BCM : Diagnosis Procedure
- CHECK FUSE AND FUSIBLE LINK Check that the following fuse and fusible link are not blown. FUSE AND FUSIBLE LINK REFERENCE Terminal No. Signal name Fuse and fusible link No. 1 Battery power supply K (40 A) 11 10 (10 A) Is the fuse fusing? YES: Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is blown. NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect BCM connectors. Check voltage between BCM harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (Approx.) BCM Connector Terminal M118 1 Ground Battery voltage M119 11 Is the measurement value normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK GROUND CIRCUIT Check continuity between BCM harness connector and ground. CONTINUITY SPECIFICATION BCM Ground Continuity Connector Terminal M119 13 Existed Does continuity exist? YES: INSPECTION END NO: Repair harness or connector.
POWER WINDOW MAIN SWITCH : Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect power window main switch connectors. Turn ignition switch ON. Check voltage between power window main switch harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Power window main switch Connector Terminal D8 10 Ground Battery voltage D9 19 Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and power window main switch harness connector. CONTINUITY SPECIFICATION BCM Power window main switch Continuity Connector Terminal Connector Terminal M118 2 D9 19 Existed 3 D8 10 Check continuity between BCM harness connector and ground. CONTINUITY SPECIFICATION BCM Ground Continuity Connector Terminal M118 2 Not existed 3 Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-368805-S10219545332010081300000) ". NO: Repair or replace harness.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between power window main switch harness connector and ground. CONTINUITY SPECIFICATION Power window main switch Ground Continuity Connector Terminal D9 17 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.
FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check voltage between front power window switch (passenger side) harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Front power window switch (passenger side) Connector Terminal D38 10 Ground Battery voltage Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT 2 Disconnect BCM connector. Check continuity between BCM harness connector and front power window switch (passenger side) harness connector. CONTINUITY SPECIFICATION BCM Front power window switch (passenger side) Continuity Connector Terminal Connector Terminal M118 2 D38 10 Existed Check continuity between BCM harness connector and ground. CONTINUITY SPECIFICATION BCM Ground Continuity Connector Terminal M118 2 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-368805-S10219545332010081300000) ". NO: Repair or replace harness.
- CHECK GROUND CIRCUIT Check continuity between front power window switch (passenger side) harness connector and ground. CONTINUITY SPECIFICATION Front power window switch (passenger side) Ground Continuity Connector Terminal D38 11 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.
REAR POWER WINDOW SWITCH : Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect rear power window switch LH connectors or rear power window switch RH. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Rear power window switch Connector Terminal LH D54 1 Ground Battery voltage RH D74 Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and rear power window switch harness connector. CONTINUITY SPECIFICATION BCM Rear power window switch Continuity Connector Terminal Connector Terminal M118 3 LH D54 1 Existed RH D74 Check continuity between BCM harness connector and ground. CONTINUITY SPECIFICATION BCM Ground Continuity Connector Terminal M118 3 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-368805-S10219545332010081300000) ". NO: Repair or replace harness.
- CHECK GROUND CIRCUIT Check continuity between rear power window switch harness connector and ground. CONTINUITY SPECIFICATION Rear power window switch Ground Continuity Connector Terminal LH D54 7 Existed RH D74 Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.
Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window switch LH or rear power window switch RH. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Condition Voltage (V) (Approx.) Rear power window switch Connector Terminal LH D54 2 Ground Power window main switch (rear LH) UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage RH D74 2 Power window main switch (rear RH) UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK REAR POWER WINDOW SWITCH CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and rear power window switch harness connector. CONTINUITY SPECIFICATION Power window main switch Rear power window switch Continuity Connector Terminal Connector Terminal D8 1 LH D54 2 Existed 3 3 5 RH D74 3 7 2 Check continuity between power window main switch connector and ground. CONTINUITY SPECIFICATION Power window main switch Ground Continuity Connector Terminal D8 1 Not existed 3 5 7 Is the inspection result normal? YES: Replace power window main switch. . " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT INSPECTION»(ref-368786-S06532044912010081300000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) " INSPECTION END
Component Inspection
- CHECK REAR POWER WINDOW SWITCH Turn ignition switch OFF. Disconnect rear power window switch terminals. Check rear power window switch. CONTINUITY SPECIFICATION Rear power window switch Terminal Power window switch condition Continuity D54 (LH) D74 (RH) 1 5 UP Existed 3 4 3 4 NEUTRAL 5 2 1 4 DOWN 5 2 Is the inspection result normal? YES: Rear power window switch is OK. NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ".
DRIVER SIDE : Diagnosis Procedure
- CHECK FRONT POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor (driver side) connector. Turn ignition switch ON. Check voltage between front power window motor (driver side) harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Condition Voltage (V) (Approx.) Front power window motor (driver side) Connector Terminal D10 2 Ground Power window main switch UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY SPECIFICATION Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D8 8 D10 2 Existed 11 1 Check continuity between power window main switch harness connector and ground. CONTINUITY SPECIFICATION Power window main switch Ground Continuity Connector Terminal D8 8 Not existed 11 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) Check front power window motor (driver side). Refer to " «DRIVER SIDE : COMPONENT INSPECTION»(ref-368786-S31114397322010081300000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S07130339842010081300000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". INSPECTION END
DRIVER SIDE : Component Inspection
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) Turn ignition switch OFF. Disconnect front power window motor (driver side) connector. Check motor operation by connecting the battery voltage directly to front power window motor (driver side) terminals. VOLTAGE SPECIFICATION Front power window motor (driver side) connector Terminal Motor operation (+) (-) D10 1 2 DOWN 2 1 UP Is the inspection result normal? YES: Front power window motor (driver side) is OK. NO: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S07130339842010081300000) ".
