DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred) as much as possible when the customer brings the vehicle in. GO TO 2.
- REPRODUCE THE MALFUNCTION INFORMATION Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. GO TO 3.
- IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS" Use "Symptom diagnosis" from the symptom inspection result in step 2 . Then identify where to start performing the diagnosis based on possible causes and symptoms. GO TO 4.
- IDENTIFY MALFUNCTIONING PARTS WITH "COMPONENT DIAGNOSIS" Perform the diagnosis with "Component diagnosis" of the applicable system. GO TO 5.
- REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. GO TO 6.
- FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Is the malfunctioning part repaired or replaced? YES: Trouble diagnosis is completed. NO: GO TO 3 .
INITIALIZATION PROCEDURE
- Disconnect battery negative terminal or power window control unit connector. Reconnect it after a minute or more.
- Turn ignition switch ON.
- Operate power window switch to fully open door glass. This operation is unnecessary if door glass is already fully open.
- Pull and hold power window switch UP (AUTO-UP operation). Even after door glass stops at the fully closed position, pull the switch for 2 seconds or more.
- Initialization procedure is complete.
- Inspect anti-pinch function.
CHECK ANTI-PINCH FUNCTION
- Fully open door glass.
- Place a piece of wood near the fully closed position.
- Close door glass completely using AUTO-UP. Check that door glass lowers approximately 150 mm (5.9 in) without pinching piece of wood and stops. Check that door glass does not rise when operating power window main switch while lowering. CAUTION: Perform initialization when AUTO-UP operation or anti-pinch function does not operate normally. Check that AUTO-UP operates before inspection when initialization is performed. Never check with hands or other body parts because they may be pinched. Never get pinched. It may switch to the fail-safe mode if open/close operation is performed continuously without fully closing door glass. Perform initialization in the above situation. Refer to " «FAIL-SAFE»(ref-368786-S23645675332010081300000) ". Finish initialization. Otherwise, the next operation cannot be done. AUTO-UP operation Anti-pinch function Door key cylinder power window function
- Disconnect battery negative terminal or power window control unit connector. Reconnect it after a minute or more.
- Turn ignition switch ON.
- Operate power window switch to fully open door glass. This operation is unnecessary if door glass is already fully open.
- Pull and hold power window switch UP (AUTO-UP operation). Even after door glass stops at the fully closed position, pull the switch for 2 seconds or more.
- Initialization procedure is complete.
- Inspect anti-pinch function.
- Fully open door glass.
- Place a piece of wood near the fully closed position.
- Close door glass completely using AUTO-UP. Check that door glass lowers approximately 150 mm (5.9 in) without pinching piece of wood and stops. Check that door glass does not rise when operating power window main switch while lowering. CAUTION: Perform initialization when AUTO-UP operation or anti-pinch function does not operate normally. Check that AUTO-UP operates before inspection when initialization is performed. Never check with hands or other body parts because they may be pinched. Never get pinched. It may switch to the fail-safe mode if open/close operation is performed continuously without fully closing. Perform initialization in the above situation. Refer to " «FAIL-SAFE»(ref-368786-S23645675332010081300000) ". Finish initialization. Otherwise, the next operation cannot be done. AUTO-UP operation Anti-pinch function Door key cylinder power window function
Scheme 5
POWER WINDOW SYSTEM
- Power window system is operable during the retained power operation timer after turning ignition switch OFF.
- Power window main switch can open/close door glass.
- Front and rear power window switch can open/close the corresponding door glass.
- AUTO UP/DOWN operation can be performed when front power window switch turns to AUTO.
- Power window lock switch can lock all power windows other than driver seat.
- Power window serial link transmits the signals from power window main switch to front power window switch (passenger side).
- If door glass receives resistance that is the specified value or more while power window of front seat is in AUTO-UP operation, power window of front seat operates in the reverse direction.
- Hold the door key cylinder to the LOCK or UNLOCK direction for 1 second or more to OPEN or CLOSE front power windows when ignition switch OFF.
