AV COMMUNICATION SYSTEM
- Do not apply voltage of 7.0 V or higher to the measurement terminals.
- Use the tester with its open terminal voltage being 7.0 V or less.
- Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before checking the circuit.
Scheme 27
Scheme 28
- Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).]
- Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of twisted line will be lost.)
Commercial Service Tools
Tool Description Power tool Loosening screws
Scheme 29
Scheme 30
COMMUNICATION SIGNAL
- AV control unit function by transmitting/receiving data one by one with each unit (slave unit) that configures them completely as a master unit by connecting between units that configure MULTI AV system with two AV communication lines (H, L).
- Two AV communication lines (H, L) adopt a twisted pair line that is resistant to noise.
- The AV control unit is connected by CAN communication, and it receives data signal from ECM and combination meter. It computes and displays fuel economy information value with the obtained information.
- The AV control unit is connected with display unit and serial communication, and it transmits the required signal of display and display control and receives the response signal from display unit.
- The AV control unit is receives a steering angle signal from the steering angle sensor via CAN communication and controls an expected course line during rear view monitor operation.
AUDIO FUNCTION
The audio system is equipped with the following functions. Each function is operated with multifunction switch, preset switch or steering switch. Operation status of audio is indicated at display unit.
| FUNCTION |
|---|
| AM/FM radio |
| Satellite radio |
| CD |
| USB connection function |
| Active noise control system |
Operating Signal
Audio system operation can be performed with multifunction switch, preset switch or steering switch.
- Operating signal is transmitted to AV control unit with AV communication when it is operated by multifunction switch or preset switch. The disk ejection operating signal is performed by hardwire.
- Operating signal is transmitted to AV control unit with steering switch signal when it is operated by steering switch.
Screen Display
- Switching of display is performed with serial communication between display unit and AV control unit.
- The image signal to display operating condition is performed with RGB image signal, RGB area signal and RGB image synchronizing signal.
AM/FM Radio Mode
- AM/FM radio tuner is built into AV control unit.
- Sound signals (AM/FM radio) are received via window antenna.
- AM/FM main antenna signal is amplified via antenna amp. and FM sub antenna signal is transmitted to AV control unit.
- AV control unit outputs sound signal is input to active noise control unit, and active noise control unit outputs to each speaker.
Satellite Radio Mode
- Satellite radio tuner is controlled by communication signal and request signal with AV control unit.
- Sound signal (satellite radio) is received by satellite radio antenna and transmitted to AV control unit via satellite radio tuner. AV control unit is output the sound signal (satellite radio) to active noise control unit.
CD Mode
- CD function is built into AV control unit.
- AV control unit outputs the sound signal to active noise control unit, and active noise control unit output the signal to each speaker during playback.
USB Connection Function
- Connecting iPod® or USB memory allows the driver to play iPod® music files or USB memory-stored music files.
- Sound signals of music files stored in iPod® or USB memory is transmitted from the USB connector to the AV control unit. The AV control unit transmits the sound signals to the each speaker via active noise control unit.
- iPod® is recharged when connected to USB connector.
- Only files that meet the following conditions will be played.
| Music file | |
|---|---|
| File format | "MP3", "WMA" |
| File extension | ".mp3", ".wma" |
| Maximum file size | 2 GB |
Note. iPod® is a trademark of Apple inc., registered in the U.S. and other countries. Image signals cannot be received from iPod® or USB memory. Use the enclosed USB harness when connecting iPod® to USB connector.
Active Noise Control System
Scheme 31
- The active noise control system outputs an antiphase sound from the speakers (front door speaker and rear door speaker) against unpleasant engine booming noise (2nd and/or 3rd engine rev at 700 - 5000 rpm) and reduce sound pressure level by the interference with engine booming noise.
- The active noise control unit receives an engine speed signal from ECM and receives microphone signals from the front and rear microphone.
- The active noise control unit receives a door state signal. The active noise control system does not operate with any door open.
- Based on signals detected by the front and rear microphones, the active noise control unit generates an antiphase sound (microphone signal) weakening interior engine booming noise in real time according to a unique algorithm*1 by a micro computer built in the active noise control unit. Then, the active noise control unit mixes the antiphase sound with a sound signal received from the AV control unit to transmit the mixed sound signal to each speaker. NOTE: *1: Algorithm means a fixed procedure to solve a question.
HANDS-FREE PHONE SYSTEM
- TEL adapter unit is controlled with AV communication from AV control unit.
- The connection between cellular phone and TEL adapter unit is performed with Bluetooth™ communication.
- The voice guidance signal is input from the TEL adapter unit to the AV control unit and output to the front speaker when operating the cellular phone.
- TEL adapter unit has the on board self-diagnosis function. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-573615-S30024148092013082200000) ".
When A Call Is Originated
- Spoken voice sound output from the microphone (microphone signal) is input to TEL adapter unit.
