Multifunction Switch: Diagnosis Hyundai Veloster I

Lighting Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

HU: Head lamp high beam

HL: Head lamp low beam

P: Head lamp passing switch

Scheme 6

Scheme 7

Wiper And Washer Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Check BCM input/output specification of multifunction switch using the GDS. If the specification is abnormal, replace the lamp or wiper switch.
2. If diagnosis is required on the multifunction switch, select model and "BCM".
3. To consult the present input/output value of BCM, "Current DATA". It provides information of BCM input/output conditions of power supply, turn signal/brake lamp, headlamp, door, locks, outside mirror, wiper, auto-light and transmitters etc.
4. To perform compulsory operation on BCM input factors, select "ACTUATION TEST".

Scheme 13

1. Disconnect the negative (-) battery terminal.
2. Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-609297-S07257609932014041600000) .
3. Remove the steering column upper and lower shrouds.
4. Remove the clock spring.
5. Disconnect the lighting switch connector and wiper & washer switch connector.
6. Remove the multifunction switch assembly (A) with loosening 2 screws.
7. If it is necessary to remove. The wiper & washer switch only, release the lock of wiper switch using tool without removing the steering wheel and the clock spring.