- Front power windows open when pressing Intelligent Key unlock button for 3 seconds.
RETAINED POWER FUNCTION CANCEL CONDITIONS
- Front door CLOSE (door switch OFF) --> OPEN (door switch ON).
- When ignition switch turns ON again.
- When timer times out. (45 seconds)
POWER WINDOW LOCK FUNCTION
Ground circuit inside power window main switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the power window main switch.
POWER WINDOW SERIAL LINK
- Front power window switches and BCM transmit and receive the power window serial link.
- Power window serial link transmits the power window main switch operation signals and IGN signal to power window main switch module, front power window switch (passenger side) module.
KEYLESS POWER WINDOW DOWN FUNCTION
Front power windows open when the unlock button on Intelligent Key is activated and kept pressed for more than 3* seconds with the ignition switch OFF. The windows keep opening if the unlock button is continuously pressed.
The power window opening stops when the following operations are performed.
- When the unlock button is kept pressed more than 15 seconds.
- When the ignition switch is turned ON while the power window opening is operated.
- When the unlock button is released.
While retained power operation activate, keyless power window down function cannot be operated.
Keyless power window down operation mode can be changed by "PW DOWN SET" mode in "WORK SUPPORT". Refer to " INTELLIGENT KEY : CONSULT-III FUNCTION (BCM - INTELLIGENT KEY) ".
Note. Use CONSULT-III to change settings. MODE 1 (3 sec)/MODE 2 (OFF)/MODE 3 (5 sec)
Scheme 6
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT-III.
| CONSULT screen item | Indication/Unit | Description | |
|---|---|---|---|
| Vehicle Speed | Km/h | Vehicle speed of the moment a particular DTC is detected | |
| Odo/Trip Meter | Km | Total mileage (Odometer value) of the moment a particular DTC is detected | |
| Vehicle Condition | SLEEP>LOCK | Power position status of the moment a particular DTC is detected | While turning BCM status from low power consumption mode to normal mode (Power supply position is "LOCK") |
| SLEEP>OFF | While turning BCM status from low power consumption mode to normal mode. Power supply position is "OFF". | ||
| LOCK>ACC | While turning power supply position from "LOCK" to "ACC" | ||
| ACC>ON | While turning power supply position from "ACC" to "IGN" | ||
| RUN>ACC | While turning power supply position from "RUN" to "ACC". Vehicle is stopping and selector lever is except P position. | ||
| CRANK>RUN | While turning power supply position from "CRANKING" to "RUN" (From cranking up the engine to run it) | ||
| RUN>URGENT | While turning power supply position from "RUN" to "ACC" (Emergency stop operation) | ||
| ACC>OFF | While turning power supply position from "ACC" to "OFF" | ||
| OFF>LOCK | While turning power supply position from "OFF" to "LOCK" | ||
| OFF>ACC | While turning power supply position from "OFF" to "ACC" | ||
| ON>CRANK | While turning power supply position from "IGN" to "CRANKING" | ||
| OFF>SLEEP | While turning BCM status from normal mode. Power supply position is "OFF" to low power consumption mode | ||
| LOCK>SLEEP | While turning BCM status from normal mode. Power supply position is "LOCK" to low power consumption mode. | ||
| LOCK | Power supply position is "LOCK". Ignition switch OFF with steering is locked. | ||
| OFF | Power supply position is "OFF". Ignition switch OFF with steering is unlocked. | ||
| ACC | Power supply position is "ACC" (Ignition switch ACC) | ||
| ON | Power supply position is "IGN" (Ignition switch ON with engine stopped) | ||
| ENGINE RUN | Power supply position is "RUN" (Ignition switch ON with engine running) | ||
| CRANKING | Power supply position is "CRANKING" (At engine cranking) | ||
| IGN Counter | 0 - 39 | The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. | |
FREEZE FRAME DATA
Data monitor
| Monitor Item | Description |
|---|---|
| DOOR SW-DR | Indicates [ON/OFF] condition of driver side door switch. |
| DOOR SW-AS | Indicates [ON/OFF] condition of passenger side door switch. |
DATA MONITOR REFERENCE
Component Function Check
- CHECK REAR POWER WINDOW OPERATION Check rear power window motor operation with rear power window switch. Is the inspection result normal? YES: Rear power window switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-368786-S16972220852010081300000) ".
