Note. If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to " DTC U1000 CAN COMMUNICATION LINE ".

Scheme 499

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS and SB section of this Service Manual.

METHOD FOR ERASING THE EEPROM IN THE TCM

1. Connect CONSULT-II to data link connector.
2. Turn ignition switch "ON" position. Confirm that CONSULT-II turn "ON".
3. Move selector lever in "R" position.
4. Touch "START" on CONSULT-II.
5. Select "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II.
6. Fully press the accelerator pedal (8/8 throttle), and hold it in the fully open position. (This will set the closed throttle position signal to "OFF".)
7. Touch "ERASE" on CONSULT-II, and then touch "YES".
8. Wait 3 seconds and then release the accelerator pedal.
9. Turn ignition switch "OFF" position.

CHECK METHOD

1. Normal: About 2 seconds after the ignition switch "ON" position, the A/T CHECK indicator lamp lights up for 2 seconds.
2. Abnormal: Even after the ignition switch "ON" position, the A/T CHECK indicator lamp does not light up after 2 seconds or illuminates immediately.

Cope for abnormal

1. Replace the control valve assembly.
2. Replace the TCM.

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

1. Before connecting or disconnecting the TCM harness connector, turn ignition switch "OFF" and disconnect negative battery cable. Because battery voltage is applied to TCM even if ignition switch is turned "OFF".
2. When connecting or disconnecting pin connectors into or from TCM, take care not to damage pin terminals (bend or break). Make sure that there are not any bends or breaks on TCM pin terminal, when connecting pin connectors.
3. Before replacing TCM, perform TCM input/output signal inspection and make sure whether TCM functions properly or not. " «TCM INSPECTION TABLE»(ref-182060-S22913988682005080600000) ".
4. After performing each TROUBLE DIAGNOSIS, perform "DTC (Diagnostic Trouble Code) CONFIRMATION PROCEDURE". If the repair is completed the DTC should not be displayed in the "DTC CONFIRMATION PROCEDURE".
5. When removing the RE5R05A model transmission from a vehicle, do not use the companion flange section at the rear end of the transmission as a support point.
6. Always use the specified brand of A/T fluid. Refer to "Fluids and Lubricants".
7. Use paper rags not cloth rags during work.
8. After replacing the A/T fluid, dispose of the waste oil using the methods prescribed by law, ordinance, etc.
9. Before proceeding with disassembly, thoroughly clean the outside of the transaxle. It is important to prevent the internal parts from becoming contaminated by dirt or other foreign matter.
10. Disassembly should be done in a clean work area.
11. Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere with the operation of the transaxle.
12. Place disassembled parts in order for easier and proper assembly.
13. All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or reassembly.
14. Gaskets, seals and O-rings should be replaced any time the transaxle is disassembled.
15. It is very important to perform functional tests whenever they are indicated.
16. The valve body contains precision parts and requires extreme care when parts are removed and serviced. Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent springs and small parts from becoming scattered or lost.
17. Properly installed valves, sleeves, plugs, etc. will slide along bores in valve body under their own weight.
18. Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings and seals, or hold bearings and washers in place during assembly. Do not use grease.
19. Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.
20. After overhaul, refill the transaxle with new ATF.
21. When the A/T drain plug is removed, only some of the fluid is drained. Old A/T fluid will remain in torque converter and ATF cooling system. Always follow the procedures under "Changing A/T Fluid" in the AT section when changing A/T fluid. Refer to " «CHANGING A/T FLUID»(ref-182060-S22752129122005080600000) " and " «CHECKING A/T FLUID»(ref-182060-S37258988642005080600000) ".

Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Scheme 505

Scheme 506

Shift Mechanism

The automatic transmission uses compact dual planetary gear systems to improve power-transmission efficiency, simplify construction and reduce weight.

It also employs an optimum shift control and super wide gear ratios. They improve starting performance and acceleration during medium and high-speed operation.

Scheme 507

Scheme 508

Scheme 509

Scheme 510

"N" Position

Since both the forward brake and the reverse brake are released, torque from the input shaft drive is not transmitted to the output shaft.

Scheme 511

1. The same as for the "N" position, both the forward brake and the reverse brake are released, so torque from the input shaft drive is not transmitted to the output shaft.
2. The parking pawl linked with the select lever meshes with the parking gear and fastens the output shaft mechanically.

Scheme 512

1. The forward brake and the forward one-way clutch regulate reverse rotation of the mid sun gear.
2. The first one-way clutch regulates reverse rotation of the rear sun gear.
3. The third one-way clutch regulates reverse rotation of the front sun gear.
4. During deceleration, the mid sun gear turns forward, so the forward one-way clutch idles and the engine brake is not activated.

Scheme 513

1. The front brake fastens the front sun gear.
2. The forward brake and the forward one-way clutch regulate reverse rotation of the mid sun gear.
3. High and low reverse clutch connects the rear sun gear and the mid sun gear.
4. The low coast brake fastens the mid sun gear.
5. During deceleration, the low coast brake regulates forward rotation of the mid sun gear and the engine brake functions.

Scheme 514

1. The forward brake and the forward one-way clutch regulate reverse rotation of the mid sun gear.
2. The third one-way clutch regulates reverse rotation of the front sun gear.
3. The direct clutch is coupled and the rear carrier and rear sun gear are connected.
4. During deceleration, the mid sun gear turns forward, so the forward one-way clutch idles and engine brake is not activated.

Scheme 515

1. The front brake fastens the front sun gear.
2. The forward brake and the forward one-way clutch regulate reverse rotation of the mid sun gear.
3. The direct clutch is coupled, and the rear carrier and rear sun gear are connected.
4. The low coast brake fastens the mid sun gear.
5. During deceleration, the low coast brake regulates forward rotation of the mid sun gear and the engine brake functions.

Scheme 516

1. The front brake fastens the front sun gear.
2. The direct clutch is coupled, and the rear carrier and rear sun gear are connected.
3. The high and low reverse clutch is coupled and the mid sun gear and rear sun gear are connected.

Scheme 517

1. The direct clutch is coupled, and the rear carrier and rear sun gear are connected.
2. The high and low reverse clutch is coupled and the mid sun gear and rear sun gear are connected.
3. The input clutch is coupled and the front internal gear and mid internal gear are connected.
4. The drive power is conveyed to the front internal gear, mid internal gear, and rear carrier and the three planetary gears rotate forward as one unit.

Scheme 518

1. The front brake fastens the front sun gear.
2. The input clutch is coupled and the front internal gear and mid internal gear are connected.
3. The high and low reverse clutch is coupled and the mid sun gear and rear sun gear are connected.

Scheme 519

1. The front brake fastens the front sun gear.
2. The high and low reverse clutch is coupled and the mid sun gear and rear sun gear are connected.
3. The reverse brake fastens the rear carrier.

