Contents Section: Windows All sections

Power Window Control System: Other Infiniti FX50 II рестайлинг

Windows 33 illustrations ~5323 words

DETAILED FLOW

  1. OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain as much malfunction information (conditions and environment when the malfunction occurred) as possible when the customer brings the vehicle in. : GO TO 2.
  2. REPRODUCE THE MALFUNCTION INFORMATION Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. : GO TO 3.
  3. IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS" Use "Symptom diagnosis" from the symptom inspection result in step 2 . Then identify where to start the diagnosis based on possible causes and symptoms. : GO TO 4.
  4. IDENTIFY MALFUNCTIONING PARTS WITH "DTC/CIRCUIT DIAGNOSIS" Perform the diagnosis with "DTC/CIRCUIT DIAGNOSIS" of the applicable system. : GO TO 5.
  5. REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. : GO TO 6.
  6. FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Is the malfunctioning part repaired or replaced? YES: Trouble diagnosis is completed. NO: GO TO 3 .

INITIALIZATION PROCEDURE

  1. Disconnect the battery negative terminal or power window main switch connector. Reconnect it after a minute or more.
  2. Turn ignition switch ON.
  3. Operate power window switch to fully open the window. (This operation is unnecessary if the window is already fully open)
  4. Continue pulling the power window switch UP (AUTO-UP operation). Even after glass stops at the fully closed position, keep pulling the switch for 3 seconds or more.
  5. Initializing procedure is completed.
  6. Inspect anti-pinch function.

CHECK ANTI-PINCH FUNCTION

  1. Fully open the door window.
  2. Place a piece of wood near fully closed position.
  3. Close door glass completely with AUTO-UP.
  1. Check that glass lowers for approximately 150 mm (5.9 in) or for 2 seconds without pinching piece of wood and stops.
  2. Check that glass does not rise when operating the power window main switch while lowering.
CAUTIONPerform initial setting when auto-up operation or anti-pinch function does not operate normally. Check that AUTO-UP operates before inspection when system initialization is performed. Never check with hands or other body parts because they may be pinched. Never get pinched. It may switch to fail-safe mode if open/close operation is performed continuously without fully closing. Perform initial setting in that situation. Refer to " FAIL-SAFE " Finish initial setting. Otherwise, next operation cannot be done. Auto-up operation Anti-pinch function
  1. Disconnect the battery negative terminal or power window main switch connector. Reconnect it after a minute or more.
  2. Turn ignition switch ON.
  3. Operate power window switch to fully open the window. (This operation is unnecessary if the window is already fully open)
  4. Continue pulling the power window switch UP (AUTO-UP operation). Even after glass stops at the fully closed position, keep pulling the switch for 3 seconds or more.
  5. Initializing procedure is completed.
  6. Inspect anti-pinch function.
  1. Fully open the door window.
  2. Place a piece of wood near fully closed position.
  3. Close door glass completely with AUTO-UP.
  1. Check that glass lowers for approximately 150 mm (5.9 in) or for 2 seconds without pinching piece of wood and stops.
  2. Check that glass does not rise when operating the power window main switch while lowering.
CAUTIONPerform initial setting when auto-up operation or anti-pinch function does not operate normally. Check that AUTO-UP operates before inspection when system initialization is performed. Never check with hands or other body parts because they may be pinched. Never get pinched. It may switch to fail-safe mode if open/close operation is performed continuously without fully closing. Perform initial setting in that situation. Refer to " FAIL-SAFE " Finish initial setting. Otherwise, next operation cannot be done. Auto-up operation Anti-pinch function

Scheme 11

Scheme 11: System Diagram
Scheme 11: System Diagram

POWER WINDOW LOCK FUNCTION

Ground circuit inside power window main switch shuts off when power window lock switch is ON. This inhibits each power window switch operation except the power window main switch.

