Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOLS SPECIFICATIONS Tool number (Kent-Moore No.) Tool name Description KV10115801 (J38956) Oil filter wrench Removing and installing oil filter a: 64.3 mm (2.531 in)

Scheme 18

Commercial Service Tools

COMMERCIAL SERVICE TOOLS SPECIFICATIONS Tool name (Kent-Moore No.) Description Power tool ( - ) Loosening nuts and bolts Spark plug wrench ( - ) Removing and installing spark plug Belt tension gauge (BT3373-F) Checking drive belt tension (VQ35DE)

Scheme 19

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their INFINITI dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

ITEM REFERENCE

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

INSIDE ITEM REFERENCE

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

ITEM REFERENCE

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals .

PERIODIC MAINTENANCE REFERENCE

EMISSION CONTROL SYSTEM MAINTENANCE (SCHEDULE 1)

MAINTENANCE OPERATION

CHASSIS AND BODY MAINTENANCE

MAINTENANCE INTERVAL OPERATION

EMISSION CONTROL SYSTEM MAINTENANCE (SCHEDULE 2)

CHASSIS AND BODY MAINTENANCE REFERENCE

Note. Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this information.

GASOLINE ENGINE OIL

SAE 5W-30 viscosity oil is preferred for all temperatures. SAE 10W-30 and 10W-40 viscosity oil may be used if the ambient temperature is above -18°C (0°F)

Scheme 20

Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

Scheme 21

Checking Drive Belts

Scheme 22

1. Inspect belts for cracks, fraying, wear and oil. If necessary, replace.
2. Inspect drive belt deflection or tension at a point on belt midway between pulleys. Inspection should be done only when engine is cold, or over 30 minutes after engine is stopped. Measure the belt tension with belt tension gauge (Commercial service tool: BT3373-F or equivalent) at points marked down triangle shown in the figure. When measuring the deflection, apply 98 N (10 kg, 22 lb) at down triangle the marked point. Adjust if the belt deflection exceeds the limit or if the belt tension is not within specifications. CAUTION: When checking the belt deflection or the tension immediately after installation, first adjust it to the specified value. Then, after turning crankshaft two turns or more, re-adjust to the specified value to avoid variation in deflection between pulleys. Tighten idler pulley lock nut by hand and measure the deflection or the tension without looseness. Belt Deflection and Tension

BELT DEFLECTION AND TENSION SPECIFICATION

A/C COMPRESSOR BELT

1. Remove front engine undercover with power tool.
2. Loosen idler pulley lock nut (C) and adjust tension by turning adjusting bolt (D). For the specified belt tension, refer to " «CHECKING DRIVE BELTS»(ref-239097-S13716433882006072600000) ".
3. Tighten nut (C). Torque Specification: 34.8 N.m (3.5 kg-m, 26 ft-lb)

Changing Engine Coolant

Scheme 23

1. Remove engine room cover (RH and LH). Refer to " «ENGINE ROOM COVER»(ref-239097-S19590603702006072600000) ".
2. Remove air duct (inlet). Refer to " «AIR CLEANER AND AIR DUCT»(ref-239097-S29792743182006072600000) ".
3. Open radiator drain plug at the bottom of radiator, and then remove radiator cap. 1: Radiator drain plug hole 2: Front engine under cover <-: Engine front When draining all of engine coolant in the system, open water drain plugs on cylinder block. Refer to " «DISASSEMBLY»(ref-239097-S20229821152006072600000) " .
4. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
5. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling system. Refer to " «FLUSHING COOLING SYSTEM»(ref-239098-S27597545522006072600000) ".

Scheme 24

Scheme 25

Scheme 26

1. Install reservoir tank if removed, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug: 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «ASSEMBLY»(ref-239097-S17370960352006072600000) " .
2. Make sure that each hose clamp has been firmly tightened.
3. Remove air relief plug on heater hose.
4. Fill radiator, and reservoir tank if removed, to specified level. Pour engine coolant through engine coolant filler neck slowly of less than 2° (2-1/8 US qt, 1-3/4 lmp qt) a minute to allow air in system to escape . Use Genuine NISSAN Long Life Antifreeze/Coolant or equivalent mixed with water (distilled or demineralized). Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-239110-S35239741612006072600000) " . Engine coolant capacity (With reservoir tank at "MAX" level): Approximately 8.9° (9-3/8 US qt, 7-7/8 lmp qt) Reservoir tank engine coolant capacity (At "MAX" level): 0.6 l (5/8 US qt, 1/2 lmp qt) When engine coolant overflows air relief hole on heater hose, install air relief plug with new O-ring. Air relief plug: 1.2 N.m (0.12 kg-m, 11 ft-lb)
5. Install radiator cap.
6. Warm up engine until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 rpm. Make sure thermostat opening condition by touching radiator hose (lower) to see a flow of warm water. CAUTION: Watch water temperature gauge so as not to overheat engine.
7. Stop the engine and cool down to less than approximately 50°C (122°F). Cool down using fan to reduce the time. If necessary, refill radiator up to filler neck with engine coolant.
8. Refill reservoir tank to "MAX" level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up the engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 rpm with heater temperature controller set at several position between "COOL" and "WARM". Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating step 4 through 7 until engine coolant level no longer drops.

