Parts Requiring Angle Tightening
- Use angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts: Cylinder head bolts Main bearing cap bolts Main bearing cap sub bolts Connecting rod cap bolts Crankshaft pulley bolt (No angle wrench is required as the bolt flange is provided with notches for angle tightening)
- Ensure thread and seat surfaces are clean and coated with engine oil.
GENERAL SPECIFICATIONS
Cylinder arrangement V-8 Displacement cm 3 (cu in) 5, 552 (338.8) Bore and stroke mm (in) 98 x 92 (3.858 x 3.622) Valve arrangement DOHC Firing order 1-8-7-3-6-5-4-2 Number of piston rings Compression 2 Oil 1 Number of main bearings 5 Compression ratio 11.5 Compression pressure kPa (kg/cm 2 , psi)/200 rpm Standard 1, 667 (17, 242) Minimum 1, 422 (14.5, 206) Differential limit between cylinders 98 (1.0, 14) Cylinder number
Scheme 315
| Unit: degree | ||
|---|---|---|
| Valve timing | Intake valve open (BTDC) | (-63) - (+ 33) |
| Intake valve close (ABDC) | (-55) - (+ 74) | |
| Exhaust valve open (BBDC) | 32 - 62 | |
| Exhaust valve close (ATDC) | 2 - 32 | |