POWER WINDOW SERIAL LINK (FRONT DRIVER SIDE & PASSENGER SIDE)

  1. Power window main switch, front power window switch (passenger side), and BCM transmit and receive the power window serial link.
  2. Power window serial link transmits the power window main switch operation signals and IGN signal to power window main switch module and front power window switch (passenger side) module.

FREEZE FRAME DATA (FFD)

The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT

CONSULT screen itemIndication/UnitDescription
Vehicle SpeedKm/hVehicle speed of the moment a particular DTC is detected
Odo/Trip MeterKmTotal mileage (Odometer value) of the moment a particular DTC is detected
Vehicle ConditionSLEEP>LOCKPower position status of the moment a particular DTC is detected (1)While turning BCM status from low power consumption mode to normal mode (Power supply position is "LOCK" ()
SLEEP>OFFWhile turning BCM status from low power consumption mode to normal mode (Power supply position is "OFF".)
LOCK>ACCWhile turning power supply position from "LOCK" (1) to "ACC"
ACC>ONWhile turning power supply position from "ACC" to "IGN"
RUN>ACCWhile turning power supply position from "RUN" to "ACC" (Vehicle is stopping and selector lever is except P position.)
CRANK>RUNWhile turning power supply position from "CRANKING" to "RUN" (From cranking up the engine to run it)
RUN>URGENTWhile turning power supply position from "RUN" to "ACC" (Emergency stop operation)
ACC>OFFWhile turning power supply position from "ACC" to "OFF"
OFF>LOCKWhile turning power supply position from "OFF" to "LOCK" (1)
OFF>ACCWhile turning power supply position from "OFF" to "ACC"
ON>CRANKWhile turning power supply position from "IGN" to "CRANKING"
OFF>SLEEPWhile turning BCM status from normal mode (Power supply position is "OFF".) to low power consumption mode
LOCK>SLEEPWhile turning BCM status from normal mode (Power supply position is "LOCK".) to low power consumption mode
LOCKPower supply position is "LOCK" (1)
OFFPower supply position is "OFF" (Ignition switch OFF)
ACCPower supply position is "ACC" (Ignition switch ACC)
ONPower supply position is "IGN" (Ignition switch ON with engine stopped)
ENGINE RUNPower supply position is "RUN" (Ignition switch ON with engine running)
CRANKINGPower supply position is "CRANKING" (At engine cranking)
IGN Counter0 - 39The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39.
(1) Power supply position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position, and any of the following conditions are met: Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power supply position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "LOCK".
(1)Power supply position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position, and any of the following conditions are met

Data monitor

Monitor ItemDescription
DOOR SW-DRIndicates [ON/OFF] condition of driver side door switch.
DOOR SW-ASIndicates [ON/OFF] condition of passenger side door switch.

Component Function Check

  1. CHECK REAR POWER WINDOW FUNCTION Check rear power window motor operation with rear power window switch. Is the inspection result normal? YES: Rear power window switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-523996-S26986781032013012500000) ".

DRIVER SIDE: Component Function Check

  1. CHECK POWER WINDOW MOTOR CIRCUIT Check front power window motor (driver side) operation with power window main switch. Is the inspection result normal? YES: Front power window motor (driver side) is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-523996-S35288172012013012500000) ".

PASSENGER SIDE: Component Function Check

  1. CHECK POWER WINDOW MOTOR CIRCUIT Check front power window motor (passenger side) operation with power window main switch or front power window switch (passenger side). Is the inspection result normal? YES: Front power window motor (passenger side) is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-523996-S30339261812013012500000) ".

REAR LH: Component Function Check

  1. CHECK REAR POWER WINDOW MOTOR CIRCUIT Check rear power window motor LH operation with power window main switch or rear power window switch LH. Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Refer to " «REAR LH: DIAGNOSIS PROCEDURE»(ref-523996-S33591252022013012500000) "

REAR RH: Component Function Check

  1. CHECK REAR POWER WINDOW MOTOR CIRCUIT Check rear power window motor RH operation with power window main switch or rear power window switch RH. Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-523996-S16227475202013012500000) ".
  1. CHECK FUNCTION Check door switches ("DOOR SW-DR", "DOOR SW-AS") in "Data Monitor" mode with CONSULT. Monitor item Door condition Display DOOR SW-DR CLOSE --> OPEN OFF --> ON DOOR SW-AS Is the inspection result normal? YES: Door switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-523996-S32595764652013012500000) ".

