PARTS REQUIRING ANGULAR TIGHTENING

Use an angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts: Cylinder head bolts Main bearing cap bolts Connecting rod cap bolts Crankshaft pulley bolt (No angle wrench is required as the bolt flange is provided with notches for angular tightening)
Do not use a torque value for final tightening.
The torque value for these parts are for a preliminary step.
Ensure thread and seat surfaces are clean and coated with engine oil.

Scheme 1

Scheme 1: Removal Of Liquid Gasket Sealing

After removing mounting bolts and nuts, separate the mating surface using a seal cutter (SST) and remove old liquid gasket sealing. CAUTION: Be careful not to damage the mating surfaces.
In areas where seal cutter (SST) is difficult to use, use a plastic hammer to lightly tap (1) seal cutter where liquid gasket is applied. Use a plastic hammer to slide seal cutter (2) by tapping on the side. CAUTION: If for some unavoidable reason a tool such as a flat-bladed screwdriver is used, be careful not to damage the mating surfaces.

Scheme 2

Scheme 2: Liquid Gasket Application Procedure

Scheme 3

Scheme 4

Using a scraper, remove old liquid gasket adhering to liquid gasket application surface and the mating surface. Remove liquid gasket completely from the groove of the liquid gasket application surface, mounting bolts, and bolt holes.
Wipe liquid gasket application surface and the mating surface with white gasoline (lighting and heating use) to remove adhering moisture, grease and foreign materials.
Attach liquid gasket tube to tube presser [SST: WS39930000 (-)]. Use Genuine RTV Silicone Sealant or equivalent. Refer to RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS
Apply liquid gasket without breaks to the specified location with the specified dimensions. If there is a groove for the liquid gasket application, apply liquid gasket to the groove. As for the bolt holes, normally apply liquid gasket inside the holes. Occasionally, it should be applied outside the holes. Make sure to read the text of service manual. Within five minutes of liquid gasket application, install the mating component. If liquid gasket protrudes, wipe it off immediately. Do not retighten mounting bolts and nuts after the installation. After 30 minutes or more have passed from the installation, fill engine oil and engine coolant. CAUTION: If there are specific instructions in this manual, observe them.

GENERAL SPECIFICATIONS

Application	Specification
Displacement	213.45 Cu. In. (3.5L)
Bore	3.760 In. (95.5 mm)
Stroke	3.205 In. (81.4 mm)
Compression Pressure	142-185 psi (10.0-13.0 kg/cm 2 )
Compression Ratio	10.3:1
Fuel System	SFI

GENERAL SPECIFICATIONS

ENGINE VALVE CLEARANCE SPECIFICATIONS

Valve	In. (mm)
Exhaust	.011-.015 (.29-.37)
Intake	.010-.013 (.26-.34)

VALVE CLEARANCE SPECIFICATIONS

CRANKSHAFT MAIN BEARINGS & CONNECTING ROD BEARINGS SPECIFICATIONS

Application			In. (mm)
Crankshaft
End Play
Standard			.0039-.0098 (.10-.25)
Service Limit			.0118 (.30)
Runout			.0039 (.10)
Main Bearings
Journal Diameter (1)
Grade No. A			2.3612-2.3612 (59.974-59.975)
Grade No. B			2.3611-2.3612 (59.973-59.974)
Grade No. C			2.3611-2.3611 (59.972-59.973)
Grade No. D			2.3611-2.3611 (59.971-59.972)
Grade No. E			2.3610-2.3611 (59.970-59.971)
Grade No. F			2.3610-2.3610 (59.969-59.970)
Grade No. G			2.3610-2.3609 (59.968-59.969)
Grade No. H			2.3609-2.3609 (59.967-59.968)
Grade No. J			2.3609-2.3609 (59.966-59.967)
Grade No. K			2.3608-2.3609 (59.965-59.966)
Grade No. L			2.3608-2.3608 (59.964-59.965)
Grade No. M			2.3607-2.3608 (59.963-59.964)
Grade No. N			2.3607-2.3607 (59.962-59.963)
Grade No. P			2.3607-2.3607 (59.961-59.962)
Grade No. R			2.3606-2.3607 (59.960-59.961)
Grade No. S			2.3606-2.3606 (59.959-59.960)
Grade No. T			2.3605-2.3606 (59.958-59.959)
Grade No. U			2.3605-2.3605 (59.957-59.958)
Grade No. V			2.3605-2.3605 (59.956-59.957)
Grade No. W			2.3604-2.3605 (59.955-59.956)
Grade No. X			2.3604-2.3604 (59.954-59.955)
Grade No. Y			2.3603-2.3604 (59.953-59.954)
Grade No. 4			2.3603-2.3603 (59.952-59.953)
Grade No. 7			2.3603-2.3603 (59.951-59.952)
Journal Out-Of-Round			.0001 (.002)
Journal Taper			.0001 (.002)
Oil Clearance
Standard			.0014-.0018 (.035-.045)
Service Limit			.0026 (.065)
Connecting Rod Bearings
Journal Diameter (1)
Grade No. 0			2.0460-2.0462 (51.968-51.974)
Grade No. 1			2.0457-2.0460 (51.962-51968)
Grade No. 2			2.0455-2.0457 (51.956-51.962)
Journal Out-Of-Round			.0001 (.002)
Journal Taper			.0001 (.002)
Oil Clearance
Standard			.0013-.0023 (.034-.059)
Service Limit			.0028 (.070)
(1) To locate engine component grade marks (Scheme 5)- (Scheme 8).

