle ahead comes to a stop, the vehicle decelerates to standstill. However, the DCA system can only apply up to 25% of the vehicles total braking power. If a vehicle moves into the traveling lane ahead or if a vehicle traveling ahead rapidly decelerates, the distance between vehicles may become closer because the DCA system cannot decelerate the vehicle quickly enough. If this occurs, the DCA system will sound a warning chime and blink the system display to notify the driver to take necessary action.
  12. The DCA system does not control vehicle speed or warn when driver approach stationary and slow moving vehicles. Driver must pay attention to vehicle operation to maintain proper distance from vehicles ahead.
  13. The detection zone of the sensor is limited. A vehicle ahead must be in the detection zone for the system to operate. A vehicle ahead may move outside of the detection zone due to its position within the same lane of travel. Motorcycles may not be detected in the same lane ahead if they are traveling offset from the center line of the lane. A vehicle that is entering the lane ahead may not be detected until the vehicle has completely moved into the lane. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime. The driver may have to manually control the proper distance away from vehicle traveling ahead. When driving on some roads, such as winding, hilly, curved, narrow roads, or roads which are under construction, the sensor may detect vehicles in a different lane, or may temporarily not detect a vehicle traveling ahead. This may cause the system to work inappropriately. The detection of vehicles may also be affected by vehicle operation (steering maneuver or traveling position in the lane, etc.) or vehicle condition. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime unexpectedly. The driver will have to manually control the proper distance away from the vehicle traveling ahead.
  14. The approach warning chime may sound and the system display may blink when the sensor detects some reflectors which are fitted on vehicles in other lanes or on the side of the road. This may cause the DCA system to operate inappropriately. The sensor may detect these reflectors when the vehicle is driven on winding roads, hilly roads or when entering or exiting a curve. The sensor may also detect reflectors on narrow roads or in road construction zones. In these cases driver will have to manually control the proper distance ahead of own vehicle. Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage).
  15. The DCA system automatically decelerates own vehicle to help assist the driver to maintain a following distance from the vehicle ahead. Manually brake when deceleration is required to maintain a safe distance upon sudden braking by the vehicle ahead or when a vehicle suddenly appears in front of own vehicle. Always stay alert when using the DCA system.
  16. When the vehicle ahead detection indicator lamp is not illuminated, system will not control or warn the driver.
  17. Depending on the position of the accelerator pedal, the system may not be able to assist the driver to release the accelerator pedal appropriately.
  18. If the vehicle ahead comes to a standstill, the vehicle decelerates to a standstill within the limitations of the system. The system will release brake control with a warning chime once it judges the vehicle is at a standstill. To prevent the vehicle from moving, the driver must depress the brake pedal. [The system will resume control automatically once the system reaches 5 km/h (3 MPH)].

METHOD OF STARTING

CAUTIONStart condition of on board self-diagnosis ICC system OFF DCA system OFF Vehicle speed 0 km/h (0 MPH)

Scheme 108

Scheme 108

Scheme 109

Scheme 109
  1. Turn the ignition switch OFF.
  2. Start the engine.
  3. Wait for 5 seconds after starting the engine. Push up the RESUME/ACCELERATE switch 5 times and push down the SET/COAST switch 5 times within 10 seconds. NOTE: If the above operation cannot be performed within 10 seconds after waiting for 5 seconds after starting the engine, repeat the procedure from step 1 .
  4. The DTC is displayed on the set vehicle speed indicator (1) on the ICC system display on the information display when the on board self-diagnosis starts. Refer to " «DTC Index»(ref-657693-S08924484212014092200000) ". NOTE: It displays for up to 5 minutes and then stops. If multiple malfunctions exist, up to 6 DTCs can be stored in memory at the most, and the most recent one is displayed first.

CONSULT Function (ICC/ADAS)

CAUTIONAfter disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must be cycled OFF --> ON (for at least 5 seconds) --> OFF. If this step is not performed, the BCM may not go to "sleep mode", potentially causing a discharged battery and a no-start condition.