- TEL adapter unit outputs to cellular phone with Bluetooth™ communication as a TEL voice signal.
- Voice sound is then heard at the other party.
When Receiving A Call
- Voice sound is input to own cellular phone from the other party.
- TEL voice signal is input to TEL adapter unit by establishing Bluetooth™ communication from cellular phone, and the signal is output to front speaker.
REAR VIEW MONITOR FUNCTION
- The AV control unit supplies power to the rear view camera when receiving a reverse signal.
- The rear view camera transmits camera images to the AV control unit when power is supplied from the AV control unit.
- The AV control unit transmits a warning message, fixed guide lines, and predictive course lines to the display unit by RGB image signal. Rear view monitor images are displayed by combining the RGB image signal and the camera image signals from the rear view camera.
- Predictive course lines are controlled by a steering angle sensor signal received the AV control unit via CAN communication.
VEHICLE INFORMATION FUNCTION
Status of audio, climate control system, fuel economy and maintenance etc. are displayed.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and the signals recognized by the system.
Scheme 32
| Diagnosis item | Display | Vehicle status | Remarks |
|---|---|---|---|
| Vehicle speed | ON | Vehicle speed > 0 km/h (0 MPH) | Changes in indication may be delayed. This is normal. |
| OFF | Vehicle speed = 0 km/h (0 MPH) | ||
| Parking brake | ON | Parking brake is applied. | |
| OFF | Parking brake is released. | ||
| Lights | ON | Light switch ON | |
| OFF | Light switch OFF | ||
| Ignition | ON | Ignition switch ON | |
| OFF | Ignition switch in ACC position | ||
| Reverse | ON | Shift the selector lever to "R" position | Changes in indication may be delayed. This is normal. |
| OFF | Shift the selector lever other than "R" position |
Climate Control
Refer to " HEATER & AIR CONDITIONING CONTROL SYSTEM (AUTOMATIC AIR CONDITIONING) " for details.
Error History
The self-diagnosis results are judged depending on whether any error occurs from when "Self-diagnosis" is selected until the self-diagnosis results are displayed.
However, the diagnosis results are judged normal if an error has occurred before the ignition switch is turned ON and then no error has occurred until the self-diagnosis start. Check the "Error Record" to detect any error that may have occurred before the self-diagnosis start because of this situation.
The frequency of occurrence is displayed in a count up manner. The actual count up method differs depending on the error item.
Count up method A
- The counter resets to 0 if an error occurs when ignition switch is turned ON. The counter increases by 1 if the condition is normal at a next ignition ON cycle.
- The counter upper limit is 39. Any counts exceeding 39 are ignored." The counter can be reset (no error record display) with the "Delete log" switch or CONSULT.
Count up method B
- The counter increases by 1 if an error occurs when ignition switch is ON. The counter will not decrease even if the condition is normal at the next ignition ON cycle.
- The counter upper limit is 50. Any counts exceeding 50 are ignored. "The counter can be reset (no error record display) with the "Delete log" switch or CONSULT.
| Display type of occurrence frequency | Error history display item |
|---|---|
| Count up method A | CAN communication line, control unit (CAN), AV communication line, control unit (AV) |
| Count up method B | Other than the above |
Scheme 33
Error item
Some error items may be displayed simultaneously according to the cause. If some error items are displayed simultaneously, the detection of the cause can be performed by the combination of display items
| Error item | Description | Possible malfunction factor/Action to take |
|---|---|---|
| CAN COMM CIRCUIT | CAN communication malfunction is detected. | Perform diagnosis with CONSULT, and then repair the malfunctioning parts according to the diagnosis results. Refer to " CONSULT FUNCTION ". |
| CONTROL UNIT (CAN) | CAN initial diagnosis malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ". |
| CONTROL UNIT (AV) | AV communication circuit initial diagnosis malfunction is detected. | |
| FLASH-ROM Error Of Control Unit | AV control unit malfunction is detected. | |
| CAN Controller Memory Error | ||
| Steer. Angle Sensor Calibration | Predictive course line center position adjustment of the steering angle sensor is incomplete. | Adjust the predictive course line center position of the steering angle sensor. Refer to " WORK PROCEDURE ". |
| Front Display Connection Error | When either one of the following items is detected: display unit power supply and ground circuits are malfunctioning. communication circuits between AV control unit and display unit are malfunctioning. | Display unit power supply and ground circuits. Refer to " DISPLAY UNIT: DIAGNOSIS PROCEDURE ". Communication circuits between AV control unit and display unit. |
| XM Connection Error | When either one of the following items is detected: satellite radio tuner power supply and ground circuit are malfunctioning. communication circuits between AV control unit and satellite radio tuner are malfunctioning. request signal circuit between AV control unit and satellite radio tuner are malfunctioning. | Satellite radio tuner power supply and ground circuit. Refer to " SATELLITE RADIO TUNER: DIAGNOSIS PROCEDURE ". Communication circuit between AV control unit and satellite radio tuner. Request signal circuit between AV control unit and satellite radio tuner. |
| AV COMM CIRCUIT Switches Connection Error | When either one of the following items is detected: multifunction switch power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and multifunction switch are malfunctioning. | Multifunction switch power supply and ground circuits. AV communication circuits between AV control unit and multifunction switch. |
| AV COMM CIRCUIT H/F Unit Connection Error | When either one of the following items is detected: TEL adapter unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and TEL adapter unit are malfunctioning. | TEL adapter unit power supply and ground circuits. Refer to " TEL ADAPTER UNIT: DIAGNOSIS PROCEDURE ". AV communication circuits between AV control unit and TEL adapter unit. |
| AV COMM CIRCUIT Switches Connection Error H/F Unit Connection Error | Malfunction is detected in AV communication circuits between AV control unit and multifunction switch are malfunctioning. | AV communication circuits between AV control unit and multifunction switch. |
Camera Cont.