TCM Function

The function of the TCM is to

1. Receive input signals sent from various switches and sensors.
2. Determine required line pressure, shifting point, lock-up operation, and engine brake operation.
3. Send required output signals to the respective solenoids.

CONTROL SYSTEM OUTLINE

The automatic transmission senses vehicle operating conditions through various sensors or signals. It always controls the optimum shift position and reduces shifting and lock-up shocks.

Scheme 520

Scheme 521

LINE PRESSURE CONTROL IS BASED ON THE TCM LINE PRESSURE CHARACTERISTIC PATTERN

1. The TCM has stored in memory a number of patterns for the optimum line pressure characteristic for the driving state.
2. In order to obtain the most appropriate line pressure characteristic to meet the current driving state, the TCM controls the line pressure solenoid current valve and thus controls the line pressure.

Normal Control

Each clutch is adjusted to the necessary pressure to match the engine drive force.

Scheme 522

Back-Up Control (Engine Brake)

When the select operation is executed during driving and the transmission is shifted down, the line pressure is set according to the vehicle speed.

Scheme 523

During Shift Change

The necessary and adequate line pressure for shift change is set. For this reason, line pressure pattern setting corresponds to input torque and gearshift selection. Also, line pressure characteristic is according to engine speed, during engine brake operation.

Scheme 524

Shift Control

The clutch pressure control solenoid is controlled by the signals from the switches and sensors. Thus, the clutch pressure is adjusted to be appropriate to the engine load state and vehicle driving state. It becomes possible to finely control the clutch hydraulic pressure with high precision and a smoother shift change characteristic is attained.

Scheme 525

SHIFT CHANGE

The clutch is controlled with the optimum timing and oil pressure by the engine speed, engine torque information, etc.

Scheme 526

Lock-Up Control

The torque converter clutch piston in the torque converter is engaged to eliminate torque converter slip to increase power transmission efficiency.

The torque converter clutch control valve operation is controlled by the torque converter clutch solenoid valve, which is controlled by a signal from TCM, and the torque converter clutch control valve engages or releases the torque converter clutch piston.

Scheme 527

Scheme 528

Lock-Up Released

1. In the lock-up released state, the torque converter clutch control valve is set into the unlocked state by the torque converter clutch solenoid and the lock-up apply pressure is drained. In this way, the torque converter clutch piston is not coupled.

Lock-Up Applied

1. In the lock-up applied state, the torque converter clutch control valve is set into the locked state by the torque converter clutch solenoid and lock-up apply pressure is generated. In this way, the torque converter clutch piston is pressed and coupled.

SMOOTH LOCK-UP CONTROL

When shifting from the lock-up released state to the lock-up applied state, the current output to the torque converter clutch solenoid is controlled with the TCM. In this way, when shifting to the lock-up applied state, the torque converter clutch is temporarily set to the half-clutched state to reduce the shock.

Half-Clutched State

1. The current output from the TCM to the torque converter clutch solenoid is varied to steadily increase the torque converter clutch solenoid pressure. In this way, the lock-up apply pressure gradually rises and while the torque converter clutch piston is put into half-clutched status, the torque converter clutch piston operating pressure is increased and the coupling is completed smoothly.

Slip Lock-Up Control

1. In the slip region, the torque converter clutch solenoid current is controlled with the TCM to put it into the half-clutched state. This absorbs the engine torque fluctuation and lock-up operates from low speed. This raises the fuel efficiency for 3rd, 4th and 5th gears at both low speed and when the accelerator has a low degree of opening.

Scheme 529

1. The forward one-way clutch transmits the drive force from the engine to the rear wheels. But the reverse drive from the rear wheels is not transmitted to the engine because the one-way clutch is idling. Therefore, the low coast brake solenoid is operated to prevent the forward one-way clutch from idling and the engine brake is operated in the same manner as conventionally.
2. The operation of the low coast brake solenoid switches the low coast brake switching valve and controls the coupling and releasing of the low coast brake. The low coast brake reducing valve controls the low coast brake coupling force.

Scheme 530

Scheme 531

Scheme 532

OBD-II Function for A/T System

The ECM provides emission-related on board diagnostic (OBD-II) functions for the A/T system. One function is to receive a signal from the TCM used with OBD-related parts of the A/T system. The signal is sent to the ECM when a malfunction occurs in the corresponding OBD-related part. The other function is to indicate a diagnostic result by means of the MIL (malfunction indicator lamp) on the instrument panel. Sensors, switches and solenoid valves are used as sensing elements.

The MIL automatically illuminates in One or Two Trip Detection Logic when a malfunction is sensed in relation to A/T system parts.

ONE TRIP DETECTION LOGIC

If a malfunction is sensed during the first test drive, the MIL will illuminate and the malfunction will be stored in the ECM memory as a DTC. The TCM is not provided with such a memory function.

TWO TRIP DETECTION LOGIC

When a malfunction is sensed during the first test drive, it is stored in the ECM memory as a 1st trip DTC (diagnostic trouble code) or 1st trip freeze frame data. At this point, the MIL will not illuminate. - First Trip If the same malfunction as that experienced during the first test drive is sensed during the second test drive, the MIL will illuminate. - Second Trip

The "trip" in the "One or Two Trip Detection Logic" means a driving mode in which self-diagnosis is performed during vehicle operation.

Freeze Frame Data and 1st Trip Freeze Frame Data

The ECM has a memory function, which stores the driving condition such as fuel system status, calculated load value, engine coolant temperature, short term fuel trim, long term fuel trim, engine speed and vehicle speed at the moment the ECM detects a malfunction.

Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data, and the data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-II or GST. The 1st trip freeze frame data can only be displayed on the CONSULT-II screen, not on the GST. For detail, refer to "CONSULT-II FUNCTIONS".

Only one set of freeze frame data (either 1st trip freeze frame data of freeze frame data) can be stored in the ECM. 1st trip freeze frame data is stored in the ECM memory along with the 1st trip DTC. There is no priority for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once freeze frame data (2nd trip detection/MIL on) is stored in the ECM memory, 1st trip freeze frame data is no longer stored. Remember, only one set of freeze frame data can be stored in the ECM. The ECM has the following priorities to update the data.

Scheme 533

Both 1st trip freeze frame data and freeze frame data (along with the DTC) are cleared when the ECM memory is erased.

FAIL-SAFE FUNCTION

If any malfunction occurs in a sensor or solenoid, this function controls the A/T to make driving possible.

Vehicle Speed Sensor

1. Signals are input from two systems - from vehicle speed sensor A/T (revolution sensor) installed on the transmission and from combination meter so normal driving is possible even if there is a malfunction in one of the systems. And if vehicle speed sensor A/T (revolution sensor) has unusual cases, 5th gear and manual mode are prohibited.