PASSENGER SIDE : Diagnosis Procedure
- CHECK FRONT POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor (passenger side) connector. Turn ignition switch ON. Check voltage between front power window motor (passenger side) harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Condition Voltage (V) (Approx.) Front power window motor (passenger side) Connector Terminal D40 1 Ground Front power window switch (passenger side) UP Battery voltage DOWN 0 2 UP 0 DOWN Battery voltage Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK POWER WINDOW MOTOR (PASSENGER SIDE) CIRCUIT Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. CONTINUITY SPECIFICATION Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D38 9 D40 1 Existed 8 2 Check continuity between front power window switch (passenger side) connector and ground. CONTINUITY SPECIFICATION Front power window switch (passenger side) Ground Continuity Connector Terminal D38 8 Not existed 9 Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) Check front power window motor (passenger side). Refer to " «PASSENGER SIDE : COMPONENT INSPECTION»(ref-368786-S40839684092010081300000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S07130339842010081300000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". INSPECTION END
PASSENGER SIDE : Component Inspection
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) Turn ignition switch OFF. Disconnect front power window motor (passenger side) connector. Check motor operation by connecting the battery voltage directly to front power window motor (passenger side) terminals. VOLTAGE SPECIFICATION Front power window motor (passenger side) connector Terminal Motor condition (+) (-) D40 2 1 DOWN 1 2 UP Is the inspection result normal? YES: Front power window motor (passenger side) is OK. NO: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S07130339842010081300000) ".
REAR LH : Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor LH connector. Turn ignition switch ON. Check voltage between rear power window motor LH harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Condition Voltage (V) (Approx.) Rear power window motor LH Connector Terminal D52 1 Ground Rear power window switch LH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH harness connector and rear power window motor LH harness connector. CONTINUITY SPECIFICATION Rear power window switch LH Rear power window motor LH Continuity Connector Terminal Connector Terminal D54 5 D52 1 Existed 4 3 Check continuity between rear power window switch LH harness connector and ground. CONTINUITY SPECIFICATION Rear power window switch LH Ground Continuity Connector Terminal D54 5 Not existed 4 Is the inspection result normal? YES: Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT INSPECTION»(ref-368786-S11662292282010081300000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S35209909512010081300000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". INSPECTION END
REAR LH : Component Inspection
- CHECK REAR POWER WINDOW MOTOR LH Turn ignition switch OFF. Disconnect rear power window motor LH connector. Check motor operation by connecting the battery voltage directly to rear power window motor LH terminals. VOLTAGE SPECIFICATION Rear power window motor LH connector Terminal Motor condition (+) (-) D52 3 1 DOWN 1 3 UP Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S35209909512010081300000) ".
REAR RH : Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor RH connector. Turn ignition switch ON. Check voltage between rear power window motor RH harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Condition Voltage (V) (Approx.) Rear power window motor RH Connector Terminal D72 1 Ground Rear power window switch RH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the measurement value within the specification? YES: GO TO 3 . NO: GO TO 2.
- CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH harness connector and rear power window motor RH harness connector. CONTINUITY SPECIFICATION Rear power window switch RH Rear power window motor RH Continuity Connector Terminal Connector Terminal D74 5 D72 1 Existed 4 3 Check continuity between rear power window switch RH harness connector and ground. CONTINUITY SPECIFICATION Rear power window switch RH Ground Continuity Connector Terminal D74 5 Not existed 4 Is the inspection result normal? YES: Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: Repair or replace harness.
- CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT INSPECTION»(ref-368786-S36727485762010081300000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S35209909512010081300000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". INSPECTION END
REAR RH : Component Inspection
- CHECK REAR POWER WINDOW MOTOR RH Turn ignition switch OFF. Disconnect rear power window motor RH connector. Check motor operation by connecting the battery voltage directly to rear power window motor RH terminals. VOLTAGE SPECIFICATION Rear power window motor RH connector Terminal Motor condition (+) (-) D72 3 1 DOWN 1 3 UP Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-368813-S35209909512010081300000) ".
- CHECK POWER WINDOW SWITCH OUTPUT SIGNAL Turn ignition switch ON. Check signal between front power window switch (passenger side) harness connector and ground. SIGNAL SPECIFICATION (+) (-) Signal (Reference value) Front power window switch (passenger side) Connector Terminal D38 16 Ground Is the inspection result normal? YES: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: GO TO 2.
- CHECK POWER WINDOW SERIAL LINK SIGNAL Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Turn ignition switch ON. Check voltage between front power window switch (passenger side) harness connector and ground. VOLTAGE SPECIFICATION (+) (-) Voltage (V) (Approx.) Front power window switch (passenger side) Connector Terminal D38 16 Ground Battery voltage Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". NO: GO TO 3.
- CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM connector and front power window switch (passenger side) connector. CONTINUITY SPECIFICATION BCM Front power window switch (passenger side) Continuity Connector Terminal Connector Terminal M123 132 D38 16 Existed Check continuity between BCM connector and ground. CONTINUITY SPECIFICATION BCM Ground Continuity Connector Terminal M123 132 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-368805-S10219545332010081300000) ". NO: Repair or replace harness.
VALUES ON THE DIAGNOSIS TOOL
CONSULT-III MONITOR ITEM
| Monitor Item | Condition | Value/Status |
|---|---|---|
| FR WIPER HI | Other than front wiper switch HI | Off |
| Front wiper switch HI | On | |
| FR WIPER LOW | Other than front wiper switch LO | Off |
| Front wiper switch LO | On | |
| FR WASHER SW | Front washer switch OFF | Off |
| Front washer switch ON | On | |
| FR WIPER INT | Other than front wiper switch INT | Off |
| Front wiper switch INT | On | |
| FR WIPER STOP | Front wiper is not in STOP position | Off |
| Front wiper is in STOP position | On | |
| INT VOLUME | Wiper intermittent dial is in a dial position 1 - 7 | Wiper intermittent dial position |
| RR WIPER ON | Other than rear wiper switch ON | Off |
| Rear wiper switch ON | On | |
| RR WIPER INT | Other than rear wiper switch INT | Off |
| Rear wiper switch INT | On | |
| RR WASHER SW | Rear washer switch OFF | Off |
| Rear washer switch ON | On | |
| RR WIPER STOP | Rear wiper is in STOP position | Off |
| Rear wiper is not in STOP position | On | |
| TURN SIGNAL R | Other than turn signal switch RH | Off |
| Turn signal switch RH | On | |
| TURN SIGNAL L | Other than turn signal switch LH | Off |
| Turn signal switch LH | On | |
| TAIL LAMP SW | Other than lighting switch 1ST and 2ND | Off |
| Lighting switch 1ST or 2ND | On | |
| HI BEAM SW | Other than lighting switch HI | Off |
| Lighting switch HI | On | |
| HEAD LAMP SW 1 | Other than lighting switch 2ND | Off |
| Lighting switch 2ND | On | |
| HEAD LAMP SW 2 | Other than lighting switch 2ND | Off |
| Lighting switch 2ND | On | |
| PASSING SW | Other than lighting switch PASS | Off |
| Lighting switch PASS | On | |
| AUTO LIGHT SW | Other than lighting switch AUTO | Off |
| Lighting switch AUTO | On | |
| FR FOG SW | Front fog lamp switch OFF | Off |
| Front fog lamp switch ON | On | |
| RR FOG SW | NOTE: The item is indicated, but not monitored. | Off |
| DOOR SW-DR | Driver door closed | Off |
| Driver door opened | On | |
| DOOR SW-AS | Passenger door closed | Off |
| Passenger door opened | On | |
| DOOR SW-RR | Rear RH door closed | Off |
| Rear RH door opened | On | |
| DOOR SW-RL | Rear LH door closed | Off |
| Rear LH door opened | On | |
| DOOR SW-BK | Back door closed | Off |
| Back door opened | On | |
| CDL LOCK SW | Other than power door lock switch LOCK | Off |
| Power door lock switch LOCK | On | |
| CDL UNLOCK SW | Other than power door lock switch UNLOCK | Off |
| Power door lock switch UNLOCK | On | |
| KEY CYL LK-SW | Other than driver door key cylinder LOCK position | Off |
| Driver door key cylinder LOCK position | On | |
| KEY CYL UN-SW | Other than driver door key cylinder UNLOCK position | Off |
| Driver door key cylinder UNLOCK position | On | |
| KEY CYL SW-TR | NOTE: The item is indicated, but not monitored. | Off |
| HAZARD SW | Hazard switch is OFF | Off |
| Hazard switch is ON | On | |
| REAR DEF SW | NOTE: The item is indicated, but not monitored. | Off |
| TR CANCEL SW | NOTE: The item is indicated, but not monitored. | Off |
| TR/BD OPEN SW | Back door opener switch OFF | Off |
| While the back door opener switch is turned ON | On | |
| TRNK/HAT MNTR | NOTE: The item is indicated, but not monitored. | Off |
| RKE-LOCK | LOCK button of the key is not pressed | Off |
| LOCK button of the key is pressed | On | |
| RKE-UNLOCK | UNLOCK button of the key is not pressed | Off |
| UNLOCK button of the key is pressed | On | |
| RKE-TR/BD | NOTE: The item is indicated, but not monitored. | Off |
| RKE-PANIC | PANIC button of the key is not pressed | Off |
| PANIC button of the key is pressed | On | |
| RKE-P/W OPEN | UNLOCK button of the key is not pressed | Off |
| UNLOCK button of the key is pressed and held | On | |
| RKE-MODE CHG | LOCK/UNLOCK button of the key is not pressed and held simultaneously | Off |
| LOCK/UNLOCK button of the key is pressed and held simultaneously | On | |
| OPTICAL SENSOR | Bright outside of the vehicle Close to 5 | V |
| Dark outside of the vehicle Close to 0 | V | |
| REQ SW-DR | Driver door request switch is not pressed | Off |
| Driver door request switch is pressed | On | |
| REQ SW-AS | Passenger door request switch is not pressed | Off |
| Passenger door request switch is pressed | On | |
| REQ SW-RR | NOTE: The item is indicated, but not monitored. | Off |
| REQ SW-RL | NOTE: The item is indicated, but not monitored. | Off |
| REQ SW-BD/TR | Back door request switch is not pressed | Off |
| Back door request switch is pressed | On | |
| PUSH SW | Push-button ignition switch (push switch) is not pressed | Off |
| Push-button ignition switch (push switch) is pressed | On | |
| IGN RLY2 -F/B | Ignition switch in OFF or ACC position | Off |
| Ignition switch in ON position | On | |
| ACC RLY-F/B | NOTE: The item is indicated, but not monitored. | Off |
| CLUCH SW | NOTE: The item is indicated, but not monitored. | Off |