The two functions of "Correct Draw Line of Rear view Cam", "Confirm Configuration" are available.
Scheme 34
Scheme 35
- Use this mode to adjust the guide line display position of the rear view monitor if necessary after removing the rear view monitor camera. CAUTION: After the adjustment, never perform other operations for one minute.
Scheme 36
- Configuration stored in the AV control unit can be checked.
Delete Unit Connection Log
Deletes any unit connection records and error records from the AV control unit memory. (Clear the records of the unit that has been removed.)
Scheme 37
Initialize Settings
"User Data Initialization" and "Accessory Number Initialization" are possible.
| CAUTION | Never perform Accessory Number Initialization except when configuration is unsuccessful. Accessory Number Initialization requires configuration. For details, refer to " DESCRIPTION ". |
Scheme 38
CONSULT FUNCTIONS
CONSULT performs the following functions via the communication with the AV control unit.
| Diagnosis mode | Description |
|---|---|
| ECU Identification | The part number of AV control unit can be checked. |
| Self Diagnostic Result | Performs a diagnosis on the AV control unit and a connection diagnosis for the communication circuit of the Multi AV system, and displays the current and past malfunctions collectively. |
| Data Monitor | The diagnosis of vehicle signal that is input to the AV control unit can be performed. |
| Work Support | Steering angle sensor can be adjusted. |
| Configuration | Read and save the vehicle specification. Write the vehicle specification when replacing AV control unit. |
AV Communication
When "AV communication" of "CAN Diag Support Monitor" is selected, the following function will be performed.
| AV communication | AV&NAVI C/U | Displays the communication status from AV control unit to each unit as well as the error counter. |
|---|---|---|
| AUDIO | Displays the AV control unit communication status and the error counter. |
ALL SIGNALS
- Displays the status of the following vehicle signals inputted into the AV control unit.
- For each signal, actual signal can be compared with the condition recognized on the system.
| Display Item | Display | Vehicle status | Remarks |
|---|---|---|---|
| VHCL SPD SIG | On | Vehicle speed > 0 km/h (0 MPH) | Changes in indication may be delayed. This is normal. |
| Off | Vehicle speed = 0 km/h (0 MPH) | ||
| PKB SIG | On | Parking brake is applied. | |
| Off | Parking brake is released. | ||
| ILLUM SIG | On | Block the light beam from the auto light optical sensor when the light SW is ON. | |
| Off | Expose the auto light optical sensor to light when the light SW is OFF or ON. | ||
| IGN SIG | On | Ignition switch ON | |
| Off | Ignition switch in ACC position | ||
| REV SIG | On | Selector lever in R position | Changes in indication may be delayed. This is normal. |
| Off | Selector lever in any position other than R |
Allows the technician to select which vehicle signals should be displayed and displays the status of the selected vehicle signals.
| Item to be selected | Description |
|---|---|
| VHCL SPD SIG | The same as when "ALL SIGNALS" is selected. |
| PKB SIG | |
| ILLUM SIG | |
| IGN SIG | |
| REV SIG |
WORK SUPPORT
Adjusts the neutral position of the steering angle sensor.
| CAUTION | For vehicles with VDC, adjust the steering angle sensor neutral position on the ABS actuator control unit side. Refer to " WORK PROCEDURE ". |
| Item | Description |
|---|---|
| ST ANGLE SENSOR ADJUSTMENT | Adjusts the neutral position of the steering angle sensor. |
CONFIGURATION
Configuration has three functions as follows.
| Function | Description | |
|---|---|---|
| Read/Write Configuration | Before Replace ECU | Allows the reading of vehicle specification written in AV control unit to store the specification in CONSULT. |
| After Replace ECU | Allows the writing of the vehicle information stored in CONSULT into the AV control unit. | |
| Manual Configuration | Allows the writing of the vehicle specification into the AV control unit by hand. | |
METHOD OF STARTING
Perform Self-diagnosis, according to the following steps
Scheme 39
- When a sound is not outputted from the speakers as a result of the preparation, check the AV control unit, active noise control unit, connector connections, or speakers.
