Description
- Automatic drive positioner control unit controls door mirror.
- Automatic drive positioner control unit inputs changeover switch signal and performs the LH/RH control of door mirror motor supplying electric power when changeover switch is operated.
- Automatic drive positioner control unit inputs mirror switch signal and supplies electric power to door mirror.
- The ignition switch signal (ACC/ON) is transmitted from BCM to the driver seat control unit via CAN communication and from the driver seat control unit to the automatic drive positioner control unit via UART communication.
- Power is supplied to folding motor when operating the open/close switch.
Operation Conditions
If the following conditions are not satisfied, operation is not performed.
- Ignition switch: ON or ACC
- Changeover switch: Select either left or right
- Select one of the door mirror faces using change over switch, and then set the selected mirror face downward/inward.
- When the ignition switch is in the ON position and control device is in the R position, the TCM sends the R signal to the driver seat control unit. The R signal is transmitted to the automatic drive positioner control unit from the driver seat control unit via UART communication. When the R signal is detected, the automatic device positioner control unit activates the mirror motor.
If the following conditions are not satisfied, operation is not performed.
- Ignition switch: ON
- Changeover switch: Select either left or right
- A/T control device: R position
During the reverse interlock door mirror system, if all of the above conditions are not satisfied, mirror face returns to original angle.
Door mirror control is included in automatic drive positioner system. Refer to automatic drive positioner system for more details.
Refer to AUTOMATIC DRIVE POSITIONER SYSTEM: SYSTEM DESCRIPTION .
Scheme 1
Component Description
| Component | Function | |
|---|---|---|
| Automatic drive positioner control unit | Door mirror is supplied with power after receiving the input of the MIRROR SWITCH and CHANGEOVER SWITCH. | |
| Door mirror remote control switch | Mirror switch | It transmits mirror face adjust operation to AUTOMATIC DRIVE POSITIONER CONTROL UNIT. |
| Changeover switch | It transmits the LH/RH control of door mirror that supplies power to AUTOMATIC DRIVE POSITIONER CONTROL UNIT. | |
| Open/close switch | Power is supplied to folding mirror from door remote control switch when operating switch. | |
| Door mirror | Door mirror motor | It makes mirror face operate from side to side and up and down via integrated motor. |
| Folding motor | The door mirror operates because power is received from power supply when pressing door mirror remote control switch. | |
COMPONENT DESCRIPTION
System Description
The sensor built in inside mirror detects the brightness of headlight of the vehicle behind and automatically changes the light transmission to decrease the brightness.
| Component | Function |
|---|---|
| Auto anti-dazzling inside mirror | It automatically changes the light transmittance according to the brightness of the light from the headlight of the vehicle behind. |
COMPONENT DESCRIPTION
Diagnosis Description
The auto drive positioner system can be checked and diagnosed for component operation with CONSULT-III.
MIRROR SWITCH: Description
It operates angle of the door mirror face.
It transmits mirror face adjust operation to AUTOMATIC DRIVE POSITIONER CONTROL UNIT.
CHANGEOVER SWITCH: Description
Changeover switch is integrated into door mirror remote control switch.
Changeover switch has three positions (L, N and R).
It changes door mirror motor operation by transmitting control signal to automatic drive positioner control unit.
