CAN: Overview Infiniti M45 II

Communication Devices 17 illustrations ~581 words

System Description

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Go to CAN system, when selecting your CAN system type from the following table.

Scheme 27

Scheme 27: CAN Communication Unit

Scheme 28

Scheme 28: TYPE 1

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31: TYPE 2

Scheme 32

Scheme 32

Scheme 33

Scheme 33

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 34

Scheme 34: Component Parts and Harness Connector Location

Scheme 35

Scheme 35: Wiring Diagram - CAN

Scheme 36

Scheme 36

Scheme 37

Scheme 37: Work Flow

Scheme 38

Scheme 38
  1. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "VDC", and "A/T" displayed on CONSULT-II.
  2. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "VDC", and "A/T" displayed on CONSULT-II.
  3. Attach the printed sheet of "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to " «CHECK SHEET»(ref-181251-S25115705952005080300000) ".
  4. Based on the "CAN DIAG SUPPORT MNTR" results, put marks "v" onto the items with "NG" or "UNKWN" in the check sheet table. Refer to " «CHECK SHEET»(ref-181251-S25115705952005080300000) ". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
  5. According to the check sheet results (example), start inspection. Refer to " «CHECK SHEET RESULTS (EXAMPLE)»(ref-181251-S36212871612005080300000) ".

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 39

Scheme 39: Component Parts and Harness Connector Location

Scheme 40

Scheme 40: Wiring Diagram - CAN

Scheme 41

Scheme 41

Scheme 42

Scheme 42: Work Flow

Scheme 43

Scheme 43
  1. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "VDC", "ICC", and "A/T" displayed on CONSULT-II.
  2. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "VDC", "ICC", and "A/T" displayed on CONSULT-II.
  3. Attach the printed sheet of "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to " «CHECK SHEET»(ref-181251-S34297523132005080300000) ".
  4. Based on the "CAN DIAG SUPPORT MNTR" results, put marks "v" onto the items with "NG" or "UNKWN" in the check sheet table. Refer to " «CHECK SHEET»(ref-181251-S34297523132005080300000) ". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
  5. According to the check sheet results (example), start inspection. Refer to " «CHECK SHEET RESULTS (EXAMPLE)»(ref-181251-S35650256002005080300000) ".