DRIVER SIDE : Component Function Check
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) OPERATION Check front power window motor (driver side) operation with power window main switch. Is the inspection result normal? YES: Power window motor (driver side) is OK. NO: Refer to " «DRIVER SIDE : DIAGNOSIS PROCEDURE»(ref-368786-S42499160302010081300000) ".
PASSENGER SIDE : Component Function Check
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) OPERATION Check front power window motor (passenger side) operation with power window main switch or front power window switch (passenger side). Is the inspection result normal? YES: Power window motor (passenger side) is OK. NO: Refer to " «PASSENGER SIDE : DIAGNOSIS PROCEDURE»(ref-368786-S06713217072010081300000) ".
REAR LH : Component Function Check
- CHECK REAR POWER WINDOW MOTOR LH OPERATION Check rear power window motor LH operation with power window main switch or rear power window switch LH. Is the inspection result normal? YES: Power window motor LH is OK. NO: Refer to " «REAR LH : DIAGNOSIS PROCEDURE»(ref-368786-S26916122152010081300000) "
REAR RH : Component Function Check
- CHECK REAR POWER WINDOW MOTOR RH OPERATION Check rear power window motor RH operation with power window main switch or rear power window switch RH. Is the inspection result normal? YES: Power window motor RH is OK. NO: Refer to " «REAR RH : DIAGNOSIS PROCEDURE»(ref-368786-S34585561142010081300000) ".
- CHECK ENCODER OPERATION Check driver side door glass perform AUTO open/close operation normally by power window main switch. Is the inspection result normal? YES: Encoder is OK. NO: Refer to " «DRIVER SIDE : DIAGNOSIS PROCEDURE»(ref-368786-S07437610272010081300000) ".
Scheme 7
- CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between power window main switch harness connector and ground using oscilloscope. SIGNAL SPECIFICATION (+) (-) Signal (Reference value) Power window main switch Connector Terminal D8 9 Ground Refer to following signal 13 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: GO TO 2.
- CHECK ENCORDER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector and front power window motor (driver side) connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY SPECIFICATION Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 9 D10 3 Existed 13 5 Check continuity between power window main switch harness connector and ground. CONTINUITY SPECIFICATION Power window main switch Ground Continuity Connector Terminal D8 9 Not existed 13 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
- CHECK ENCORDER POWER SUPPLY CIRCUIT 1 Connect power window main switch connector. Turn ignition switch ON. Check voltage between front power window motor (driver side) harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Front power window motor (driver side) Connector Terminal D10 4 Ground Battery voltage Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
- CHECK ENCORDER POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY SPECIFICATION Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 15 D10 4 Existed Check continuity between power window main switch harness connector and ground. CONTINUITY SPECIFICATION Power window main switch Ground Continuity Connector Terminal D8 15 Not existed Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK GROUND CIRCUIT 1 Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY SPECIFICATION Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 2 D10 6 Existed Is the inspection result normal? YES: GO TO 6. NO: Repair or replace harness.
- CHECK GROUND CIRCUIT 2 Connect power window main switch connector. Check continuity between power window main switch harness connector and ground. CONTINUITY SPECIFICATION Power window main switch Ground Continuity Connector Terminal D8 2 Existed Is the inspection result normal? YES: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S07130339842010081300000) ". NO: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ".
- CHECK ENCODER OPERATION Check passenger side door glass perform AUTO open/close operation normally by power window main switch or front power window switch (passenger side). Is the inspection result normal? YES: Encoder is OK. NO: Refer to " «PASSENGER SIDE : DIAGNOSIS PROCEDURE»(ref-368786-S26033293442010081300000) ".