- When Self-diagnosis mode does not start at Step 1, check the door state signal circuit.
- When a malfunction is detected in the microphone at Step 8, check the signal circuit of each microphone.
- When an error is detected in an engine speed signal at Step 10, check the engine speed signal circuit.
The Details of Error Count
The error count guides "0" when the error occurs. The next time it counts up "1" if it is normal with the ignition switch ON. It continues the count up unless the initialization of hands-free phone system is performed.
Scheme 40
PHYSICAL VALUES
Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 2 (G) 3 (L) Sound signal front LH Output Ignition switch ON Sound output 4 (GR) 5 (G) Sound signal rear LH Output Ignition switch ON Sound output 6 (P) 15 (B) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch. 0 V Keep pressing MENU UP switch. 0.7 V Keep pressing MENU DOWN switch. 1.3 V Keep pressing switch 2.0 V Except for above. 3.3 V 7 (V) Ground ACC power supply Input Ignition switch ACC - Battery voltage 9 (SB) Ground Illumination signal Input Ignition switch OFF Lighting switch is OFF. 0 V Lighting switch is ON. 12.0 V 11 (BR) 12 (R) Sound signal front RH Output Ignition switch ON Sound output 13 (P) 14 (V) Sound signal rear RH Output Ignition switch ON Sound output 16 (L) 15 (B) Steering switch signal B Input Ignition switch ON Keep pressing VOL DOWN switch. 0 V Keep pressing VOL UP switch. 0.7 V Keep pressing switch. 1.3 V Except for above. 3.3 V 19 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 20 (B) Ground Ground - Ignition switch ON - 0 V 36 (BG) Ground Signal VCC Output Ignition switch ACC - 9.0 V 37 (B) Ground Signal ground - Ignition switch OFF - 0 V 38 (G) Ground Horizontal synchronizing (HP) signal Input Ignition switch ON - 39 (Y) Ground Communication signal (DISP-->CONT) Input Ignition switch ON When adjusting display brightness. 40 (R) Ground RGB area (YS) signal Output Ignition switch ON At RGB image is displayed. 5.0 V At DVD image is displayed. 41 - Shield - - - - 42 (W) Ground RGB synchronizing signal Output Ignition switch ON - 43 (R) Ground RGB signal (R: red) Output Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. 44 (B) Ground RGB signal (G: green) Output Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. 45 (W) Ground RGB signal (B: blue) Output Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. 46 (V) Ground Composite image ground - Ignition switch ON - 0 V 47 (SB) Ground Composite image signal Output Ignition switch ON At rear camera image is displayed. 48 (L) Ground Inverter VCC Output Ignition switch ACC - 9.0 V 49 (LG) Ground Inverter ground - Ignition switch OFF - 0 V 50 (B) Ground Vertical synchronizing (VP) signal Input Ignition switch ON - 51 (BR) Ground Communication signal (CONT-->DISP) Output Ignition switch ON When adjusting display brightness. 52 - Shield - - - - 57 - Shield - - - - 58 - Shield - - - - 62 (W) Ground Camera image signal Input Ignition switch ON At rear camera image is displayed. 71 - Shield - - - - 72 (B) Ground Camera ground - Ignition switch ON - 0 V 73 (W) Ground Camera power supply Output Ignition switch ON At rear camera image is displayed. 6.0 V 76 (LG) - AV communication signal (L) Input/Output - - - 77 (SB) - AV communication signal (H) Input/Output - - - 78 (SB) - AV communication signal (H) Input/Output - - - 79 (LG) - AV communication signal (L) Input/Output - - - 80 (P) - CAN-L Input/Output - - - 81 (L) - CAN-H Input/Output - - - 82 (BR) Ground Switch ground - Ignition switch ON - 0 V 86 - Shield - - - - 87 (P) 88 (L) TEL voice signal Input Ignition switch ON During voice guide output with the switch pressed. 92 (R) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 93 (V) Ground Parking brake signal Input Ignition switch ON Parking brake is ON. 0 V Parking brake is OFF. 94 (BG) Ground Reverse signal Input Ignition switch ON R position 12.0 V Other than R position 0 V 95 (W) Ground Ignition signal Input Ignition switch ON - Battery voltage 96 (SB) Ground Disk eject signal Input Ignition switch ON Pressing the eject switch. 0 V Except for above. 3.3 V 120 (B) 124 (W) Satellite radio sound signal LH Input Ignition switch ON When satellite radio mode is selected. 121 (G) 125 (R) Satellite radio sound signal RH Input Ignition switch ON When satellite radio mode is selected. 122 (O) Ground Communication signal (CONT-->SAT) Output Ignition switch ON When satellite radio mode is selected. 126 - Shield - - - - 127 - Shield - - - - 129 (Y) Ground Request signal (SAT-->CONT) Input Ignition switch ON When satellite radio mode is selected. 130 (BR) Ground Communication signal (SAT-->CONT) Input Ignition switch ON When satellite radio mode is selected. 132 (G) - USB ground - - - - 133 (W) - V BUS signal - - - - 134 (R) - USB D- signal - - - - 135 (L) - USB D+ signal - - - - 136 - Shield - - - - 137 Ground Antenna amp. ON signal Output Ignition switch ACC - 12.0 V 138 - AM-FM main Input - - - 139 - FM sub Input
