Maintenance: Other Infiniti M45 III рестайлинг

Special Service Tool

SPECIAL SERVICE TOOL DESCRIPTION CHART Tool number (Kent-Moore No.) Tool name Description KV10115801 (J38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)

Commercial Service Tool

COMMERCIAL SERVICE TOOL DESCRIPTION CHART Tool name (Kent-Moore No.) Description Power tool (-) Loosening nuts and bolts Spark plug wrench (-) Removing and installing spark plug

Scheme 17

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or they can have their INFINITI dealers do them.

OUTSIDE THE VEHICLE

OUTSIDE VEHICLE REFERENCE CHART

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

INSIDE VEHICLE REFERENCE CHART

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

UNDER HOOD AND VEHICLE REFERENCE CHART

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals .

PERIODIC MAINTENANCE REFERENCE CHART

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

ITEM MAINTENANCE REFERENCE CHART

CHASSIS AND BODY MAINTENANCE REFERENCE CHART

AUTOMATIC TRANSMISSION FLUID REFERENCE CHART

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

CHASSIS AND BODY MAINTENANCE REFERENCE CHART

Engine Oil Recommendation

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.

Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Scheme 18

Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

Scheme 19

Scheme 20

1. Make sure that the indicator (C) (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A). NOTE: Check the drive belt auto-tensioner indication when the engine is cold.
2. When new drive belt is installed, the indicator (C) (notch on fixed side) should be within the range (B) in the figure.
3. Visually check entire drive belt for wear, damage or cracks.
4. If the indicator (C) (notch on fixed side) is out of the possible use range or belts is damaged, replace drive belt.

Changing Engine Coolant

Scheme 21

1. Remove undercover with power tool.
2. Open radiator drain plug (2) at the bottom of radiator, and then remove radiator cap. When drain all of engine coolant in the system, open water drain plugs on engine cylinder block. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-356257-S35285500702010021300000) ".
3. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
4. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling system. Refer to " «FLUSHING COOLING SYSTEM»(ref-356264-S19705062472010021300000) ".

Scheme 22

Scheme 23

Scheme 24

1. Install reservoir tank, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-356257-S35285500702010021300000) ".
2. Make sure that each hose clamp has been firmly tightened.
3. Remove air relief plug (1) on heater hose (2).
4. Fill radiator and reservoir tank to specified level. Pour engine coolant through engine coolant filler neck slowly of less than 2 l (2-1/8 US qt, 1-3/4 lmp qt) a minute to allow air in system to escape . Use Genuine NISSAN Long Life Antifreeze/Coolant or equivalent mixed with water (distilled or demineralized). Refer to " «FLUIDS AND LUBRICANTS»(ref-356264-S33360835822010021300000) ". Engine coolant capacity (with reservoir tank at "MAX" level) : Approx. 9.2 l (9-6/8 US qt, 8-1/8 lmp qt) Reservoir tank capacity (at "MAX" level) : 0.8 l (7/8 US qt, 3/4 lmp qt) When engine coolant overflows air relief hole on heater hose, install air relief plug with new O-ring. Air relief plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb)
5. Install radiator cap.
6. Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 RPM. Make sure thermostat condition by touching radiator hose (lower) to see flow of warm water. CAUTION: Watch water temperature gauge so as not to overheat engine.
7. Stop engine and cool down to less than approximately 50°C (122°F). Cool down using fan to reduce the time. If necessary, refill radiator up to filler neck with engine coolant.
8. Refill reservoir tank to "MAX" level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 RPM with heater temperature controller set at several position between "COOL" and "WARM". Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating step 4 through 7 until engine coolant level no longer drops. Clean excess engine coolant from engine .

Scheme 25

1. Install reservoir tank, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-356257-S35285500702010021300000) ".
2. Remove air relief plug (1) on heater hose (2).
3. Fill radiator with water until water spills from the air relief hole, then close air relief plug. Fill radiator and reservoir tank with water and reinstall radiator cap. Air relief plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb)
4. Run engine and warm it up to normal operating temperature.
5. Rev engine two or three times under no-load.
6. Stop engine and wait until it cools down.
7. Drain water from the system. Refer to " «DRAINING ENGINE COOLANT»(ref-356264-S02521156212010021300000) ".
8. Repeat steps 1 through 7 until clear water begins to drain from radiator.

Checking Fuel Line

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Scheme 26

VISCOUS PAPER TYPE

The viscous paper type filter does not need cleaning between replacement intervals. Refer to " INTRODUCTION OF PERIODIC MAINTENANCE ".