(1)	To locate engine component grade marks (Scheme 5)- (Scheme 8).

CRANKSHAFT MAIN & CONNECTING ROD BEARINGS

MAIN BEARING SPECIFICATIONS

Grade Number (3)	ID Color	Thickness - In. (mm)
0	Black	.0787-.0789 (2.000-2.003)
1	Brown	.0789-.0790 (2.003-2.006)
2	Green	.0790-.0791 (2.006-2.009)
3	Yellow	.0791-.0792 (2.009-2.012)
4	Blue	.0792-.0793 (2.012-2.015)
5	Pink	.0793-.0794 (2.015-2.018)
6	Purple	.0794-.0796 (2.018-2.021)
7	White	.0796-.0797 (2.021-2.024)
(1) Width for all bearings is.783-.791 In. (19.9-20.1 mm). (2) Grade is the same for lower and upper bearings. (3) To locate engine component grade marks (Scheme 5)- (Scheme 8).

(1)	Width for all bearings is .783-.791 In. (19.9-20.1 mm).

(2)	Grade is the same for lower and upper bearings.

(3)	To locate engine component grade marks (Scheme 5)- (Scheme 8).

MAIN BEARING SPECIFICATIONS (MATCHED SET) (1) (2)

Grade Number (3)	ID Color	Thickness - In. (mm)
01
Lower	Brown/Black	.0787-.0789 (2.000-2.003
Upper	Brown/Black	.0789-.0790 (2.003-2.006)
12
Lower	Green/Brown	.0789-.0790 (2.003-2.006)
Upper	Green/Brown	.0790-.0791 (2.006-2.009)
23
Lower	Yellow/Green	.0790-.0791 (2.006-2.009)
Upper	Yellow/Green	.0791-.0792 (2.009-2.012)
34
Lower	Blue/Yellow	.0791-.0792 (2.009-2.012)
Upper	Blue/Yellow	.0792-.0793 (2.012-2.015)
45
Lower	Pink/Blue	.0792-.0793 (2.012-2.015)
Upper	Pink/Blue	.0793-.0794 (2.015-2.018)
56
Lower	Purple/Pink	.0793-.0794 (2.015-2.018)
Upper	Purple/Pink	.0794-.0796 (2.018-2.021)
67
Lower	White/Purple	.0794-.0796 (2.018-2.021)
Upper	White/Purple	.0796-.0797 (2.021-2.024)
(1) Width for all bearings is.783-.791 In. (19.9-20.1 mm). (2) Grade is different for lower and upper bearings. (3) To locate engine component grade marks (Scheme 5)- (Scheme 8).

(1)	Width for all bearings is .783-.791 In. (19.9-20.1 mm).

(2)	Grade is different for lower and upper bearings.

(3)	To locate engine component grade marks (Scheme 5)- (Scheme 8).