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (B) Ground Ground - Ignition switch ON - 0 V 2 (L) Ground Inverter VCC Input Ignition switch ACC - 9.0 V 3 (BG) Ground Signal VCC Input Ignition switch ACC - 9.0 V 4 (V) Ground Composite image ground - Ignition switch ON - 0 V 5 - Shield - - - - 6 (B) Ground RGB signal (G: green) Input Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. 7 - Shield - - - - 8 (G) Ground Horizontal synchronizing (HP) signal Output Ignition switch ON - 9 (R) Ground RGB area (YS) signal Input Ignition switch ON At RGB image is displayed. 5.0 V At DVD image is displayed. 11 (BR) Ground Communication signal (CONT-->DISP) Input Ignition switch ON When adjusting display brightness. 13 (LG) Ground Inverter ground - Ignition switch ON - 0 V 14 (B) Ground Signal ground - Ignition switch ON - 0 V 15 (SB) Ground Composite image signal Input Ignition switch ON At rear camera image is displayed. 17 (R) Ground RGB signal (R: red) Input Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. 18 (W) Ground RGB signal (B: blue) Input Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. 19 (W) Ground RGB synchronizing signal Input Ignition switch ON - 20 (B) Ground Vertical synchronizing (VP) signal Output Ignition switch On - 21 - Shield - - - - 22 (Y) Ground Communication signal (DISP-->CONT) Output Ignition switch ON When adjusting display brightness. 23 - Shield
Scheme 48
Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (B/R) Ground Ground - Ignition switch OFF - 0 V 2 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 3 (Y) 12 (L) Sound signal front LH Input Ignition switch ON Sound output 4 (V) 13 (GR) Sound signal front RH Input Ignition switch ON Sound output 5 (LG) 14 (W) Sound signal rear LH Input Ignition switch ON Sound output 6 (O) 15 (SB) Sound signal rear RH Input Ignition switch ON Sound output 8 (W) 17 (B) Sound signal front door speaker LH Output Ignition switch ON Sound output 9 (B) 18 (W) Sound signal front door speaker RH Output Ignition switch ON Sound output 10 (G) 19 (R) Sound signal rear door speaker LH Output Ignition switch ON Sound output 11 (R) 20 (G) Sound signal rear door speaker RH Output Ignition switch ON Sound output 23 (Y) 31 (BR) Front microphone signal Input Ignition switch ON When inputting interior sound 24 (L) 32 (LG) Rear microphone signal Input Ignition switch ON When inputting interior sound 25 (P) Ground Step lamp signal Input Ignition switch ON When anything door open 0 V Ignition switch ON All doors are closed 12.0 V 27 (O) Ground Engine type signal Input Ignition switch ON - 0 V 33 (SB) Ground Engine speed output signal Input Ignition switch ON Idle speed 36 (V) Ground ACC power supply Input Ignition switch ACC - Battery voltage
Scheme 49
Scheme 50
Terminal Description Condition Reference value (Approx.) + - Signal name Input/Output 2 (R) 1 (G) Satellite radio sound signal LH Output Ignition switch ON When satellite radio mode is selected. 4 (B) 3 (W) Satellite radio sound signal RH Output Ignition switch ON When satellite radio mode is selected 5 - Shield - - - - 6 - Shield - - - - 8 (R) Ground Request signal (SAT-->CONT) Output Ignition switch ON When satellite radio mode is selected 9 (B) Ground Communication signal (SAT-->CONT) Output Ignition switch ON When satellite radio mode is selected 10 (W) Ground Communication signal (CONT-->SAT) Input Ignition switch ON When satellite radio mode is selected 12 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 16 (V) Ground ACC power supply Input Ignition switch ACC - Battery voltage 33 - Satellite radio antenna Input - - - 34 - Shield
Scheme 51
Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (LG) Ground Battery power supply Input Ignition switch OFF - Battery voltage 2 (L) Ground ACC power supply Input Ignition switch ACC - Battery voltage 3 (P) Ground Ignition signal Input Ignition switch ON - Battery voltage 4 (B/R) Ground Ground - Ignition switch ON - 0 V 7 (W/R) 8 Microphone signal Input Ignition switch ON Give a voice 9 (W/L) 10 (GR/V) TEL voice signal Output Ignition switch ON During voice guide output with the switch pressed 21 (B/R) Ground Control signal Input Ignition switch ON - 0 V 23 (B/R) Ground Control signal Input Ignition switch ON - 0 V 24 (B/R) Ground Control signal Input Ignition switch ON - 0 V 28 (W) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 29 (B/R) 8 Microphone VCC Output Ignition switch ON - 5.0 V 33 - TEL antenna Input - - - 34 - Shield - - - - 35 (GR) - AV communication signal (H) Input/Output - - - 36 (SB) - AV communication signal (L) Input/Output
DETAILED FLOW
- INTERVIEW AND SYMPTOM CONFIRMATION Check the malfunction symptoms by performing the following items. Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred). Check the symptom. Is the occurred symptom malfunction? YES: GO TO 2. NO: INSPECTION END
- DIAGNOSIS WITH CONSULT Connect CONSULT and perform a self-diagnosis for "MULTI AV". Refer to " «CONSULT FUNCTION»(ref-573615-S29208422672013082200000) ". NOTE: Skip to step 4 of the diagnosis procedure if "MULTI AV" is not displayed. When DTC is detected, follow the instructions below: Record DTC and Freeze Frame Data. Is DTC displayed? YES: GO TO 3. NO: GO TO 4 .
- TROUBLE DIAGNOSIS FOR DTC Check the DTC indicated in the "Self-Diagnosis Results". Perform the relevant diagnosis referring to the DTC Index. Refer to " «DTC INDEX»(ref-573615-S24246081632013082200000) ". : GO TO 5 .
- TROUBLE DIAGNOSIS FOR SYMPTOMS Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-573615-S41171724822013082200000) ". : GO TO 5.
- ERROR PART REPAIR Repair or replace the identified malfunctioning parts. Perform a self-diagnosis for "MULTI AV" with CONSULT. NOTE: Erase the stored self-diagnosis results after repairing or replacing the relevant components if any DTC has been indicated in the "Self-Diagnosis Results". Check that the symptom does not occur. Does the symptom occur? YES: GO TO 1 . NO: INSPECTION END
Work Procedure
- SAVING VEHICLE SPECIFICATION -CONSULT Configuration Perform "Before Replace ECU" to save or print current vehicle specification. Refer to " «DESCRIPTION»(ref-573615-S09657755382013082200000) ". NOTE: If "Before Replace ECU" can not be used, use the "Manual Configuration". : GO TO 2.
- REPLACE AV CONTROL UNIT Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573615-S41908307542013082200000) ". : GO TO 3.
- WRITING VEHICLE SPECIFICATION -CONSULT Configuration Perform "After Replace ECU" or "Manual Configuration" to write vehicle specification. Refer to " «WORK PROCEDURE»(ref-573615-S40263716482013082200000) ". : GO TO 4.
- OPERATION CHECK Check that the operation of the AV control unit and camera images (fixed guide lines and predictive course lines) are normal. : WORK END
- WRITE VEHICLE SPECIFICATION CONSULT Configuration Write vehicle specification into AV control unit. To write vehicle specification stored in CONSULT into the AV control unit: GO TO 2. To write vehicle specification into the AV control unit by hand: GO TO 3 .
- WRITE STORED DATA CONSULT Configuration Select "After Replace ECU" in "Read/Write Configuration." Write data stored in CONSULT with the "Before Replace ECU" function into the AV control unit. : GO TO 4 .
- MANUALLY WRITE VEHICLE SPECIFICATION CONSULT Configuration Perform "Manual Configuration." Refer to the «CONFIGURATION LIST»(ref-573615-S19406990852013082200000) to write vehicle specification into the AV control unit. Refer to " «CONFIGURATION LIST»(ref-573615-S19406990852013082200000) ". : GO TO 4.
- OPERATION CHECK Check that the operation of the AV control unit and camera images (fixed guide lines and predictive course lines) are normal. : WORK END
Configuration List
| CAUTION | Grasp vehicle specifications precisely. The control of ECU may not function normally if the specifications are misread. |
Note. The items shown in this list below depend on vehicle specifications. The config list may not be displayed depending on vehicle specifications. This is not a malfunction.
| MANUAL SETTING ITEM | |
|---|---|
| Items | Setting value |
| STEERING | LHD |
| RHD | |
| SOUND SYSTEM | BASE |
| BOSE | |
| ENGINE TYPE | NORMAL |
| HYBRID | |
Simple Check for Bluetooth™ Communication
If cellular phone and AV control unit cannot be connected with Bluetooth™ communication, following procedure allows the technician to judge which device has malfunction.
