POWER WINDOW MAIN SWITCH: Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect power window main switch connectors. Turn ignition switch ON. Check voltage between power window main switch harness connector and ground. (+) (-) Voltage (V) (Approx.) Power window main switch Connector Terminal D8 10 Ground Battery voltage D9 19 Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D9 17 Existed Is the inspection result normal? YES: GO TO 4 . NO: Repair or replace harness.
- CHECK POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and power window main switch harness connector. BCM Power window main switch Continuity Connector Terminal Connector Terminal M118 2 D9 19 Existed 3 D8 10 Check continuity between BCM harness connector and ground. BCM Ground Continuity Connector Terminal M118 2 Not existed 3 Is the inspection result normal? YES: Replace BCM. Refer to " «EXPLODED VIEW»(ref-524035-S22977608852013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) " : INSPECTION END
FRONT POWER WINDOW SWITCH (PASSENGER SIDE): Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check voltage between front power window switch (passenger side) harness connector and ground. (+) (-) Voltage (V) (Approx.) Front power window switch (passenger side) Connector Terminal D38 10 Ground Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK GROUND CIRCUIT Check continuity between front power window switch (passenger side) harness connector and ground. Front power window switch (passenger side) Ground Continuity Connector Terminal D38 11 Existed Is the inspection result normal? YES: GO TO 4 . NO: Repair or replace harness.
- CHECK POWER SUPPLY CIRCUIT 2 Disconnect BCM connector. Check continuity between BCM harness connector and front power window switch (passenger side) harness connector. BCM Front power window switch (passenger side) Continuity Connector Terminal Connector Terminal M118 2 D38 10 Existed Check continuity between BCM harness connector and ground. BCM Ground Continuity Connector Terminal M118 2 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «EXPLODED VIEW»(ref-524035-S22977608852013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) " : INSPECTION END
REAR POWER WINDOW SWITCH: Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect rear power window switch connectors. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. (+) (-) Voltage (V) (Approx.) Rear power window switch Connector Terminal LH D54 1 Ground Battery voltage RH D74 Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK GROUND CIRCUIT Check continuity between rear power window switch harness connector and ground. Rear power window switch Ground Continuity Connector Terminal LH D54 7 Existed RH D74 Is the inspection result normal? YES: GO TO 4 . NO: Repair or replace harness.
- CHECK POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and rear power window switch harness connector. BCM Rear power window switch Continuity Connector Terminal Connector Terminal M118 3 LH D54 1 Existed RH D74 Check continuity between BCM harness connector and ground. BCM Ground Continuity Connector Terminal M118 3 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «EXPLODED VIEW»(ref-524035-S22977608852013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) " : INSPECTION END
Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. (+) (-) Condition Voltage (V) (Approx.) Rear power window switch Connector Terminal LH D54 2 Ground Power window main switch (rear LH) UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage RH D74 2 Power window main switch (rear RH) UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT INSPECTION»(ref-523996-S22008926152013012500000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ".
- CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect power window main switch connector and rear power window switch connector. Check continuity between power window main switch harness connector and rear power window switch harness connector. Power window main switch Rear power window switch Continuity Connector Terminal Connector Terminal D8 1 LH D54 2 Existed 3 3 5 RH D74 3 7 2 Check continuity between power window main switch connector and ground. Power window main switch Ground Continuity Connector Terminal D8 1 Not existed 3 5 7 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) " : INSPECTION END
COMPONENT INSPECTION
- CHECK REAR POWER WINDOW SWITCH Turn ignition switch OFF. Disconnect rear power window switch connector. Check rear power window switch. Rear power window switch Terminal Power window switch condition Continuity 1 5 UP Existed 3 4 3 4 NEUTRAL 5 2 1 4 DOWN 5 2 Is the inspection result normal? YES: Rear power window switch is OK. NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ".
DRIVER SIDE: Diagnosis Procedure
- CHECK FRONT POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor (driver side) connector. Turn ignition switch ON. Check voltage between front power window motor (driver side) harness connector and ground. (+) (-) Condition Voltage (V) (Approx.) Front power window motor (driver side) Connector Terminal D10 2 Ground Power window main switch UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK POWER WINDOW MOTOR Check front power window motor (driver side). Refer to " «DRIVER SIDE: COMPONENT INSPECTION»(ref-523996-S41514822512013012500000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S40404789682013012500000) ".