MAIN BEARING SPECIFICATIONS (MISMATCHED SET) (1) (2)

CONNECTING RODS SPECIFICATIONS

Application			In. (mm)
Bore Diameter
Pin Bore
Grade No. 0			.8661-.8664 (22.000-22.006)
Grade No. 1			.8664-.8666 (22.006-22.012)
Crankpin Bore			2.1654-2.1659 (55.000-55.013)
Center-To-Center Length			5.8110-5.8149 (144.15-144.25)
Maximum Bend Per 3.94 In. (100 mm)			.006 (.15)
Maximum Twist Per 3.94 In. (100 mm)			.012 (.30)
Side Play
Standard			.0079-.0138 (.20-.35)
Service Limit			.0157 (.40)

CONNECTING RODS

CONNECTING ROD BEARING SPECIFICATIONS

Grade Number	ID Color	Thickness - In. (mm)
0	Black	.0591-.0592 (1.500-1.503)
1	Brown	.0592-.0593 (1.503-1.506)
2	Green	.0593-.0594 (1.506-1.509)

CONNECTING ROD BEARING SPECIFICATIONS

PISTONS, PISTON PINS & PISTON RINGS SPECIFICATIONS

Application			In. (mm)
Pistons
Clearance			.0004-.0012 (.010-.030)
Diameter (1)
Grade No. 1			3.7590-3.7594 (95.480-95.490)
Grade No. 2			3.7594-3.7598 (95.490-95.500)
Grade No. 3			3.7598-3.7602 (95.000-95.510)
.008 In. (.20 mm) Oversize			3.7669-3.7681 (95.680-95.710)
Piston Pin Hole
Diameter
Grade No. 0			.8659-.8661 (21.993-21.999)
Grade No. 1			.8661-.8663 (21.999-22.005)
Pins
Diameter
Grade No. 01			.8657-.8659 (21.989-21.995)
Grade No. 02			.8659-.8662 (21.995-22.001)
Piston Interference Fit			.0001-.0002 (.002-.006)
Rod Bushing Clearance
Standard			.0002-.0007 (.005-.017)
Service Limit			.0012 (.030)
Rings
No. 1
End Gap			.0091-.0130 (.23-.33)
Limit			.0213 (.54)
Side Clearance			.0016-.0031 (.040-.080)
No. 2
End Gap			.0130-.0189 (.33-.48)
Limit			.0315 (.80)
Side Clearance			.0012-.0028 (.030-.070)
No. 3 (Oil Control)
End Gap			.0079-.0197 (.20-.50)
Limit			.0374 (.95)
Side Clearance			.0006-.0020 (.015-.050)
(1) To locate engine component grade marks (Scheme 5)- (Scheme 8).

(1)	To locate engine component grade marks (Scheme 5)- (Scheme 8).

PISTONS, PINS & RINGS

CYLINDER BLOCK SPECIFICATIONS

Application			In. (mm)
Cylinder Bore
Standard Diameter (1)
Grade No. 1			3.7598-3.7602 (95.500-95.510)
Grade No. 2			3.7602-3.7606 (95.510-95.520)
Grade No. 3			3.7606-3.7610 (95.520-95.530)
Main Journal Inner Diameter Grade (Without Bearing)
Journal Diameter (1)
Grade No. A			2.5194-2.5194 (63.993-63.994)
Grade No. B			2.5194-2.5195 (63.994-63.995)
Grade No. C			2.5195-2.5195 (63.995-63.996)
Grade No. D			2.5195-2.5196 (63.996-63.997)
Grade No. E			2.5196-2.5196 (63.997-63.998)
Grade No. F			2.5196-2.5196 (63.998-63.999)
Grade No. G			2.5196-2.5197 (63.999-64.000)
Grade No. H			2.5197-2.5197 (64.000-64.001)
Grade No. J			2.5197-2.5198 (64.001-64.002)
Grade No. K			2.5198-2.5198 (64.002-64.003)
Grade No. L			2.5198-2.5198 (64.003-64.004)
Grade No. M			2.5198-2.5199 (64.004-64.005)
Grade No. N			2.5199-2.5199 (64.005-64.006)
Grade No. P			2.5199-2.5200 (64.006-64.007)
Grade No. R			2.5200-2.5200 (64.007-64.008)
Grade No. S			2.5200-2.5200 (64.008-64.009)
Grade No. T			2.5200-2.5201 (64.009-64.010)
Grade No. U			2.5201-2.5201 (64.010-64.011)
Grade No. V			2.5201-2.5202 (64.011-64.012)
Grade No. W			2.5202-2.5202 (64.012-64.013)
Grade No. X			2.5202-2.5202 (64.013-64.014)
Grade No. Y			2.5202-2.5203 (64.014-64.015)
Grade No. 4			2.5203-2.5203 (64.015-64.016)
Grade No. 7			2.5203-2.5203 (64.016-64.017)
Maximum Taper			.0006 (.015)
Maximum Out-Of-Round			.0006 (.015)
Maximum Deck Warpage (2)			.004 (.10)
(1) To locate engine component grade marks (Scheme 5)- (Scheme 8). (2) Maximum resurfacing limit of cylinder block and cylinder head combined is.008 In. (.20).