- Turn on a cellular phone, not connecting Bluetooth™ communication.
- Start CONSULT, then start Windows®.
- Set CONSULT near a cellular phone.
- When operated Bluetooth™ registration by cellular phone, check if CONSULT* would be displayed on the device name. (If other Bluetooth™ device is located near cellular phone, a name of the device would be displayed also.) NOTE: *: Displayed device name is "NISSAN-********".
Scheme 52
- If no device name is displayed, cellular phone is malfunctioning. Repair the cellular phone first, then perform diagnosis.
- If CONSULT is displayed on device name, cellular phone is normal. Perform diagnosis as per the following table.
| Symptoms | Check items | Possible malfunction location/Action to take |
|---|---|---|
| RGB image is not shown. | There is malfunction in the CONSULT self-diagnosis result. Refer to " CONSULT FUNCTION ". | Perform detected DTC diagnosis. Refer to " DTC INDEX ". |
| There is no malfunction in CONSULT self-diagnosis results. Refer to " CONSULT FUNCTION ". | Vertical synchronizing (VP) signal circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| Color of RGB image is not proper. | Light blue (Cyan) tint. | RGB signal (R: red) circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| Purple (Magenta) tint. | RGB signal (G: green) circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| Screen looks yellowish. | RGB signal (B: blue) circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| RGB screen is rolling. | RGB synchronizing signal circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| Symptoms | Check items | Possible malfunction location/Action to take |
|---|---|---|
| The disk cannot be removed. | Disk eject signal circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| No sound comes out. | No sound from all speakers. | Active noise control unit power supply and ground circuit malfunction. Refer to " ACTIVE NOISE CONTROL UNIT: DIAGNOSIS PROCEDURE ". AV control unit power supply and ground circuit malfunction. Refer to " AV CONTROL UNIT: DIAGNOSIS PROCEDURE ". |
| Only a certain speaker (front right, front left, rear right, or rear left) does not output sound. | Poor connector connection of speaker. Sound signal circuit of malfunctioning system between AV control unit and active noise control unit. Sound signal circuit of malfunctioning system between active noise control unit and speaker. Malfunction in speaker. Malfunction in AV control unit. Malfunction in active noise control unit. | |
| Noise is mixed with audio. | Noise comes out from all speakers. | Malfunction in active noise control unit. Malfunction in AV control unit. |
| Noise comes out only from a certain speaker (front right, front left, rear right, or rear left). | Poor connector connection of speaker. Sound signal circuit of malfunctioning system between AV control unit and active noise control unit. Sound signal circuit of malfunctioning system between active noise control unit and speaker. Malfunction in speaker. Poor installation of speaker (e.g. backlash and looseness). Malfunction in active noise control unit. Malfunction in AV control unit. | |
| Noise is mixed with radio only (when the car hits a bump or while driving over bad roads). | Poor connector connection of antenna or antenna feeder. | |
| Satellite radio is not received. | There is malfunction in the CONSULT self-diagnosis result. Refer to " CONSULT FUNCTION ". | Malfunction in antenna, antenna feeder, or AV control unit. Perform DTC diagnosis. Refer to " DTC INDEX ". Poor continuity in antenna feeder. Poor connector connection of antenna or antenna feeder. |
| There is malfunction in the CONSULT self-diagnosis result. Refer to " CONSULT FUNCTION ". | Poor continuity in antenna feeder. Poor connector connection of antenna or antenna feeder. Loose satellite radio antenna mounting nut. Refer to " EXPLODED VIEW ". | |
| The sound of satellite radio is not heard. | Other audio sounds are normal. | Satellite radio sound signal circuit between AV control unit and satellite radio tuner. |
| It does not change to satellite radio mode. | There is malfunction in the CONSULT self-diagnosis result. Refer to " CONSULT FUNCTION ". | Perform detected DTC diagnosis. Refer to " DTC INDEX ". |
| Radio is not received or poor reception. | Other audio sounds are normal. Any radio cannot be received or poor reception is caused even after moving to a service area with good reception (e.g. a place with clear view and no obstacles generating external noises). | Antenna amp. ON signal circuit malfunction. Poor connector connection of antenna or antenna feeder. |
Note. Check that there is no malfunction of USB equipment main body before performing a diagnosis.
| Symptoms | Check items | Possible malfunction location/Action to take |
|---|---|---|
| IPod® or USB memory can not be recognized. | USB harness malfunction. USB connector malfunction. |
iPod® is a trademark of Apple inc., registered in the U.S. and other countries.