Scheme 12

Scheme 12: Diagnosis Procedure
Scheme 12: Diagnosis Procedure
  1. CHECK FRONT DOOR SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect malfunction front door switch connector. Check signal between malfunction front door switch harness connector and ground with oscilloscope. (+) (-) Voltage (V) (Approx.) Front door switch Connector Terminal Driver side B16 2 Ground Passenger side B216 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK DOOR SWITCH CIRCUIT Disconnect BCM connector. Check continuity between BCM harness connector and malfunction door switch harness connector. BCM Front door switch Continuity Connector Terminal Connector Terminal M123 124 B216 2 Exists 150 B16 Check continuity between BCM harness connector and ground. BCM Ground Continuity Connector Terminal M123 124 Not exist 150 Is the inspection result normal? YES: Replace BCM. Refer to " «EXPLODED VIEW»(ref-524035-S22977608852013012500000) ". NO: Repair or replace harness.
  3. CHECK FRONT DOOR SWITCH Check front door switch. Refer to " «COMPONENT INSPECTION»(ref-523996-S10833725712013012500000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace malfunction front door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523998-S06493978572013012500000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
  1. CHECK ENCODER Check that driver side door glass performs AUTO open/close operation normally by power window main switch. Is the inspection result normal? YES: Encoder is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-523996-S24809133212013012500000) ".

Scheme 13

Scheme 13: DRIVER SIDE: Diagnosis Procedure
Scheme 13: DRIVER SIDE: Diagnosis Procedure
  1. CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between power window main switch harness connector and ground with oscilloscope. (+) (-) Signal (Reference value) Power window main switch Connector Terminal D8 9 Ground Refer to following signal: 13 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: GO TO 2.
  2. CHECK ENCODER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector and front power window motor (driver side) connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 9 D10 3 Existed 13 5 Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D8 9 Not existed 13 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
  3. CHECK ENCODER POWER SUPPLY CIRCUIT 1 Connect power window main switch connector. Turn ignition switch ON. Check voltage between front power window motor (driver side) harness connector and ground. (+) (-) Voltage (V) (Approx.) Front power window motor (driver side) Connector Terminal D10 4 Ground Battery voltage Is the inspection result normal? YES: GO TO 4. NO: GO TO 5 .
  4. CHECK GROUND CIRCUIT 2 Turn ignition switch OFF. Check continuity between front power window motor (driver side) harness connector and ground. Front power window motor (driver side) Ground Continuity Connector Terminal D10 6 Existed Is the inspection result normal? YES: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S40404789682013012500000) ". NO: GO TO 6 .
  5. CHECK ENCODER POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 15 D10 4 Existed Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D8 15 Not existed Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: Repair or replace harness.
  6. CHECK GROUND CIRCUIT 2 Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 2 D10 6 Existed Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: Repair or replace harness.
  1. CHECK ENCODER Check that passenger side door glass performs AUTO open/close operation normally by power window main switch or front power window switch (passenger side). Is the inspection result normal? YES: Encoder is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-523996-S32095775452013012500000) ".
  1. CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Check ("KEY CYL LK-SW", "KEY CYL UN-SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT. Refer to " «INTELLIGENT KEY: CONSULT FUNCTION (BCM - INTELLIGENT KEY)»(ref-523998-S12694983672013012500000) ". Monitor item Condition KEY CYL LK-SW Lock : ON Neutral / Unlock : OFF KEY CYL UN-SW Unlock : ON Neutral / Lock : OFF Is the inspection result normal? YES: Door key cylinder switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-523996-S23788042462013012500000) ".