- CHECK POWER WINDOW MOTOR CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 8 D10 2 Existed 11 1 Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D8 8 Not existed 11 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
- CHECK POWER WINDOW MOTOR Turn ignition switch OFF. Disconnect front power window motor (driver side) connector. Check motor operation by connecting the battery voltage directly to front power window motor (driver side) connector. Front power window motor (driver side) connector Terminal Motor operation (+) (-) D10 1 2 DOWN 2 1 UP Is the inspection result normal? YES: Front power window motor (driver side) is OK. NO: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S40404789682013012500000) ".
PASSENGER SIDE: Diagnosis Procedure
- CHECK FRONT POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor (passenger side) connector. Turn ignition switch ON. Check voltage between front power window motor (passenger side) harness connector and ground. (+) (-) Condition Voltage (V) (Approx.) Front power window motor (passenger side) Connector Terminal D40 2 Ground Front power window switch (passenger side) UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK POWER WINDOW MOTOR Check front power window motor (passenger side). Refer to " «PASSENGER SIDE: COMPONENT INSPECTION»(ref-523996-S41251448502013012500000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S40404789682013012500000) ".
- CHECK POWER WINDOW MOTOR CIRCUIT Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 8 D40 1 Existed 9 2 Check continuity between front power window switch (passenger side) connector and ground. Front power window switch (passenger side) Ground Continuity Connector Terminal D38 8 Not existed 9 Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
- CHECK POWER WINDOW MOTOR Turn ignition switch OFF. Disconnect front power window motor (passenger side) connector. Check motor operation by connecting the battery voltage directly to front power window motor (passenger side) connector. Front power window motor (passenger side) connector Terminal Motor condition (+) (-) D40 1 2 UP 2 1 DOWN Is the inspection result normal? YES: Front power window motor (passenger side) is OK. NO: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S40404789682013012500000) ".
REAR LH: Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor LH connector. Turn ignition switch ON. Check voltage between rear power window motor LH harness connector and ground. (+) (-) Condition Voltage (V) (Approx.) Rear power window motor LH Connector Terminal D52 1 Ground Rear power window switch LH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK REAR POWER WINDOW MOTOR Check rear power window motor LH. Refer to " «REAR LH: COMPONENT INSPECTION»(ref-523996-S02379464252013012500000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S07028129602013012500000) ".
- CHECK POWER WINDOW MOTOR CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH harness connector and rear power window motor LH harness connector. Rear power window switch LH Rear power window motor LH Continuity Connector Terminal Connector Terminal D54 5 D52 1 Existed 4 3 Check continuity between rear power window switch LH harness connector and ground. Rear power window switch LH Ground Continuity Connector Terminal D54 5 Not existed 4 Is the inspection result normal? YES: Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
- CHECK REAR POWER WINDOW MOTOR Turn ignition switch OFF. Disconnect rear power window motor LH connector. Check motor operation by connecting the battery voltage directly to rear power window motor LH connector. Rear power window motor LH connector Terminal Motor condition (+) (-) D52 3 1 DOWN 1 3 UP Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S07028129602013012500000) ".
REAR RH: Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor RH connector. Turn ignition switch ON. Check voltage between rear power window motor RH harness connector and ground. (+) (-) Condition Voltage (V) (Approx.) Rear power window motor RH Connector Terminal D72 1 Ground Rear power window switch RH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK REAR POWER WINDOW MOTOR Check rear power window motor RH. Refer to " «REAR RH: COMPONENT INSPECTION»(ref-523996-S15467735332013012500000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S07028129602013012500000) ".
- CHECK POWER WINDOW MOTOR CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH harness connector and rear power window motor RH harness connector. Rear power window switch RH Rear power window motor RH Continuity Connector Terminal Connector Terminal D74 5 D72 1 Existed 4 3 Check continuity between rear power window switch RH harness connector and ground. Rear power window switch RH Ground Continuity Connector Terminal D74 5 Not existed 4 Is the inspection result normal? YES: Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
- CHECK REAR POWER WINDOW MOTOR RH Turn ignition switch OFF. Disconnect rear power window motor RH connector. Check motor operation by connecting the battery voltage directly to rear power window motor RH connector. Rear power window motor RH connector Terminal Motor condition (+) (-) D72 3 1 DOWN 1 3 UP Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S07028129602013012500000) ".
