Engine Control System: Specifications Hyundai Tucson II

Testing & Diagnostics 16 illustrations ~159 words

Specifications

Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

MANIFOLD ABSOLUTE PRESSURE SENSOR SPECIFICATIONS

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29: Circuit Diagram
Scheme 29: Circuit Diagram

Specification

Temperature [°C (°F)]Resistance (kohms)
40 (-40)40.93 ~ 48.35
20 (-4)13.89 ~ 16.03
0 (32)5.38 ~ 6.09
10 (50)3.48 ~ 3.90
20 (68)2.31 ~ 2.57
40 (104)1.08 ~ 1.21
50 (122)0.76 ~ 0.85
60 (140)0.54 ~ 0.62
80 (176)0.29 ~ 0.34

INTAKE AIR TEMPERATURE SENSOR SPECIFICATIONS

Scheme 30

Scheme 30: Circuit Diagram
Scheme 30: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

ENGINE COOLANT TEMPERATURE SENSOR SPECIFICATIONS

Scheme 31

Scheme 31: Circuit Diagram
Scheme 31: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1, 150

KNOCK SENSOR SPECIFICATIONS

Scheme 32

Scheme 32: Circuit Diagram
Scheme 32: Circuit Diagram

Scheme 33

Scheme 33: Removal
Scheme 33: Removal

Scheme 34

Scheme 34
Scheme 34
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Drain the engine coolant. (Refer to «COOLING SYSTEM»(ref-583685) .)
  3. Remove the radiator upper hose. (Refer to «COOLING SYSTEM»(ref-583685) .)
  4. Disconnect the knock sensor connector (A).
  5. Remove the intake manifold. (Refer to «INTAKE AND EXHAUST SYSTEM»(/hyundai/tucson/ii-2009-2015/remont/exhaust/#intake-exhaust-system) .)
  6. Remove the installation bolt (A), and then remove the sensor from the cylinder block.
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

ACCELERATOR POSITION SENSOR SPECIFICATIONS

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36: Circuit Diagram
Scheme 36: Circuit Diagram
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, +26.8)4.5

FUEL TANK PRESSURE SENSOR SPECIFICATIONS

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38: Circuit Diagram
Scheme 38: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C (68°F)]

FUEL INJECTOR SPECIFICATIONS

Scheme 39

Scheme 39: Circuit Diagram
Scheme 39: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C (68°F)]

PURGE CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 40

Scheme 40: Circuit Diagram
Scheme 40: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

CVVT OIL CONTROL VALVE SPECIFICATIONS

Scheme 41

Scheme 41: Circuit Diagram
Scheme 41: Circuit Diagram
ItemSpecification
Coil resistance (ohms)30.0 ~ 35.0 [20°C (68°F)]

VARIABLE INTAKE SOLENOID VALVE SPECIFICATIONS

Scheme 42

Scheme 42: Circuit Diagram
Scheme 42: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 [20°C (68°F)

CANISTER CLOSE VALVE SPECIFICATIONS

Scheme 43

Scheme 43: Circuit Diagram
Scheme 43: Circuit Diagram