Scheme 27

1. Install reservoir tank if removed, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug: 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «ASSEMBLY»(ref-239097-S17370960352006072600000) " .
2. Remove air relief plug on heater hose.
3. Fill radiator with water until water spills from the air relief hole, then close air relief plug. Fill radiator and reservoir tank with water and reinstall radiator cap. Air relief plug: 1.2 N.m (0.12 kg-m, 11 ft-lb)
4. Run the engine and warm it up to normal operating temperature.
5. Rev the engine two or three times under no-load.
6. Stop the engine and wait until it cools down.
7. Drain water from the system. Refer to " «DRAINING ENGINE COOLANT»(ref-239098-S00512234262006072600000) ".
8. Repeat steps 1 through 7 until clear water begins to drain from radiator.

Checking Fuel Lines

Inspect fuel lines, filler cap and tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration. If necessary, repair or replace damaged parts.

Scheme 28

VISCOUS PAPER TYPE

The viscous paper type filter does not need cleaning between replacement intervals. Refer to " PERIODIC MAINTENANCE ".

Changing Engine Oil

Scheme 29

1. Warm up the engine, and check for engine oil leakage from engine components. Refer to " «ENGINE OIL LEAKAGE»(ref-239102-S10087337272006072700000) ".
2. Stop the engine and wait for 10 minutes.
3. Loosen oil filler cap.
4. Remove mounting bolts, and then pull down the rear of front engine under cover (1) and secure it using clip.
5. Remove drain plug (2) and then drain engine oil.
6. Install drain plug with new washer. Refer to " «OIL PAN AND OIL STRAINER»(ref-239097-S22517911782006072600000) ". CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug: 34.3 N.m (3.5 kg-m, 25 ft-lb)
7. Refill with new engine oil. Engine oil specification and viscosity: Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-239110-S35239741612006072600000) ". ENGINE OIL CAPACITY (APPROXIMATE) SPECIFICATION Unit: l (US qt, lmp qt) Drain and refill With oil filter change 4.7 (5, 4-1/8) Without oil filter change 4.4 (4-5/8, 3-7/8) Dry engine (Overhaul) 5.4 (5-3/4, 4-3/4) CAUTION: When filling engine oil, do not pull out oil level gauge. The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in engine.
8. Warm up the engine and check area around drain plug and oil filter for engine oil leakage.
9. Stop the engine and wait for 10 minutes.
10. Check the engine oil level.

Scheme 30

Checking EVAP Vapor Lines

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to " «EVAPORATIVE EMISSION SYSTEM»(ref-239099-S31435283692006072600000) ".

Scheme 31

1. Remove air duct (inlet) when inspecting drive belt for alternator, water pump and A/C compressor.
2. Remove front engine undercover with power tool when inspecting power steering oil pump belt.
3. Make sure that indicator (single line notch) of each auto tensioner is within the allowable working range (between three line notches). NOTE: Check auto tensioner indication when engine is cold. When new drive belt is installed, the range should be "A". The indicator notch is located on the moving side of the tensioner for alternator, water pump and A/C compressor belt, while it is found on the fixed side for power steering oil pump belt.
4. Visually check entire belt for wear, damage or cracks.
5. If the indicator is out of allowable working range or belt is damaged, replace belt.

Scheme 32

1. Remove engine room cover (RH and LH) Refer to " «ENGINE ROOM COVER»(ref-239114-S21858393402006072700000) ".
2. Remove engine cover with power tool. Refer to " «INTAKE MANIFOLD»(ref-239114-S15410214292006072700000) ".
3. Open radiator drain plug at the bottom of radiator, and then remove radiator cap. 1: Radiator drain plug hole 2: Front engine undercover <-: Engine front When draining all of engine coolant in the system, open water drain plugs on cylinder block. Refer to " «DISASSEMBLY»(ref-239114-S11411128422006072700000) " .
4. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
5. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling system. Refer to " «FLUSHING COOLING SYSTEM»(ref-239110-S36691130112006072700000) ".

