Seat Electrical: Overview Hyundai Veloster I

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Remove the seat and Lumbar support motor (A) connectors.
2. With the battery connected directly to the motor terminals, check if the motors run smoothly.
3. Reverse the connections and check that the motor rotates in reverse.
4. If there is an abnormality, replace the motor.

Scheme 60

Scheme 61

1. With the lumbar support switch (A) in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the lumbar support switch.

Scheme 62

Scheme 63

Scheme 64

1. Disconnect the negative (-) battery terminal.
2. Remove the seat side cover (A). (Refer to " «FRONT SEAT»(ref-609321-S38586554702014041600000) ")
3. Remove the power seat control switch connector.
4. Remove the power seat control switch (A) after loosening the mounting screw.