Accelerator Pedal Position Sensor

1. If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM according to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow systems, the engine speed is fixed by ECM to a pre-determined engine speed to make driving possible.

Throttle Position Sensor

1. If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM according to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow systems, the accelerator opening angle is controlled by the idle signal sent from the ECM which is based on input indicating either idle condition or off-idle condition (pre-determined accelerator opening) in order to make driving possible.

PNP Switch

1. In the unlikely event that a malfunction signal enters the TCM, the position indicator is switched "OFF", the starter relay is switched "OFF" (starter starting is disabled), and the position is fixed to the "D" range to make driving possible.

PNP Relay

1. The PNP relay is switched "OFF". (Starter starting is disabled.)

A/T Interlock

1. If there is an A/T interlock judgment malfunction, the transmission is fixed in 2nd gear to make driving possible. NOTE: When the vehicle is driven fixed in 2nd gear, a turbine revolution sensor malfunction is displayed, but this is not a turbine revolution sensor malfunction.
2. When the coupling pattern below is detected, the fail-safe action corresponding to the pattern is executed.

Scheme 534

A/T 1st Engine Braking

1. When there is an A/T first gear engine brake judgment malfunction, the low coast brake solenoid is switched "OFF" to avoid the engine brake operation.

Line Pressure Solenoid

1. The solenoid is switched "OFF" and the line pressure is set to the maximum hydraulic pressure to make driving possible.

Low Coast Brake Solenoid

1. When a (electrical or functional) malfunction occurs, in order to make driving possible, if the solenoid is "ON", the transmission is held in 2nd gear; if the solenoid is "OFF", the transmission is held in 4th gear, (engine brake is not applied in 1st and 2nd gear.)

Input Clutch Solenoid

1. If a (electrical or functional) malfunction occurs with the solenoid either "ON" or "OFF", the transmission is held in 4th gear to make driving possible.

Direct Clutch Solenoid

1. If a (electrical or functional) malfunction occurs with the solenoid either "ON" or "OFF", the transmission is held in 4th gear to make driving possible.

Front Brake Clutch Solenoid

1. If a (electrical or functional) malfunction occurs with the solenoid "ON", in order to make driving possible, the A/T is held in 5th gear; if the solenoid is OFF, 4th gear.

High and Low Reverse Clutch Solenoid

1. If a (electrical or functional) malfunction occurs with the solenoid either "ON" or "OFF", the transmission is held in 4th gear to make driving possible.

Turbine Revolution Sensor 1 or 2

1. The control is the same as if there were no turbine revolution sensors, 5th gear and manual mode are prohibited.

WORK FLOW

A good understanding of the malfunction conditions can make troubleshooting faster and more accurate. In general, each customer feels differently about a malfunction. It is important to fully understand the symptoms or conditions for a customer complaint.

Make good use of the two sheets provided, " INFORMATION FROM CUSTOMER ". Refer to " DIAGNOSTIC WORKSHEET " to perform the best troubleshooting possible.

Scheme 535

Information From Customer

KEY POINTS

1. WHAT ..... Vehicle & A/T model
2. WHEN ..... Date, Frequencies
3. WHERE ..... Road conditions
4. HOW ..... Operating conditions, Symptoms

Scheme 536

Scheme 537

Scheme 538

Scheme 539

Scheme 540

Check Before Engine is Started

1. CHECK A/T CHECK INDICATOR LAMP Park vehicle on level surface. Move selector lever to "P" position. Turn ignition switch to "OFF" position and wait at least 10 seconds. Turn ignition switch to "ON" position. (Do not start engine.) Does A/T CHECK indicator lamp light up for about 2 seconds? Yes >> GO TO 2. No >> Stop the road test and go to " «A/T CHECK INDICATOR LAMP DOES NOT COME ON SYMPTOM»(ref-182060-S06558776092005080600000) ".
2. CHECK A/T CHECK INDICATOR LAMP Does A/T CHECK indicator lamp flash for about 8 seconds? Yes >> For TCM fail-safe mode, carry out self-diagnostics and record all NG items on the diagnostics worksheet. Refer to «SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)»(ref-182060-S41411913712005080600000) , «DIAGNOSTIC PROCEDURE WITHOUT CONSULT-II»(ref-182060-S35216964172005080600000) . No >> Turn ignition switch to "OFF" position. Carry out the self-diagnostics and record all NG items on the diagnostics worksheet. Refer to «SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)»(ref-182060-S41411913712005080600000) , «DIAGNOSTIC PROCEDURE WITHOUT CONSULT-II»(ref-182060-S35216964172005080600000) . GO TO " «CHECK AT IDLE»(ref-182060-S01051747732005080600000) ".

Check at Idle

1. CHECK STARTING THE ENGINE Park vehicle on level surface. Move selector lever to "P" or "N" position. Turn ignition switch to "OFF" position. Turn ignition switch to "START" position. Does the engine start? Yes >> GO TO 2. No >> Stop the road test and go to " «ENGINE CANNOT BE STARTED IN "P" OR "N" POSITION»(ref-182060-S33541509222005080600000) ".
2. CHECK STARTING THE ENGINE Turn ignition switch to "ON" position. Move selector lever in "D" or "R" position. Turn ignition switch to "START" position. Does the engine start in either position? Yes >> Stop the road test and go to " «ENGINE CANNOT BE STARTED IN "P" OR "N" POSITION»(ref-182060-S33541509222005080600000) ". No >> GO TO 3.
3. CHECK "P" POSITION FUNCTIONS Move selector lever to "P" position. Turn ignition switch to "OFF" position. Disengage the parking brake. Push the vehicle forward or backward. Engage the parking brake. When you push the vehicle with disengaging the parking brake, does it move? Yes >> Enter a check mark at "Vehicle moves when pushed in "P" position" on the diagnostics worksheet, then continue the road test. No >> GO TO 4.
4. CHECK "N" POSITION FUNCTIONS Start the engine. Move selector lever to "N" position. Disengage the parking brake. Does vehicle move forward or backward? Yes >> Enter a check mark at "Vehicle moves in "N" position" on the diagnostics worksheet, then continue the road test. No >> GO TO 5.
5. CHECK SHIFT SHOCK Engage the brake. Move selector lever to "D" position. When the transmission is shifted from "N" to "D", is there an excessive shock? Yes >> Enter a check mark at "Large shock when shifted from N to D" on the diagnostics worksheet, then continue the road test. No >> GO TO 6.
6. CHECK "R" POSITION FUNCTIONS Engage the brake. Move selector lever to "R" position. Disengage the brake for 4 to 5 seconds. Does the vehicle creep backward? Yes >> GO TO 7. No >> Enter a check mark at "Vehicle does not creep backward in R position" on the diagnostics worksheet, then continue the road test.
7. CHECK "D" POSITION FUNCTIONS Inspect whether the vehicle moves forward when the transmission is put into the "D" position. Does the vehicle move forward in the "D" positions? Yes >> GO TO " «CRUISE TEST - PART 1»(ref-182060-S06551298802005080600000) ", " «CRUISE TEST - PART 2»(ref-182060-S09755513382005080600000) ", and " «CRUISE TEST - PART 3»(ref-182060-S38530378012005080600000) ". No >> Enter a check mark at "Vehicle does not move forward in D positions" on the diagnostics worksheet, then continue the road test.