WORK SUPPORT

Work support itemsDescription
CAUSE OF AUTO-CANCEL 1Displays causes of automatic system cancellation occurred during control of the following systems Vehicle-to-vehicle distance control mode Conventional (fixed speed) cruise control mode Distance Control Assist (DCA)
CAUSE OF AUTO-CANCEL 2Displays causes of automatic system cancellation occurred during control of the following systems Lane Departure Prevention (LDP) Blind Spot Intervention
CAUSE OF AUTO-CANCEL 3Displays causes of automatic system cancellation occurred during control of the following system Backup Collision Intervention
NOTE: Causes of the maximum five cancellations (system cancel) are displayed. The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to 254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.
NOTE
Causes of the maximum five cancellations (system cancel) are displayed. The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to 254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.

Scheme 110

Scheme 110: Display Items for The Cause of Automatic Cancellation 1

Scheme 111

Scheme 111: Display Items for The Cause of Automatic Cancellation 2

Scheme 112

Scheme 112

Scheme 113

Scheme 113: Display Items for The Cause of Automatic Cancellation 3

BRAKE ACTUATOR

Note. The test can be performed only when the engine is running.

Test itemOperationDescription"PRESS SENS" value
BRAKE ACTUATORMODE1Transmits the brake fluid pressure control signal to the ABS actuator and electric unit (control unit) via CAN communication10 bar
MODE220 bar
MODE330 bar
Test startStarts the tests of "MODE1", "MODE2" and "MODE3"
ResetStops transmitting the brake fluid pressure control signal below to end the test
EndReturns to the "SELECT TEST ITEM" screen

Note. The test is finished in 10 seconds after starting

Scheme 114

Scheme 114

ICC BUZZER

Test itemOperationDescriptionICC warning chime operation sound
ICC BUZZERMODE1Transmits the buzzer output signals to the combination meter via CAN communicationIntermittent beep sound
Test startStarts the tests of "MODE1"
ResetStops transmitting the buzzer output signal below to end the test
EndReturns to the "SELECT TEST ITEM" screen

METER LAMP

Note. The test can be performed only when the engine is running.

Test itemOperationDescriptionMAIN switch indicator ICC system warning lamp IBA OFF indicator lamp
METER LAMPOffStops sending the following signals to exit from the test Meter display signal ICC warning lamp signal IBA OFF indicator lamp signalOFF
OnTransmits the following signals to the combination meter via CAN communication Meter display signal ICC warning lamp signal IBA OFF indicator lamp signalON

STOP LAMP

Test itemOperationDescriptionStop lamp
STOP LAMPOffStops transmitting the ICC brake hold relay drive signal below to end the testOFF
OnTransmits the ICC brake hold relay drive signalON

ACTIVE PEDAL

CAUTIONShift the selector lever to "P" position, and then perform the test. Never depress the accelerator pedal excessively. (The engine speed may rise unexpectedly when finishing the test.)

Note. Depress the accelerator pedal to check when performing the test. The test can be performed only when the engine is running.

Test itemOperationDescriptionAccelerator pedal operation
Active PedalMODE1Transmit the accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS communication.Constant with a force of 25 N for 8 seconds
MODE2Constant with a force of 15 N for 8 seconds
MODE3Change up to a force of 25 N for 8 seconds
MODE4Change up to a force of 15 N for 8 seconds
Test startStarts the tests of "MODE1", "MODE2", "MODE3" and "MODE4"
ResetStops transmitting the accelerator pedal feedback force control signal below to end the test.
EndReturns to the "SELECT TEST ITEM" screen

Note. The test is finished in 10 seconds after starting

Scheme 115

Scheme 115

DCA INDICATOR

Note. The test can be performed only when the engine is running.

