Engine and Transaxle Assembly - Turbo: Overview Hyundai Veloster I

Mechanical 5 illustrations ~225 words

Scheme 35

Scheme 35: Removal and Installation
  1. Remove the engine cover (A).
  2. Install in the reverse order of removal.

Scheme 36

Scheme 36: Removal and Installation
  1. Loosen the mounting clip and bolt and then remove the under cover (A). Tightening torque: 6.8 ~ 10.7 N.m (0.7 ~1.1kgf.m, 5.0 ~ 7.9 lb-ft)
  2. Install in the reverse order of removal.

Scheme 37

Scheme 37: Components

Scheme 38

Scheme 38: Rollroad Mounting
  1. Rollroad bracket mounting bolts and rollroad bracket (A). Tightening torque Nut (B): 107.9 ~ 127.5 N.m (11.0 ~ 13.0 kgf.m, 79.6 ~ 94.0 lb-ft) Bolt (C): 49.0 ~ 63.7 N.m (5.0 ~ 6.5 kgf.m, 36.2 ~ 47.0 lb-ft)
  2. Remove the rollroad support bracket (D). Tightening torque: 49.0 ~ 68.6 N.m (5.0 ~ 7.0 kgf.m, 36.2 ~ 50.6 lb-ft)
  3. Install in the reverse order of removal.

Scheme 39

Scheme 39: Engine Mounting Support Bracket
  1. Disconnect the ground cable. Tightening torque Ground line bolt: 10.8 ~ 13.7 N.m (1.1 ~ 1.4 kgf.m, 8.0 ~ 10.1 lb-ft)
  2. Install the jack to the edge of upper oil pan to support the engine. NOTE: Insert the rubber block between jack and oil pan.
  3. Remove the engine mounting support bracket (A). Tightening torque Nut (B): 63.7 ~ 83.4 N.m (6.5 ~ 8.5 kgf.m, 47.0 ~ 61.5 lb-ft) Bolt and nuts (C): 49.0 ~ 63.7 N.m (5.0 ~ 6.5 kgf.m, 36.2 ~ 47.0 lb-ft)
  4. Install in the reverse order of removal.