CONSULT-II

After performing " SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II) , place check marks for results on the " DIAGNOSTIC WORKSHEET ". Reference pages are provided following the items.

Note. The CONSULT-II electrically displays shift timing and lock-up timing (that is, operation timing of each solenoid). Check for time difference between actual shift timing and the CONSULT-II display. If the difference is noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical parts using applicable diagnostic procedures. Shift schedule (which implies gear position) displayed on CONSULT-II and that indicated in Service Manual may differ slightly. This occurs because of the following reasons: Actual shift schedule has more or less tolerance or allowance, Shift schedule indicated in Service Manual refers to the point where shifts start, and Gear position displayed on CONSULT-II indicates the point where shifts are completed. Display of solenoid valves on CONSULT-II changes at the start of shifting, while gear position is displayed upon completion of shifting (which is computed by TCM). Additional CONSULT-II information can be found in the Operation Manual supplied with the CONSULT-II unit.

Scheme 541

Scheme 542

CONSULT-II Setting Procedure

1. For details, refer to the separate "CONSULT-II Operations Manual".

Scheme 543

Scheme 544

Scheme 545

Scheme 546

1. Turn ignition switch "OFF" position.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector, which is located in instrument lower panel on driver side.
3. Turn ignition switch "ON" position.
4. Touch "START".
5. Touch "ENGINE" for OBD-II detected items or touch "A/T" for TCM self-diagnosis. If "A/T" or "ENGINE" is not indicated, go to "CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT ".
6. Touch "SELF-DIAG RESULTS". Display shows malfunction experienced since the last erasing operation. CONSULT-II performs REAL-TIME SELF-DIAGNOSIS. Also, any malfunction detected while in this mode will be displayed at real time.

Scheme 547

Scheme 548

Scheme 549

Scheme 550

Scheme 551

Scheme 552

Scheme 553

Scheme 554

1. For details, refer to the separate "CONSULT-II Operation Manual".

Scheme 555

Scheme 556

Scheme 557

Scheme 558

Scheme 559

Scheme 560

Scheme 561

Scheme 562

Scheme 563

Scheme 564

Scheme 565

1. Turn ignition switch "OFF".
2. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector, which is located in instrument lower panel on driver side.
3. Turn ignition switch "ON".
4. Touch "START".
5. Touch "A/T". If "A/T" is not indicated, go to "CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT ".
6. Touch "DTC WORK SUPPORT".
7. Touch select item menu.
8. Touch "START".
9. Perform driving test according to "DTC CONFIRMATION PROCEDURE" in "TROUBLE DIAGNOSIS FOR DTC". When testing conditions are satisfied, CONSULT-II screen changes from "OUT OF CONDITION" to "TESTING".
10. Stop vehicle. If "NG" appears on the screen, malfunction may exist. Go to " «DIAGNOSTIC PROCEDURE»(ref-182060-S31418968102005080600000) ".
11. Perform test drive to check gear shift feeling in accordance with instructions displayed.
12. Touch "YES" or "NO".
13. CONSULT-II procedure is ended. If "NG" appears on the screen, a malfunction may exist. Go to " «DIAGNOSTIC PROCEDURE»(ref-182060-S31418968102005080600000) ".

Scheme 566

Possible Cause

Harness or connectors

(CAN communication line is open or shorted.)

WITH GST

Follow the procedure "WITH CONSULT-II".

Scheme 567

TCM terminals and data are reference value.

Scheme 568

Scheme 569

1. CHECK CAN COMMUNICATION CIRCUIT With CONSULT-II Turn ignition switch to "ON" position and start engine. Select "DATA MONITOR" mode for "A/T" with CONSULT-II. Is any malfunction of the "CAN COMM CIRCUIT" indicated? Yes >> Print out CONSULT-II screen, GO TO LAN section. Refer to "CAN SYSTEM (FOR VDC MODELS) ", "CAN SYSTEM (FOR ICC MODELS) ". No >> INSPECTION END

1. Harness or connectors [The park/neutral position (PNP) relay and TCM circuit is open or shorted.]
2. Park/neutral position (PNP) relay

1. Harness or connectors [The park/neutral position (PNP) switch 1, 2, 3, 4 and TCM circuit is open or shorted.]
2. Park/neutral position (PNP) switch 1, 2, 3, 4
3. Park/neutral position (PNP) switch 3 monitor terminal disconnected

Follow the procedure "With CONSULT-II".

Scheme 570

TCM terminal and data are reference value. Measured between each terminal and ground.

Scheme 571

Scheme 572

Scheme 573

Scheme 574

Scheme 575

Scheme 576

1. CHECK PNP SWITCH CIRCUIT (WITH CONSULT-II) With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out "N.P", "R" and "D" position switches moving selector lever to each position. OK or NG OK >> GO TO 5 . NG >> GO TO 3 .
2. CHECK PNP SWITCH CIRCUIT (WITHOUT CONSULT-II) Without CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Selector lever to "P", "R", "N", or "D" position to check the voltage between the TCM connector terminals and ground. OK or NG OK >> GO TO 5 . NG >> GO TO 3.
3. DETECT MALFUNCTIONING ITEM Check the following items. Disconnection or short-circuit in the harness between TCM and A/T unit harness connector. PNP switch. Refer to " «COMPONENT INSPECTION»(ref-182060-S04475446742005080600000) ". OK or NG OK >> GO TO 4. NG >> Repair or replace damaged parts.
4. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> Replace control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S16227624402005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Scheme 577

Scheme 578

1. Selector lever to various positions to check the continuity between terminals on the PNP switch and ground.
2. If NG, check the continuity with the control linkage disconnected. (Refer to Step 1 above.)
3. If OK with the control linkage disconnected, adjust the control linkage. Refer to " «ADJUSTMENT OF A/T POSITION»(ref-182060-S11382102512005080600000) ".
4. If NG even when the control linkage is disconnected, replace the control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".

1. Harness or connectors (The sensor circuit is open or shorted.)
2. Revolution sensor
3. Vehicle speed sensor MTR

Follow the procedure "With CONSULT-II".