Scheme 33

1. Install reservoir tank if removed, and radiator drain plug. CAUTION: Be sure to clean radiator drain plug and install with new O-ring. Radiator drain plug: 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «ASSEMBLY»(ref-239114-S03838532332006072700000) " .
2. Make sure that each hose clamp has been firmly tightened.
3. Remove air relief plug (1) on heater hose. <-: Engine front
4. Fill thermostat housing and reservoir tank to specified level. Refill engine coolant up to filler neck of thermostat housing . Pour engine coolant through engine coolant filler neck slowly of less than 2° (2-1/8 US qt, 1-3/4 Imp qt) a minute to allow air in system to escape . Use Genuine NISSAN Long Life Antifreeze/Coolant or equivalent mixed with water (distilled or demineralized). Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-239110-S35239741612006072600000) " . Engine coolant capacity (With reservoir tank at "MAX" level): Approx. 10.4° (11 US qt, 9-1/8 Imp qt) Reservoir tank engine coolant capacity (At "MAX" level): 0.6° (5/8 US qt, 1/2 lmp qt) When engine coolant overflows air relief hole on heater hose, install air relief plug. Air relief plug: 1.2 N.m (0.12 kg-m, 11 in-lb)
5. Install radiator cap.
6. Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 rpm. Make sure thermostat opening condition by touching radiator hose (lower) to see a flow of warm water. CAUTION: Watch water temperature gauge so as not to overheat engine.
7. Stop engine and cool down to less than approximately 50°C (122°F). Cool down using a fan to reduce the time. If necessary, refill engine coolant up to filler neck of thermostat housing.
8. Refill reservoir tank to "MAX" level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 rpm with heater temperature controller set at several position between "COOL" and "WARM". Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating steps 4 through 7 until engine coolant level no longer drops.

Scheme 34

1. Install reservoir tank, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug: 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «ASSEMBLY»(ref-239114-S03838532332006072700000) " .
2. Remove air relief plug (1) on heater hose. <-: Engine front
3. Fill thermostat housing with water until water spills from the air relief hole, then close air relief plug. Fill thermostat housing and reservoir tank with water and reinstall radiator cap. Air relief plug: 1.2 N.m (0.12 kg-m, 11 in-lb)
4. Run engine and warm it up to normal operating temperature.
5. Rev engine two or three times under no-load.
6. Stop engine and wait until it cools down.
7. Drain water from the system. Refer to " «DRAINING ENGINE COOLANT»(ref-239115-S17969294252006072600000) ".
8. Repeat steps 1 through 7 until clear water begins to drain from radiator.

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Scheme 35

Changing Air Cleaner Filter

VISCOUS PAPER TYPE

The viscous paper type filter does not need cleaning between replacement intervals. Refer to " PERIODIC MAINTENANCE " .

Scheme 36

1. Warm up engine, put vehicle horizontally and check for engine oil leakage from engine components. Refer to " «ENGINE OIL LEAKAGE»(ref-239117-S01167325192006072700000) ".
2. Stop engine and wait for 15 minutes.
3. Loosen oil filler cap.
4. Remove mounting bolts, and then pull down the rear of front engine undercover and secure it using clip.
5. Remove drain plug and then drain engine oil.
6. Install drain plug with new washer. Refer to " «OIL PAN AND OIL STRAINER»(ref-239114-S25579830522006072700000) ". CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug: 34.3 N.m (3.5 kg-m, 25 ft-lb)
7. Refill with new engine oil . Engine oil specification and viscosity: Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-239110-S35239741612006072600000) ". Engine oil capacity (Approximate): ENGINE OIL SPECIFICATION Unit: l (US qt, Imp qt) Drain and refill With oil filter change 5.5 (5-3/4, 4-7/8) without oil filter change 4.9 (5-1/8, 4-1/4) Dry engine (engine overhaul) 6.7 (7-1/8, 5-7/8) CAUTION: The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in the engine.
8. Warm up engine and check area around drain plug and oil filter for oil leakage.
9. Stop engine and wait for 15 minutes.
10. Check the engine oil level.

Scheme 37

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc.

Refer to " EVAPORATIVE EMISSION SYSTEM " .

Checking Exhaust System

Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage, chafing or deterioration.