Scheme 27

Changing Engine Oil

Scheme 28

1. Warm up engine, put vehicle horizontally and check for oil leakage from engine components. Refer to " «INSPECTION»(ref-356262-S29238252412010021300000) ".
2. Stop engine and wait for 10 minutes.
3. Loosen oil filler cap.
4. Remove mounting bolts, and then pull down the rear of front engine undercover and secure it using clip.
5. Remove drain plug and then drain engine oil.
6. Install drain plug with new washer. Refer to " «2WD : COMPONENT»(ref-356257-S24724904552010021300000) ". CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug: Torque Specifications : 34.3 N.m (3.5 kg-m, 25 ft-lb)
7. Refill with new engine oil. Engine oil specification and viscosity: Refer to " «FLUIDS AND LUBRICANTS»(ref-356264-S33360835822010021300000) ". Engine oil capacity (Approximate): ENGINE OIL CAPACITY REFERENCE CHART Unit: (US qt, lmp qt) Drain and refill With oil filter change 4.9 (5-1/8, 4-1/4) Without oil filter change 4.6 (4-7/8, 4) Dry engine (Overhaul) 5.7 (6, 5) CAUTION: When filling engine oil, do not pull out oil level gauge. The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in the engine.
8. Warm up engine and check area around drain plug and oil filter for oil leakage.
9. Stop engine and wait for 10 minutes.
10. Check the engine oil level. A : Make sure that the oil level is between "L" and "H"

Checking EVAP Vapor Line

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to " «SYSTEM DIAGRAM»(ref-356259-S14093708962010021300000) ".

Scheme 29

1. Remove air duct (inlet) when inspecting drive belt for alternator, water pump and A/C compressor.
2. Remove front engine undercover with power tool when inspecting power steering oil pump belt.
3. Check that indicator (single line notch) of each auto tensioner is within the allowable working range (between three line notches). NOTE: Check auto tensioner indication when engine is cold. When new drive belt is installed, the range should be "A". The indicator notch is located on the moving side of the tensioner for alternator, water pump and A/C compressor belt, while it is found on the fixed side for power steering oil pump belt.
4. Visually check entire belt for wear, damage or cracks.
5. If the indicator is out of allowable working range or belt is damaged, replace belt.

Scheme 30

1. Remove engine room cover (RH and LH). Refer to «ENGINE ROOM COVER»(ref-356271-S37574715152010021300000) .
2. Remove engine cover with power tool. Refer to " «REMOVAL AND INSTALLATION»(ref-356271-S28692469112010021300000) ".
3. Open radiator drain plug at the bottom of radiator, and then remove radiator cap. When draining all of engine coolant in the system, open water drain plugs on cylinder block. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-356271-S30354377962010021300000) ".
4. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
5. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling system. Refer to " «FLUSHING COOLING SYSTEM»(ref-356264-S19705062472010021300000) ".

Scheme 31

1. Install reservoir tank if removed, and radiator drain plug. CAUTION: Be sure to clean radiator drain plug and install with new O-ring. Radiator drain plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-356271-S30354377962010021300000) ".
2. Check that each hose clamp has been firmly tightened.
3. Remove air relief plug (1) on heater hose.
4. Fill thermostat housing and reservoir tank to specified level. Refill engine coolant up to filler neck of thermostat housing . Pour engine coolant through engine coolant filler neck slowly of less than 2 l (2-1/8 US qt, 1-3/4 lmp qt) a minute to allow air in system to escape . Use Genuine NISSAN Long Life Antifreeze/Coolant or equivalent mixed with water (distilled or demineralized). Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-356264-S33360835822010021300000) . Engine coolant capacity (With reservoir tank at "MAX" level): Approx. 10.4 l (11 US qt, 9-1/8 lmp qt) Reservoir tank engine coolant capacity (At "MAX" level): 0.8 l (7/8 US qt, 3/4 lmp qt) When engine coolant overflows air relief hole on heater hose, install air relief plug. Air relief plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb)
5. Install radiator cap.
6. Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 RPM. Check thermostat opening condition by touching radiator hose (lower) to see a flow of warm water. CAUTION: Watch water temperature gauge so as not to overheat engine.
7. Stop engine and cool down to less than approximately 50°C (122°F). Cool down using a fan to reduce the time. If necessary, refill engine coolant up to filler neck of thermostat housing.
8. Refill reservoir tank to "MAX" level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 RPM with heater temperature controller set at several position between "COOL" and "WARM". Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating steps 4 through 7 until engine coolant level no longer drops.

