Reverse Interlock Door Mirror System: Other Infiniti M45 II

MIRROR POSITION MEMORY FUNCTIONS

Equipped with a function which allows memorizing the desired mirror face positions (2 positions each for LH/RH door mirror).

POWER SUPPLY

Power is supplied at all times

1. through 10A fuse [No.8,located in the fuse block (J/B)]
2. to driver side door mirror control unit terminal No.8 and passenger side door mirror remote control unit terminal No.8.
3. through 10A fuse [No.3,located in the fuse block (J/B)]
4. to BCM terminal No.105.

With the ignition switch in the ON or START position, power is supplied

1. through 10A fuse [No.9 located in the fuse block (J/B)]
2. to back-up lamp relay terminal No. 2 and 5.

With the ignition switch in the ON or START position and selector lever is in R position, power is supplied

1. though back-up lamp relay terminal No.3
2. to TCM terminal No.141.

Work Flow

1. Check the symptom and customer's requests.
2. Understand the system description. Refer to " «SYSTEM DESCRIPTION»(ref-181226-S09485994002005080200000) ".
3. Carry out the preliminary check. Refer to " «PRELIMINARY CHECK»(ref-181226-S22457873592005080200000) ".
4. Carry out the communication inspection. If CONSULT-II is used, refer to " «IVMS COMMUNICATION DIAGNOSIS»(ref-181226-S13852904222005080200000) ". If CONSULT-II is not used, refer to " «IVMS COMMUNICATION INSPECTION»(ref-181226-S21300752392005080200000) ". Is the communication diagnosis result OK? If OK, GO TO 7 . If NG, GO TO 5.
5. Repair or replace depending on the diagnosis result.
6. Carry out the communication diagnosis again. If CONSULT-II is used, refer to " «IVMS COMMUNICATION DIAGNOSIS»(ref-181226-S13852904222005080200000) ". If CONSULT-II is not used, refer to " «IVMS COMMUNICATION INSPECTION»(ref-181226-S21300752392005080200000) ". Is communication diagnosis result OK? If OK, GO TO 7. If NG, GO TO 5 .
7. Perform self-diagnosis. If CONSULT-II is used, refer to " «OPERATION PROCEDURE»(ref-181226-S24522168042005080200000) ". If CONSULT-II is not used, refer to " «ON BOARD DIAGNOSIS FOR AUTOMATIC DRIVE POSITIONER»(ref-181226-S29199205342005080200000) ". Is self-diagnosis result OK? If OK, GO TO 11 . If NG, GO TO 8.
8. Repair or replace depending on the diagnosis result.
9. Carry out the self-diagnosis again. If CONSULT-II is used, refer to , " «OPERATION PROCEDURE»(ref-181226-S24522168042005080200000) ". If CONSULT-II is not used, refer to " «ON BOARD DIAGNOSIS FOR AUTOMATIC DRIVE POSITIONER»(ref-181226-S29199205342005080200000) ". Is self-diagnosis result OK? If OK, GO TO 11 If NG, GO TO 8 .
10. Referring to Trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to " «SYMPTOM CHART»(ref-181226-S15213672942005080200000) ".
11. Does the Reverse Interlock Door Mirror System operate normally? If it operates normally, GO TO 12. If not, GO TO 10 .
12. Inspection end.

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

1. CHECK FUSE Check that any of the following fuses in BCM and door mirror control unit are blown. NOTE: Refer to " «COMPONENT PARTS AND HARNESS CONNECTOR LOCATION»(ref-181226-S36515211532005080200000) ". OK or NG? OK >> GO TO 2. NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.Refer to "POWER SUPPLY ROUTING ".
2. POWER SUPPLY CIRCUIT INSPECTION (BCM) Turn ignition switch OFF. Disconnect BCM connector. Check voltage between BCM connector M4 terminal 105 and ground. 105(Y/L) - Ground : Battery voltage OK or NG? OK >> GO TO 3. NG >> Repair or replace the harnesses for BCM power supply circuit.
3. GROUND CIRCUIT INSPECTION (BCM) Turn ignition switch OFF. Check continuity between BCM connector M4 terminal 56, 113 and ground. 56 (B) - Ground : Continuity should exist. 113 (B) - Ground : Continuity should exist. OK or NG? OK >> GO TO 4. NG >> Repair or replace harness.
4. CHECK POWER SUPPLY CIRCUIT (DOOR MIRROR CONTROL UNIT) Turn ignition switch OFF. Disconnect door mirror control unit connector. Check voltage between door mirror control unit connector D5 (driver side), D35 (passenger side) terminal 8 and ground. 8 (L) - Ground : Battery voltage OK or NG? OK >> GO TO 5. NG >> Repair or replace harness.
5. CHECK GROUND CIRCUIT (DOOR MIRROR CONTROL UNIT) Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminal 10 and ground. 10 (B) - Ground : Continuity should exist. OK or NG? OK >> Preliminary check is OK. NG >> Repair or replace harness.