(1)	To locate engine component grade marks (Scheme 5)- (Scheme 8).

(2)	Maximum resurfacing limit of cylinder block and cylinder head combined is .008 In. (.20).

CYLINDER BLOCK

OIL PUMP SPECIFICATIONS SPECIFICATIONS

Application	Clearance - In. (mm)
Body-To-Outer Rotor	.0045-.0102 (.114-.260)
Inner Rotor-To-Outer Rotor Tip	Less Than .0071 (.180)
Housing-To-Inner Rotor (1)	.0012-.0028 (.030-.070)
Housing-To-Outer Rotor (1)	.0020-.0043 (.050-.110)
Inner Rotor Shoulder-To-Housing	.0018-.0036 (.045-.091)
(1) Lay straightedge across gears and housing. Insert feeler gauge between straightedge and gear.

(1)	Lay straightedge across gears and housing. Insert feeler gauge between straightedge and gear.

OIL PUMP SPECIFICATIONS

ENGINE VALVES & VALVE SPRINGS SPECIFICATIONS

Application			In. (mm)
Intake Valves
Face Angle			45 Degrees 15 Min.-45 Degrees 45 Min.
Head Diameter			1.4567-1.4685 (37.00-37.30)
Valve Margin
Standard			.043 (1.1)
Limit			More Than .020 (.50)
Valve Length			3.794 (96.37)
Stem Diameter			.2348-.2354 (5.965-5.980)
Valve Tip Maximum Refinish			.008 (.20)
Exhaust Valves
Face Angle			45 Degrees 15 Min-45 Degrees 45 Min
Head Diameter			1.228-1.240 (31.20-31.50)
Valve Margin
Standard			.051 (1.3)
Limit			More Than .020 (.50)
Valve Length			3.697 (93.90)
Stem Diameter			.2344-.2350 (5.955-5.970)
Valve Tip Maximum Refinish			.008 (.20)
Valve Springs
Free Length			1.8531 (47.07)
Out-Of-Square			.083 (2.10)
Lbs. @ In. (kg @ mm)
Pressure
Standard Installed			37.3-42.3 @ 1.457 (17.0-19.2 @ 37.0)
Valve Open			84.0-94.6 @ 1.071 (38-43 @ 27.2)

VALVES & VALVE SPRINGS

CYLINDER HEAD SPECIFICATIONS

Application				In. (mm)
Cylinder Head Height (1)				4.972-4.980 (126.30-126.50)
Maximum Warpage (2)				.004 (.10)
Valve Seats
Seat Angle				45 Degrees
Seat Width
Exhaust				.051-.059 (1.29-1.51)
Intake				.043-.052 (1.09-1.31)
Seat Bore (Oversize)
Exhaust				1.2873-1.2880 (32.700-32.716)
Intake				1.5157-1.5164 (38.500-38.516)
Valve Guides
Cylinder Head Valve Guide Bore I.D.
Standard				.3927-.3935 (9.975-9.996)
Service Limit				.4006-.4014 (10.175-10.196)
Valve Guide I.D.				.2362-.2369 (6.000-6.018)
Valve Guide Installed Height				.496-.504 (12.60-12.80)
Valve Stem-To-Guide Oil Clearance
Exhaust
Standard				.0012-.0025 (.030-.063)
Service Limit				.0035 (.09)
Intake
Standard				.0008-.0021 (.020-.053)
Service Limit				.003 (.08)
(1) Measure from cylinder head cover surface to head gasket surface. (2) Maximum resurfacing limit of cylinder block and cylinder head combined is .008 (.20).