Scheme 8
- CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between front power window switch (passenger side) harness connector and ground using oscilloscope. SIGNAL SPECIFICATION (+) (-) Signal (Reference value) Front power window switch (passenger side) Connector Terminal D38 12 Ground Refer to following signal 15 Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: GO TO 2.
- CHECK ENCORDER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector and front power window motor (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. CONTINUITY SPECIFICATION Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 12 D40 5 Existed 15 3 Check continuity between front power window switch (passenger side) harness connector and ground. CONTINUITY SPECIFICATION Front power window switch (passenger side) Ground Continuity Connector Terminal D38 12 Not existed 15 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
- CHECK ENCORDER POWER SUPPLY CIRCUIT Connect front power window switch (passenger side) connector. Turn ignition switch ON. Check voltage between front power window motor (passenger side) harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Front power window motor (passenger side) Connector Terminal D40 4 Ground Battery voltage Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
- CHECK ENCODER POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. CONTINUITY SPECIFICATION Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 4 D40 4 Existed Check continuity between front power window switch (passenger side) harness connector and ground. CONTINUITY SPECIFICATION Front power window switch (passenger side) Ground Continuity Connector Terminal D38 4 Not existed Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK GROUND CIRCUIT 1 Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. CONTINUITY SPECIFICATION Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 3 D40 6 Existed Is the inspection result normal? YES: GO TO 6. NO: Repair or replace harness.
- CHECK GROUND CIRCUIT 2 Connect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and ground. CONTINUITY SPECIFICATION Front power window switch (passenger side) Ground Continuity Connector Terminal D38 3 Existed Is the inspection result normal? YES: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S07130339842010081300000) ". NO: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ".
POWER WINDOW MAIN SWITCH : Component Function Check
- CHECK POWER WINDOW SWITCH OUTPUT SIGNAL With CONSULT-III Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «DOOR LOCK : CONSULT-III FUNCTION (BCM - DOOR LOCK)»(ref-368800-S12814958392010081300000) ". CONDITION CHART Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «POWER WINDOW MAIN SWITCH : DIAGNOSIS PROCEDURE»(ref-368786-S27080006042010081300000) ".
Scheme 9
- CHECK POWER WINDOW SWITCH OUTPUT SIGNAL Turn ignition switch ON. Check signal between power window main switch harness connector and ground. SIGNAL SPECIFICATION (+) (-) Signal (Reference value) Power window main switch Connector Terminal D8 14 Ground Is the inspection result normal? YES: GO TO 4 . NO: GO TO 2.
- CHECK POWER WINDOW SERIAL LINK SIGNAL Turn ignition switch OFF. Disconnect power window main switch connector. Turn ignition switch ON. Check voltage between power window main switch harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Power window main switch Connector Terminal D8 14 Ground Battery voltage Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: GO TO 3.
- CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM connector and power window main switch connector. CONTINUITY SPECIFICATION BCM Power window main switch Continuity Connector Terminal Connector Terminal M123 132 D8 14 Existed Check continuity between BCM connector and ground. CONTINUITY SPECIFICATION BCM Ground Continuity Connector Terminal M123 132 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-368805-S10219545332010081300000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". INSPECTION END
FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : Component Function Check
- CHECK POWER WINDOW SWITCH OUTPUT SIGNAL With CONSULT-III Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «DOOR LOCK : CONSULT-III FUNCTION (BCM - DOOR LOCK)»(ref-368800-S12814958392010081300000) ". CONDITION CHART Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : DIAGNOSIS PROCEDURE»(ref-368786-S06706428762010081300000) ".