- CHECK FRONT DOOR SWITCH Turn ignition switch OFF. Disconnect malfunction front door switch connector. Check malfunction front door switch. (+) (-) Condition Continuity Front door switch Connector Terminal Driver side B16 2 Ground part of door switch Door switch pressed Not exist Door switch released Exists Passenger side B216 2 Door switch pressed Not exist Door switch released Exists Is the inspection result normal? YES: Front door switch is OK. NO: Replace malfunction front door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523998-S06493978572013012500000) ".
- CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between front power window switch (passenger side) harness connector and ground with oscilloscope. (+) (-) Signal (Reference value) Front power window switch (passenger side) Connector Terminal D38 12 Ground Refer to following signal: 15 Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) ". NO: GO TO 2.
- CHECK ENCODER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector and front power window motor (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 12 D40 5 Existed 15 3 Check continuity between front power window switch (passenger side) harness connector and ground. Front power window switch (passenger side) Ground Continuity Connector Terminal D38 12 Not existed 15 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
- CHECK ENCODER POWER SUPPLY CIRCUIT 1 Connect front power window switch (passenger side) connector. Turn ignition switch ON. Check voltage between front power window motor (passenger side) harness connector and ground. (+) (-) Voltage (V) (Approx.) Front power window motor (passenger side) Connector Terminal D40 4 Ground Battery voltage Is the inspection result normal? YES: GO TO 4. NO: GO TO 5 .
- CHECK GROUND CIRCUIT 2 Turn ignition switch OFF. Check continuity between front power window motor (passenger side) harness connector and ground. Front power window motor (passenger side) Ground Continuity Connector Terminal D40 6 Existed Is the inspection result normal? YES: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-524065-S40404789682013012500000) ". NO: GO TO 6 .
- CHECK ENCODER POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 4 D40 4 Existed Check continuity between front power window switch (passenger side) harness connector and ground. Front power window switch (passenger side) Ground Continuity Connector Terminal D38 4 Not existed Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) ". NO: Repair or replace harness.
- CHECK GROUND CIRCUIT 2 Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 3 D40 6 Existed Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) ". NO: Repair or replace harness.
- CHECK DOOR KEY CYLINDER SWITCH SIGNAL Turn ignition switch OFF. Disconnect front door lock assembly (driver side) (key cylinder switch) connect. Turn ignition switch ON. Check voltage between front door lock assembly (driver side) (key cylinder switch) harness connector and ground. (+) (-) Voltage (V) (Approx.) Front door lock assembly (driver side) (key cylinder switch) Connector Terminal D15 5 Ground 5 6 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
- CHECK DOOR KEY CYLINDER SWITCH CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front door lock assembly (driver side) (key cylinder switch) harness connector. Power window main switch Front door lock assembly (driver side) (key cylinder switch) Continuity Connector Terminal Connector Terminal D8 4 D15 6 Existed 6 5 Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D8 4 Not existed 6 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". NO: Repair or replace harness.
- CHECK DOOR KEY CYLINDER SWITCH GROUND CIRCUIT Check continuity between front door lock assembly (driver side) (key cylinder switch) harness connector and ground. Front door lock assembly (driver side) (key cylinder switch) Ground Continuity Connector Terminal D15 4 Existed Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
- CHECK DOOR KEY CYLINDER SWITCH Check front door lock assembly (driver side) (key cylinder switch). Refer to " «COMPONENT INSPECTION»(ref-523996-S30989906282013012500000) ". Is the inspection result normal? YES: GO TO 5. NO: Replace front door lock assembly (driver side) (key cylinder switch). Refer to " «DOOR LOCK: REMOVAL AND INSTALLATION»(ref-523998-S21293157992013012500000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
- CHECK DOOR KEY CYLINDER SWITCH Turn ignition switch OFF. Disconnect front door lock assembly (driver side) (key cylinder switch) connector. Check front door lock assembly (driver side) (key cylinder switch). Front door lock assembly (driver side) (key cylinder switch) Key position Continuity Connector Terminal D15 5 4 Unlock Existed Neutral / Lock Not existed 6 Lock Existed Neutral / Unlock Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace front door lock assembly (driver side) (key cylinder switch). Refer to " «DOOR LOCK: REMOVAL AND INSTALLATION»(ref-523998-S21293157992013012500000) ".