CONSULT-II Function

CONSULT-II executes the following functions by combining data received and command transmitted via the communication line from BCM. IVMS communication inspection, work support (only function setting of seats and steering wheel), self-diagnosis, data monitor, and active test display.

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

1. Turn ignition switch "OFF".
2. Connect "CONSULT-II" and "CONSULT-II CONVERTER" to the data link connector.
3. Turn ignition switch "ON".
4. Touch "START (NISSAN BASED VHCL)".
5. Touch "IVMS" on the "SELECT SYSTEM" screen. If "IVMS" is not indicated, go to "CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT ".
6. Check the model specification, touch either "WITH SUNROOF" or "WITHOUT SUNROOF" on the "SELECT SYS COND" screen.
7. Touch "OK". If the selection is wrong, touch "CANCEL".
8. Select the desired part to be diagnosed on the "SELECT TEST ITEM" screen.

COMMUNICATION SYSTEM A

1. BCM INSPECTION Replace BCM with a known-good one, and carry out the communication diagnosis. Refer to " «IVMS COMMUNICATION DIAGNOSIS»(ref-181226-S13852904222005080200000) ". OK or NG? OK >> Replace BCM NG >> GO TO 2.
2. LCU INSPECTION Replace with the previously installed BCM. Replace LCU with a known-good one, and carry out the communication diagnosis. Refer to " «IVMS COMMUNICATION DIAGNOSIS»(ref-181226-S13852904222005080200000) ". OK or NG? OK >> Replace LCU NG >> Perform the following. Repair or replace communication harness between LCU and BCM. Replace with the previously installed LCU.

COMMUNICATION SYSTEM B

1. HARNESS CONNECTOR INSPECTION Check the terminals (at the control unit and harness) on the malfunctioning LCU for disconnection, bend, loose connection, and other malfunctions. OK or NG? OK >> GO TO 2. NG >> Repair the terminals and connectors.
2. LCU INSPECTION Replace the malfunctioning LCU with a known-good one, and carry out the communication diagnosis. Refer to " «IVMS COMMUNICATION DIAGNOSIS»(ref-181226-S13852904222005080200000) ". OK or NG? OK >> Replace LCU NG >> Perform the following. Repair or replace communication harness between LCU and BCM. Replace with the previously installed LCU.

COMMUNICATION SYSTEM C

1. HARNESS CONNECTOR INSPECTION Check the terminals (at the control unit and harness) on BCM and LCU for disconnection, bend, loose connction, and other malfunctions. OK or NG? OK >> GO TO 2. NG >> Repair the terminals and connectors.
2. BCM INSPECTION Replace the malfunctioning BCM with a known-good one, and carry out the communication diagnosis. Refer to " «IVMS COMMUNICATION DIAGNOSIS»(ref-181226-S13852904222005080200000) ". OK or NG? OK >> Replace the BCM NG >> Perform the following. Repair or replace communication harness between LCU and BCM control. Replace with the previously installed BCM.

1. BCM INSPECTION Replace BCM with a known-good one, and carry out the communication diagnosis. Refer to " «COMMUNICATION DIAGNOSIS»(ref-181226-S35327960072005080200000) ". OK or NG? OK >> Replace BCM NG >> GO TO 2.
2. LCU INSPECTION Replace with the previously installed BCM Replace the LCU with a known-good one, and carry out the communication diagnosis. Refer to " «COMMUNICATION DIAGNOSIS»(ref-181226-S35327960072005080200000) ". OK or NG? OK >> Replace LCU NG >> Perform the following. Repair or replace communication harness between LCU and BCM. Replace with the previously installed LCU.