| BRAKE SW 1 | The brake pedal is depressed when No. 7 fuse is blown | Off |
| The brake pedal is not depressed when No. 7 fuse is blown, or No. 7 fuse is normal | On | |
| BRAKE SW 2 | The brake pedal is not depressed | Off |
| The brake pedal is depressed | On | |
| DETE/CANCL SW | Selector lever in P position | Off |
| Selector lever in any position other than P | On | |
| SFT PN/N SW | Selector lever in any position other than P and N | Off |
| Selector lever in P or N position | On | |
| S/L-LOCK | Steering is unlocked | Off |
| Steering is locked | On | |
| S/L-UNLOCK | Steering is locked | Off |
| Steering is unlocked | On | |
| S/L RELAY-F/B | Ignition switch in OFF or ACC position | Off |
| Ignition switch in ON position | On | |
| UNLK SEN-DR | Driver door is unlocked | Off |
| Driver door is locked | On | |
| PUSH SW-IPDM | Push-button ignition switch (push-switch) is not pressed | Off |
| Push-button ignition switch (push-switch) is pressed | On | |
| IGN RLY1 -F/B | Ignition switch in OFF or ACC position | Off |
| Ignition switch in ON position | On | |
| DETE SW-IPDM | Selector lever in any position other than P | Off |
| Selector lever in P position | On | |
| SFT PN-IPDM | Selector lever in any position other than P and N | Off |
| Selector lever in P or N position | On | |
| SFT P-MET | Selector lever in any position other than P | Off |
| Selector lever in P position | On | |
| SFT N-MET | Selector lever in any position other than N | Off |
| Selector lever in N position | On | |
| ENGINE STATE | Engine stopped | Stop |
| While the engine stalls | Stall | |
| At engine cranking | Crank | |
| Engine running | Run | |
| S/L LOCK-IPDM | Steering is unlocked | Off |
| Steering is locked | On | |
| S/L UNLK-IPDM | Steering is locked | Off |
| Steering is unlocked | On | |
| S/L RELAY-REQ | Steering lock system is not the LOCK condition and the changing condition from LOCK to UNLOCK. | Off |
| Steering lock system is the LOCK condition or the changing condition from LOCK to UNLOCK. | On | |
| VEH SPEED 1 | While driving | Equivalent to speedometer reading |
| VEH SPEED 2 | While driving | Equivalent to speedometer reading |
| DOOR STAT-DR | Driver door is locked | LOCK |
| Wait with selective UNLOCK operation (5 seconds) | READY | |
| Driver door is unlocked | UNLOCK | |
| DOOR STAT-AS | Passenger door is locked | LOCK |
| Wait with selective UNLOCK operation (5 seconds) | READY | |
| Passenger door is unlocked | UNLOCK | |
| ID OK FLAG | Steering is locked | Reset |
| Steering is unlocked | Set | |
| PRMT ENG STRT | The engine start is prohibited | Reset |
| The engine start is permitted | Set | |
| PRMT RKE STRT | NOTE: The item is indicated, but not monitored. | Reset |
| KEY SW-SLOT | The key is not inserted into key slot | Off |
| The key is inserted into key slot | On | |
| RKE OPE COUN1 | During the operation of the key | Operation frequency of the key |
| RKE OPE COUN2 | NOTE: The item is indicated, but not monitored. | |
| CONFRM ID ALL | The key ID that the key slot receives does not accord with any key ID registered to BCM. | Yet |
| The key ID that the key slot receives accords with any key ID registered to BCM. | Done | |
| CONFIRM ID4 | The key ID that the key slot receives does not accord with the fourth key ID registered to BCM. | Yet |
| The key ID that the key slot receives accords with the fourth key ID registered to BCM. | Done | |
| CONFIRM ID3 | The key ID that the key slot receives does not accord with the third key ID registered to BCM. | Yet |
| The key ID that the key slot receives accords with the third key ID registered to BCM. | Done | |
| CONFIRM ID2 | The key ID that the key slot receives does not accord with the second key ID registered to BCM. | Yet |
| The key ID that the key slot receives accords with the second key ID registered to BCM. | Done | |
| CONFIRM ID1 | The key ID that the key slot receives does not accord with the first key ID registered to BCM. | Yet |
| The key ID that the key slot receives accords with the first key ID registered to BCM. | Done | |
| TP 4 | The ID of fourth key is not registered to BCM | Yet |
| The ID of fourth key is registered to BCM | Done | |
| TP 3 | The ID of third key is not registered to BCM | Yet |
| The ID of third key is registered to BCM | Done | |
| TP 2 | The ID of second key is not registered to BCM | Yet |
| The ID of second key is registered to BCM | Done | |
| TP 1 | The ID of first key is not registered to BCM | Yet |
| The ID of first key is registered to BCM | Done | |
| AIR PRESS FL | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of front LH tire |
| AIR PRESS FR | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of front RH tire |
| AIR PRESS RR | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of rear RH tire |
| AIR PRESS RL | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of rear LH tire |
| ID REGST FL1 | ID of front LH tire transmitter is registered | Done |
| ID of front LH tire transmitter is not registered | Yet | |
| ID REGST FR1 | ID of front RH tire transmitter is registered | Done |
| ID of front RH tire transmitter is not registered | Yet | |
| ID REGST RR1 | ID of rear RH tire transmitter is registered | Done |
| ID of rear RH tire transmitter is not registered | Yet | |
| ID REGST RL1 | ID of rear LH tire transmitter is registered | Done |
| ID of rear LH tire transmitter is not registered | Yet | |