- CHECK POWER WINDOW SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check signal between front power window switch (passenger side) harness connector and ground with oscilloscope when door lock and unlock switch (driver side and passenger side) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (driver side and passenger side) is turned to "LOCK" or "UNLOCK": (+) (-) Signal (Reference value) Front power window switch (passenger side) Connector Terminal D38 16 Ground Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) ". NO: GO TO 2.
- CHECK POWER WINDOW SERIAL LINK CIRCUIT Disconnect BCM connector. Check continuity between BCM harness connector and front power window switch (passenger side) harness connector. BCM Front power window switch (passenger side) Continuity Connector Terminal Connector Terminal M123 132 D38 16 Existed Check continuity between BCM harness connector and ground. BCM Ground Continuity Connector Terminal M123 132 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «EXPLODED VIEW»(ref-524035-S22977608852013012500000) ". NO: Repair or replace harness.
VALUES ON THE DIAGNOSIS TOOL
CONSULT MONITOR ITEM
| Monitor Item | Condition | Value/Status |
|---|---|---|
| FR WIPER HI | Other than front wiper switch HI | Off |
| Front wiper switch HI | On | |
| FR WIPER LOW | Other than front wiper switch LO | Off |
| Front wiper switch LO | On | |
| FR WASHER SW | Front washer switch OFF | Off |
| Front washer switch ON | On | |
| FR WIPER INT | Other than front wiper switch INT/AUTO | Off |
| Front wiper switch INT/AUTO | On | |
| FR WIPER STOP | Front wiper is not in STOP position | Off |
| Front wiper is in STOP position | On | |
| INT VOLUME | Wiper volume dial is in a dial position 1 - 7 | Wiper volume dial position |
| RR WIPER ON | Other than rear wiper switch ON | Off |
| Rear wiper switch ON | On | |
| RR WIPER INT | Other than rear wiper switch INT | Off |
| Rear wiper switch INT | On | |
| RR WASHER SW | Rear washer switch OFF | Off |
| Rear washer switch ON | On | |
| RR WIPER STOP | Rear wiper is in STOP position | Off |
| Rear wiper is not in STOP position | On | |
| TURN SIGNAL R | Other than turn signal switch RH | Off |
| Turn signal switch RH | On | |
| TURN SIGNAL L | Other than turn signal switch LH | Off |
| Turn signal switch LH | On | |
| TAIL LAMP SW | Other than lighting switch 1ST and 2ND | Off |
| Lighting switch 1ST or 2ND | On | |
| HI BEAM SW | Other than lighting switch HI | Off |
| Lighting switch HI | On | |
| HEAD LAMP SW 1 | Other than lighting switch 2ND | Off |
| Lighting switch 2ND | On | |
| HEAD LAMP SW 2 | Other than lighting switch 2ND | Off |
| Lighting switch 2ND | On | |
| PASSING SW | Other than lighting switch PASS | Off |
| Lighting switch PASS | On | |
| AUTO LIGHT SW | Other than lighting switch AUTO | Off |
| Lighting switch AUTO | On | |
| FR FOG SW | Front fog lamp switch OFF | Off |
| Front fog lamp switch ON | On | |
| RR FOG SW | NOTE: The item is indicated, but not monitored. | Off |
| DOOR SW-DR | Driver door closed | Off |
| Driver door opened | On | |
| DOOR SW-AS | Passenger door closed | Off |
| Passenger door opened | On | |
| DOOR SW-RR | Rear RH door closed | Off |
| Rear RH door opened | On | |
| DOOR SW-RL | Rear LH door closed | Off |
| Rear LH door opened | On | |
| DOOR SW-BK | Back door closed | Off |
| Back door opened | On | |
| CDL LOCK SW | Other than power door lock switch LOCK | Off |
| Power door lock switch LOCK | On | |
| CDL UNLOCK SW | Other than power door lock switch UNLOCK | Off |
| Power door lock switch UNLOCK | On | |
| KEY CYL LK-SW | Other than driver door key cylinder LOCK position | Off |
| Driver door key cylinder LOCK position | On | |
| KEY CYL UN-SW | Other than driver door key cylinder UNLOCK position | Off |
| Driver door key cylinder UNLOCK position | On | |
| KEY CYL SW-TR | NOTE: The item is indicated, but not monitored. | Off |
| HAZARD SW | Hazard switch is OFF | Off |
| Hazard switch is ON | On | |
| REAR DEF SW | NOTE: The item is indicated, but not monitored. | Off |
| TR CANCEL SW | NOTE: The item is indicated, but not monitored. | Off |
| TR/BD OPEN SW | Back door opener switch OFF | Off |
| While the back door opener switch is turned ON | On | |
| TRNK/HAT MNTR | NOTE: The item is indicated, but not monitored. | Off |
| REVERSE SW | NOTE: The item is indicated, but not monitored. | Off |
| RKE-LOCK | LOCK button of the Intelligent Key is not pressed | Off |
| LOCK button of the Intelligent Key is pressed | On | |
| RKE-UNLOCK | UNLOCK button of the Intelligent Key is not pressed | Off |
| UNLOCK button of the Intelligent Key is pressed | On | |
| RKE-TR/BD | NOTE: The item is indicated, but not monitored. | Off |
| RKE-PANIC | PANIC button of the Intelligent Key is not pressed | Off |
| PANIC button of the Intelligent Key is pressed | On | |
| RKE-P/W OPEN | UNLOCK button of the Intelligent Key is not pressed | Off |
| UNLOCK button of the Intelligent Key is pressed and held | On | |
| RKE-MODE CHG | LOCK/UNLOCK button of the Intelligent Key is not pressed and held simultaneously | Off |
| LOCK/UNLOCK button of the Intelligent Key is pressed and held simultaneously | On | |
| OPTICAL SENSOR | Bright outside of the vehicle | Close to 5 V |
| Dark outside of the vehicle | Close to 0 V | |
| REQ SW-DR | Driver door request switch is not pressed | Off |
| Driver door request switch is pressed | On | |
| REQ SW-AS | Passenger door request switch is not pressed | Off |
| Passenger door request switch is pressed | On | |
| REQ SW-RR | NOTE: The item is indicated, but not monitored. | Off |
| REQ SW-RL | NOTE: The item is indicated, but not monitored. | Off |
| REQ SW-BD/TR | Back door request switch is not pressed | Off |
| Back door request switch is pressed | On | |
| PUSH SW | Push-button ignition switch (push switch) is not pressed | Off |
| Push-button ignition switch (push switch) is pressed | On | |
| IGN RLY2-F/B | NOTE: The item is indicated, but not monitored. | Off |
| ACC RLY-F/B | NOTE: The item is indicated, but not monitored. | Off |
| CLUCH SW | NOTE: The item is indicated, but not monitored. | Off |
| BRAKE SW 1 | The brake pedal is depressed when No. 7 fuse is blown | Off |
| The brake pedal is not depressed when No. 7 fuse is blown, or No. 7 fuse is normal | On | |
| BRAKE SW 2 | The brake pedal is not depressed | Off |
| The brake pedal is depressed | On | |
| DETE/CANCL SW | Selector lever in P position | Off |
| Selector lever in any position other than P | On | |
| SFT PN/N SW | Selector lever in any position other than P and N | Off |
| Selector lever in P or N position | On | |
| S/L-LOCK | NOTE: The item is indicated but not monitored. | Off |
| S/L-UNLOCK | NOTE: The item is indicated but not monitored. | Off |
| S/L RELAY-F/B | NOTE: The item is indicated but not monitored. | Off |
| UNLK SEN-DR | Driver door is unlocked | Off |
| Driver door is locked | On | |
| PUSH SW-IPDM | Push-button ignition switch (push-switch) is not pressed | Off |
| Push-button ignition switch (push-switch) is pressed | On | |
| IGN RLY1-F/B | Ignition switch in OFF or ACC position | Off |
| Ignition switch in ON position | On | |
| DETE SW-IPDM | Selector lever in any position other than P | Off |
| Selector lever in P position | On | |
| SFT PN-IPDM | Selector lever in any position other than P and N | Off |
| Selector lever in P or N position | On | |
| SFT P-MET | Selector lever in any position other than P | Off |
