ADJUSTMENTS

WARNINGVehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION.

Note. Band adjustments are not part of on-vehicle adjustment procedures. Band adjustments should only be performed during bench inspection or overhaul.

ADJUSTMENT OF A/T POSITION

  1. Loosen nut of control rod.
  2. Place PNP switch and selector lever in P position.
  3. While pressing lower lever toward rear of vehicle (in P position direction), tighten nut to specified torque. CAUTION: Do not push the bracket. :26 N.m (2.7 kg-m, 19 ft-lb)

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2: CHECKING OF A/T POSITION
Scheme 2: CHECKING OF A/T POSITION
  1. Place selector lever in P position, and turn ignition switch ON (Do not start engine).
  2. Make sure selector lever can be shifted to other than P position when brake pedal is depressed. Also make sure selector lever can be shifted from P position only when brake pedal is depressed.
  3. Move the selector lever and check for excessive effort, sticking, noise or rattle.
  4. Confirm the selector lever stops at each position with the feel of engagement when it is moved through all the positions. Check whether or not the actual position the selector lever is in matches the position shown by the shift position indicator and the transmission body.
  5. The method of operating the lever to individual positions correctly should be as shown in the figure.
  6. When selector button is pressed in P, R, or N position without applying forward/backward force to selector lever, check button operation for sticking.
  7. Confirm the back-up lamps illuminate only when lever is placed in the R position. Confirm the back-up lamps does not illuminate when selector lever is pushed against R position in the P or N position.
  8. Confirm the engine can only be started with the selector lever in the P and N positions.
  9. Make sure transmission is locked completely in P position.
  10. When selector lever is set to manual shift gate, make sure manual mode is displayed on combination meter. Shift selector lever to "+" and "-" sides, and make sure set shift position changes.
