Mirrors (Without Adp): Removal & Installation Infiniti FX50 II

Mirrors 2 illustrations ~142 words

INSTALLATION

Install in the reverse order of removal.

Scheme 47

Scheme 47: DOOR MIRROR ASSEMBLY: Exploded View
Scheme 47: DOOR MIRROR ASSEMBLY: Exploded View

REMOVAL

  1. Remove front door finisher. Refer to «REMOVAL AND INSTALLATION»(ref-368866-S42566746702010081300000) .
  2. Remove front door sash inner cover. Refer to «EXPLODED VIEW»(ref-368906-S21701773472010081300000) .
  3. Disconnect door mirror harness connector.
  4. Remove door mirror mounting nuts, and remove door mirror assembly.

Install in the reverse order of removal.

CAUTIONPerform camera image calibration. Refer to CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): SPECIAL REPAIR REQUIREMENT .

Scheme 48

Scheme 48: DISASSEMBLY
Scheme 48: DISASSEMBLY
  1. Remove door mirror assembly. Refer to «DOOR MIRROR ASSEMBLY: REMOVAL AND INSTALLATION»(ref-368907-S27497572542010081300000) .
  2. Remove glass mirror. Refer to «GLASS MIRROR: DISASSEMBLY AND ASSEMBLY»(ref-368907-S20665230492010081300000) .
  3. Remove door mirror cover. Refer to «DOOR MIRROR COVER: DISASSEMBLY AND ASSEMBLY»(ref-368907-S07816855062010081300000) .
  4. Remove screws (A) and connector, and then remove actuator (1).
  5. Remove side camera and LED lamp. Refer to «REMOVAL AND INSTALLATION»(ref-368888-S28225644712010081300000) (SIDE CAMERA LH), «REMOVAL AND INSTALLATION»(ref-368888-S21461165902010081300000) (SIDE CAMERA RH).
  6. Remove base cover and puddle lamp.

Install in the reverse order of removal.