| Selector lever in P position | On | |
| SFT N-MET | Selector lever in any position other than N | Off |
| Selector lever in N position | On | |
| ENGINE STATE | Engine stopped | Stop |
| While the engine stalls | Stall | |
| At engine cranking | Crank | |
| Engine running | Run | |
| S/L LOCK-IPDM | NOTE: The item is indicated but not monitored. | Off |
| S/L UNLK-IPDM | NOTE: The item is indicated but not monitored. | Off |
| S/L RELAY-REQ | NOTE: The item is indicated but not monitored. | Off |
| VEH SPEED 1 | While driving | Equivalent to speedometer reading |
| VEH SPEED 2 | While driving | Equivalent to speedometer reading |
| DOOR STAT-DR | Driver door is locked | LOCK |
| Wait with selective UNLOCK operation (5 seconds) | READY | |
| Driver door is unlocked | UNLOCK | |
| DOOR STAT-AS | Passenger door is locked | LOCK |
| Wait with selective UNLOCK operation (5 seconds) | READY | |
| Passenger door is unlocked | UNLOCK | |
| ID OK FLAG | Driver side door is open after ignition switch is turned OFF (Selector lever is in the P position) | Reset |
| Ignition switch ON | Set | |
| PRMT ENG STRT | The engine start is prohibited | Reset |
| The engine start is permitted | Set | |
| PRMT RKE STRT | NOTE: The item is indicated, but not monitored. | Reset |
| KEY SW-SLOT | The Intelligent Key is not inserted into key slot | Off |
| The Intelligent Key is inserted into key slot | On | |
| RKE OPE COUN1 | During the operation of the Intelligent Key | Operation frequency of the Intelligent Key |
| RKE OPE COUN2 | NOTE: The item is indicated, but not monitored. | |
| CONFRM ID ALL | The key ID that the key slot receives is not recognized by any key ID registered to BCM. | Yet |
| The key ID that the key slot receives accords with any key ID registered to BCM. | Done | |
| CONFIRM ID4 | The key ID that the key slot receives is not recognized by the fourth key ID registered to BCM. | Yet |
| The key ID that the key slot receives is recognized by the fourth key ID registered to BCM. | Done | |
| CONFIRM ID3 | The key ID that the key slot receives is not recognized by the third key ID registered to BCM. | Yet |
| The key ID that the key slot receives is recognized by the third key ID registered to BCM. | Done | |
| CONFIRM ID2 | The key ID that the key slot receives is not recognized by the second key ID registered to BCM. | Yet |
| The key ID that the key slot receives is recognized by the second key ID registered to BCM. | Done | |
| CONFIRM ID1 | The key ID that the key slot receives is not recognized by the first key ID registered to BCM. | Yet |
| The key ID that the key slot receives is recognized by the first key ID registered to BCM. | Done | |
| TP 4 | The ID of fourth Intelligent Key is not registered to BCM | Yet |
| The ID of fourth Intelligent Key is registered to BCM | Done | |
| TP 3 | The ID of third Intelligent Key is not registered to BCM | Yet |
| The ID of third Intelligent Key is registered to BCM | Done | |
| TP 2 | The ID of second Intelligent Key is not registered to BCM | Yet |
| The ID of second Intelligent Key is registered to BCM | Done | |
| TP 1 | The ID of first Intelligent Key is not registered to BCM | Yet |
| The ID of first Intelligent Key is registered to BCM | Done |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated but not monitored. |
| NOTE |
|---|
| The item is indicated but not monitored. |
| NOTE |
|---|
| The item is indicated but not monitored. |
| NOTE |
|---|
| The item is indicated but not monitored. |
| NOTE |
|---|
| The item is indicated but not monitored. |
| NOTE |
|---|
| The item is indicated but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
Scheme 2
FAIL-SAFE CONTROL BY DTC
BCM performs fail-safe control when any DTC are detected.
