Audio: Removal & Installation Infiniti FX35 I

Installation

Install in the reverse order of removal.

Scheme 27

Install in the reverse order of removal.

Scheme 28

1. Remove front door finisher. Refer to «DOOR FINISHER»(ref-178951-S15349716202005062500000) .
2. Remove screws (3) and remove door speaker.

Install in the reverse order of removal.

Scheme 29

1. Remove rear door finisher. Refer to «DOOR FINISHER»(ref-178951-S15349716202005062500000) .
2. Remove screws (3) and remove rear speaker.

Install in the reverse order of removal.

1. When carrying audio unit body, do not touch internal mechanism access from cassette tape slot.
2. Be careful not to allow foreign matter from cassette tape slot.

Removal

1. Remove grille from instrument panel.
2. Remove screws (4) and disconnect connector.
3. Remove instrument speaker.

Install in the reverse order of removal.

Scheme 30

1. Remove rear pillar upper garnish assembly. Refer to «DOOR FINISHER»(ref-178951-S15349716202005062500000) .
2. Remove screws (4), and disconnect connector.
3. Remove tweeter.

Install in the reverse order of removal.

Scheme 31

1. Open luggage floor board.
2. Remove speaker clamp and harness clip.
3. Disconnect connector.
4. Remove woofer. CAUTION: Connectors must be placed in the left side, when installed.

Install in the reverse order of removal.

Scheme 32

Scheme 33

1. Remove luggage side right box assembly. Refer to illustration in «LUGGAGE FLOOR TRIM»(ref-178951-S05681723642005062500000) .
2. Remove nuts (3) with power tool, and remove BOSE speaker amp. from luggage room floor.
3. Remove nuts (2) with power tool, and remove assist bracket.
4. Remove nuts (4) with power tool, and remove bracket.

Install in the reverse order of removal.