| WARNING LAMP | Tire pressure indicator OFF | Off |
| Tire pressure indicator ON | On | |
| BUZZER | Tire pressure warning alarm is not sounding | Off |
| Tire pressure warning alarm is sounding | On |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
DIAGNOSIS TOOL REFERENCE VALUE
Scheme 3
FAIL-SAFE CONTROL BY DTC
BCM performs fail-safe control when any DTC are detected.
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| B2013: ID DISCORD BCM-S/L | Inhibit engine cranking | Erase DTC |
| B2014: CHAIN OF S/L-BCM | Inhibit engine cranking | Erase DTC |
| B2190: NATS ANTENNA AMP | Inhibit engine cranking | Erase DTC |
| B2191: DIFFERENCE OF KEY | Inhibit engine cranking | Erase DTC |
| B2192: ID DISCORD BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2193: CHAIN OF BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2195: ANTI SCANNING | Inhibit engine cranking | Ignition switch ON --> OFF |
| B2557: VEHICLE SPEED | Inhibit steering lock | When normal vehicle speed signals are received from ABS actuator and electric unit (control unit) for 500 ms |
| B2560: STARTER CONT RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status becomes consistent Starter control relay signal Starter relay status signal |
| B2601: SHIFT POSITION | Inhibit steering lock | 500 ms after the following signal reception status becomes consistent Selector lever P position switch signal P range signal (CAN) |
| B2602: SHIFT POSITION | Inhibit steering lock | 5 seconds after the following BCM recognition conditions are fulfilled Ignition switch is in the ON position Selector lever P position switch signal: Except P position (battery voltage) Vehicle speed: 4 km/h (2.5 MPH) or more |
| B2603: SHIFT POSI STATUS | Inhibit steering lock | 500 ms after the following BCM recognition conditions are fulfilled Ignition switch is in the ON position Selector lever P position switch signal: Except P position (battery voltage) Selector lever P/N position signal: Except P and N positions (0 V) |
| B2604: PNP SW | Inhibit steering lock | 500 ms after any of the following BCM recognition conditions are fulfilled Status 1 Ignition switch is in the ON position Selector lever P/N position signal: P and N position (battery voltage) P range signal or N range signal (CAN): ON Status 2 Ignition switch is in the ON position Selector lever P/N position signal: Except P and N positions (0 V) P range signal and N range signal (CAN): OFF |
| B2605: PNP SW | Inhibit steering lock | 500 ms after any of the following BCM recognition conditions are fulfilled Ignition switch is in the ON position Power position: IGN Selector lever P/N position signal: Except P and N positions (0 V) Interlock/PNP switch signal (CAN): OFF Status 2 Ignition switch is in the ON position Selector lever P/N position signal: P or N position (battery voltage) PNP switch signal (CAN): ON |
| B2606: S/L RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status becomes consistent Steering lock relay signal (Request signal) Steering lock relay signal (Condition signal) |
| B2607: S/L RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status becomes consistent Steering lock relay signal (Request signal) Steering lock relay signal (Condition signal) |
| B2608: STARTER RELAY | Inhibit engine cranking | 500 ms after the following signal communication status becomes consistent Starter motor relay control signal Starter relay status signal (CAN) |
| B2609: S/L STATUS | Inhibit engine cranking Inhibit steering lock | When the following steering lock conditions agree BCM steering lock control status Steering lock condition No. 1 signal status Steering lock condition No. 2 signal status |
| B260A: IGNITION RELAY | Inhibit engine cranking | 500 ms after the following conditions are fulfilled IGN relay (IPDM E/R) control signal: OFF (Battery voltage) Ignition ON signal (CAN to IPDM E/R): OFF (Request signal) Ignition ON signal (CAN from IPDM E/R): OFF (Condition signal) |
| B260F: ENG STATE SIG LOST | Maintains the power supply position attained at the time of DTC detection | When any of the following conditions are fulfilled Power position changes to ACC Receives engine status signal (CAN) |
| B2612: S/L STATUS | Inhibit engine cranking Inhibit steering lock | When any of the following conditions are fulfilled Steering lock unit status signal (CAN) is received normally The BCM steering lock control status matches the steering lock status recognized by the steering lock unit status signal (CAN from IPDM E/R) |
| B2617: STARTER RELAY CIRC | Inhibit engine cranking | 1 second after the starter motor relay control inside BCM becomes normal |
| B2618: BCM | Inhibit engine cranking | 1 second after the ignition relay (IPDM E/R) control inside BCM becomes normal |
| B2619: BCM | Inhibit engine cranking | 1 second after the steering lock unit power supply output control inside BCM becomes normal |
| B261E: VEHICLE TYPE | Inhibit engine cranking | BCM initialization |
| B26E9: S/L STATUS | Inhibit engine cranking Inhibit steering lock | When BCM transmits the LOCK request signal to steering lock unit, and receives LOCK response signal from steering lock unit, the following conditions are fulfilled Steering condition No. 1 signal: LOCK (0 V) Steering condition No. 2 signal: LOCK (Battery voltage) |
DTC CHART
DTC Inspection Priority Chart
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority chart.