POWER WINDOW MAIN SWITCH: Component Function Check

  1. CHECK POWER WINDOW SWITCH OUTPUT SIGNAL With CONSULT Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT. Refer to " «INTELLIGENT KEY: CONSULT FUNCTION (BCM - INTELLIGENT KEY)»(ref-523998-S12694983672013012500000) ". Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S14304035132013012500000) ".

Scheme 14

Scheme 14: POWER WINDOW MAIN SWITCH: Diagnosis Procedure
Scheme 14: POWER WINDOW MAIN SWITCH: Diagnosis Procedure
  1. CHECK POWER WINDOW SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect power window main switch connector. Check signal between power window main switch harness connector and ground with oscilloscope when door lock and unlock switch (driver side and passenger side) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (driver side and passenger side) is turned to "LOCK" or "UNLOCK": (+) (-) Signal (Reference value) Power window main switch Connector Terminal D8 14 Ground Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: GO TO 2.
  2. CHECK POWER WINDOW SERIAL LINK CIRCUIT Disconnect BCM connector. Check continuity between BCM harness connector and power window main switch harness connector. BCM Power window main switch Continuity Connector Terminal Connector Terminal M123 132 D8 14 Existed Check continuity between BCM harness connector and ground. BCM Ground Continuity Connector Terminal M123 132 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «EXPLODED VIEW»(ref-524035-S22977608852013012500000) ". NO: Repair or replace harness.

FRONT POWER WINDOW SWITCH (PASSENGER SIDE): Component Function Check

  1. CHECK POWER WINDOW SWITCH OUTPUT SIGNAL With CONSULT Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT. Refer to " «INTELLIGENT KEY: CONSULT FUNCTION (BCM - INTELLIGENT KEY)»(ref-523998-S12694983672013012500000) ". Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE): DIAGNOSIS PROCEDURE»(ref-523996-S21565500472013012500000) ".

PHYSICAL VALUES

Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (W) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (Y) Ground P/W power supply (BAT) Output Ignition switch OFF 12 V 3 (BG) Ground P/W power supply (IGN) Output Ignition switch ON 12 V 4 (P) Ground Interior room lamp power supply Output Interior room lamp battery saver is activated. (Cuts the interior room lamp power supply) 0 V Interior room lamp battery saver is not activated. (Outputs the interior room lamp power supply) 12 V 5 (V) Ground Passenger door UNLOCK Output Passenger door UNLOCK (Actuator is activated) 12 V Other than UNLOCK (Actuator is not activated) 0 V 7 (Y) Ground Step lamp control Output Step lamp ON 0 V OFF 12 V 8 (V) Ground All doors, fuel lid LOCK Output All doors, fuel lid LOCK (Actuator is activated) 12 V Other than LOCK (Actuator is not activated) 0 V 9 (G) Ground Driver door, fuel lid UNLOCK Output Driver door, fuel lid UNLOCK (Actuator is activated) 12 V Other than UNLOCK (Actuator is not activated) 0 V 10 (BR) Ground Rear RH door and rear LH door UNLOCK Output Rear RH door and rear LH door UNLOCK (Actuator is activated) 12 V Other than UNLOCK (Actuator is not activated) 0 V 11 (R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0 V 15 (Y) Ground ACC indicator lamp Output Ignition switch OFF (LOCK indicator is not illuminated) Battery voltage ACC or ON 0 V 17 (W) Ground Turn signal RH (Front) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 6.5 V 18 (BG) Ground Turn signal LH (Front) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 6.5 V 19 (SB) Ground Interior room lamp control Output Other than under condition 5.0 V Interior room lamp timer is activated. (Door is unlocked. etc...) Welcome light function is activated. 0 V 20 (V) Ground Turn signal RH (Rear) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 6.5 V 25 (G) Ground Turn signal LH (Rear) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 6.5 V 26 (P) Ground Rear wiper Output Rear wiper OFF (Stopped) 0 V ON (Operated) 12 V 34 (SB) Ground Luggage room antenna (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 35 (V) Ground Luggage room antenna (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 38 (B) Ground Back door antenna (-) Output When the back door opener request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 39 (W) Ground Back door antenna (+) Output When the back door opener request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 47 (Y) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC 12 V ON 0 V 52 (LG) Ground Starter relay control Output Ignition switch ON When selector lever is in P or N position 12 V When selector lever is not in P or N position 0 V 60 (SB) Ground Push-button ignition switch (Push switch) Input Push-button ignition switch (Push switch) Pressed 0 V Not pressed 12 V 61 (W) Ground Back door opener request switch Input Back door request switch ON (Pressed) 0 V OFF (Not pressed) 1.0 V 64 (L) Ground Intelligent Key warning buzzer (Engine room) Output Intelligent Key warning buzzer (Engine room) Sounding 0 V Not sounding 12 V 65 (BG) Ground Rear wiper stop position Input Rear wiper In stop position 1.0 V Not in stop position 0 V 66 (LG) Ground Back door switch Input Back door switch OFF (Door close) 12 V ON (Door open) 0 V 67 (P) Ground Back door opener switch Input Back door opener switch Pressed 0 V Not pressed 8.5 - 9.0 V 68 (BR) Ground Rear RH door switch Input Rear RH door switch OFF (Door close) 8.5 - 9.0 V ON (Door open) 0 V 69 (R) Ground Rear LH door switch Input Rear LH door switch OFF (Door close) 8.5 - 9.0 V ON (Door open) 0 V 74 (SB) Ground Passenger door antenna (-) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 75 (BR) Ground Passenger door antenna (+) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 76 (V) Ground Driver door antenna (-) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 77 (LG) Ground Driver door antenna (+) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 78 (Y) Ground Room antenna (-) (Instrument panel) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 79 (BR) Ground Room antenna (+) (Instrument panel) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 80 (GR) Ground NATS antenna amp. Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 81 (W) Ground NATS antenna amp. Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 82 (P) Ground Ignition relay [Fuse block (J/B)] control Output Ignition switch OFF or ACC 0 V ON 12 V 83 (GR) Ground Remote keyless entry receiver communication Input/Output During waiting When operating either button on the Intelligent Key 87 (BR) Ground Combination switch INPUT 5 Input Combination switch All switches OFF (Wiper volume dial 4) 1.4 V Front fog lamp switch ON (Wiper volume dial 4) 1.3 V Rear wiper switch ON (Wiper volume dial 4) 1.3 V Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 2 Wiper volume dial 6 Wiper volume dial 7 1.3 V 88 (V) Ground Combination switch INPUT 3 Input Combination switch All switches OFF (Wiper volume dial 4) 1.4 V Lighting switch HI (Wiper volume dial 4) 1.3 V Lighting switch 2ND (Wiper volume dial 4) 1.3 V Rear washer