Test itemOperationDescriptionDCA system switch indicator
DCA INDICATOROffStops transmitting the DCA system switch indicator signal below to end the test
OnTransmits the DCA system switch indicator signal to the combination meter via CAN communicationON

LDP BUZZER

Test itemOperationDescriptionWarning buzzer
LDP BUZZEROffStops transmitting the warning buzzer signal below to end the test
OnTransmits the warning buzzer signal to the warning buzzerON

WARNING SYSTEM IND

Test itemOperationDescriptionWarning systems ON indicator
WARNING SYSTEM INDOffStops transmitting the warning systems ON indicator signal below to end the test
OnTransmits the warning systems ON indicator signal to the warning systems ON indicatorON

LDP ON IND

Test itemOperationDescriptionLDP ON indicator lamp (Green)
LDP ON INDOffStops transmitting the LDP ON indicator lamp signal below to end the test
OnTransmits the LDP ON indicator lamp signal to the combination meter via CAN communicationON

LANE DEPARTURE W/L

Test itemOperationDescriptionLane departure warning lamp (Yellow)
LANE DEPARTURE W/LOffStops transmitting the lane departure warning lamp signal below to end the test
OnTransmits the lane departure warning lamp signal to the combination meter via CAN communicationON

BSW/BSI WARNING LAMP

Test itemOperationDescriptionBlind Spot Warning/Blind Spot Intervention warning lamp (Yellow)
BSW/BSI WARNING LAMPOffStops transmitting the Blind Spot Warning/Blind Spot Intervention warning lamp signal below to end the test
OnTransmits the Blind Spot Warning/Blind Spot Intervention warning lamp signal to the combination meter via CAN communicationON

BSI ON INDICATOR

Test itemOperationDescriptionBlind Spot Intervention ON indicator lamp (Green)
BSI ON INDICATOROffStops transmitting the Blind Spot Intervention ON indicator signal below to end the test
OnTransmits the Blind Spot Intervention ON indicator signal to the combination meter via CAN communicationON

LDW ON INDICATOR

Test itemOperationDescriptionLane Departure Warning ON indicator lamp (Yellow)
LDW ON INDICATOROffStops transmitting the Lane Departure Warning ON indicator signal below to end the test
OnTransmits the Lane Departure Warning ON indicator signal to the combination meter via CAN communicationON

BSW ON INDICATOR

Test itemOperationDescriptionBlind Spot Warning ON indicator lamp (Yellow)
BSW ON INDICATOROffStops transmitting the Blind Spot Warning ON indicator signal below to end the test
OnTransmits the Blind Spot Warning ON indicator signal to the warning lamp on the doorON

CONSULT Function (LASER/RADAR)

CAUTIONAfter disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must be cycled OFF --> ON (for at least 5 seconds) --> OFF. If this step is not performed, the BCM may not go to "sleep mode", potentially causing a discharged battery and a no-start condition.

DATA MONITOR

Monitored item [Unit]Description
VHCL SPEED SE [km/h] or [mph]Vehicle speed judged from a vehicle speed signal read by the ICC sensor via ITS communication is displayed [ADAS control unit receives a vehicle speed signal from ABS actuator and electric unit (control unit) via CAN communication and transmits the calculated vehicle speed to ICC sensor via ITS communication]
YAW RATE [deg/s]Indicates yaw rate read from ADAS control unit through ITS communication (ADAS control unit receives yaw rate signal from ABS actuator and electric unit (control unit) via CAN communication and transmits yaw rate calculated by the ADAS control unit) Yaw rate judged from a yaw rate signal read by ICC sensor via ITS communication is displayed [ADAS control unit receives a yaw rate signal from ABS actuator and electric unit (control unit) via CAN communication and transmits the calculated yaw rate to ICC sensor via ITS communication]
PWR SUP MONI [V]Indicates IGN voltage input by ICC sensor
DISTANCE [m]Indicates the distance from the vehicle ahead
RELATIVE SPD [m/s]Indicates the relative speed of the vehicle ahead
RADAR OFFSET [m]NOTE: The item is indicated, but not used
RADAR HEIGHT [m]NOTE: The item is indicated, but not used
STEERING ANGLE [deg]The steering angle is displayed
STRG ANGLE SPEED [deg/s]The steering angle speed is displayed
L/R ADJUST [deg]Indicates a horizontal correction value of the radar
U/D ADJUST [deg]Indicates a vertical correction value of the radar
NOTE
The item is indicated, but not used
NOTE
The item is indicated, but not used
Work support itemsDescription
MILLIWAVE RADAR ADJUSTOutputs ICC sensor waves, calculates the displacement in radar direction, and indicates an adjustment direction

CONSULT Function (ACCELERATOR PEDAL ACT)

CAUTIONAfter disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must be cycled OFF --> ON (for at least 5 seconds) --> OFF. If this step is not performed, the BCM may not go to "sleep mode", potentially causing a discharged battery and a no-start condition.

