Ignition System - Turbo: Specifications Hyundai Veloster I

Ignition System 4 illustrations

Specification

ItemSpecification
Primary Coil Resistance (ohms)0.79 ± 15% [20°C (68°F)]
Secondary Coil Resistance (kohms)7.0 ± 15% [20°C (68°F)]

Scheme 14

Scheme 14: Circuit Diagram
Scheme 14: Circuit Diagram

Scheme 15

Scheme 15: Removal
Scheme 15: Removal

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Disconnect the battery negative terminal.
  2. Remove the engine cover.
  3. Disconnect the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
  4. Remove the ignition coil (A).
ItemSpecification
TypeSILZKR6D8E
Gap0.7 ~ 0.8 mm (0.028 ~ 0.031 in.)