Scheme 579

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 580

Scheme 581

Scheme 582

Scheme 583

Scheme 584

Scheme 585

Scheme 586

Scheme 587

1. CHECK INPUT SIGNALS With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Start the engine. Read out the value of "VHCL/S SE.A/T" while driving. Check the value changes according to driving speed. With GST Follow the procedure "With CONSULT-II". OK or NG OK >> GO TO 6 . NG >> GO TO 3 .
2. CHECK REVOLUTION SENSOR (WITH CONSULT-II) With CONSULT-II Start the engine. Check the pulse when vehicle cruises. OK or NG OK >> GO TO 6 . NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND A/T UNIT ASSEMBLY HARNESS CONNECTOR Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 4. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 5. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. DETECT MALFUNCTION ITEMS Check control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disassemble A/T. Refer to " «DISASSEMBLY»(ref-182060-S17760255892005080600000) ". Check revolution sensor. Refer to " «DISASSEMBLY»(ref-182060-S17760255892005080600000) ". OK or NG OK >> GO TO 6. NG >> Repair or replace damaged parts.
6. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S09197548122005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 7.
7. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Harness or connectors

(The ECM to the TCM circuit is open or shorted.)

1. Torque converter clutch solenoid valve
2. Harness or connectors (The solenoid circuit is open or shorted.)

Follow the procedure "With CONSULT-II".

Scheme 588

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 589

Scheme 590

Scheme 591

Scheme 592

Scheme 593

Scheme 594

Scheme 595

1. CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE CIRCUIT Turn ignition switch to "OFF" position. Disconnect A/T unit assembly harness connector at the transmission right side. Check the resistance between terminal and ground. OK or NG OK >> GO TO 4 . NG >> GO TO 2.
2. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK VALVE RESISTANCE Check valve resistance Refer to " «COMPONENT INSPECTION»(ref-182060-S41514251992005080600000) ". OK or NG OK >> GO TO 4. NG >> Replace the control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
4. CHECK POWER SOURCE CIRCUIT Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 5. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S04816003512005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Scheme 596

Scheme 597

1. Turn ignition switch "OFF".
2. Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
3. Disconnect control valve assembly harness connector.
4. Check resistance between terminal and ground.
5. If NG, replace control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".

Scheme 598

1. Check solenoid valve by listening for its operating sound while applying battery voltage to the terminal 11 and ground.

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. Torque converter clutch solenoid valve
3. Hydraulic control circuit

Follow the procedure "With CONSULT-II".

Scheme 599

TCM terminal and data are reference value. Measured between each terminal and ground.

Scheme 600

Scheme 601

Scheme 602

Scheme 603

Scheme 604

Scheme 605

Scheme 606

1. CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE CIRCUIT Turn ignition switch to "OFF" position. Disconnect A/T unit assembly harness connector at the transmission right side. Check the resistance between terminal and ground. OK or NG OK >> GO TO 4 . NG >> GO TO 2.
2. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK VALVE RESISTANCE Check valve resistance Refer to " «COMPONENT INSPECTION»(ref-182060-S12305224702005080600000) ". OK or NG OK >> GO TO 5 . NG >> Replace the control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
4. CHECK POWER SOURCE CIRCUIT Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 5. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S04816003512005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Scheme 607

Scheme 608

1. Turn ignition switch "OFF".
2. Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
3. Disconnect control valve assembly harness connector.
4. Check resistance between terminal and ground.
5. If NG, replace control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".

Scheme 609

1. Check solenoid valve by listening for its operating sound while applying battery voltage to the terminal 11 and ground.

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. Line pressure solenoid valve

Follow the procedure "With CONSULT-II".

Scheme 610

TCM terminal and data are reference value. Measured between each terminal and ground.

Scheme 611

Scheme 612

Scheme 613

Scheme 614

Scheme 615

Scheme 616

Scheme 617

1. CHECK LINE PRESSURE SOLENOID VALVE CIRCUIT Turn ignition switch to "OFF" position. Disconnect A/T unit assembly harness connector at the transmission right side. Check the resistance between terminal and ground. OK or NG OK >> GO TO 4 . NG >> GO TO 2.
2. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK VALVE RESISTANCE Check valve resistance Refer to " «COMPONENT INSPECTION»(ref-182060-S07577528762005080600000) ". OK or NG OK >> GO TO 5 . NG >> Replace the control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
4. CHECK POWER SOURCE CIRCUIT Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 5. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S37338106242005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Scheme 618

Scheme 619

1. Turn ignition switch "OFF".
2. Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
3. Disconnect control valve assembly harness connector.
4. Check resistance between terminal and ground.
5. If NG, replace control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".

Scheme 620

1. Check solenoid valve by listening for its operating sound while applying battery voltage to the terminal 10 and ground.

Harness or connectors

(Battery or ignition switch and TCM circuit is open or shorted.)

TCM

TCM

TCM

Harness or connectors

(The sensor circuit is open or shorted.)

1. Harness or connectors (The sensor circuit is open or shorted.)
2. A/T fluid temperature sensors 1, 2

Follow the procedure "With CONSULT-II".

Scheme 621

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 622

Scheme 623

Scheme 624

Scheme 625

Scheme 626

Scheme 627

Scheme 628

Scheme 629

Scheme 630

Scheme 631

Scheme 632

1. CHECK INPUT SIGNALS (WITH CONSULT-II) With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out the value of "ATF TEMP SE 1" or "ATF TEMP SE 2". OK or NG OK >> GO TO 7 . NG >> GO TO 3 .
2. CHECK INPUT SIGNALS (WITHOUT CONSULT-II) Without CONSULT-II Start engine. Check voltage between TCM connector and ground while warming up A/T. Refer to " «WIRING DIAGRAM - AT - FTS»(ref-182060-S12356433812005080600000) ". Turn ignition switch to "OFF" position. Disconnect the TCM connector. Check if there is continuity between the connector terminal and ground. OK or NG OK >> GO TO 7 . NG >> GO TO 3.
3. CHECK FLUID TEMPERATURE SENSOR CIRCUIT Turn ignition switch to "OFF" position. Disconnect A/T unit assembly harness connector at the transmission right side. Check the resistance between terminal and ground. Reinstall any part removed. OK or NG OK >> GO TO 7 . NG >> GO TO 4.
4. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 5. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK HARNESS BETWEEN FLUID TEMPERATURE SENSOR 2 AND CONTROL VALVE ASSEMBLY Disconnect fluid temperature sensor 2 harness connector and control valve assembly harness connector. Check continuity between fluid temperature sensor 2 harness connector and control valve assembly harness connector. OK or NG OK >> GO TO 6. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
6. CHECK FLUID TEMPERATURE SENSOR 2 Check fluid temperature sensor 2. Refer to " «COMPONENT INSPECTION»(ref-182060-S29598612402005080600000) ". OK or NG OK >> GO TO 7. NG >> Repair or replace damaged parts.
7. DETECT MALFUNCTIONING ITEM Check the following items: Harness for short to ground or short to power or open between TCM and A/T unit assembly harness connector. OK or NG OK >> GO TO 8. NG >> Repair or replace damaged parts.
8. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S14481497892005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 9.
9. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Scheme 633

Scheme 634

1. Remove fluid temperature sensor 2. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ".
2. Check resistance between terminal 1 and 2.

