O-Ring Part Numbers and Specifications
| Connection type | Piping connection point | Part number | QTY | O-ring size |
|---|
| New | Low-pressure pipe 1 to low-pressure pipe 2 (One-touch joint) | 92473 N8221 | 2 | 16 |
| Low-pressure pipe 2 to expansion valve | 92473 N8210 | 1 | 16 |
| High-pressure pipe 1 to high-pressure pipe 2 (One-touch joint) | 92471 N8221 | 2 | 8 |
| High-pressure pipe 3 to expansion valve | 92471 N8210 | 1 | 8 |
| High-pressure pipe 2 to high-pressure pipe 3 (One-touch joint) | 92471 N8221 | 2 | 8 |
| Condenser to high-pressure flexible hose (One-touch joint) | 92472 N8221 | 2 | 12 |
| Condenser to high-pressure pipe 1 (One-touch joint) | 92471 N8221 | 2 | 8 |
| Low-pressure flexible hose to low-pressure pipe 1 (One-touch joint) | 92473 N8221 | 2 | 16 |
| Low-pressure pipe to low-pressure flexible hose (VK45DE) | 92474 N8210 | 1 | 19 |
| Compressor to low-pressure flexible hose (VQ35DE) | 92474 N8210 | 1 | 19 |
| Compressor to low-pressure pipe (VK45DE) | 92474 N8210 | 1 | 19 |
| Compressor to high-pressure flexible hose | 92472 N8210 | 1 | 12 |
| Liquid tank to condenser pipe | Inlet | 92471 N8210 | 1 | 8 |
| Outlet | 1 |
| Former | Refrigerant pressure sensor to condenser | J2476 89956 | 1 | 10 |
| Expansion valve to evaporator | Inlet | 92475 71L00 | 1 | 12 |
| Outlet | 92475 72L00 | 1 | 16 |
O-RING PART NUMBERS AND SPECIFICATIONS
| WARNING | Make sure all refrigerant is discharged into the recycling equipment and the pressure in the system is less than atmospheric pressure. Then gradually loosen the discharge side hose fitting and remove it. |
| CAUTION | When replacing or cleaning refrigerant cycle components, observe the following. When the compressor is removed, store it in the same way at it is when mounted on the car. Failure to do so will cause lubricant to enter the low-pressure chamber. When connecting tubes, always use a torque wrench and a back-up wrench. After disconnecting tubes, immediately plug all openings to prevent entry of dust and moisture. When installing an air conditioner in the vehicle, connect the pipes at the final stage of the operation. Never remove the seal caps of pipes and other components until just before required for connection. Allow components stored in cool areas to warm to working area temperature before removing seal caps. This prevents condensation from forming inside A/C components. Thoroughly remove moisture from the refrigeration system before charging the refrigerant. Always replace used O-rings. When connecting tubes, apply lubricant to circle of the O-rings shown in illustration. Be careful not to apply lubricant to threaded portion. Name : Nissan A/C System Oil Type S O-ring must be closely attached to the groove of tube. When replacing the O-ring, be careful not to damage O-ring and tube. Connect tube until a click can be heard, then tighten the nut or bolt by hand. Make sure that the O-ring is installed to tube correctly. After connecting line, perform leak test and make sure that there is no leakage from connections. When the refrigerant leaking point is found, disconnect that line and replace the O-ring. Then tighten connections of seal seat to the specified torque. |
Scheme 1