Scheme 32

1. Install reservoir tank, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-356271-S30354377962010021300000) ".
2. Remove air relief plug (1) on heater hose.
3. Fill thermostat housing with water until water spills from the air relief hole, then close air relief plug. Fill thermostat housing and reservoir tank with water and reinstall radiator cap. Air relief plug: Torque Specifications : 1.2 N.m (0.12 kg-m, 11 in-lb)
4. Run engine and warm it up to normal operating temperature.
5. Rev engine two or three times under no-load.
6. Stop engine and wait until it cools down.
7. Drain water from the system. Refer to " «CHANGING ENGINE COOLANT»(ref-356272-S21215035982010021300000) ".
8. Repeat steps 1 through 7 until clear water begins to drain from radiator.

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

The viscous paper type filter does not need cleaning between replacement intervals. Refer to PERIODIC MAINTENANCE .

Scheme 33

Scheme 34

1. Warm up engine, put vehicle horizontally and check for engine oil leakage from engine components. Refer to " «INSPECTION»(ref-356274-S00153837772010021300000) ".
2. Stop engine and wait for 15 minutes.
3. Loosen oil filler cap.
4. Remove mounting bolts, and then pull down the rear of front engine undercover and secure it using clip.
5. Remove drain plug and then drain engine oil.
6. Install drain plug with new washer. Refer to «OIL PAN AND OIL STRAINER»(ref-356271-S15531296612010021300000) . CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug: Torque Specifications : 34.3 N.m (3.5 kg-m, 25 ft-lb)
7. Refill with new engine oil. Engine oil specification and viscosity: Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-356264-S33360835822010021300000) . Engine oil capacity (Approximate): ENGINE OIL CAPACITY REFERENCE CHART Unit: (US qt, lmp qt) Drain and refill With oil filter change 5.5 (5-3/4, 4-7/8) without oil filter change 4.9 (5-1/8, 4-1/4) Dry engine (engine overhaul) 6.7 (7-1/8, 5-7/8) CAUTION: The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in the engine.
8. Warm up engine and check area around drain plug and oil filter for oil leakage.
9. Stop engine and wait for 15 minutes.
10. Check the engine oil level.

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to «EVAPORATIVE EMISSION SYSTEM»(ref-356273-S26901142712010021300000) .

Checking Exhaust System

Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage, chafing or deterioration.

Scheme 35

1. If anything is found, repair or replace damaged parts.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Warm up engine.
2. Check for A/T fluid leakage.
3. Loosen the level gauge bolt.
4. Before driving, A/T fluid level can be checked at A/T fluid temperatures of 30 to 50°C (86 to 122°F) using "COLD" range on A/T fluid level gauge as follows. Park vehicle on level surface and set parking brake. Start engine and move selector lever through each gear position. Leave selector lever in "P" position. Check A/T fluid level with engine idling. Remove A/T fluid level gauge and wipe clean with lint-free paper. CAUTION: When wiping away the A/T fluid level gauge, always use lint-free paper, not a cloth one. Re-insert A/T fluid level gauge into A/T fluid charging pipe as far as it will go. CAUTION: To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the end of the A/T fluid charging pipe, with the A/T fluid level gauge reversed from the normal attachment conditions. Remove A/T fluid level gauge and note reading. If reading is at low side of range, add ATF to the A/T fluid charging pipe. CAUTION: Do not overfill.
5. Drive vehicle for approximately 5 minutes in urban areas.
6. Make the A/T fluid temperature approximately 65°C (149°F). NOTE: A/T fluid level will be greatly affected by temperature as shown in figure. Therefore, be certain to perform operation while checking data with CONSULT-III. Select "DATA MONITOR". Read out the value of "ATF TEMP 1".
7. Re-check A/T fluid level at A/T fluid temperatures of approximately 65°C (149°F) using "HOT" range on A/T fluid level gauge. CAUTION: When wiping away the A/T fluid level gauge, always use lint-free paper, not a cloth one. To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the end of the A/T fluid charging pipe, with the A/T fluid level gauge reversed from the normal attachment conditions as shown.
8. Check A/T fluid condition. If ATF is very dark or smells burned, check operation of A/T. Flush cooling system after repair of A/T. If A/T fluid contains frictional material (clutches, bands, etc.), replace radiator and flush cooler line using cleaning solvent and compressed air after repair of A/T. Refer to «RADIATOR»(ref-356258-S03660796322010021300000) (for VQ35HR engine), «RADIATOR»(ref-356272-S23734032422010021300000) (for VK45DE engine) and " «VQ35HR : A/T FLUID COOLER CLEANING»(ref-356265-S01004015012010021300000) ".
9. Install the removed A/T fluid level gauge in the A/T fluid charging pipe.
10. Tighten level gauge bolt. Level gauge bolt Torque Specifications : 5.1 N.m (0.52 kg-m, 45 in-lb)

Checking Propeller Shaft

Check propeller shaft for damage, looseness or grease leakage.