PHYSICAL VALUES
CONNECTOR TERMINAL REFERENCE Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (W) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (Y) Ground P/W power supply (BAT) Output Ignition switch OFF Battery voltage 3 (O) Ground P/W power supply (RAP) Output Ignition switch ON Battery voltage 4 (LG) Ground Interior room lamp power supply Output Interior room lamp battery saver is activated. (Cuts the interior room lamp power supply) 0 V Interior room lamp battery saver is not activated. (Outputs the interior room lamp power supply) Battery voltage 5 (L) Ground Passenger door UNLOCK Output Passenger door UNLOCK (Actuator is activated) Battery voltage Other than UNLOCK (Actuator is not activated) 0 V 7 (Y) Ground Step lamp Output Step lamp ON 0 V OFF Battery voltage 8 (V) Ground All doors, fuel lid LOCK Output All doors LOCK (Actuator is activated) Battery voltage Other than LOCK (Actuator is not activated) 0 V 9 (G) Ground Driver door, fuel lid UNLOCK Output Driver door UNLOCK (Actuator is activated) Battery voltage Other than UNLOCK (Actuator is not activated) 0 V 10 (BR) Ground Rear RH door and rear LH door UNLOCK Output Rear RH door and rear LH door UNLOCK (Actuator is activated) Battery voltage Other than UNLOCK (Actuator is not activated) 0 V 11 (R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0 V 14 (W) Ground Push-button ignition switch illumination ground Output Tail lamp OFF 0 V ON NOTE: When the illumination brightening/dimming level is in the neutral position 15 (Y) Ground ACC indicator lamp Output Ignition switch OFF or ON Battery voltage ACC 0 V 17 (W) Ground Turn signal RH (Front) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 6.5 V 18 (O) Ground Turn signal LH (Front) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 19 (V) Ground Room lamp timer control Output Interior room lamp OFF Battery voltage ON 0 V 20 (V) Ground Turn signal RH (Rear) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 23 (G) Ground Back door open Output Back door OPEN (Back door opener actuator is activated) Battery voltage Other than OPEN (Back door opener actuator is not activated) 0 V 25 (G) Ground Turn signal LH (Rear) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 26 (G) Ground Rear wiper Output Rear wiper OFF (Stopped) 0 V ON (Operated) Battery voltage 34 (SB) Ground Luggage room antenna (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 35 (V) Ground Luggage room antenna (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 38 (B) Ground Back door antenna (-) Output When the back door opener request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 39 (W) Ground Back door antenna (+) Output When the back door opener request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 47 (Y) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC Battery voltage ON 0 V 52(SB) Ground Starter relay control Output Ignition switch ON When selector lever is in P or N position Battery voltage When selector lever is not in P or N position 0 V 61 (W) Ground Back door opener request switch Input Back door opener request switch ON (Pressed) 0 V OFF (Not pressed) 64 (V) Ground Intelligent Key warning buzzer (Engine room) Output Intelligent Key warning buzzer (Engine room) Sounding 0 V Not sounding Battery voltage 65 (O) Ground Rear wiper stop position Input Rear wiper In stop position Not in stop position 0 V 66 (R) Ground Back door switch Input Back door switch OFF (Door close) ON (Door open) 0 V 67 (G) Ground Back door opener switch Input Back door opener switch Pressed 0 V Not pressed 68 (BR) Ground Rear RH door switch Input Rear RH door switch OFF (Door close) ON (Door open) 0 V 69 (R) Ground Rear LH door switch Input Rear LH door switch OFF (Door close) ON (Door open) 0 V 72 (R) Ground Room antenna 2 (-) (Center console) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 73 (G) Ground Room antenna 2 (+) (Center console) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 74 (SB) Ground Passenger door antenna (-) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 75 (GR) Ground Passenger door antenna (+) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 76 (V) Ground Driver door antenna (-) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 77 (LG) Ground Driver door antenna (+) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 78 (Y) Ground Room antenna 1 (-) (Instrument panel) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 79 (BR) Ground Room antenna 1 (+) (Instrument panel) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 80 (GR) Ground NATS antenna amp (Built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 81 (W) Ground NATS antenna amp (Built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 82 (R) Ground Ignition relay [Fuse block (J/B)] control Output Ignition switch OFF or ACC 0 V ON Battery voltage 83 (Y) Ground Remote keyless entry receiver communication Input/Output During waiting When operating either button on the key 87 (BR) Ground Combination switch INPUT 5 Input Combination switch All switches OFF (Wiper intermittent dial 4) Front fog lamp switch ON (Wiper intermittent dial 4) Rear wiper switch ON (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 88 (V) Ground Combination switch INPUT 3 Input Combination switch All switches OFF (Wiper intermittent dial 4) Lighting switch HI (Wiper intermittent dial 4) Lighting switch 2ND (Wiper intermittent dial 4) Rear washer switch ON (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 89 (BR) Ground Push-button ignition switch (Push switch) Input Push-button ignition switch (push switch) Pressed 0 V Not pressed Battery voltage 90 (P) Ground CAN-L Input/Output - - 91 (L) Ground CAN-H Input/Output - - 92 (LG) Ground Key slot illumination Output Key slot illumination OFF 0 V Blinking ON Battery voltage 93 (V) Ground ON indicator lamp Output Ignition switch OFF or ACC Battery voltage ON 0 V 94 (Y) Ground Puddle lamp control Output Puddle lamp OFF Battery voltage ON 0 V 95 (O) Ground ACC relay control Output Ignition switch OFF 0 V ACC or ON Battery voltage 96 (GR) Ground Control device (Detention switch) power supply Output - Battery voltage 97 (L) Ground Steering lock condition No. 1 Input Steering lock LOCK status 0 V UNLOCK status Battery voltage 98 (P) Ground Steering lock condition No. 2 Input Steering lock LOCK status Battery voltage UNLOCK status 0 V 99 (R) Ground Selector lever P position switch Input Selector lever P position 0 V Any position other than P Battery voltage 100 (G) Ground Passenger door request switch Input Passenger door request switch ON (Pressed) 0 V OFF (Not pressed) 101 (SB) Ground Driver door request switch Input Driver door request switch ON (Pressed) 0 V OFF (Not pressed) 102 (O) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0 V ON Battery voltage 103 (LG) Ground Remote keyless entry receiver power supply Output Ignition switch OFF Battery voltage 106 (W) Ground Steering lock unit power supply Output Ignition switch OFF or ACC Battery voltage ON 0 V 107 (LG) Ground Combination switch INPUT 1 Input Combination switch (Wiper intermittent dial 4) All switches OFF Turn signal switch LH Turn signal switch RH Front wiper switch LO Front washer switch ON 108 (R) Ground Combination switch INPUT 4 Input Combination switch All switches OFF (Wiper intermittent dial 4) Lighting switch AUTO (Wiper intermittent dial 4) Lighting switch 1ST (Wiper intermittent dial 4) Rear wiper switch INT (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 109 (Y) Ground Combination switch INPUT 2 Input Combination switch (Wiper intermittent dial 4) All switches OFF Lighting switch PASS Lighting switch 2ND Front wiper switch INT Front wiper switch HI 110 (G) Ground Hazard switch Input Hazard switch ON 0 V OFF 111 (Y) Ground Steering lock unit communication Input/Output Steering lock LOCK status Battery voltage LOCK or UNLOCK For 15 seconds after UNLOCK Battery voltage 15 seconds or later after UNLOCK 0 V 113 (P) Ground Optical sensor Input Ignition switch ON When bright outside of the vehicle Close to 5 V When dark outside of the vehicle Close to 0 V 116 (SB) Ground Stop lamp switch 1 Input - Battery voltage 118 (P) Ground Stop lamp switch 2 (Without ICC) Input Stop lamp switch OFF (Brake pedal is not depressed) 0 V ON (Brake pedal is depressed) Battery voltage Stop lamp switch 2 (With ICC) Stop lamp switch OFF (Brake pedal is not depressed) and ICC brake hold relay OFF 0 V Stop lamp switch ON (Brake pedal is depressed) or ICC brake hold relay ON Battery voltage 119 (SB) Ground Front door lock assembly driver side (Unlock sensor) Input Driver door LOCK status (Unlock sensor switch OFF) UNLOCK status (Unlock switch sensor ON) 0 V 121 (BR) Ground Key slot switch Input When the key is inserted into key slot Battery voltage When the key is not inserted into key slot 0 V 123 (W) Ground IGN feedback Input Ignition switch OFF or ACC 0 V ON Battery voltage 124 (LG) Ground Passenger door switch Input Passenger door switch OFF (Door close) ON (Door open) 0 V 132 (V) Ground Power window switch communication Input/Output Ignition switch ON Ignition switch OFF or ACC Battery voltage 133 (W) Ground Push-button ignition switch illumination Output Push-button ignition switch illumination ON (Tail lamps OFF) 9.5 V ON (Tail