Scheme 1
Component Description
| Part | Description |
|---|---|
| Total illumination control unit | Controls each interior room lamp and each illumination depending on the vehicle conditions and each signal. |
| BCM | Outputs room lamp timer signal and battery saver signal to the total illumination control unit depending on the vehicle conditions. Turns the step lamp ON/OFF according to any door switch status. Controls welcome light function of Intelligent Key system. |
| Combination meter | Illuminates the meter illumination according to request signals from BCM via CAN communication (through the unified meter and A/C amp. Outputs the illumination control signal to the total illumination control unit. |
| Remote keyless entry receiver | Receives the lock/unlock signal from keyfob. |
| Outside key antenna | Transmits the lock/unlock signal to BCM. |
| Request switch Key cylinder lock/unlock switch Door lock/unlock switch | Inputs the lock/unlock signal to BCM. |
| Door switch | Inputs the door switch signal to BCM and the total illumination control unit. |
| Tail lamp relay | Inputs the tail lamp signal to the total illumination control unit. |
| Map lamp main switch | Inputs the map lamp switch signal to the total illumination control unit. |
COMPONENT DESCRIPTION
Scheme 2
| Part | Description |
|---|---|
| Total illumination control unit | Cuts the hospitality lighting power supply according to interior room lamp power supply (battery saver signal). |
| BCM | Operates the interior room lamp battery saver depending on the vehicle condition to cut the interior room lamp power supply (battery saver signal). |
| Remote keyless entry receiver | Receives the lock/unlock signal from keyfob. Transmits the lock/unlock signal to BCM. |
| Request switch Key cylinder lock/unlock switch Door lock/unlock switch | Inputs the lock/unlock signal to BCM. |
| Door switch Back door switch | Inputs a switch signal to BCM. |
| Key slot | Inputs the key switch status to BCM. |
COMPONENT DESCRIPTION
Scheme 3
| Part | Description |
|---|---|
| BCM | Detects each switch condition by the combination switch reading function. Judges the illumination lamp ON/OFF status depending on the vehicle condition. And then it transmits position light request signal to IPDM E/R and combination meter via CAN communication, through the unified meter and A/C amp. |
| IPDM E/R | Controls the integrated relay according to the request from BCM via CAN communication. |
| Combination meter | Enters in the nighttime mode according to the request from BCM via CAN communication. Controls each illumination brightness in the nighttime mode. Refer to METER ILLUMINATION CONTROL: SYSTEM DIAGRAM . |
| Total illumination control unit | Turns each illumination (linked with hospitality lighting system) ON according to tail lamp signal from IPDM E/R Controls each illumination (linked with hospitality lighting system) brightness according to the illumination control signal from combination meter. |
| Combination switch (Lighting & turn signal switch) | Refer to SYSTEM DIAGRAM . |
COMPONENT DESCRIPTION
Description
BCM provides the step lamp power supply. Also BCM outputs it as the battery saver signal to total illumination control unit. And BCM cuts the power supply when the interior room lamp battery saver is activated.
BCM cuts the interior room lamp power supply depending on the vehicle condition. Total illumination control unit cuts the hospitality lighting power supply according to interior room lamp power supply (battery saver signal). This function prevents the battery from over-discharging if the driver neglects turning OFF any lamps.
Total illumination control unit provides the following lamps power supply according to the battery saver signal from BCM.
- Mood lamps (rear door armrest)
- Foot lamps
- Map lamps
- Center console indirect illumination (Ambience lamp)
- Personal lamps
- Vanity mirror lamps
- Push-button ignition switch illumination
Total illumination control unit provides the following lamps power supply according to the battery saver signal from BCM.
- Puddle lamp
- Mood lamp (front door armrest)
Total illumination control unit provides the following illuminations power supply according to the battery saver signal from BCM.
Illuminations
- Trip computer switch
- Illumination control switch
- Multifunction switch
- Climate controlled seat switch
- LDW switch
- Snow mode switch
- Door mirror remote control switch
- AFS OFF switch
- Headlamp aiming switch
- Mode select switch
- Clock
- Steering switch
- IBA OFF switch
- DCA switch
- VDC OFF switch
Controls the lamp (ground side) by PWM signal (duty) when the map lamp main switch is DOOR.
Scheme 4
Controls the lamp (ground side) by PWM signal (duty) when map lamp main switch is DOOR.
Controls the lamp (ground side) by PWM signal (duty).
Controls the lamp (ground side) by PWM signal (duty).
Controls the lamp (ground side) by PWM signal (duty).
Controls the lamp (ground side) by PWM signal (duty).
Controls the lamp (ground side) by PWM signal (duty).
Controls the lamp (ground side) by PWM signal (duty).
Controls the lamp (ground side) by PWM signal (duty).
Controls the step lamp (ground side) to turn the step lamp ON and OFF.
Total illumination control unit inputs tail lamp signal from IPDM E/R.
HIGH FLASHER OPERATION
BCM detects the turn signal lamp circuit status by the current value.
BCM increases the turn signal lamp blinking speed if the bulb or harness open is detected with the turn signal lamp operating.
Note. The blinking speed is normal while activating the hazard warning lamp.