1. If anything is found, repair or replace damaged parts.

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Warm up engine.
2. Check for A/T fluid leakage.
3. Loosen the level gauge bolt.
4. Before driving, A/T fluid level can be checked at A/T fluid temperatures of 30 to 50°C (86 to 122°F) using "COLD" range on A/T fluid level gauge as follows. Park vehicle on level surface and set parking brake. Start engine and move selector lever through each gear position. Leave selector lever in "P" position. Check A/T fluid level with engine idling. Remove A/T fluid level gauge and wipe clean with lint-free paper. CAUTION: When wiping away the A/T fluid level gauge, always use lint-free paper, not a cloth one. Re-insert A/T fluid level gauge into A/T fluid charging pipe as far as it will go. CAUTION: To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the end of the A/T fluid charging pipe, with the A/T fluid level gauge reversed from the normal attachment conditions. Remove A/T fluid level gauge and note reading. If reading is at low side of range, add ATF to the A/T fluid charging pipe. CAUTION: Do not overfill.
5. Drive vehicle for approximately 5 minutes in urban areas.
6. Make the A/T fluid temperature approximately 65°C (149°F). NOTE: A/T fluid level will be greatly affected by temperature as shown in figure. Therefore, be certain to perform operation while checking data with CONSULT-II. Connect CONSULT-II to data link connector. Refer to " «CONSULT-II SETTING PROCEDURE»(ref-239105-S25571018252006072600000) ". Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out the value of "ATF TEMP 1".
7. Re-check A/T fluid level at A/T fluid temperatures of approximately 65°C (149°F) using "HOT" range on A/T fluid level gauge. CAUTION: When wiping away the A/T fluid level gauge, always use lint-free paper, not a cloth one. To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the end of the A/T fluid charging pipe, with the A/T fluid level gauge reversed from the normal attachment conditions as shown.
8. Check A/T fluid condition. If ATF is very dark or smells burned, check operation of A/T. Flush cooling system after repair of A/T. If A/T fluid contains frictional material (clutches, bands, etc.), replace radiator and flush cooler line using cleaning solvent and compressed air after repair of A/T. Refer to " «RADIATOR»(ref-239098-S40220793482006072600000) " (for VQ35DE engine), " «RADIATOR»(ref-239115-S03757741242006072600000) " (for VK45DE engine) and " «A/T FLUID COOLER CLEANING»(ref-239105-S13683043812006072600000) ".
9. Install the removed A/T fluid level gauge in the A/T fluid charging pipe.
10. Tighten level gauge bolt. Level gauge bolt: 5.1 N.m (0.52 kg-m, 45 in-lb)

Scheme 43

1. Warm up ATF.
2. Stop engine.
3. Loosen the level gauge bolt.
4. Drain ATF from drain plug and refill with new ATF. Always refill same volume with drained ATF. To replace the ATF, pour in new ATF at the A/T fluid charging pipe with the engine idling and at the same time drain the old ATF from the radiator cooler hose return side. When the color of the ATF coming out is about the same as the color of the new ATF, the replacement is complete. The amount of new ATF to use should be 30 to 50% increase of the stipulated amount. ATF: Genuine NISSAN Matic J ATF Fluid capacity: 10.3 l (10-7/8 US qt, 9-1/8 lmp qt) CAUTION: Use only Genuine NISSAN Matic J ATF. Do not mix with other ATF. Using ATF other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not covered by the warranty. When filling ATF, take care not to scatter heat generating parts such as exhaust. Do not reuse drain plug gasket. Drain plug: 34 N.m (3.5 kg-m, 25 ft-lb)
5. Run engine at idle speed for 5 minutes.
6. Check A/T fluid level and condition. Refer to " «CHECKING A/T FLUID»(ref-239105-S38124368742006072600000) ". If ATF is still dirty, repeat step 2 through 5 .
7. Install the removed A/T fluid level gauge into A/T fluid charging pipe.
8. Tighten the level gauge bolt. Level gauge bolt: 5.1 N.m (0.52 kg-m, 45 in-lb)

Checking Propeller Shaft

Check propeller shaft for damage, looseness or grease leakage.

Tightening torque: Refer to " REAR PROPELLER SHAFT "

Scheme 44

Checking Differential Gear Oil

Check for oil leakage.

(For details, refer to " CHECKING DIFFERENTIAL GEAR OIL " and " CHECKING DIFFERENTIAL GEAR OIL ".)

