ILLUMINATION CONTROL Infiniti FX50 II

Interior Lighting System 1 illustration ~165 words

ILLUMINATION CONTROL

  1. BCM detects the combination switch condition by the combination switch reading function.
  2. BCM transmits position light request signal to IPDM E/R and combination meter, through the unified meter and A/C amp. according to tail lamp ON condition.

Tail lamp ON condition

  1. Lighting switch 1ST
  2. Lighting switch 2ND
  3. Lighting switch AUTO, and the auto light function ON judgment (With auto light system) IPDM E/R turns the integrated tail lamp relay ON according to position light request signal. It provides the power supply to each illumination lamp. Total illumination control unit turns each illumination (linked with hospitality lighting system) ON according to tail lamp signal from IPDM E/R. Combination meter enters in the nighttime mode according to position light request signal, through the unified meter and A/C amp. Under the nighttime mode the combination meter controls each illumination brightness. Total illumination control unit controls each illumination (linked with hospitality lighting system) brightness according to the illumination control signal from combination meter.

Scheme 41

Scheme 41: Component Parts Location
Scheme 41: Component Parts Location