FFD (Freeze Frame Data)

The accelerator pedal actuator records the following data when the malfunction is detected.

Freeze Frame Data item [Unit]Description
TGT FBK FRC [N]It displays the target accelerator pedal actuation force that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication at the time when the malfunction is detected
TGT MOT POSI [%]It displays the target motor position that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication at the time when the malfunction is detected
ACT MOT POSI [%]It displays the integrated motor position that the accelerator pedal actuator read out at the time when the malfunction is detected
AP OPEN [%]It displays the accelerator pedal position signal that the accelerator pedal actuator read out via ITS communication at the time when the malfunction is detected
APA TEMP [°C]It displays the integrated motor temperature that the accelerator pedal actuator read out at the time when the malfunction is detected
APA CURRENT [A]It displays the integrated motor consumption current that the accelerator pedal actuator read out at the time when the malfunction is detected
APA PWR [V]It displays the power supply voltage that the accelerator pedal actuator read out at the time when the malfunction is detected
APA OPE STATS [On/Off]It displays the activation permission status of accelerator pedal actuator at the time when the malfunction is detected
APA STATS [READY/NG/TP NG/INIT]It displays the condition of accelerator pedal actuator at the time when the malfunction is detected
IGN Counter NoteIt displays number of ignition switch OFF --> ON after the malfunction is detected
NOTE: The number is 0 when is detected now. The number increases like 1--> 2... 38 --> 39 after returning to the normal condition whenever IGN OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39.
NOTE
The number is 0 when is detected now. The number increases like 1--> 2... 38 --> 39 after returning to the normal condition whenever IGN OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39.
Monitor item [Unit]FUNCTION DESCRIPTION
TGT FBK FRC [N]It displays the target accelerator pedal actuation force that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication (The ADAS control unit transmits the accelerator pedal feedback force control signal via ITS communication)
TGT MOT POSI [%]It displays the target motor position that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication (The ADAS control unit transmits the accelerator pedal feedback force control signal via ITS communication)
ACT MOT POSI [%]It displays the integrated motor position that the accelerator pedal actuator read out
AP OPEN [%]It displays the accelerator pedal position signal that the accelerator pedal actuator read out via ITS communication (The ADAS control unit transmits with ITS communication the accelerator pedal position signal that is received from ECM via CAN communication)
APA TEMP [°C]It displays the accelerator pedal actuator integrated motor temperature
APA CURRENT [A]It displays the accelerator pedal actuator integrated motor consumption current
APA PWR [V]It displays the power supply voltage that the accelerator pedal actuator read out
APA OPE STATS [On/Off]It displays the activation permission status of accelerator pedal actuator
APA STATS [READY/NG/TP NG/INIT]It displays the condition of accelerator pedal actuator

PHYSICAL VALUES

Terminal No. (Wire color)DescriptionConditionValue (Approx.)
+Signal nameInput/Output
5 (G)GroundICC brake hold relay drive signalOutputIgnition switch ON12 V
At "STOP LAMP" test of "Active test"0 V
6 (B)GroundInput0 V
7 (L)ITS communication-H
8 (Y)ITS communication-L
14 (B)CAN-H
15 (W)CAN-L
16 (R)Ignition power supplyInputIgnition switch ONBattery Voltage

Fail-safe

If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.