1. HARNESS CONNECTOR INSPECTION Check the terminals (at the control unit and harness) on the malfunctioning LCU for disconnection, bend, poor connection and other malfunctions. OK or NG? OK >> GO TO 2. NG >> Repair the terminals and connectors.
2. LCU INSPECTION Replace the malfunctioning LCU with a known-good one, and carry out the communication diagnosis. Refer to " «COMMUNICATION DIAGNOSIS»(ref-181226-S35327960072005080200000) ". OK or NG? OK >> Replace LCU NG >> Perform the following. Repair or replace communication harness between LCU and BCM. Replace with the previously installed LCU.

1. HARNESS CONNECTOR INSPECTION Check the terminals (at the control unit and harness) on BCM and LCU for disconnection, bend, poor connection, and other malfunctions. OK or NG? OK >> GO TO 2. NG >> Repair the terminals and connectors.
2. BCM INSPECTION Replace the malfunctioning BCM with a known-good one, and carry out the communication diagnosis. Refer to " «COMMUNICATION DIAGNOSIS»(ref-181226-S35327960072005080200000) ". OK or NG? OK >> Replace BCM NG >> Perform the following. Repair or replace communication harness between LCU and BCM control. Replace with the previously installed BCM.

SWITCH MONITOR

Carry out the diagnosis for the switch system input to each control unit.

Scheme 179

Scheme 180

1. Detects the status change (switch ON/OFF operation) of the switch to be checked, and turns on/off the indicator lamps (the map lamp and step lamp). Also sounds the buzzer (the key remainder and light remainder) for 0.5 seconds.
2. If a malfunction is detected, no indicator lamp and buzzer react.

Scheme 181

1. The status of the switch (except the ignition switch, interior lamp switch, and map lamp switch) input to each control unit can be monitored.

Cancel of Switch Monitor

If one of the following conditions are satisfied, the switch monitor is cancelled.

1. When the ignition switch is turned OFF.
2. The vehicle speed becomes 7 km/h (4 MPH) or higher.

Scheme 182

1. Check the operations of the auto drive positioner system.

Scheme 183

1. The malfunctioning items are indicated by how many times LEDs on the seat memory switches 1 and 2 flash simultaneously.
2. If the vehicle speed is less than 7 km/h (4 MPH) for 15 seconds after the diagnosis for the seat and steering wheel systems were completed, the vehicle speed signal is judged malfunctioning.
3. If LH door mirror is malfunctioning, only indicator lamp on the memory switch 1 flashes, and if RH door mirror is malfunctioning, only indicator lamp on the memory switch 2 flashes.
4. When all the diagnosis are finished normally, the indicator lamps on the memory switches 1 and 2 go off after the vehicle speed signal diagnosis.
5. If there are multiple malfunctioning parts, the lamps indicate them in sequence from the smallest diagnosis trouble code.
6. The diagnosis results repeat until the diagnosis mode is cancelled.

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

1. FUNCTION INSPECTION With CONSULT-II Check the operation on "MIR CHNG SW-R" or "MIR CHNG SW-L" in the DATA MONITOR. Refer to " «DATA MONITOR»(ref-181226-S06924703992005080200000) ". Without CONSULT-II Carry out the switch monitor in the self-diagnostic function. Refer to " «SWITCH MONITOR»(ref-181226-S36795501752005080200000) ". OK or NG? OK >> Door mirror remote control switch (changeover switch) circuit is OK. NG >> GO TO 2.
2. DOOR MIRROR REMOTE CONTROL SWITCH (CHANGEOVER SWITCH) INSPECTION Turn ignition switch OFF. Disconnect door mirror remote control switch connector. Check continuity between door mirror remote control switch terminal 5 (RH), 6 (LH) and 7. Changeover switch RIGHT position 5 - 7 : Continuity should exist. Changeover switch LEFT position 6 - 7 : Continuity should exist. OK or NG? OK >> GO TO 3. NG >> Replace malfunction door mirror remote control switch.
3. HARNESS CONTINUITY INSPECTION Disconnect the BCM connector. Check continuity between BCM connector M4 terminals 21, 24 and door mirror remote control switch connector M19 terminals 5, 6. 21 (SB) - 5 (SB) : Continuity should exist. 24 (BR/Y) - 6 (BR/Y) : Continuity should exist. Check continuity between BCM connector M4 terminals 21, 24 and ground. 21 (SB) - Ground : Continuity should not exist. 24 (BR/Y) - Ground :Continuity should not exist. OK or NG? OK >> GO TO 4 NG >> Repair or replace harness.
4. GROUND CIRCUIT INSPECTION OF DOOR MIRROR REMOTE CONTROL SWITCH Check continuity between the door mirror remote control switch connector M19 terminal 7 and ground. 7 (B) - Ground : Continuity should exist. OK or NG? OK >> Check connector for damage or loose connection. NG >> Repair or replace harness.