lamps ON) NOTE: The pulse width of this wave is varied by the illumination brightening/dimming level. OFF 0 V 134 (GR) Ground LOCK indicator lamp Output LOCK indicator lamp OFF Battery voltage ON 0 V 137 (O) Ground Receiver and sensor ground Input Ignition switch ON 0 V 138 (Y) Ground Receiver and sensor power supply Output Ignition switch OFF 0 V ACC or ON 5.0 V 139 (L) Ground Tire pressure receiver communication Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 140 (GR) Ground Selector lever P/N position Input Selector lever P or N position Battery voltage Except P and N positions 0 V 141 (G) Ground Security indicator Output Security indicator ON 0 V Blinking OFF Battery voltage 142 (O) Ground Combination switch OUTPUT 5 Output Combination switch (Wiper intermittent dial 4) All switches OFF 0 V Lighting switch 1ST Lighting switch HI Lighting switch 2ND Turn signal switch RH 143 (P) Ground Combination switch OUTPUT 1 Output Combination switch All switches OFF (Wiper intermittent dial 4) 0 V Front wiper switch HI (Wiper intermittent dial 4) Rear wiper switch INT (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 144 (G) Ground Combination switch OUTPUT 2 Output Combination switch All switches OFF (Wiper intermittent dial 4) 0 V Front washer switch ON (Wiper intermittent dial 4) Rear wiper switch ON (Wiper intermittent dial 4) Rear washer switch ON (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 145 (L) Ground Combination switch OUTPUT 3 Output Combination switch (Wiper intermittent dial 4) All switches OFF 0 V Front wiper switch INT Front wiper switch LO Lighting switch AUTO 146 (SB) Ground Combination switch OUTPUT 4 Output Combination switch (Wiper intermittent dial 4) All switches OFF 0 V Front fog lamp switch ON Lighting switch 2ND Lighting switch PASS Turn signal switch LH 149 (W) Ground Tire pressure warning check switch Input Ignition switch ON 150 (LG) Ground Driver door switch Input Driver door switch OFF (Door close) ON (Door open) 0 V 151 (G) Ground Rear window defogger relay control Output Rear window defogger Active 0 V Not activated Battery voltage
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
REAR WIPER MOTOR PROTECTION
BCM detects the rear wiper stopping position according to the rear wiper stop position signal.
When the rear wiper stop position signal does not change for more than 5 seconds while driving the rear wiper, BCM stops power supply to protect the rear wiper motor.
Condition of cancellation
- More than 1 minute is passed after the rear wiper stops.
- Turn rear wiper switch OFF.
- Operate the rear wiper switch or rear washer switch.
POWER WINDOW MAIN SWITCH
CONNECTOR TERMINAL REFERENCE Terminal No. (Wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 1 (W) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is UP at operated Battery voltage 2 (R) Ground Encoder ground - - 0 3 (GR) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is DOWN at operated Battery voltage 4 (V) Ground Door key cylinder switch LH LOCK signal Input Key position (Neutral --> Locked) 5 --> 0 5 (O) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is DOWN at operated Battery voltage 6 (Y) Ground Door key cylinder switch LH UNLOCK signal Input Key position (Neutral --> Unlocked) 5 --> 0 7 (BR) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is UP at operated Battery voltage 8 (L) Ground Front power window motor (driver side) UP signal Output When front LH switch in power window main switch is UP at operated Battery voltage 9 (O) Ground Encoder pulse signal 2 Input When front power window motor (driver side) operates 10 (SB) Ground Retained power signal Input Ignition switch ON Battery voltage Within 45 seconds after ignition switch is turned to OFF Battery voltage When driver side or passenger side door is opened during retained power operation 0 11 (G) Ground Front power window motor (driver side) DOWN signal Output When front LH switch in power window main switch is DOWN at operated Battery voltage 13 (P) Ground Encoder pulse signal 1 Input When front power window motor (driver side) operates. 14 (V) Ground Power window serial link Input/Output Ignition switch ON or power window timer operating 15 (B) Ground Encoder power supply Output Ignition switch ON Battery voltage 17 (B) Ground Ground - - 0 19 (Y) Ground Battery power supply Input Ignition switch OFF Battery voltage
Scheme 43
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
FAIL-SAFE CONTROL
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when a signal that is out of the specified value is detected between the fully closed position and the actual position of the glass.