switch ON (Wiper volume dial 4) 1.3 V Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 2 Wiper volume dial 3 1.3 V 90 (P) Ground CAN-L Input/Output - - 91 (L) Ground CAN-H Input/Output - - 92 (LG) Ground Key slot illumination Output Key slot illumination OFF 12 V Blinking 6.5 V ON 0 V 93 (V) Ground ON indicator lamp Output Ignition switch OFF (LOCK indicator is not illuminated) Battery voltage ON or ACC 0 V 95 (BG) Ground ACC relay control Output Ignition switch OFF 0 V ACC or ON 12 V 96 (GR) Ground A/T shift selector (Detention switch) power supply Output - 12 V 99 (R) Ground Selector lever P position switch Input Selector lever P position 0 V Any position other than P 12 V 100 (G) Ground Passenger door request switch Input Passenger door request switch ON (Pressed) 0 V OFF (Not pressed) 1.0 V 101 (SB) Ground Driver door request switch Input Driver door request switch ON (Pressed) 0 V OFF (Not pressed) 1.0 V 102 (BG) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0 V ON 12 V 103 (BR) Ground Remote keyless entry receiver power supply Output Ignition switch OFF 12 V 107 (LG) Ground Combination switch INPUT 1 Input Combination switch (Wiper volume dial 4) All switches OFF 1.4 V Turn signal switch LH 1.3 V Turn signal switch RH 1.3 V Front wiper switch LO 1.3 V Front washer switch ON 1.3 V 108 (R) Ground Combination switch INPUT 4 Input Combination switch All switches OFF (Wiper volume dial 4) 1.4 V Lighting switch AUTO (Wiper volume dial 4) 1.3 V Lighting switch 1ST (Wiper volume dial 4) 1.3 V Rear wiper switch INT (Wiper volume dial 4) 1.3 V Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 5 Wiper volume dial 6 1.3 V 109 (Y) Ground Combination switch INPUT 2 Input Combination switch (Wiper volume dial 4) All switches OFF 1.4 V Lighting switch PASS 1.3 V Lighting switch 2ND 1.3 V Front wiper switch INT/AUTO 1.3 V Front wiper switch HI 1.3 V 110 (G) Ground Hazard switch Input Hazard switch ON 0 V OFF 1.1 V 112 (GR) Ground Rain sensor serial link Input/Output Ignition switch ON 8.7 V 113 (P) Ground Optical sensor Input Ignition switch ON When bright outside of the vehicle Close to 5 V When dark outside of the vehicle Close to 0 V 116 (BR) Ground Stop lamp switch 1 Input - Battery voltage 118 (P) Ground Stop lamp switch 2 (Without ICC) Input Stop lamp switch OFF (Brake pedal is not depressed) 0 V ON (Brake pedal is depressed) Battery voltage Stop lamp switch 2 (With ICC) Stop lamp switch OFF (Brake pedal is not depressed) and ICC brake hold relay OFF 0 V Stop lamp switch ON (Brake pedal is depressed) or ICC brake hold relay ON Battery voltage 119 (SB) Ground Front door lock assembly driver side (Unlock sensor) Input Driver door LOCK status (Unlock sensor switch OFF) 8.5 - 9.0 V UNLOCK status (Unlock switch sensor ON) 0 V 121 (BR) Ground Key slot switch Input When the Intelligent Key is inserted into key slot 12 V When the Intelligent Key is not inserted into key slot 0 V 123 (W) Ground IGN feedback Input Ignition switch OFF or ACC 0 V ON Battery voltage 124 (LG) Ground Passenger door switch Input Passenger door switch OFF (Door close) 8.5 - 9.0 V ON (Door open) 0 V 132 (BG) Ground Power window switch communication Input/Output Ignition switch ON 10.2 V Ignition switch OFF or ACC 12 V 134 (GR) Ground LOCK indicator lamp Output LOCK indicator lamp OFF Battery voltage ON 0 V 137 (B) Ground Receiver and sensor ground Input Ignition switch ON 0 V 138 (Y) Ground Sensor power supply Output Ignition switch OFF 0 V ACC or ON 5.0 V 140 (R) Ground Selector lever P/N position Input Selector lever P or N position 12 V Except P and N positions 0 V 141 (G) Ground Security indicator lamp Output Security indicator lamp ON 0 V Blinking 11.3 V OFF 12 V 142 (BG) Ground Combination switch OUTPUT 5 Output Combination switch (Wiper volume dial 4) All switches OFF 0 V Lighting switch 1ST 10.7 V Lighting switch HI Lighting switch 2ND Turn signal switch RH 143 (P) Ground Combination switch OUTPUT 1 Output Combination switch All switches OFF (Wiper volume dial 4) 0 V Front wiper switch HI (Wiper volume dial 4) 10.7 V Rear wiper switch INT (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 2 Wiper volume dial 3 Wiper volume dial 6 Wiper volume dial 7 144 (G) Ground Combination switch OUTPUT 2 Output Combination switch All switches OFF (Wiper volume dial 4) 0 V Front washer switch ON (Wiper volume dial 4) 10.7 V Rear wiper switch ON (Wiper volume dial 4) Rear washer switch ON (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 5 Wiper volume dial 6 145 (L) Ground Combination switch OUTPUT 3 Output Combination switch (Wiper volume dial 4) All switches OFF 0 V Front wiper switch INT/AUTO 10.7 V Front wiper switch LO Lighting switch AUTO 146 (SB) Ground Combination switch OUTPUT 4 Output Combination switch (Wiper volume dial 4) All switches OFF 0 V Front fog lamp switch ON 10.7 V Lighting switch 2ND Lighting switch PASS Turn signal switch LH 150 (GR) Ground Driver door switch Input Driver door switch OFF (Door close) 8.5 - 9.0 V ON (Door open) 0 V 151 (G) Ground Rear window defogger relay control Output Rear window defogger Active 0 V Not activated Battery voltage