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| B2190: NATS ANTENNA AMP | Inhibit engine cranking | Erase DTC |
| B2191: DIFFERENCE OF KEY | Inhibit engine cranking | Erase DTC |
| B2192: ID DISCORD BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2193: CHAIN OF BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2195: ANTI SCANNING | Inhibit engine cranking | Ignition switch ON --> OFF |
| B2560: STARTER CONT RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status becomes consistent: Starter control relay signal Starter relay status signal |
| B2608: STARTER RELAY | Inhibit engine cranking | 500 ms after the following signal communication status becomes consistent: Starter relay control signal Starter relay status signal (CAN) |
| B260A: IGNITION RELAY | Inhibit engine cranking | 500 ms after the following conditions are fulfilled: IGN relay (IPDM E/R) control signal: OFF (Battery voltage) Ignition ON signal (CAN to IPDM E/R): OFF (Request signal) Ignition ON signal (CAN from IPDM E/R): OFF (Condition signal) |
| B260F: ENG STATE SIG LOST | Maintains the power supply position attained at the time of DTC detection | When any of the following conditions are fulfilled: Power position changes to ACC Receives engine status signal (CAN) |
| B2617: STARTER RELAY CIRC | Inhibit engine cranking | 1 second after the starter relay control inside BCM becomes normal |
| B2618: BCM | Inhibit engine cranking | 1 second after the ignition relay (IPDM E/R) control inside BCM becomes normal |
| B261E: VEHICLE TYPE | Inhibit engine cranking | BCM initialization |
DTC Inspection Priority Chart
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority chart
| Priority | DTC |
|---|---|
| 1 | B2562: LOW VOLTAGE |
| 2 | U1000: CAN COMM U1010: CONTROL UNIT(CAN) |
| 3 | B2190: NATS ANTENNA AMP B2191: DIFFERENCE OF KEY B2192: ID DISCORD BCM-ECM B2193: CHAIN OF BCM-ECM B2195: ANTI SCANNING |
| 4 | B2553: IGNITION RELAY B2555: STOP LAMP B2556: PUSH-BTN IGN SW B2557: VEHICLE SPEED B2560: STARTER CONT RELAY B2601: SHIFT POSITION B2602: SHIFT POSITION B2603: SHIFT POSI STATUS B2604: PNP/CLUTCH SW B2605: PNP/CLUTCH SW B2608: STARTER RELAY B260A: IGNITION RELAY B260F: ENG STATE SIG LOST B2614: BCM B2615: BCM B2616: BCM B2617: BCM B2618: BCM B261A: PUSH-BTN IGN SW B261E: VEHICLE TYPE B26EA: KEY REGISTRATION U0415: VEHICLE SPEED SIG |
| 5 | B2621: INSIDE ANTENNA B2623: INSIDE ANTENNA |
| 6 | B26E7: TPMS CAN COMM |
DTC Index
Note. The details of time display are as follows
- CRNT: A malfunction is detected now.
- PAST: A malfunction was detected in the past.
IGN counter is displayed on Freeze Frame Data. For details of Freeze Frame Data, refer to " COMMON ITEM: CONSULT FUNCTION (BCM - COMMON ITEM) ".
| CONSULT display | Fail-safe | Freeze Frame Data Vehicle Speed Odo/Trip Meter Vehicle Condition | Intelligent Key warning lamp ON |
|---|---|---|---|
| No DTC is detected. Further testing may be required. | |||
| U1000: CAN COMM | |||
| U1010: CONTROL UNIT(CAN) | |||
| U0415: VEHICLE SPEED SIG | |||
| B2190: NATS ANTENNA AMP | X | ||
| B2191: DIFFERENCE OF KEY | X | ||
| B2192: ID DISCORD BCM-ECM | X | ||
| B2193: CHAIN OF BCM-ECM | X | ||
| B2195: ANTI SCANNING | X | ||
| B2553: IGNITION RELAY | X | ||
| B2555: STOP LAMP | X | ||
| B2556: PUSH-BTN IGN SW | X | X | |
| B2557: VEHICLE SPEED | X | X | X |
| B2560: STARTER CONT RELAY | X | X | X |
| B2562: LOW VOLTAGE | X | ||
| B2601: SHIFT POSITION | X | X | X |
| B2602: SHIFT POSITION | X | X | X |
| B2603: SHIFT POSI STATUS | X | X | X |
| B2604: PNP/CLUTCH SW | X | X | X |
| B2605: PNP/CLUTCH SW | X | X | X |
| B2608: STARTER RELAY | X | X | X |
| B260A: IGNITION RELAY | X | X | X |
| B260F: ENG STATE SIG LOST | X | X | X |
| B2614: BCM | X | X | |
| B2615: BCM | X | X | |
| B2616: BCM | X | X | |
| B2617: BCM | X | X | X |
| B2618: BCM | X | X | X |
| B261A: PUSH-BTN IGN SW | X | X | |
| B261E: VEHICLE TYPE | X | X | X (Turn ON for 15 seconds) |
| B2621: INSIDE ANTENNA | X | ||
| B2623: INSIDE ANTENNA | X | ||
| B26E7: TPMS CAN COMM | |||
| B26EA: KEY REGISTRATION | X | X (Turn ON for 15 seconds) |
POWER WINDOW CONTROL SYSTEM DTC INDEX
Scheme 3
- CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-524035-S38166817992013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- CHECK POWER WINDOW MAIN SWITCH POWER SUPPLY AND GROUND CIRCUIT Check power window switch power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S25726071262013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK DRIVER SIDE POWER WINDOW MOTOR Check driver side power window motor. Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-523996-S12606821162013012500000) ". Is the measurement value within the specification? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
WHEN POWER WINDOW MAIN SWITCH IS OPERATED: Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) SERIAL LINK CIRCUIT Check front power window switch (passenger side) serial link circuit. Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE): COMPONENT FUNCTION CHECK»(ref-523996-S22431841992013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
WHEN FRONT POWER WINDOW SWITCH (PASSENGER SIDE) IS OPERATED: Diagnosis Procedure
