REAR SUNSHADE SYSTEM: Component Description
| Component parts | Description |
|---|
| Rear sunshade assembly | Rear sunshade control unit | Rear sunshade control unit is installed to rear sunshade assembly. Controls rear sunshade system by rear sunshade control unit. |
| Rear sunshade motor | Rear sunshade motor is installed to rear sunshade assembly. Rear sunshade motor is activated with rear sunshade control unit. |
| Rear sunshade switch | Rear sunshade switch is integrated in heated steering wheel switch (with heated steering wheel). Operates rear sunshade motor and opens or closes rear sunshade, according to rear sunshade switch operation. |
| Back up lamp relay | The reverse signal is transmitted to rear sunshade control unit. |
Scheme 53
Scheme 53: REAR SUNSHADE SYSTEM: System Diagram
REAR SUNSHADE SYSTEM: System Description
- Rear sunshade switch signal is transmitted to rear sunshade control unit when rear sunshade switch is operated.
- Rear sunshade control unit operates rear sunshade motor and opens or closes rear sunshade.
- Reverse signal is transmitted to rear sunshade control unit and rear sunshade is operated to the fully open position, when A/T shift selector is shifted to the R position while rear sunshade is in the closed position.
- When rear sunshade reaches fully open or closed position or its operation is interrupted by an obstacle, rear sunshade control unit detects overload of rear sunshade motor, interrupts power supply, and stops the operation.
Scheme 54
Scheme 54: TERMINAL LAYOUT