Scheme 189

Scheme 190

1. CHECK THE SYMPTOM Check that other systems using the reverse signal are under normal operation. Whether back-up lamp lights is checked. OK or NG? OK >> GO TO 2. NG >> Refer to "VEHICLE DOES NOT CREEP BACKWARD IN "R" Position ".
2. FUNCTION INSPECTION With CONSULT-II Check the operation on "R POSITION SW" in the DATA MONITOR. Refer to " «DATA MONITOR»(ref-181226-S06924703992005080200000) ". Without CONSULT-II Carry out switch monitor in self-diagnostic function. Refer to " «SWITCH MONITOR»(ref-181226-S36795501752005080200000) ". GO or NG? OK >> System is OK. NG >> GO TO 3.
3. HARNESS CONTINUITY INSPECTION Turn ignition switch OFF. Disconnect the BCM and back-up lamp relay connector. Check continuity between BCM connector B4 terminal 141 and back-up lamp relay connector E2-2 terminal 3. 141 (R/B) - 3 (R/B) : Continuity should exist. Check continuity between BCM connector B4 terminal 141 and ground. 141 (R/B) - Ground : Continuity should not exist. OK or NG? OK >> Replace BCM. NG >> Repair or replace harness.

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

1. DOOR MIRROR REMOTE CONTROL SWITCH(MIRROR SWITCH) SIGNAL INSPECTION With CONSULT-II Check the operation on "MIR CON SW-UP/DN" and "MIR CON SW-RH/LH" in the DATA MONITOR. Refer to " «DATA MONITOR»(ref-181226-S06924703992005080200000) ". Without CONSULT-II Carry out the switch monitor in the self-diagnostic function. Refer to GW- 104, "SWITCH MONITOR" OK or NG? OK >> Door mirror remote control switch (mirror switch) circuit is OK. NG >> GO TO 2.
2. DOOR MIRROR REMOTE CONTROL SWITCH (MIRROR SWITCH) INSPECTION Turn ignition switch OFF. Disconnect door mirror remote control switch connector. Check continuity between door remote control switch (mirror switch) terminals 1, 2, 3, 4 and 7. OK or NG? OK >> GO TO 3. NG >> Replace the door mirror remote control switch.
3. GROUND CIRCUIT INSPECTION OF DOOR MIRROR REMOTE CONTROL SWITCH Check continuity between the door mirror remote control switch connector M19 terminal 7 and ground. 7 - Ground : Continuity should exist. OK or NG? OK >> GO TO 4. NG >> Repair or replace harness
4. HARNESS CONTINUITY INSPECTION Disconnect BCM harness connector. Check continuity between BCM connector M4 terminals 25, 29, 32, 34 and door mirror remote control switch connector M19 terminals 1, 2, 3, 4. 25 (G/R) - 2 (G/R) : Continuity should exist. 29 (LG/R) - 1 (LG/R) : Continuity should exist. 32 (L/W) - 3 (L/W) : Continuity should exist. 34 (P/L) - 4 (P/L) : Continuity should exist. Check continuity between BCM connector M4 terminals 25, 29, 32, 34 and ground. 25 (G/R) - Ground : Continuity should not exist. 29 (LG/R) - Ground : Continuity should not exist. 32 (L/W) - Ground : Continuity should not exist. 34 (P/L) - Ground : Continuity should not exist. OK or NG? OK >> Check connector for damage or loose connection. NG >> Repair or replace harness between BCM and door mirror remote control switch.