| Priority | DTC |
|---|---|
| 1 | B2562: LOW VOLTAGE |
| 2 | U1000: CAN COMM CIRCUIT U1010: CONTROL UNIT (CAN) |
| 3 | B2190: NATS ANTENNA AMP B2191: DIFFERENCE OF KEY B2192: ID DISCORD BCM-ECM B2193: CHAIN OF BCM-ECM B2195: ANTI SCANNING |
| 4 | B2013: ID DISCORD BCM-S/L B2014: CHAIN OF S/L-BCM B2553: IGNITION RELAY B2555: STOP LAMP B2556: PUSH-BTN IGN SW B2557: VEHICLE SPEED B2560: STARTER CONT RELAY B2601: SHIFT POSITION B2602: SHIFT POSITION B2603: SHIFT POSI STATUS B2604: PNP SW B2605: PNP SW B2606: S/L RELAY B2607: S/L RELAY B2608: STARTER RELAY B2609: S/L STATUS B260A: IGNITION RELAY B260B: STEERING LOCK UNIT B260C: STEERING LOCK UNIT B260D: STEERING LOCK UNIT B260F: ENG STATE SIG LOST B2612: S/L STATUS B2614: ACC RELAY CIRC B2615: BLOWER RELAY CIRC B2616: IGN RELAY CIRC B2617: STARTER RELAY CIRC B2618: BCM B2619: BCM B261A: PUSH-BTN IGN SW B261E: VEHICLE TYPE B26E9: S/L STATUS B26EA: KEY REGISTRATION C1729: VHCL SPEED SIG ERR U0415: VEHICLE SPEED SIG |
| 5 | C1704: LOW PRESSURE FL C1705: LOW PRESSURE FR C1706: LOW PRESSURE RR C1707: LOW PRESSURE RL C1708: [NO DATA] FL C1709: [NO DATA] FR C1710: [NO DATA] RR C1711: [NO DATA] RL C1712: [CHECKSUM ERR] FL C1713: [CHECKSUM ERR] FR C1714: [CHECKSUM ERR] RR C1715: [CHECKSUM ERR] RL C1716: [PRESSDATA ERR] FL C1717: [PRESSDATA ERR] FR C1718: [PRESSDATA ERR] RR C1719: [PRESSDATA ERR] RL C1720: [CODE ERR] FL C1721: [CODE ERR] FR C1722: [CODE ERR] RR C1723: [CODE ERR] RL C1724: [BATT VOLT LOW] FL C1725: [BATT VOLT LOW] FR C1726: [BATT VOLT LOW] RR C1727: [BATT VOLT LOW] RL C1734: CONTROL UNIT |
| 6 | B2621: INSIDE ANTENNA B2622: INSIDE ANTENNA B2623: INSIDE ANTENNA |
DTC INSPECTION PRIORITY CHART
DTC Index
Note. The details of time display are as follows. CRNT: A malfunction is detected now. PAST: A malfunction was detected in the past. IGN counter is displayed on Freeze Frame Data. For details of Freeze Frame Data, refer to " COMMON ITEM : CONSULT-III FUNCTION (BCM - COMMON ITEM) ".