1. Harness or connectors (The sensor circuit is open or shorted.)
2. Turbine revolution sensor 1, 2

Follow the procedure "With CONSULT-II".

Scheme 635

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 636

Scheme 637

Scheme 638

Scheme 639

Scheme 640

Scheme 641

Scheme 642

Scheme 643

Scheme 644

Scheme 645

1. CHECK INPUT SIGNALS With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Vehicle start and read out the value of "TURBINE REV". With GST Follow the procedure "With CONSULT-II". OK or NG OK >> GO TO 5 . NG >> GO TO 2.
2. CHECK TURBINE REVOLUTION SENSOR With CONSULT-II Start engine. Check the pulse when vehicle cruises. OK or NG OK >> GO TO 5 . NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND A/T UNIT ASSEMBLY HARNESS CONNECTOR Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 4. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> Replace the control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-182060-S38888081362005080600000) ". NG >> Repair or replace damaged parts.
5. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S04816003512005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Harness or connectors

(The sensor circuit is open or shorted.)

1. Harness or connectors (The solenoid and switch circuit is open or shorted.)
2. Low coast brake solenoid valve
3. Pressure switch 2

Follow the procedure "With CONSULT-II".

Scheme 646

Scheme 647

Scheme 648

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 649

Scheme 650

Judgement of A/T Interlock

When A/T Interlock is judged to be malfunctioning, the vehicle should be fixed in 2nd gear, and should be set in a condition in which it can travel.

When one of the following fastening patterns is detected, the fail-safe function in correspondence with the individual pattern should be executed.

Scheme 651

Scheme 652

1. SELF-DIAGNOSIS With CONSULT-II Start engine. Select "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. Drive vehicle. Without CONSULT-II Drive vehicle. Stop vehicle and turn ignition switch OFF. Turn ignition switch "ON". (Do not start engine.) Perform self-diagnosis. Refer to " «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-182060-S21022747872005080600000) ". OK or NG OK >> GO TO 2. NG >> Check each solenoid valves. Refer to " «DTC P1772 LOW COAST BRAKE SOLENOID VALVE»(ref-182060-S38643195612005080600000) ", " «DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION»(ref-182060-S08087308512005080600000) ".
2. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-182060-S41854389602005080600000) ". OK or NG OK >> INSPECTION END NG >> GO TO 3.
3. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. Harness or connectors (The sensor circuit is open or shorted.)
2. Low coast brake solenoid valve
3. ATF pressure switch 2

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. Input clutch solenoid valve

1. Harness or connectors (The solenoid and switch circuits are open or shorted.)
2. Input clutch solenoid valve
3. ATF pressure switch 3

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. Front brake solenoid valve

1. Harness or connectors (The solenoid and switch circuits are open or shorted.)
2. Front brake solenoid valve
3. ATF pressure switch 1

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. Direct clutch solenoid valve

1. Harness or connectors (The solenoid and switch circuits are open or shorted.)
2. Direct clutch solenoid valve
3. ATF pressure switch 5

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. High & low reverse clutch solenoid valve

1. Harness or connectors (The solenoid and switch circuits are open or shorted.)
2. High & low reverse clutch solenoid valve
3. ATF pressure switch 6

1. Harness or connectors (The solenoid circuit is open or shorted.)
2. Low coast brake solenoid valve

1. Harness or connectors (The solenoid and switch circuits are open or shorted.)
2. Low coast brake solenoid valve
3. ATF pressure switch 2

1. Harness or connectors (These switches circuit is open or shorted.)
2. Mode select switch (Into control device)
3. Position select switch (Into control device)

MANUAL MODE SWITCH

Check continuity between terminals.

Scheme 653

Scheme 654

Scheme 655

1. CHECK INPUT SIGNALS (WITH CONSULT-II) WITH CONSULT-II Start engine. Select "MAIN SIGNALS" in "DATA MONITOR" mode for A/T with CONSULT-II and read out the value of "GEAR". Drive vehicle in the manual mode, and confirm that the actual gear position and the meter's indication of the position mutually coincide when the select lever is shifted to the "+ (up)" or "- (down)" side (1st <--> 5th gear). OK or NG OK >> INSPECTION END NG >> Check the following items.

Scheme 656

1. ATF pressure switch 1
2. Harness or connectors (The switch circuit is open or shorted.)

1. ATF pressure switch 3
2. Harness or connectors (The switch circuit is open or shorted.)

1. ATF pressure switch 5
2. Harness or connectors (The switch circuit is open or shorted.)

1. ATF pressure switch 6
2. Harness or connectors (The switch circuit is open or shorted.)

SHIFT LOCK SOLENOID

1. Check operation by applying battery voltage to the A/T device harness connector.

Scheme 657

Scheme 658

DETENTION SWITCH

For Key

Scheme 659

Scheme 660

1. Check continuity between terminals of the A/T device harness connector.

Key Lock

1. Check operation by applying battery voltage to key switch and key lock solenoid harness connector.

Scheme 661

Scheme 662

Key Unlock

1. Check operation by applying battery voltage to key switch and key lock solenoid harness connector.

Scheme 663

Scheme 664

Scheme 665

Scheme 666

1. Check continuity between terminals of the key switch and key lock solenoid harness connector.

Scheme 667

Scheme 668

1. Check continuity between terminals of the stop lamp switch harness connector. Check stop lamp switch after adjusting brake pedal. Refer to "BRAKE PEDAL".

3rd One-Way Clutch

1. Check frictional surface for wear or damage. CAUTION: If necessary, replace the 3rd one-way clutch.

Front Sun Gear Snap Ring

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the snap ring.

Front Sun Gear

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the front sun gear.

Scheme 669

Scheme 670

Scheme 671

1. Install 3rd one-way clutch in front sun gear. CAUTION: Apply ATF to 3rd one-way clutch.
2. Using a flat-bladed screwdriver, install snap ring in front sun gear.
3. Check operation of 3rd one-way clutch. Hold oil pump assembly and turn front sun gear. Check 3rd one-way clutch for correct locking and unlocking directions. CAUTION: If not as shown in illustration, check installation direction of 3rd one-way clutch.