Scheme 45

Scheme 46

1. Drain oil from drain plug and refill with new gear oil. (For details, refer to " «CHANGING DIFFERENTIAL GEAR OIL»(ref-239107-S24185453822006072700000) (Front Final Drive)" and " «CHANGING DIFFERENTIAL GEAR OIL»(ref-239131-S35245337602006072600000) (Rear Final Drive)".
2. Check oil level. Oil grade and Viscosity: Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-239110-S35239741612006072600000) " . Capacity: Front final drive (F160A): 0.65 l (1 - 3/8 US pt, 1 - 1/8 lmp pt) Rear final drive (R200): 1.4 l (3 US pt, 2 - 1/2 lmp pt) Filler plug: Front final drive : 34.5 N-m (3.5 kg-m, 25 ft-lb) Rear final drive : 34.5 N-m (3.5 kg-m, 25 ft-lb) Drain plug: Front final drive : 34.5 N-m (3.5 kg-m, 25 ft-lb) Rear final drive : 34.5 N-m (3.5 kg-m, 25 ft-lb)

Tire Rotation

1. After rotation the tires, adjust the tire pressure.
2. Retighten the wheel nuts when the vehicle has been driven for 1,000 km (600 miles) (also in cases of a flat tire, etc.).

Scheme 47

Checking Brake Lines and Cables

1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.

Scheme 48

Scheme 49

1. Drain brake fluid from each bleed valve.
2. Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «BLEEDING BRAKE SYSTEM»(ref-239123-S41525390782006072600000) ". Refill with recommended Genuine Nissan Super Heavy Duty Brake Fluid or equivalent DOT 3 (US FMVSS No. 116). Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-239110-S35239741612006072600000) ". Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas.

ROTOR

Check condition, wear, and damage.

CHECKING DISC BRAKE SPECIFICATION

CALIPER

1. Check for leakage.

Scheme 50

Scheme 51

1. Check for wear or damage. BRAKE PAD SPECIFICATION Brake model CLZ31VD CLZ31VB AD14VF AD14VE Standard thickness 11.0 mm (0.433 in) 8.5 mm (0.335 in) Minimum thickness (Wear limit) 2.0 mm (0.079 in) 2.0 mm (0.079 in)

STEERING GEAR

1. Check gear housing and boots for looseness, damage and grease leakage.
2. Check connection with steering column for looseness.

Scheme 52

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

Axle and Suspension Parts

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

1. Shake each wheel to check for excessive play.
2. Check wheel bearings for smooth operation.
3. Check axle and suspension nuts and bolts for looseness.
4. Check strut (shock absorber) for oil leakage or other damage.
5. Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage.

Scheme 53

Scheme 54

Drive Shaft

Check boot and drive shaft for cracks, wear, damage and grease leakage.

Scheme 55

Scheme 56

Scheme 57

For details, refer to " SEAT BELT INSPECTION ".

1. Check anchors for loose mounting
2. Check belts for damage
3. Check retractor for smooth operation
4. Check function of buckles and tongues when buckled and released

BELT DEFLECTION AND TENSION (VQ35DE)

BELT DEFLECTION AND TENSION SPECIFICATIONS (VQ35DE) Deflection adjustment Unit: mm (in) Tension adjustment (1) Unit: N (kg, lb) Used belt New belt Used belt New belt Limit After adjustment Limit After adjustment Alternator and power steering oil pump belt 7 (0.28) 4 - 5 (0.16 - 0.20) 3.5 - 4.5 (0.138 - 0.177) 294 (30, 66) 730 - 818 (74.5 - 83.5, 164 - 184) 838 - 926 (85.5 - 94.5, 188 - 208) A/C compressor belt 12 (0.47) 9 - 10 (0.35 - 0.39) 8 - 9 (0.31 - 0.35) 196 (20, 44) 348 - 436 (35.5 - 44.5, 78 - 98) 470 - 559 (48 - 57, 106 - 126) Applied pushing force 98 N (10 kg, 22 lb) - (1) If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on the belt

Scheme 58

BELT DEFLECTION AND TENSION (VK45DE)

BELT DEFLECTION AND TENSION SPECIFICATIONS (VK45DE)

RADIATOR

RADIATOR SPECIFICATION

SPARK PLUG (PLATINUM-TIPPED TYPE) (VQ35DE)

SPARK PLUG SPECIFICATIONS (PLATINUM-TIPPED TYPE) (VQ35DE)

SPARK PLUG (PLATINUM-TIPPED TYPE) (VK45DE)

SPARK PLUG SPECIFICATIONS (PLATINUM-TIPPED TYPE) (VK45DE)

WHEEL BALANCE

WHEEL BALANCE SPECIFICATIONS