| CONSULT display | Fail-safe | Freeze Frame Data Vehicle Speed Odo/Trip Meter Vehicle Condition | Intelligent Key warning lamp ON | Tire pressure monitor warning lamp ON | Reference |
|---|---|---|---|---|---|
| No DTC is detected. further testing may be required. | |||||
| U1000: CAN COMM CIRCUIT | U1000 CAN COMM CIRCUIT | ||||
| U1010: CONTROL UNIT (CAN) | U1010 CONTROL UNIT (CAN) | ||||
| U0415: VEHICLE SPEED SIG | U0415 VEHICLE SPEED SIG | ||||
| B2013: ID DISCORD BCM-S/L | X | X | B2013 ID DISCORD, IMMU-STRG | ||
| B2014: CHAIN OF S/L-BCM | X | X | B2014 CHAIN OF STRG-IMMU | ||
| B2190: NATS ANTENNA AMP | X | B2190 NATS ANTENNA AMP | |||
| B2191: DIFFERENCE OF KEY | X | B2191 DIFFERENCE OF KEY | |||
| B2192: ID DISCORD BCM-ECM | X | B2192 ID DISCORD, IMMU-ECM | |||
| B2193: CHAIN OF BCM-ECM | X | B2193 CHAIN OF ECM-IMMU | |||
| B2195: ANTI SCANNING | X | B2195 ANTI-SCANNING | |||
| B2553: IGNITION RELAY | X | B2553 IGNITION RELAY | |||
| B2555: STOP LAMP | X | B2555 STOP LAMP | |||
| B2556: PUSH-BTN IGN SW | X | X | B2556 PUSH-BUTTON IGNITION SWITCH | ||
| B2557: VEHICLE SPEED | X | X | X | B2557 VEHICLE SPEED | |
| B2560: STARTER CONT RELAY | X | X | X | B2560 STARTER CONTROL RELAY | |
| B2562: LOW VOLTAGE | X | B2562 LOW VOLTAGE | |||
| B2601: SHIFT POSITION | X | X | X | B2601 SHIFT POSITION | |
| B2602: SHIFT POSITION | X | X | X | B2602 SHIFT POSITION | |
| B2603: SHIFT POSI STATUS | X | X | X | B2603 SHIFT POSITION STATUS | |
| B2604: PNP SW | X | X | X | B2604 PNP SWITCH | |
| B2605: PNP SW | X | X | X | B2605 PNP SWITCH | |
| B2606: S/L RELAY | X | X | X | B2606 STEERING LOCK RELAY | |
| B2607: S/L RELAY | X | X | X | B2607 STEERING LOCK RELAY | |
| B2608: STARTER RELAY | X | X | X | B2608 STARTER RELAY | |
| B2609: S/L STATUS | X | X | X | B2609 STEERING STATUS | |
| B260A: IGNITION RELAY | X | X | X | B260A IGNITION RELAY | |
| B260B: STEERING LOCK UNIT | X | X | B260B STEERING LOCK UNIT | ||
| B260C: STEERING LOCK UNIT | X | X | B260C STEERING LOCK UNIT | ||
| B260D: STEERING LOCK UNIT | X | X | B260D STEERING LOCK UNIT | ||
| B260F: ENG STATE SIG LOST | X | X | X | B260F ENGINE STATUS | |
| B2612: S/L STATUS | X | X | X | B2612 STEERING STATUS | |
| B2614: ACC RELAY CIRC | X | X | B2614 ACC RELAY | ||
| B2615: BLOWER RELAY CIRC | X | X | B2615 BLOWER RELAY CIRCUIT | ||
| B2616: IGN RELAY CIRC | X | X | B2616 IGNITION RELAY CIRCUIT | ||
| B2617: STARTER RELAY CIRC | X | X | X | B2617 STARTER RELAY CIRCUIT | |
| B2618: BCM | X | X | X | B2618 BCM | |
| B2619: BCM | X | X | X | B2619 BCM | |
| B261A: PUSH-BTN IGN SW | X | X | B261A PUSH-BUTTON IGNITION SWITCH | ||
| B261E: VEHICLE TYPE | X | X | X (Turn ON for 15 seconds) | B261E VEHICLE TYPE | |
| B2621: INSIDE ANTENNA | X | B2621 INSIDE KEY ANTENNA 1 | |||
| B2622: INSIDE ANTENNA | X | B2622 INSIDE KEY ANTENNA 2 | |||
| B2623: INSIDE ANTENNA | X | B2623 INSIDE KEY ANTENNA 3 | |||
| B26E1: ENG STATE NO RES | X | X | X | B26E1 NO RECEPTION OF ENGINE STATUS SIGNAL | |
| B26E9: S/L STATUS | X | X | X (Turn ON for 15 seconds) | B26E9 STEERING STATUS | |
| B26EA: KEY REGISTRATION | X | X (Turn ON for 15 seconds) | B26EA KEY REGISTRATION | ||
| C1704: LOW PRESSURE FL | X | C1704, C1705, C1706, C1707 LOW TIRE PRESSURE | |||
| C1705: LOW PRESSURE FR | X | ||||
| C1706: LOW PRESSURE RR | X | ||||
| C1707: LOW PRESSURE RL | X | ||||
| C1708: [NO DATA] FL | X | C1708, C1709, C1710, C1711 TRANSMITTER | |||
| C1709: [NO DATA] FR | X | ||||
| C1710: [NO DATA] RR | X | ||||
| C1711: [NO DATA] RL | X | ||||
| C1712: [CHECKSUM ERR] FL | X | C1712, C1713, C1714, C1715 TRANSMITTER | |||
| C1713: [CHECKSUM ERR] FR | X | ||||
| C1714: [CHECKSUM ERR] RR | X | ||||
| C1715: [CHECKSUM ERR] RL | X | ||||
| C1716: [PRESSDATA ERR] FL | X | C1716, C1717, C1718, C1719 TRANSMITTER | |||
| C1717: [PRESSDATA ERR] FR | X | ||||
| C1718: [PRESSDATA ERR] RR | X | ||||
| C1719: [PRESSDATA ERR] RL | X | ||||
| C1720: [CODE ERR] FL | X | C1720, C1721, C1722, C1723 TRANSMITTER | |||
| C1721: [CODE ERR] FR | X | ||||
| C1722: [CODE ERR] RR | X | ||||
| C1723: [CODE ERR] RL | X | ||||
| C1724: [BATT VOLT LOW] FL | X | C1724, C1725, C1726, C1727 TRANSMITTER | |||
| C1725: [BATT VOLT LOW] FR | X | ||||
| C1726: [BATT VOLT LOW] RR | X | ||||
| C1727: [BATT VOLT LOW] RL | X | ||||
| C1729: VHCL SPEED SIG ERR | X | C1729 VEHICLE SPEED SIGNAL | |||
| C1734: CONTROL UNIT | X | C1734 BCM |
DTC INDEX
Scheme 4
- CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «BCM : DIAGNOSIS PROCEDURE»(ref-368786-S02259813522010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK POWER WINDOW MAIN SWITCH POWER SUPPLY AND GROUND CIRCUIT Check power window switch power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH : DIAGNOSIS PROCEDURE»(ref-368786-S26361796692010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK DRIVER SIDE POWER WINDOW MOTOR Check driver side power window motor. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-368786-S17762888772010081300000) ". Is the measurement value within the specification? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) SERIAL LINK CIRCUIT Check front power window switch (passenger side) serial link circuit. Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : COMPONENT FUNCTION CHECK»(ref-368786-S27287118222010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
