Maintenance: Removal & Installation Infiniti M45 III рестайлинг

REMOVAL

Scheme 8

Scheme 9

1. Remove undercover with power tool.
2. Using oil filter wrench [SST: KV10115801 (J38956)] (B), remove oil filter. CAUTION: Oil filter is provided with relief valve. Use genuine NISSAN engine oil filter or equivalent. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Do not allow engine oil to adhere to drive belts. Completely wipe off any engine oil that adheres to engine and vehicle.

Scheme 10

Scheme 11

1. Remove foreign materials adhering to oil filter installation surface.
2. Apply engine oil to the oil seal contact surface of new oil filter.
3. Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn. Or tighten to specification. Oil filter: Torque Specifications : 17.7 N.m (1.8 kg-m, 13 ft-lb)

INSTALLATION

Installation is the reverse order of removal.

Spark plug

Torque Specifications : 19.6 N.m (2.0 kg-m, 14 ft-lb)

Scheme 12

1. Remove front engine undercover with power tool.
2. Using the oil filter wrench (SST), remove the oil filter. CAUTION: Oil filter is provided with relief valve. Use Genuine NISSAN engine oil filter or equivalent. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Never allow engine oil to adhere to drive belts. Completely wipe off any engine oil that adhere to engine and vehicle.

1. Remove foreign materials adhering to oil filter installation surface.
2. Apply new engine oil to the oil seal circumference of the new oil filter.
3. Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn. Or tighten to specification. Oil filter: Torque Specifications : 17.7 N.m (1.8 kg-m, 13 ft-lb)

Install in the reverse order of removal.

Spark plug

Torque Specifications : 24.5 N.m (2.5 kg-m, 18 ft-lb)

1. Remove inner and outer balance weights from the road wheel. CAUTION: Be careful not to scratch the road wheel during removal.
2. Using releasing agent, remove double-faced adhesive tape from the road wheel. CAUTION: Be careful not to scratch the road wheel during removal. After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road wheel.
