Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the "SRS AIRBAG" and "SEAT BELT" of this Service Information.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the " SRS Airbag ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Commercial Service Tools
COMMERCIAL SERVICE TOOLS SPECIFICATION Tool name Description Power tool Loosening bolts and nuts Radiator cap tester Checking radiator and radiator cap Radiator cap tester adapter Adapting radiator cap tester to radiator cap and water outlet (front) filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in)
Scheme 27
Scheme 28
Scheme 29
- Check if the reservoir tank engine coolant level is within the "MIN" to "MAX" when the engine is cool.
- Adjust the engine coolant level if necessary.
- Check that the reservoir tank cap is tightened.
Scheme 30
- To check for leakage, apply pressure to the cooling system with the radiator cap tester and radiator cap tester adapter (commercial service tool) (A). Testing pressure : Refer to " «RADIATOR»(ref-368795-S19024683352010081300000) ". WARNING: Never remove radiator cap when engine is hot. Serious burns could occur from high-pressure engine coolant escaping from water outlet (front). CAUTION: Higher test pressure than specified may cause radiator damage. NOTE: In a case that engine coolant decreases, replenish radiator with engine coolant.
- If anything is found, repair or replace damaged parts.
Radiator
| Unit: kPa (kg/cm 2 , psi) | ||
|---|---|---|
| Cap relief pressure | Standard | 122.3 - 151.7 (1.2 - 1.5, 18 - 22) |
| Limit | 107 (1.1, 16) | |
| Leakage testing pressure | 157 (1.6, 23) | |
RADIATOR SPECIFICATION
Thermostat
| Thermostat | Standard |
|---|---|
| Valve opening temperature | 82°C (180°F) |
| Maximum valve lift | 9.0 mm/95°C (0.354 in/203°F) |
| Valve closing temperature | 77°C (171°F) |
THERMOSTAT SPECIFICATION