WHEN FRONT POWER WINDOW SWITCH (PASSENGER SIDE) IS OPERATED : Diagnosis Procedure
- REPLACE FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) " INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW SWITCH ARE OPERATED : Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) POWER SUPPLY AND GROUND CIRCUIT Check front power window switch (passenger side) power supply and ground circuit. Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : DIAGNOSIS PROCEDURE»(ref-368786-S36603283102010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK PASSENGER SIDE POWER WINDOW MOTOR CIRCUIT Check passenger side power window motor circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-368786-S01365418142010081300000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-368786-S22263108542010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
WHEN REAR POWER WINDOW SWITCH LH IS OPERATED : Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-368786-S04449028092010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- REPLACE REAR POWER WINDOW SWITCH LH Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH LH ARE OPERATED : Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT FUNCTION CHECK»(ref-368786-S39352262842010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-368786-S22263108542010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
WHEN REAR POWER WINDOW SWITCH RH IS OPERATED : Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-368786-S04449028092010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- REPLACE REAR POWER WINDOW SWITCH RH Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH RH ARE OPERATED : Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT FUNCTION CHECK»(ref-368786-S39845163482010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK POWER WINDOW AUTO OPERATION Check power window auto operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «DRIVER SIDE : DIAGNOSIS PROCEDURE»(ref-368786-S34340217182010081300000) ".
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK POWER WINDOW AUTO OPERATION Check power window auto operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «PASSENGER SIDE : DIAGNOSIS PROCEDURE»(ref-368786-S21248921212010081300000) ".
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : SPECIAL REPAIR REQUIREMENT»(ref-368786-S41142180872010081300000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER (DRIVER SIDE) CIRCUIT Check encoder (driver side) circuit. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-368786-S15996609702010081300000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : SPECIAL REPAIR REQUIREMENT»(ref-368786-S41142180872010081300000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER (PASSENGER SIDE) CIRCUIT Check encoder (passenger side) circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-368786-S00767188282010081300000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK DOOR SWITCH Check door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-368800-S42138002532010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : SPECIAL REPAIR REQUIREMENT»(ref-368786-S41142180872010081300000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK DRIVER SIDE DOOR LOCK ASSEMBLY (DOOR KEY CYLINDER SWITCH) Check driver side door lock assembly (door key cylinder switch). Refer to " «COMPONENT FUNCTION CHECK»(ref-368800-S35613390282010081300000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- CHECK REMOTE KEYLESS ENTRY FUNCTION Check remote keyless entry function. Does door lock/unlock with Intelligent Key button? YES: GO TO 2. NO: Refer to " «DESCRIPTION»(ref-368800-S23765553362010081300000) ".
- CHECK POWER WINDOW OPERATION Check power window operation. Does power window operate up/down using power window main switch? YES: GO TO 3. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-368786-S31963044342010081300000) ".
- CHECK "PW DOWN SET" SETTING IN "WORK SUPPORT" Check "PW DOWN SET" setting in "WORK SUPPORT". Refer to " «INTELLIGENT KEY : CONSULT-III FUNCTION (BCM - INTELLIGENT KEY)»(ref-368800-S39920677432010081300000) ". Is the inspection result normal? YES: GO TO 4. NO: Set "PW DOWN SET" setting in "WORK SUPPORT".
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-368779-S37787215052010081300000) ". NO: GO TO 1 .
- REPLACE POWER WINDOW MAIN SWITCH Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ".
- REPLACE POWER WINDOW MAIN SWITCH Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". INSPECTION END
- REPLACE FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". INSPECTION END
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-368786-S04449028092010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness.
- REPLACE REAR POWER WINDOW SWITCH LH Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". INSPECTION END
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-368786-S04449028092010081300000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness.
- REPLACE REAR POWER WINDOW SWITCH RH Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-368786-S41719980852010081300000) ". INSPECTRION END
