Ventilation System: Removal & Installation Infiniti FX35 II

Automatic HVAC System 27 illustrations ~804 words

INSTALLATION

Installation is basically the reverse order of removal.

Replacement

Replace in-cabin microfilter.

Refer to " SCHEDULE 1 " and " SCHEDULE 2 ".

Affix a caution label inside the glove box when replacing filter.

Scheme 245

Scheme 245: FRONT

Scheme 246

Scheme 246: REAR

Scheme 247

Scheme 247: REMOVAL
  1. Remove cluster lid D. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting screw (A), and then remove center ventilator grilles (1) (left and right).

Installation is basically the reverse order of removal.

REMOVAL

Driver side

Scheme 248

Scheme 248: REMOVAL
  1. Remove ventilator duct (left). Refer to " «EXPLODED VIEW»(ref-337278-S21871653922009073100000) ".
  2. Remove mounting screws (A), and then remove side ventilator grille (left) (1).

Passenger side

Scheme 249

Scheme 249
  1. Remove ventilator duct (right). Refer to " «EXPLODED VIEW»(ref-337278-S21871653922009073100000) ".
  2. Remove mounting screws (A).
  3. Remove harness clip (B), and then remove side ventilator grille (right) (1).

Installation is basically the reverse order of removal.

Remove front defroster grilles (1), using remover tools (A).

Scheme 250

Scheme 250: REMOVAL

Installation is basically the reverse order of removal.

Remove side defroster grilles (left and right) (1), using remover tools (A).

Scheme 251

Scheme 251: REMOVAL

Installation is basically the reverse order of removal.

Scheme 252

Scheme 252: REMOVAL
  1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting screws (A), and then remove ventilator duct (left) (1) and ventilator duct (right) (2).

Installation is basically the reverse order of removal.

Scheme 253

Scheme 253: REMOVAL
  1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting screw (A), and then remove adaptor duct (1).

Installation is basically the reverse order of removal.

Scheme 254

Scheme 254: REMOVAL
  1. Remove side defroster nozzles. Refer to " «EXPLODED VIEW»(ref-337278-S21871653922009073100000) ".
  2. Remove defroster nozzle (1).

Installation is basically the reverse order of removal.

Driver side

Scheme 255

Scheme 255: REMOVAL
  1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting clip (A) and harness clip (B), and then remove side defroster nozzle (left) (1).

Passenger side

Scheme 256

Scheme 256
  1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting clip (A), and then remove side defroster nozzle (right) (1).

Installation is basically the reverse order of removal.

Scheme 257

Scheme 257: REMOVAL
  1. Remove front pillar garnishes. Refer to " «EXPLODED VIEW»(ref-337246-S00214158912009073100000) ".
  2. Remove mounting screws (A), and then remove side defroster ducts (left and right) (1).

Installation is basically the reverse order of removal.

Scheme 258

Scheme 258: REMOVAL
  1. Remove console rear finisher. Refer to " «EXPLODED VIEW»(ref-337259-S33801265162009073100000) ".
  2. Remove mounting screws (A), and then remove rear ventilator grille (1).

Installation is basically the reverse order of removal.

Scheme 259

Scheme 259: REMOVAL
  1. Remove center console assembly. Refer to " «EXPLODED VIEW»(ref-337259-S33801265162009073100000) ".
  2. Remove mounting screws (A), and then remove rear ventilator duct 1 (1).

Installation is basically the reverse order of removal.

Scheme 260

Scheme 260: REMOVAL
  1. Remove console rear finisher. Refer to " «EXPLODED VIEW»(ref-337259-S33801265162009073100000) ".
  2. Remove rear ventilator duct 2 (1).

Installation is basically the reverse order of removal.

Driver side

Scheme 261

Scheme 261: REMOVAL
  1. Remove foot grille (left) (1).

Passenger side

Scheme 262

Scheme 262
  1. Remove foot grille (right) (1).

Installation is basically the reverse order of removal.

Scheme 263

Scheme 263: REMOVAL

Scheme 264

Scheme 264
  1. Set the temperature at 18.0°C (60°F).
  2. Disconnect the battery cable from the negative terminal.
  3. Remove heater & cooling unit assembly. Refer to " «EXPLODED VIEW»(ref-337228-S34599796552009073100000) " (VQ35HR) or " «EXPLODED VIEW»(ref-337258-S07001654122009073100000) " (VK50VE).
  4. Remove mounting screws (A), and then remove heater pipe cover (1).
  5. Remove mounting screws (B), and then remove foot duct (left) (2).
  6. Remove air mix door motor (passenger side). Refer to " «EXPLODED VIEW»(ref-337230-S36539377172009073100000) ".
  7. Remove mode door motor and links. Refer to " «EXPLODED VIEW»(ref-337230-S36539377172009073100000) ".
  8. Remove mounting screws (A), and then remove evaporator cover (1).
  9. Remove mounting screws (B), and then remove foot duct (right) (2).

Installation is basically the reverse order of removal.

Scheme 265

Scheme 265: REMOVAL
  1. Remove instrument lower panel LH. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting screw (A), and then remove heater duct (1).

Installation is basically the reverse order of removal.

Scheme 266

Scheme 266: REMOVAL
  1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Remove mounting clips (A), and then remove rear floor duct 1 (1).

Installation is basically the reverse order of removal.

Scheme 267

Scheme 267: Exploded View

Scheme 268

Scheme 268: REMOVAL

Scheme 269

Scheme 269
  1. Remove instrument lower panel RH. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Disconnect AWD control unit connector (AWD). Refer to " «EXPLODED VIEW»(ref-337279-S36914789972009073100000) ".
  3. Disconnect ECM (1) connectors.
  4. Remove mounting nuts (A), and then remove ECM with bracket attached.
  5. Remove power steering control unit. Refer to " «EXPLODED VIEW»(ref-337290-S19738044282009073100000) ".
  6. Disconnect intake door motor connector and blower motor connector.
  7. Remove mounting bolt (A) and screw (B), from blower unit (1).
  8. Remove blower unit. CAUTION: Move blower unit rightward, and remove locating pin (1 part) and joint. Then remove blower unit downward.

Installation is basically the reverse order of removal.

CAUTIONMake sure locating pin (A) and joint (B) are securely inserted.

Scheme 270

Scheme 270

Scheme 271

Scheme 271: REMOVAL
  1. Remove instrument lower cover RH. Refer to " «EXPLODED VIEW»(ref-337259-S21570214892009073100000) ".
  2. Disconnect blower motor connector.
  3. Remove mounting screws (A), and then remove blower motor (1).

Installation is basically the reverse order of removal.