Scheme 672

Scheme 673

Scheme 674

Scheme 675

Scheme 676

Scheme 677

Scheme 678

Scheme 679

1. Remove front carrier assembly from rear internal gear.
2. Remove bearing race from front carrier.
3. Remove needle bearing from front carrier.
4. Remove snap ring from front carrier.
5. Remove input clutch assembly from rear internal gear. Remove O-ring and seal rings from input clutch assembly. Remove needle bearing from input clutch assembly. Using a flat-bladed screwdriver, remove snap ring from input clutch drum. Remove drive plate, driven plate and retaining plate from input clutch drum.

Front Carrier Snap Ring

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the snap ring.

Input Clutch Snap Ring

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the input clutch assembly.

Input Clutch Drum

1. Check for deformation, fatigue or damage or burns. CAUTION: If necessary, replace the input clutch assembly.

Input Clutch Drive Plates

1. Check facing for burns, cracks or damage. CAUTION: If necessary, replace the input clutch assembly.

Input Clutch Retaining Plates and Driven Plates

1. Check facing for burns, cracks or damage. CAUTION: If necessary, replace the input clutch assembly.

Front Carrier

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the front carrier assembly.

Rear Internal Gear

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the rear internal gear assembly.

Scheme 680

Scheme 681

Scheme 682

Scheme 683

Scheme 684

Scheme 685

Scheme 686

1. Install input clutch. Install drive plate, driven plate and retaining plate in input clutch drum. Using a flat-bladed screwdriver, install snap ring in input clutch drum. Install needle bearing in input clutch assembly. CAUTION: Apply petroleum jelly to needle bearing. Install O-ring and seal rings in input clutch assembly. CAUTION: Do not reuse O-ring and seal rings. Apply ATF to O-ring. Apply petroleum jelly to seal rings.
2. Install input clutch assembly in rear internal gear.
3. Install front carrier assembly. Install snap ring in front carrier. Install needle bearing in front carrier. CAUTION: Apply petroleum jelly to needle bearing. Install bearing race in front carrier. CAUTION: Apply petroleum jelly to bearing race. Install front carrier assembly in input clutch and rear internal gear.

Scheme 687

Scheme 688

Scheme 689

Scheme 690

Scheme 691

Scheme 692

Scheme 693

Scheme 694

Scheme 695

1. Remove needle bearing and bearing race.
2. Using a snap ring pliers, remove snap ring from high and low reverse clutch hub.
3. Remove high and low reverse clutch hub from mid sun gear assembly.
4. Remove needle bearing from high and low reverse clutch hub.
5. Remove rear sun gear assembly from mid sun gear assembly. Using a flat-bladed screwdriver, remove snap ring from rear sun gear. Remove 1st one-way clutch from rear sun gear.
6. Remove seal rings from mid sun gear.

High and Low Reverse Clutch Hub Snap Ring, Rear Sun Gear Snap Ring

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the snap ring.

1st One-Way Clutch

1. Check frictional surface for wear or damage. CAUTION: If necessary, replace the 1st one-way clutch.

Mid Sun Gear

1. Check for deformation, fatigue or damage. CAUTION: Replace mid sun gear assembly and high and low reverse clutch assembly as a set if necessary.

Rear Sun Gear

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the rear sun gear.

High and Low Reverse Clutch Hub

1. Check for deformation, fatigue or damage. CAUTION: If necessary, replace the high and low reverse clutch hub.

Scheme 696

Scheme 697

Scheme 698

Scheme 699

Scheme 700

Scheme 701

Scheme 702

Scheme 703

Scheme 704

1. Install seal rings from mid sun gear. CAUTION: Do not reuse seal rings. Apply petroleum jelly to seal rings.
2. Install 1st one-way clutch in rear sun gear. CAUTION: Apply petroleum jelly to 1st one-way clutch.
3. Using a flat-bladed screwdriver, install snap ring in rear sun gear.
4. Install rear sun gear assembly in mid sun gear assembly.
5. Install needle bearing in high and low reverse clutch hub. CAUTION: Apply petroleum jelly to needle bearing.
6. Install high and low reverse clutch hub in mid sun gear assembly.
7. Using a snap ring pliers, install snap ring in high and low reverse clutch hub.
8. Check operation of 1st one-way clutch. Hold mid sun gear and turn rear sun gear. Check 1st one-way clutch for correct locking and unlocking directions. CAUTION: If not as shown in illustration, check installation direction of 1st one-way clutch.
9. Install needle bearing and bearing race. CAUTION: Apply petroleum jelly to needle bearing and bearing race.

Scheme 705

Scheme 706

1. Using a flat-bladed screwdriver, remove snap ring from high and low reverse clutch drum.
2. Remove drive plates, driven plates and retaining plate from high and low reverse clutch drum.

High and Low Reverse Clutch Snap Ring

1. Check for deformation, fatigue or damage.

High and Low Reverse Clutch Drive Plates

1. Check facing for burns, cracks or damage.

High and Low Reverse Clutch Retaining Plates and Driven Plates

1. Check facing for burns, cracks or damage.

Scheme 707

1. Install drive plates, driven plates and retaining plate in high and low reverse clutch drum.
2. Using a flat-bladed screwdriver, install snap ring in high and low reverse clutch drum.

Scheme 708

Scheme 709

1. Using a flat-bladed screwdriver, remove snap ring from direct clutch drum.
2. Remove drive plates, driven plates and retaining plate from direct clutch drum.

Direct Clutch Snap Ring

1. Check for deformation, fatigue or damage.

Direct Clutch Drive Plates

1. Check facing for burns, cracks or damage.

Direct Clutch Retaining Plates and Driven Plates

1. Check facing for burns, cracks or damage.

Scheme 710

1. Install drive plates, driven plates and retaining plate in direct clutch drum.
2. Using a flat-bladed screwdriver, install snap ring in direct clutch drum.