Scheme 15

Scheme 15: PHYSICAL VALUES
Scheme 15: PHYSICAL VALUES

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

FAIL-SAFE CONTROL BY RAIN SENSOR MALFUNCTION

  1. BCM judges the rain sensor serial link error by the rain sensor serial link condition and detects the rain sensor malfunction by rain sensor malfunction signal.
  2. When BCM detects the rain sensor serial link error or the rain sensor malfunction while front wiper AUTO operation, BCM operates a fail-safe control.

Note. If rain sensor malfunction is detected when ignition switch is turned OFF ==> ON and front wiper switch is INT position, BCM operates a fail-safe control.

REAR WIPER MOTOR PROTECTION

BCM detects the rear wiper stopping position according to the rear wiper stop position signal.

When the rear wiper stop position signal does not change for more than 5 seconds while driving the rear wiper, BCM stops power supply to protect the rear wiper motor.

Condition of cancellation

  1. More than 1 minute is passed after the rear wiper stops.
  2. Turn rear wiper switch OFF.
  3. Operate the rear wiper switch or rear washer switch.

Terminal No. (wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 1 (W) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is in UP operation. Battery voltage 2 (LG) Ground Encoder ground - - 0 3 (GR) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is in DOWN operation. Battery voltage 4 (V) Ground Door key cylinder switch LOCK signal Input Key position (Neutral --> Locked) 5 --> 0 5 (SB) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is in DOWN operation. Battery voltage 6 (Y) Ground Door key cylinder switch UNLOCK signal Input Key position (Neutral --> Unlocked) 5 --> 0 7 (BR) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is in UP operation. Battery voltage 8 (L) Ground Front driver side power window motor UP signal Output When front LH switch in power window main switch is in UP operation. Battery voltage 9 (W) Ground Encoder pulse signal 2 Input When power window motor operates. 10 (O) Ground Rap signal Input IGN SW ON Battery voltage Within 45 second after ignition switch is turned to OFF Battery voltage When driver side or passenger side door is opened during retained power operation 0 11 (G) Ground Front driver side power window motor DOWN signal Output When front LH switch in power window main switch is in DOWN operation. Battery voltage 13 (P) Ground Encoder pulse signal 1 Input When power window motor operates. 14 (V) Ground Power window serial link Input/Output IGN SW ON or power window timer operating. 15 (W) Ground Encoder power supply Output When ignition switch ON or power window timer operates. 12 17 (B) Ground Ground - - 0 19 (Y) Ground Battery power supply Input - Battery voltage

Scheme 40

Scheme 40: PHYSICAL VALUES
Scheme 40: PHYSICAL VALUES

For connector terminal arrangements, harness layouts, and alphabets in a "diamond-shaped" symbol (option abbreviation; if not described in wiring diagram), refer to " CONNECTOR INFORMATION ".

Scheme 41

Scheme 41: WIRING DIAGRAM - POWER WINDOW CONTROL SYSTEM
Scheme 41: WIRING DIAGRAM - POWER WINDOW CONTROL SYSTEM

FAIL-SAFE CONTROL

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when a signal that is out of the specified value is detected between the fully closed position and the actual position of the glass.