Scheme 196

Scheme 197

Scheme 198

Scheme 199

1. DOOR MIRROR FUNCTION INSPECTION Check the following items. Operation malfunction caused by a foreign object caught in door mirror face edge. OK or NG? OK >> GO TO 2. NG >> Repair the malfunctioning parts, and check the symptom again.
2. MIRROR MOTOR INSPECTION With CONSULT-II Check the operation with "MIRROR MOTOR RH" or "MIRROR MOTOR LH" in the ACTIVE TEST. Refer to " «ACTIVE TEST»(ref-181226-S11695419052005080200000) ". NOTE: If CONSULT-II is not available, skip this procedure and go to the next step. OK or NG? OK >> System is OK. NG >> GO TO 3.
3. HARNESS CONTINUITY INSPECTION Turn ignition switch OFF. Disconnect door mirror control unit D5 (driver side), D35 (passenger side) and door mirror connector D2 (driver side), D32 (passenger side) connectors. Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminals 3, 4, 9 and door mirror connector D2 (driver side), D32 (passenger side) terminals 8, 9, 11. 3 (GY/R)(R)* - 8 (GY/R)(R)* : Continuity should exist. 4 (BR) - 9 (BR) : Continuity should exist. 9 (PU/W) (OR)*-11 (PU/W) (OR)* : Continuity should exist. Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminals 3, 4, 9 and ground. 3 (GY/R) (R)*-Ground : Continuity should not exist. 4 (BR) - Ground : Continuity should not exist. 9 (PU/W) (OR)* - Ground : Continuity should not exist. * :Wire color for passenger side door mirror and passenger side door mirror control unit. OK or NG? OK >> GO TO 4. NG >> Repair or replace harness between door mirror control unit and door mirror.
4. MIRROR MOTOR SIGNAL INSPECTION Connect door mirror control unit D5 (driver side), D35 (passenger side) and door mirror connector D2 (driver side), D32 (passenger side) connectors. Turn ignition switch ON. Check voltage between door mirror control unit connector D5 (driver side), D35 (passenger side) terminals 3, 4, 9 and ground. OK or NG? OK >> Replace the door mirror motor (driver side) or (passenger side). NG >> Replace the door mirror control unit (driver side) or (passenger side).

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

1. DOOR MIRROR FUNCTION INSPECTION Check the following items. Operation malfunction caused by a foreign object caught in door mirror face edge. Operation malfunction in memory control NOTE: If a door mirror face position is set to an implausible angle, the set position may not be reproduced. OK or NG? OK >> GO TO 2. NG >> Repair the malfunctioning parts, and check the symptom again.
2. MIRROR SENSOR INSPECTION With CONSULT-II Check that "ON" is displayed on "MIR/SE RH R-L ", "MIR/ SE RH U-D" or MIR/SE LH R-L ", "MIR/SE LH U-D" in the DATA MONITOR. Refer to , " «DATA MONITOR»(ref-181226-S06924703992005080200000) ". Without CONSULT-II GO TO 3. Question OK >> System is OK. NG >> GO TO 3.
3. MIRROR SENSOR POWER SUPPLY INSPECTION Turn ignition switch ON. Check voltage between door mirror control unit connector D5 (driver side), D35 (passenger side) terminal 1 and ground. 1 (W/L) - Ground : Approx. 5V OK or NG OK >> GO TO 4 NG >> Replace door mirror control unit.
4. MIRROR SENSOR GROUND CIRCUIT INSPECTION Turn ignition switch OFF. Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminal 2 and ground. 2 (Y) - Ground : Continuity should exist. OK or NG OK >> GO TO 5 NG >> Replace door mirror control unit.
5. HARNESS CONTINUITY INSPECTION 1 Disconnect door mirror control unit connector D5 (driver side), D35 (passenger side) and door mirror connector D2 (driver side), D32 (passenger side). Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminal 1, 2 and door mirror connector D2 (driver side), D32 (passenger side) terminal 10, 16. 1 (W/L) - 16 (W/L) : Continuity should exist. 2 (Y) - 10 (Y) : Continuity should exist. OK or NG OK >> GO TO 6 NG >> Repair or replace harness.
6. HARNESS CONTINUITY INSPECTION 2 Disconnect door mirror control unit connector D5 (driver side), D35 (passenger side) and door mirror connector D2 (driver side), D32 (passenger side). Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminals 5, 6 and door mirror connector D2 (driver side) D32 (passenger side) terminals 12, 14. 5 (L/Y) - 14 (L/Y) : Continuity should exist. 6 (G) - 12 (G) : Continuity should exist. Check continuity between door mirror control unit connector D5 (driver side), D35 (passenger side) terminals 5, 6 and ground. 5 (L/Y) - Ground : Continuity should not exist. 6 (G) - Ground : Continuity should not exist. OK or NG? OK >> GO TO 7. NG >> Repair or replace harness.
7. MIRROR SENSOR SIGNAL INSPECTION Connect door mirror control unit D5 (driver side), D35 (passenger side) and door mirror D2 (driver side), D32 (passenger side) connectors. Turn ignition switch ON. Check voltage between door mirror control unit connector D5 (driver side), D35 (passenger side) terminals 5, 6and ground. OK or NG? OK >> Replace the door mirror control unit. NG >> Replace the door mirror.