Scheme 711

Scheme 712

Scheme 713

Scheme 714

Scheme 715

Scheme 716

Scheme 717

Scheme 718

Scheme 719

Scheme 720

Scheme 721

Scheme 722

Scheme 723

Scheme 724

Scheme 725

Scheme 726

Scheme 727

Scheme 728

Scheme 729

Scheme 730

Scheme 731

Scheme 732

Scheme 733

Scheme 734

Scheme 735

Scheme 736

Scheme 737

Scheme 738

Scheme 739

Scheme 740

Scheme 741

Scheme 742

Scheme 743

Scheme 744

Scheme 745

Scheme 746

Scheme 747

Scheme 748

Scheme 749

Scheme 750

Scheme 751

Scheme 752

Scheme 753

Scheme 754

1. As shown below, use a drift (commercial service tool .22) to drive manual shaft oil seal into the transmission case until it is flush. CAUTION: Apply ATF to manual shaft oil seal. Do not reuse manual shaft oil seal.
2. Install detent spring and spacer in transmission case.
3. Assemble manual shaft, manual plate, and parking rod after installing manual shaft to transmission case.
4. Install retaining pin into the manual plate and manual shaft. Fit pinhole of the manual plate to pinhole of the manual shaft with a pin punch. Use a hammer to tap the retaining pin into the manual plate. CAUTION: Drive retaining pin to 2+/-0.5 mm over the manual plate. Do not reuse retaining pin.
5. Install retaining pin into the transmission case and manual shaft. Fit pinhole of the transmission case to pinhole of the manual shaft with a pin punch. Use a hammer to tap the retaining pin into the transmission case. CAUTION: Drive retaining pin to 5+/-1 mm over the transmission case. Do not reuse retaining pin.
6. Install terminal cord assembly in transmission case. CAUTION: Apply petroleum jelly to O-ring.
7. Install terminal cord assembly connectors in bracket.
8. Install O-rings in servo assembly. CAUTION: Do not reuse O-rings. Apply petroleum jelly to O-rings.
9. Install return spring in servo assembly.
10. Install servo assembly in transmission case.
11. Using snap ring pliers, install snap ring in transmission case.
12. Install lip seal and D-ring in reverse brake piston. CAUTION: Do not reuse lip seal and lathe cut seal ring. Apply petroleum jelly to lip seal. Apply ATF to D-ring.
13. Install reverse brake piston in transmission case.
14. Install seal rings in drum support. CAUTION: Do not reuse seal rings. Apply petroleum jelly to seal rings.
15. Install needle bearing in transmission case. CAUTION: Apply petroleum jelly to needle bearing.
16. After installing the return spring and spring retainer in transmission case, use a clutch spring compressor to install snap ring in transmission case. CAUTION: Securely assemble them using a flat-bladed screwdriver so that snap ring tension is slightly weak.
17. Install reverse brake retaining plate, drive plate, driven plate and dish plate in transmission case.
18. Assemble N-spring.
19. Install snap ring in transmission case.
20. Measure clearance between retaining plate and snap ring. If not within specified clearance, select proper retaining plate. Specified clearance "A": Standard: 0.7 - 1.1 mm (0.028 - 0.043 in) Retaining plate: Refer to " «REVERSE BRAKE»(ref-182060-S37027095542005080600000) ".
21. Install return spring in parking pawl.
22. Install parking pawl and pawl shaft in output shaft & companion flange complement.
23. Install parking actuator support in output shaft & companion flange complement.
24. Install intermediate shaft in transmission case. CAUTION: Be careful not to mistake front for rear because both sides looks similar. (Thinner end is front side.)
25. Install revolution sensor in transmission case.
26. Install needle bearing in transmission case. CAUTION: Apply petroleum jelly to needle bearing.
27. Apply recommended sealant (Genuine Anaerobic Liquid Gasket or equivalent. Refer to "RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS ".) to output shaft & companion flange complement as shown in illustration. CAUTION: Complete remove all moisture, oil and old sealant, etc. From the transmission case and output shaft & companion flange complement mounting surfaces.
28. Install output shaft & companion flange complement in transmission case.
29. Tighten output shaft & companion flange complement mounting bolts to specified torque. (Because terminal bracket is tightened together with output shaft & companion flange, it should be installed before procedure 27.) CAUTION: Do not reuse self-sealing bolt. Output shaft & companion flange complement mounting bolt: 52 N.m (5.3 kg-m, 38 ft-lb) Self-sealing bolt: 61 N.m (6.2 kg-m, 45 ft-lb)
30. Install direct clutch assembly in transmission case. CAUTION: Make sure that drum support edge surface and direct clutch inner boss edge surface come to almost same place.
31. Install needle bearing in high and low reverse clutch drum. CAUTION: Apply petroleum jelly to needle bearing.
32. Install high and low reverse clutch assembly in transmission case. CAUTION: Be sure to replace high and low reverse clutch and mid sun gear as a set.
33. Using a flat-bladed screwdriver, range the drive plate.
34. Install mid sun gear assembly in transmission case. CAUTION: Check that portion A of high and low reverse clutch drum protrudes approximately 2 mm (0.08 in) beyond portion B of rear sun gear.
35. Install needle bearing in rear carrier assembly. CAUTION: Apply petroleum jelly to needle bearing.
36. Install bearing race in rear carrier assembly. CAUTION: Apply petroleum jelly to bearing race.
37. Install rear carrier assembly in transmission case.
38. Install needle bearing (rear side) in mid carrier assembly. CAUTION: Apply petroleum jelly to needle bearing.
39. Install needle bearing (front side) in mid carrier assembly. CAUTION: Apply petroleum jelly to needle bearing.
40. Install mid carrier assembly in transmission case.
41. Install front carrier assembly in transmission case. (With input clutch assembly and rear internal gear.)
42. Install seal rings in input clutch assembly. CAUTION: Do not reuse seal rings. Apply petroleum jelly to seal rings.
43. Install band servo anchor end pin and lock nut in transmission case. CAUTION: Do not reuse band servo anchor end pin.
44. Install brake band in transmission case. CAUTION: Assemble it so that identification to avoid incorrect installation faces servo side.
45. Install front sun gear in transmission case. CAUTION: Apply ATF to front sun gear bushing and one-way clutch end bearing.
46. Install needle bearing in front sun gear. CAUTION: Apply petroleum jelly to needle bearing.
47. Adjust brake band tilting using clips so that brake band contacts front sun gear drum evenly.
48. Adjust brake band. Loosen lock nut. Tighten band servo anchor end pin to specified torque. : 5.0 N.m (0.51 kg-m, 44 in-lb) Back of band servo anchor end pin three turns. While band servo anchor end pin, tighten lock nut to specified torque.

Scheme 755

1. Measure clearance between front sun gear and needle bearing for oil pump cover.
2. Select proper thickness of bearing race so that end play is within specifications.

Scheme 756

Scheme 757

Scheme 758

Scheme 759

Scheme 760

Scheme 761

Scheme 762

1. Measure dimensions "K" and "L" and then calculate dimension "J". Measure dimension "K". Measure dimension "L". Calculate dimension "J". "J": Distance between oil pump fitting surface of transmission case and needle bearing mating surface of front sun gear. J = K-L
2. Measure dimensions "M1" and "M2" and then calculate dimension "M". Place bearing race and needle bearing on oil pump assembly. Measure thickness of straightedge "M1". Measure thickness of straightedge "M2". Calculate dimension "M". "M": Distance between trans mission case fitting surface of oil pump and needle bearing on oil pump. M = M1 - M2
3. Adjust total end play "T1". T1 =J-M Total end play "T1": 0.25 - 0.55 mm (0.0098 - 0.0217 in) Select proper thickness of bearing race so that total end play is within specifications. Bearing races: Refer to " «BEARING RACE FOR ADJUSTING TOTAL END PLAY»(ref-182060-S23490129002005080600000) ".