MalfunctionMalfunction condition
Pulse sensor malfunctionWhen one pulse signal that is the specified value or more is detected continuously for the specified time or more, while door glass is being operated UP or DOWN.
Both pulse sensors malfunctionWhen both pulse signals are not detected continuously for the specified time or more, while door glass is being operated UP or DOWN.
Pulse direction malfunctionWhen a pulse signal indicating that window is moving in the opposite direction against the power window motor is detected for the specified value or more, while door glass is being operated UP or DOWN.
Glass recognition position malfunction 1When the actual door glass position that is out of specified value is detected compared to the door glass fully closed position memorized in module, while door glass is being operated UP or DOWN.
Glass recognition position malfunction 2When pulse count that is out of the door glass full stroke value or more is detected, while door glass is being operated UP or DOWN.

If fail-safe control, the system changes to a non-initialized condition and the following function do not operate

  1. Auto-up operation
  2. Anti-pinch function
  3. Retained power function

When fail-safe control is activated, perform initialization procedure to recover. If a malfunction is detected in power window switch or more, fail-safe control is activated again.

Scheme 42

Scheme 42: TERMINAL LAYOUT
Scheme 42: TERMINAL LAYOUT

Terminal No. (wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 3 (LG) Ground Encoder ground - - 0 4 (W) Ground Encoder power supply Output When ignition switch ON or power window timer operates Battery voltage 8 (L) Ground Power window motor UP signal Output When power window motor is in UP operation. Battery voltage 9 (G) Ground Power window motor DOWN signal Output When power window motor is in DOWN operation. Battery voltage 10 (Y) Ground Battery power supply Input - Battery voltage 11 (B) Ground Ground - - 0 12 (P) Ground Encoder pulse signal 1 Input When power window motor operates. 15 (R) Ground Encoder pulse signal 2 Input When power window motor operates. 16 (V) Ground Power window serial link Input/Output IGN SW ON or power window timer operating

For connector terminal arrangements, harness layouts, and alphabets in a "diamond-shaped" symbol (option abbreviation; if not described in wiring diagram), refer to " CONNECTOR INFORMATION ".

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when a signal that is out of the specified value is detected between the fully closed position and the actual position of the glass.

MalfunctionMalfunction condition
Pulse sensor malfunctionWhen one pulse signal that is the specified value or more is detected continuously for the specified time or more, while door glass is being operated UP or DOWN.
Both pulse sensors malfunctionWhen both pulse signals are not detected continuously for the specified time or more, while door glass is being operated UP or DOWN.
Pulse direction malfunctionWhen a pulse signal indicating that window is moving in the opposite direction against the power window motor is detected for the specified value or more, while door glass is being operated UP or DOWN.
Glass recognition position malfunction 1When the actual door glass position that is out of specified value is detected compared to the door glass fully closed position memorized in module, while door glass is being operated UP or DOWN.
Glass recognition position malfunction 2When pulse count that is out of the door glass full stroke value or more is detected, while door glass is being operated UP or DOWN.

If fail-safe control, the system changes to a non-initialized condition and the following function do not operate

  1. Auto-up operation
  2. Anti-pinch function
  3. Retained power function

When fail-safe control is activated, perform initialization procedure to recover. If a malfunction is detected in power window switch or more, fail-safe control is activated again.

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELT " .

WARNINGAlways observe the following items for preventing accidental activation: To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIRBAG ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNINGAlways observe the following items for preventing accidental activation: When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Scheme 43

Scheme 43: REMOVAL
Scheme 43: REMOVAL
  1. Remove the front door finisher. Refer to " «EXPLODED VIEW»(ref-524011-S09991688552013012500000) " and " «REMOVAL AND INSTALLATION»(ref-524011-S09684262812013012500000) ".
  2. Power window main switch (1) is removed from power window main switch finisher (2) using remover tool (A). CAUTION: Never fold pawl of front door finisher.