- REPLACE FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) " : INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW SWITCH ARE OPERATED: Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) POWER SUPPLY AND GROUND CIRCUIT Check front power window switch (passenger side) power supply and ground circuit. Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE): DIAGNOSIS PROCEDURE»(ref-523996-S37373336692013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK PASSENGER SIDE POWER WINDOW MOTOR CIRCUIT Check passenger side power window motor circuit. Refer to " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-523996-S21238407702013012500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-523996-S07394902282013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
WHEN REAR POWER WINDOW SWITCH LH IS OPERATED: Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S24870136312013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- REPLACE REAR POWER WINDOW SWITCH LH Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ". : INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH LH ARE OPERATED: Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH: COMPONENT FUNCTION CHECK»(ref-523996-S33459804252013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-523996-S07394902282013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
WHEN REAR POWER WINDOW SWITCH RH IS OPERATED: Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S24870136312013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- REPLACE REAR POWER WINDOW SWITCH RH Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ". : INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH RH ARE OPERATED: Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH: COMPONENT FUNCTION CHECK»(ref-523996-S11110143182013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-523996-S24460160732013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER (DRIVER SIDE) CIRCUIT Check encoder (driver side) circuit. Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-523996-S31711405352013012500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-523996-S24460160732013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER (PASSENGER SIDE) CIRCUIT Check encoder (passenger side) circuit. Refer to " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-523996-S42713576262013012500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-523996-S24460160732013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER (DRIVER SIDE) CIRCUIT Check encoder (driver side) circuit. Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-523996-S31711405352013012500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-523996-S24460160732013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER (PASSENGER SIDE) CIRCUIT Check encoder (passenger side) circuit. Refer to " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-523996-S42713576262013012500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- CHECK DOOR SWITCH Check door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-523996-S20878918692013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-523996-S24460160732013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK DRIVER SIDE DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) Check driver side door lock assembly (key cylinder switch). Refer to " «COMPONENT FUNCTION CHECK»(ref-523996-S25181805532013012500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- CHECK REMOTE KEYLESS ENTRY FUNCTION Check remote keyless entry function. Does door lock/unlock with Intelligent key button? YES: GO TO 2. NO: Go to " «DESCRIPTION»(ref-523998-S21193025972013012500000) ".
- CHECK POWER WINDOW OPERATION Check power window operation. Does power window up/down with power window main switch? YES: GO TO 3. NO: Go to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S25726071262013012500000) ".
- CHECK "PW DOWN SET" SETTING IN "WORK SUPPORT" Check "PW DOWN SET" setting in "WORK SUPPORT". Refer to " «INTELLIGENT KEY: CONSULT FUNCTION (BCM - INTELLIGENT KEY)»(ref-523998-S12694983672013012500000) ". Is the inspection result normal? YES: GO TO 4. NO: Set "PW DOWN SET" setting in "WORK SUPPORT".
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". NO: GO TO 1 .
- REPLACE POWER WINDOW MAIN SWITCH Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". : INSPECTION END
- REPLACE POWER WINDOW MAIN SWITCH Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S38447700232013012500000) ". : INSPECTION END
- REPLACE FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S30795211132013012500000) ". : INSPECTION END
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S24870136312013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness.
- REPLACE REAR POWER WINDOW SWITCH LH Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ". : INSPECTION END
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-523996-S24870136312013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness.
- REPLACE REAR POWER WINDOW SWITCH RH Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-523996-S08968486142013012500000) ". : INSPECTION END