| Symptoms | Probable malfunction location |
|---|---|
| None of the steering switch operations work. | Steering switch ground circuit malfunction. Refer to " DIAGNOSIS PROCEDURE ". |
| Only specified switch cannot be operated. | Check steering switch. Refer to " COMPONENT INSPECTION ". Malfunction is detected. Replace steering switch. Refer to " REMOVAL AND INSTALLATION ". |
| "SOURCE", "MENU UP", "MENU DOWN" and " " switches are not operated. | Steering switch signal A circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| "VOL UP", "VOL DOWN" and " " switches are not operated. | Steering switch signal B circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| Symptoms | Check items | Probable malfunction location |
|---|---|---|
| Camera image is not shown. (Vehicle width and possible route line is displayed.) | Camera image signal circuit. Refer to " DIAGNOSIS PROCEDURE ". Composite image signal circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| Camera image does not switch. | "Reverse" is not turned ON on "Vehicle Signals" screen of "Confirmation/Adjustment". | Reverse signal circuit malfunction. |
| "Reverse" is turned ON on "Vehicle Signals" screen of "Confirmation/Adjustment". | AV control unit malfunction. Replace AV control unit. Refer to " REMOVAL AND INSTALLATION ". |
TROUBLE DIAGNOSIS CHART BY SYMPTOM
The system should respond correctly to all voice commands without difficulty. If problems are encountered, try the following solutions.
Where the solutions are listed by number, try each solution in turn, starting with number 1, until the problem is resolved.
| Symptom | Solution |
|---|---|
| System fails to interpret the command correctly. | 1. Ensure that the command is valid. |
| 2. Ensure that the command is spoken after the tone. | |
| 3. Speak clearly without pausing between words and at level appropriate to the ambient noise level in the vehicle. | |
| 4. Ensure that the ambient noise level is not excessive (for example, windows open or defroster on). NOTE: If it is too noisy to use the phone, it is likely that the voice commands will not be recognized. | |
| 5. If more than one command was said at a time, try saying the commands separately. | |
| 6. If the system consistently fails to recognize commands, the voice training procedure should be carried out to improve the recognition response for the speaker. See "Speaker adaptation (SA) mode" earlier in this article. See ON BOARD DIAGNOSIS ITEM. Refer to "OWNER'S MANUAL". | |
| The system consistently selects the wrong voice tag | 1. Ensure that the phone book entry name requested matches what was originally stored. This can be confirmed by using the "List Names" command. |
| 2. Replace one of the names being confused with a new name. |
| NOTE |
|---|
| If it is too noisy to use the phone, it is likely that the voice commands will not be recognized. |
- The majority of the audio malfunctions are the result of outside causes (bad CD, electromagnetic interference, etc.). Check the symptoms below to diagnose the malfunction.
- The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning. Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and operation of each piece of electrical equipment, and then determine the cause.
Note. CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incorrectly mastered by the customer on a computer. Check if the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the "red book" Compact Disc Standard and may not play.
| Symptom | Cause and Counter measure |
|---|---|
| Cannot play | Check if the CD was inserted correctly. |
| Check if the CD is scratched or dirty. | |
| Check if there is condensation inside the player, and if there is, wait until the condensation is gone (about 1 hour) before using the player. | |
| If there is a temperature increase error, the player will play correctly after it returns to the normal temperature. | |
| If there is a mixture of music CD files (CD-DA data) and MP3/WMA files on a CD, only the music CD files (CD-DA data) will be played. | |
| Files with extensions other than ".MP3", ".WMA", ".mp3" or ".wma" cannot be played. In addition, the character codes and number of characters for folder names and file names should be in compliance with the specifications. | |
| Check if the disc or the file is generated in an irregular format, This may occur depending on the variation or the setting of MP3/WMA writing applications or other text editing applications. | |
| Check if the finalization process, such as session close and disc close, is done for the disc. | |
| Check if the CD is protected by copyright. | |
| Discs recorded in live file system format are not supported. (For Microsoft Windows Vista, check the settings.) | |
| Poor sound quality | Check if the CD is scratched or dirty. |
| It takes a relatively long time before the music starts playing. | If there are many folder or file levels on the MP3/WMA CD, or if it is a multisession disc, some time may be required before the music starts playing. |
| Music cuts off or skips | The writing software and hardware combination might not match, or the writing speed, writing depth, writing width might not match the specifications. Try using the slowest writing speed. |
| Skipping with high bit rate files | Skipping may occur with large quantities if data such as for high bit rate data. |
| Move immediately to the next song when playing | When a non-MP3/WMA file has been given an extension of ".MP3", ".WMA", ".mp3" or ".wma" or when play is prohibited by copyright protection, the player will skip to the next song. |
| The songs do not play back in the desired order. | The playback order is the order in which the files were written by the software, so the files might not play in the desired order. |
| Poor reception only from a certain radio broadcast station. | Check incoming radio wave signal strength of applicable broadcast station. |
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other sources, is not a malfunction.
Note. Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking the signal. Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the antenna and the waves reflected by mountains or buildings.