SystemBuzzerWarning lamp/Indicator lampDescription
Vehicle-to-vehicle distance control modeHigh-pitched toneICC system warning lampCancel
Conventional (fixed speed) cruise control modeHigh-pitched toneICC system warning lampCancel
Intelligent Brake Assist (IBA)High-pitched toneIBA OFF indicator lampCancel
Forward Collision Warning (FCW)High-pitched toneWarning messageCancel
Distance Control Assist (DCA)High-pitched toneDCA system warningCancel
Lane Departure Warning (LDW)Lane departure warning lampCancel
Lane Departure Prevention (LDP)Low-pitched toneLane departure warning lampCancel
Blind Spot Warning (BSW)Blind Spot Warning/Blind Spot Intervention warning lampCancel
Blind Spot InterventionLow-pitched toneBlind Spot Warning/Blind Spot Intervention warning lampCancel
Backup Collision Intervention (BCI)High-pitched toneBackup Collision Intervention warning indicatorCancel
Terminal No. (Wire color)DescriptionConditionStandard valueReference value (Approx.)
+Signal nameInput/Output
1 (P)8 (B)Ignition power supplyInputIgnition switch ON9.5 - 16 VBattery voltage
6 (Y)ITS communication-L
7 (L)ITS communication-H
8 (B)GroundGroundIgnition switch ON0 - 0.1 V0 V

If a malfunction occurs in the ICC sensor, ADAS control unit cancels control, sounds a beep, and turns ON the ICC system warning lamp in the combination meter.

Terminal No. (Wire color)DescriptionConditionValue (Approx.)
+Signal nameInput/Output
1 (BG)GroundBattery power supplyInputIgnition switch OFFBattery voltage
2 (GR)GroundIgnition switch ON0 V
3 (G)Ignition power supplyInputIgnition switch ONBattery voltage
4 (Y)ITS communication-L
5 (BG)ITS communication-H

DETAILED FLOW

  1. INTERVIEW FOR MALFUNCTION It is also important to clarify the customer concerns before starting the inspection. Interview the customer about the concerns carefully and understand the symptoms fully. NOTE: The customers are not professionals. Never assume that "maybe the customer means..." or "maybe the customer mentioned this symptom". : GO TO 2 .
  2. SELF-DIAGNOSIS WITH CONSULT Perform "All DTC Reading" with CONSULT. Check if the DTC is detected on the self-diagnosis results of "ICC/ADAS" and/or "ACCELE PEDAL ACT". Is any DTC detected? YES: GO TO 5 . NO: GO TO 3 .
  3. ACTION TEST Perform DCA system action test to check the operation status. Refer to " «DESCRIPTION»(ref-657693-S28604245742014092200000) ". Check if any other malfunctions occur. : GO TO 4 .
  4. SYMPTOM DIAGNOSIS Perform the applicable diagnosis according to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-657693-S28532145462014092200000) ". : GO TO 6 .
  5. TROUBLE DIAGNOSIS BY DTC Check the DTC in the self-diagnosis results. Perform trouble diagnosis for the detected DTC. Refer to " «DTC Index»(ref-657693-S08924484212014092200000) " (ICC/ADAS) and/or " «DTC Index»(ref-657693-S24078851352014092100000) " (ACCELE PEDAL ACT). NOTE: If "DTC: U1000" is detected, first diagnose the CAN communication system or ITS communication system. : GO TO 6 .
  6. MALFUNCTIONING PART REPAIR Repair or replace the identified malfunctioning parts. : GO TO 7 .
  7. REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT) Erases self-diagnosis results. Perform "All DTC Reading" again after repairing or replacing the specific items. Check if any DTC is detected in self-diagnosis results of "ICC/ADAS" and "ACCELE PEDAL ACT". Is any DTC detected? YES: GO TO 5 . NO: GO TO 8 .
  8. REPAIR CHECK (ACTION TEST) Perform the DCA system action test. Check that the malfunction symptom is solved or no other symptoms occur. Is there a malfunction symptom? YES: GO TO 4 . NO: INSPECTION END

Work Procedure

  1. ICC SENSOR AIMING ADJUSTMENT Adjust the ICC sensor aiming. Refer to " «DESCRIPTION»(ref-657689-S28649848972014092200000) ". : GO TO 2 .
  2. DCA SYSTEM ACTION TEST Perform the DCA system action test. Refer to " «DESCRIPTION»(ref-657693-S28604245742014092200000) ". Check that the DCA system operates normally. : INSPECTION END
  1. ACCELERATOR PEDAL RELEASED POSITION LEARNING Perform accelerator pedal released position learning. Refer to " «DESCRIPTION»(ref-657693-S19513660292014092200000) ". : GO TO 2 .
  2. DCA SYSTEM ACTION TEST Perform the DCA system action test. Refer to " «DESCRIPTION»(ref-657693-S28604245742014092200000) ". Check that the DCA system operates normally. : INSPECTION END

Note. When the ICC system is set, the information display changes to the ICC system display.