(1)	Measure from cylinder head cover surface to head gasket surface.

(2)	Maximum resurfacing limit of cylinder block and cylinder head combined is .008 (.20).

CYLINDER HEAD

CAMSHAFT SPECIFICATIONS

Application			In. (mm)
Bore Diameter
No. 1			1.0236-1.0244 (26.000-26.021)
No. 2, 3 & 4			.9252-.9260 (23.500-.23.521)
End Play
Standard			.0045-.0074 (.115-.188)
Service Limit			.0094 (.24)
Journal Diameter
No. 1			1.0211-1.0218 (25.935-25.955)
No. 2, 3 & 4			.9230-.9238 (23.445-23.465)
Camshaft Runout			Less Than .0020 (.050)
Sprocket Runout			Less Than .006 (.15)
Lobe Height
Standard			1.7663-1.7738 (44.865-45.055)
Service Limit			.008 (.20)
Oil Clearance
Standard
Journal No. 1			.0018-.0034 (.045-.086)
Journal No. 2, 3, & 4			.0014-.0030 (.035-.076)
Service Limit			.0059 (.150)

CAMSHAFT

VALVE LIFTERS SPECIFICATIONS

Application	In. (mm)
Bore Diameter	1.3386-1.3392 (34.000-34.016)
Lifter Diameter	1.3377-1.3381 (33.977-33.987)
Oil Clearance	.0005-.0015 (.013-.039)

VALVE LIFTERS

TORQUE SPECIFICATIONS

Application		Ft. Lbs. (N.m)
Camshaft Sprocket Bolts
Primary		76 (103)
Secondary		91 (123)
Connecting Rod Nut
Step 1		15 (20)
Step 2		(1)
Crankshaft Pulley Bolt
Step 1		32 (44)
Step 2		(2)
Cylinder Head Bolt (3)
Step 1		72 (98)
Step 2		Loosen to Zero
Step 3		29 (39)
Step 4		(4)
Step 5		(4)
Engine Mount
Bracket-To-Engine Bolt		36 (49)
Bracket-To-Mount Nut		36 (49)
Mount-To-Chassis Nut		36 (49)
Exhaust Manifold Nut (5)		23 (31)
Flywheel/Flexplate Bolt		65 (88)
Front Timing Chain Case Bolt (6)
8 mm Bolt		21 (28)
6 mm Bolt		115 INCH Lbs. (13)
Intake Manifold (7)
Step 1		62 INCH Lbs. (7)
Step 2		21 (29)
Step 3		21 (29)
Main Bearing Cap Bolt (8)
Step 1		26 (35)
Step 2		(4)
Oil Drain Plug		26 (35)
Oil Pan Bolt (Aluminum Pan) (9)		12-14 (16-19)
Oil Pump Pick-Up Tube-To-Oil Pump Bolt		16 (22)
Water Pump Bolt		21 (28)
INCH Lbs. (N.m)
Camshaft Bracket Bolt (10)
Step 1 (Bolts No. 7-10 First, Then Tighten Bolts No. 1-6)		18 (2)
Step 2 (Bolts No. 1 Through 10)		53 (6)
Step 3 (Bolts No. 1 to 6)		89 (10)
Step 4 (Bolts No. 7 to 10)		80 (9)
Intake Manifold Collector Bolt/Nut
Lower		97 (11)
Upper		97 (11)
Oil Pan Bolt (Steel Pan) (11)		80 (9)
Oil Pump Cover Bolt
Long Bolt		62 (7)
Short Bolt		62 (7)
Rear Oil Seal Retainer Bolt		89 (10)
Rear Timing Chain Case Bolt		115 (13)
Timing Chain Tensioner Bolt		72 (8)
(1) Tighten all bolts an additional 90 degrees. (2) Tighten bolt an additional 60 degrees. (3) Tighten in sequence. (Scheme 9) (4) Tighten bolts an additional 90 degrees. (5) Tighten in sequence. (Scheme 10) (6) Tighten in sequence. (Scheme 11) (7) Tighten in sequence. (Scheme 12) (8) Tighten in sequence. (Scheme 13) (9) Tighten in sequence. (Scheme 14) (10) Tighten in sequence. (Scheme 15) (11) Tighten in sequence. (Scheme 16)
