Starting System: Removal & Installation Hyundai Veloster I

Installation

1. Install in the reverse order of removal. Starter installation bolt: 49.0 ~ 63.7 N.m (5.0 ~ 6.5 kgf.m, 36.2 ~ 47.0 lb-ft)

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. Disconnect the M-terminal (A) on the magnet switch assembly.
2. After loosening the 2 screws (A), detach the magnet switch assembly (B).
3. Loosen the brush holder mounting screw (A) and the trough bolts (B).
4. Remove the rear bracket (A) and brush holder assembly (B).
5. Remove the yoke (A).
6. Remove the packing (A), lever plate (B), lever (C), armature (D).
7. Press the stopper (A) using a socket (B).
8. After removing the stop ring (A) using stopper pliers (B).
9. Remove the stop ring (B), stopper (A), overrunning clutch (C) and armature (D). NOTE: Using a suitable pulling tool (A), pull the overrunning clutch stopper (C) over the stop ring (B).