Scheme 116

Scheme 116: Work Procedure
  1. ICC SYSTEM ACTION TEST Perform the ICC system action test. Refer to " «DESCRIPTION»(ref-657693-S28604245742014092200000) ". : GO TO 2 .
  2. CHECK DCA SYSTEM SETTING Start the engine. After starting the engine wait for 30 seconds or more. Check that the DCA system setting can be enabled/disabled on the navigation screen. Turn OFF the ignition switch and wait for 5 seconds or more. Check that the previous setting is saved when the engine starts again. : GO TO 3 .
  3. CHECK DYNAMIC DRIVER ASSISTANCE SWITCH Start the engine. After starting the engine wait for 30 seconds or more. Enable the setting of the DCA system on the navigation screen. Press the dynamic driver assistance switch (1). Check that the DCA system switch indicator (2) on the information display illuminates. Check that the DCA system switch indicator turns OFF when the system is turned OFF by pressing the dynamic driver assistance switch. Check that the DCA system switch indicator turns OFF when the engine starts again. NOTE: The DCA system switch indicator does not illuminate even when the dynamic driver assistance switch is turned ON within approximately 5 seconds after starting the engine. If the accelerator pedal assembly is not replaced: INSPECTION END If the accelerator pedal assembly is replaced: GO TO 4 .
  4. CHECK DCA SYSTEM OPERATION Check that the accelerator pedal actuator operates by the "Active Test" items "ACCELERATOR PEDAL ACTUATOR TEST1" and "ACCELERATOR PEDAL ACTUATOR TEST2" of "ACCELE PEDAL ACT" with CONSULT. : INSPECTION END

CAN COMMUNICATION

CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control units, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H, CAN-L) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads the required data only.

CAN communication signal chart. Refer to " CAN COMMUNICATION SYSTEM: CAN COMMUNICATION SIGNAL CHART ".

ITS COMMUNICATION

  1. ITS communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with 2 communication lines.
  2. ITS communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.
  1. ITS communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with 2 communication lines
  2. ITS communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.

The switch does not turn ON

  1. When the DCA system setting is ON, the DCA system switch indicator does not illuminate even if the dynamic driver assistance switch is depressed.

The switch does not turn OFF

  1. The DCA system switch indicator does not turn OFF even if the dynamic driver assistance switch is pressed when the DCA system switch indicator illuminates. NOTE: The system cannot be operated when setting conventional (fixed speed) cruise control mode.