Tightening torque

Refer to REAR PROPELLER SHAFT

Scheme 40

Checking Differential Gear Oil

Check for oil leakage.

(For details, refer to " CHECKING DIFFERENTIAL GEAR OIL " and " CHECKING DIFFERENTIAL GEAR OIL ".)

Scheme 41

Scheme 42

1. Drain oil from drain plug and refill with new gear oil. (For details, refer to " «CHANGING DIFFERENTIAL GEAR OIL»(ref-356270-S13643702582010021300000) " and " «CHANGING DIFFERENTIAL GEAR OIL»(ref-356287-S29763041902010021300000) ".)
2. Check oil level. Oil grade and Viscosity: Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-356264-S33360835822010021300000) . Capacity: Front final drive (F160A) 0.65 l (1 - 3/8 US pt, 1 - 1/8 lmp pt) Rear final drive (R200) 1.4 l (3 US pt, 2 - 1/2 lmp pt) Filler plug: Front final drive Torque Specifications : 34.5 N-m (3.5 kg-m, 25 ft-lb) Rear final drive Torque Specifications : 34.5 N-m (3.5 kg-m, 25 ft-lb) Drain plug: Front final drive Torque Specifications : 34.5 N-m (3.5 kg-m, 25 ft-lb) Rear final drive Torque Specifications : 34.5 N-m (3.5 kg-m, 25 ft-lb)

Rotation

1. Follow the maintenance schedule for tire rotation service intervals. Refer to «GENERAL MAINTENANCE»(ref-356264-S40501104542010021300000) .
2. Do not include the spare tire when rotating the tires.

Scheme 43

Scheme 44

1. If fluid level is extremely low, check brake system for leaks.

Scheme 45

1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.

Scheme 46

1. Drain brake fluid from each bleed valve.
2. Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «BLEEDING BRAKE SYSTEM»(ref-356250-S14431348972010021300000) ". Refill with recommended genuine Nissan Super Heavy Duty Brake Fluid or equivalent DOT 3 (US FMVSS No. 116). Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-356264-S33360835822010021300000) . Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas.

ROTOR

Check condition, wear, and damage.

DISC BRAKE CONDITION CHART

Scheme 47

1. Check for leakage.

Scheme 48

1. Check for wear or damage. PAD CONDITION CHART - Front Rear Standard thickness 11.0 mm (0.433 in) 8.5 mm (0.335 in) Repair limit thickness 2.0 mm (0.079 in) 2.0 mm (0.079 in)

Scheme 49

1. Check gear housing and boots for looseness, damage and grease leakage.
2. Check connection with steering column for looseness.

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

Axle and Suspension Parts

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

Scheme 50

Scheme 51

1. Shake each wheel to check for excessive play.
2. Check wheel bearings for smooth operation.
3. Check axle and suspension nuts and bolts for looseness.
4. Check strut (shock absorber) for oil leakage or other damage.
5. Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage.

Drive Shaft

Check boot and drive shaft for cracks, wear, damage and grease leakage.

Scheme 52

Scheme 53

Scheme 54

For details, refer to " SEAT BELT INSPECTION " inn

1. Check anchors for loose mounting
2. Check belts for damage
3. Check retractor for smooth operation
4. Check function of buckles and tongues when buckled and released

BELT DEFLECTION AND TENSION (VQ35HR)

BELT DEFLECTION AND TENSION SPECIFICATION CHART

BELT DEFLECTION AND TENSION (VK45DE)

BELT DEFLECTION AND TENSION SPECIFICATION CHART

RADIATOR (VQ35HR)

RADIATOR SPECIFICATION CHART

RADIATOR (VK45DE)

RADIATOR SPECIFICATION CHART

SPARK PLUG (PLATINUM-TIPPED TYPE) (VQ35HR)

SPARK PLUG SPECIFICATION CHART

SPARK PLUG (PLATINUM-TIPPED TYPE) (VK45DE)

SPARK PLUG SPECIFICATION CHART

WHEEL BALANCE

WHEEL BALANCE SPECIFICATION CHART
