Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 22 ~ +176°F (-30°C ~ +80°C) | |
| Rated load | Dimmer & passing switch | High: 0.2A (Relay load) Low: 0.2A (Relay load) Passing: 0.2A (Relay load) |
| Lighting switch | Lighting: 0.2A (Relay load) | |
| Turn signal switch | 6.6 ± 0.5A (Lamp load) | |
| Wiper & mist switch | Low, High: 4.5A (Motor load) Intermittent: 0.22 ± 0.05A (Relay load) Lock: Max. 28A (Motor load) Mist: 4.0A (Motor load) Washer: 4.0A (Motor load) | |
| Front fog lamp switch | 0.2A (Relay load) | |
| Rear wiper & washer | Wiper: 1.0A (Relay load) Washer: 4.0A (Motor load) | |
Scheme 1
Scheme 2
| Connector name | No | Description | Connector name | No | Description |
|---|---|---|---|---|---|
| Lighting (13 pin) | 1 | Tail lamp switch | Wiper & Washer (14 pin) | 1 | Mist switch |
| 2 | Lighting switch GND | 2 | Wiper parking | ||
| 3 | Auto light switch | 3 | Wiper low speed | ||
| 4 | Head lamp switch | 4 | