APPLICATION ITEM
CONSULT-III performs the following functions via DDL2 communication line with the total illumination control unit.
| Diagnosis mode | Function Description |
|---|---|
| Work Support | Changes the setting for each function. |
| Data Monitor | Total illumination control unit input/output signals are displayed. |
| Active Test | The signals used to activate each device are forcibly supplied from total illumination control unit. |
| ECU Identification | Total illumination control unit part number is displayed. |
APPLICATION ITEM TABLE
Scheme 36
| Service item | Setting item | Setting | |
|---|---|---|---|
| FOOT LAMP FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (1.0 seconds (1) ) | Sets fade-in/fade-out time of the foot lamps. |
| FADE-OUT | 0 - 3.0 seconds (1.0 seconds (1) ) | ||
| MAP&PERSONAL LAMP FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (1.0 seconds (1) ) | Sets fade-in/fade-out time of the map lamps and personal lamps. |
| FADE-OUT | 0 - 3.0 seconds (1.0 seconds (1) ) | ||
| PUDDLE LAMP FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (0 seconds (1) ) | Sets fade-in/fade-out time of the puddle lamps. |
| FADE-OUT | 0 - 3.0 seconds (3.0 seconds (1) ) | ||
| MOOD LAMP FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (1.0 seconds (1) ) | Sets fade-in/fade-out time of the mood lamps. |
| FADE-OUT | 0 - 3.0 seconds (1.0 seconds (1) ) | ||
| AMBIENCE LAMP FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (1.0 seconds (1) ) | Sets fade-in/fade-out time of the ambience lamp (center console indirect illumination). |
| FADE-OUT | 0 - 3.0 seconds (1.0 seconds (1) ) | ||
| HSPL ILLUMINATION FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (1.0 seconds (1) ) | Sets fade-in/fade-out time of each illumination (linked with hospitality lighting). |
| FADE-OUT | 0 - 3.0 seconds (1.0 seconds (1) ) | ||
| E/G SW ILLUMI FADE-IN/OUT | FADE-IN | 0 - 3.0 seconds (1.5 seconds (1) ) | Sets fade-in/fade-out time of the engine switch illumination. |
| FADE-OUT | 0 - 3.0 seconds (1.5 seconds (1) ) | ||
| E/G SW ILL HEART BEAT FUNCTION | On (1) | With the engine switch illumination heart beat function | |
| Off | Without the engine switch illumination heart beat function | ||
| (1) Factory setting | |||
| (1) | Factory setting |
WORK SUPPORT
CONSULT-III performs the following functions via CAN communication with BCM.
| Diagnosis mode | Function Description |
|---|---|
| Work Support | Changes the setting for each system function. |
| Self Diagnostic Result | Displays the diagnosis results judged by BCM. |
| CAN Diag Support Monitor | Monitors the reception status of CAN communication viewed from BCM. Refer to CONSULT-III operation instructions. |
| Data Monitor | The BCM input/output signals are displayed. |
| Active Test | The signals used to activate each device are forcibly supplied from BCM. |
| ECU Identification | The BCM part number is displayed. |
| Configuration | Read and save the vehicle specification. Write the vehicle specification when replacing BCM. |
APPLICATION ITEM TABLE
SYSTEM APPLICATION
BCM can perform the following functions for each system.
Note. It can perform the diagnosis modes except the following for all sub system selection items.
| X: Applicable item | ||||
|---|---|---|---|---|
| System | Sub system selection item | Diagnosis mode | ||
| Work Support | Data Monitor | Active Test | ||
| Door lock | DOOR LOCK | X | X | X |
| Rear window defogger | REAR DEFOGGER | X | X | |
| Warning chime | BUZZER | X | X | |
| Interior room lamp timer | INT LAMP | X | X | X |
| Exterior lamp | HEAD LAMP | X | X | X |
| Wiper and washer | WIPER | X | X | X |
| Turn signal and hazard warning lamps | FLASHER | X | X | X |
| AIR CONDITIONER (1) | ||||
| Intelligent Key system Engine start system | INTELLIGENT KEY | X | X | X |
| Combination switch | COMB SW | X | ||
| Body control system | BCM | X | ||
| IVIS - NATS | IMMU | X | X | |
| Interior room lamp battery saver | BATTERY SAVER | X | X | X |
| Back door open | TRUNK | X | X | |
| Vehicle security system | THEFT ALM | X | X | X |
| RAP system | RETAINED PWR | X | ||
| Signal buffer system | SIGNAL BUFFER | X | X | |
| (1) This item is displayed, but is not used. | ||||
| (1) | This item is displayed, but is not used. |
SUB SYSTEM SELECTION ITEM TABLE