| Malfunction | Malfunction condition |
|---|---|
| Pulse sensor malfunction | When one pulse signal that is the specified value or more is detected continuously for the specified time or more, while door glass is being operated UP or DOWN. |
| Both pulse sensors malfunction | When both pulse signals are not detected continuously for the specified time or more, while door glass is being operated UP or DOWN. |
| Pulse direction malfunction | When a pulse signal indicating that window is moving in the opposite direction against the power window motor is detected for the specified value or more, while door glass is being operated UP or DOWN. |
| Glass recognition position malfunction 1 | When the actual door glass position that is out of specified value is detected compared to the door glass fully closed position memorized in module, while door glass is being operated UP or DOWN. |
| Glass recognition position malfunction 2 | When pulse count that is out of the door glass full stroke value or more is detected, while door glass is being operated UP or DOWN. |
MALFUNCTION CONDITION CHART
If fail-safe control, the system changes to a non-initialized condition and the following function do not operate.
- Auto-up operation
- Anti-pinch function
- Door key cylinder switch power window function
When fail-safe control is activated, perform initialization procedure to recover. If a malfunction is detected in power window switch or more, fail-safe control is activated again.
Scheme 50
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
CONNECTOR TERMINAL REFERENCE Terminal No. Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 3 (L) Ground Encoder ground - - 0 4 (GR) Ground Encoder power supply Output When ignition switch ON or power window timer operates Battery voltage 8 (L) Ground Power window motor UP signal Output When power window motor is UP at operated. Battery voltage 9 (G) Ground Power window motor DOWN signal Output When power window motor is DOWN at operated. Battery voltage 10 (Y) Ground Battery power supply Input - Battery voltage 11 (B) Ground Ground - - 0 12 (P) Ground Encoder pulse signal 1 Input When power window motor operates. 15 (O) Ground Encoder pulse signal 2 Input When power window motor operates. 16 (V) Ground Power window serial link Input/Output Ignition switch ON or power window timer operating
Scheme 51
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when a signal that is out of the specified value is detected between the fully closed position and the actual position of the glass.
| Malfunction | Malfunction condition |
|---|---|
| Pulse sensor malfunction | When one pulse signal that is the specified value or more is detected continuously for the specified time or more, while door glass is being operated UP or DOWN. |
| Both pulse sensors malfunction | When both pulse signals are not detected continuously for the specified time or more, while door glass is being operated UP or DOWN. |
| Pulse direction malfunction | When a pulse signal indicating that window is moving in the opposite direction against the power window motor is detected for the specified value or more, while door glass is being operated UP or DOWN. |
| Glass recognition position malfunction 1 | When the actual door glass position that is out of specified value is detected compared to the door glass fully closed position memorized in module, while door glass is being operated UP or DOWN. |
| Glass recognition position malfunction 2 | When pulse count that is out of the door glass full stroke value or more is detected, while door glass is being operated UP or DOWN. |
MALFUNCTION CONDITION CHART
If fail-safe control, the system changes to a non-initialized condition and the following function do not operate.
- Auto-up operation
- Anti-pinch function
- Door key cylinder switch power window function
When fail-safe control is activated, perform initialization procedure to recover. If a malfunction is detected in power window switch or more, fail-safe control is activated again.