PRECAUTIONS FOR DISTANCE CONTROL ASSIST (DCA) SYSTEM

  1. If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limitations of the system. The system will cancel once it judges that the vehicle has come to a standstill with a warning chime. To prevent the vehicle from moving, the driver must depress the brake pedal.
  2. The DCA system will not apply brake control while the driver is depressing the accelerator pedal.
  3. This system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the driver's responsibility to stay alert, drive safely and be in control of the vehicle at all times.
  4. This system will not adapt automatically to road conditions. Do not use the system on roads with sharp curves, or on icy roads, in heavy rain or in fog.
  5. The distance sensor will not detect under most conditions. Stationary and slow moving vehicles Pedestrians or objects in the roadway Oncoming vehicles in the same lane Motorcycles traveling offset in the travel lane
  6. As there is a performance limit to the distance control function, never rely solely on the DCA system. This system does not correct careless, inattentive or absent-minded driving, or overcome poor visibility in rain, fog, or other bad weather. Decelerate the vehicle speed by depressing the brake pedal, depending on the distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance between vehicles.
  7. The system may not detect the vehicle in front of own vehicle in certain road or weather conditions. To avoid accidents, never use the DCA system under the following conditions. On roads with sharp curves On slippery road surfaces such as on ice or snow, etc. On off-road surfaces such as on sand or rock, etc. During bad weather (rain, fog, snow, etc.) When rain, snow or dirt are on system sensor On steep downhill roads (frequent braking may result in overheating the brakes) On repeated uphill and downhill roads When towing a trailer or other vehicle
  8. In some road or traffic conditions, a vehicle or object can unexpectedly come into the sensor detection zone and cause automatic braking. Driver may need to control the distance from other vehicles using the accelerator pedal. Always stay alert and avoid using the DCA system when it is not recommended in this article.
  9. The following are some conditions in which the sensor cannot detect the signals. When the snow or road spray from traveling vehicles reduces the sensor's visibility When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle
  10. The DCA system is designed to automatically check the sensor's operation. When the front bumper area of the distance sensor is covered with dirt or is obstructed, the system will automatically be cancelled. If the front bumper area of the distance sensor is covered with ice, a transparent or translucent vinyl bag, etc., the DCA system may not detect them. In these instances, the DCA system may not be able to decelerate the vehicle properly. Be sure to check and clean the sensor regularly.
  11. The DCA system is designed to help assist the driver to maintain a following distance from the vehicle ahead. The system will decelerate as necessary and if the vehicle ahead comes to a stop, the vehicle decelerates to standstill. However, the DCA system can only apply up to 25% of the vehicles total braking power. If a vehicle moves into the traveling lane ahead or if a vehicle traveling ahead rapidly decelerates, the distance between vehicles may become closer because the DCA system cannot decelerate the vehicle quickly enough. If this occurs, the DCA system will sound a warning chime and blink the system display to notify the driver to take necessary action.
  12. The DCA system does not control vehicle speed or warn when driver approach stationary and slow moving vehicles. Driver must pay attention to vehicle operation to maintain proper distance from vehicles ahead.
  13. The detection zone of the sensor is limited. A vehicle ahead must be in the detection zone for the system to operate. A vehicle ahead may move outside of the detection zone due to its position within the same lane of travel. Motorcycles may not be detected in the same lane ahead if they are traveling offset from the center line of the lane. A vehicle that is entering the lane ahead may not be detected until the vehicle has completely moved into the lane. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime. The driver may have to manually control the proper distance away from vehicle traveling ahead. When driving on some roads, such as winding, hilly, curved, narrow roads, or roads which are under construction, the sensor may detect vehicles in a different lane, or may temporarily not detect a vehicle traveling ahead. This may cause the system to work inappropriately. The detection of vehicles may also be affected by vehicle operation (steering maneuver or traveling position in the lane, etc.) or vehicle condition. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime unexpectedly. The driver will have to manually control the proper distance away from the vehicle traveling ahead.
  14. The approach warning chime may sound and the system display may blink when the sensor detects some reflectors which are fitted on vehicles in other lanes or on the side of the road. This may cause the DCA system to operate inappropriately. The sensor may detect these reflectors when the vehicle is driven on winding roads, hilly roads or when entering or exiting a curve. The sensor may also detect reflectors on narrow roads or in road construction zones. In these cases driver will have to manually control the proper distance ahead of own vehicle. Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage).
  15. The DCA system automatically decelerates own vehicle to help assist the driver to maintain a following distance from the vehicle ahead. Manually brake when deceleration is required to maintain a safe distance upon sudden braking by the vehicle ahead or when a vehicle suddenly appears in front of own vehicle. Always stay alert when using the DCA system.
  16. When the vehicle ahead detection indicator lamp is not illuminated, system will not control or warn the driver.
  17. Depending on the position of the accelerator pedal, the system may not be able to assist the driver to release the accelerator pedal appropriately.
  18. If the vehicle ahead comes to a standstill, the vehicle decelerates to a standstill within the limitations of the system. The system will release brake control with a warning chime once it judges the vehicle is at a standstill. To prevent the vehicle from moving, the driver must depress the brake pedal. [The system will resume control automatically once the system reaches 5 km/h (3 MPH)].

Scheme 117

Scheme 117: Exploded View
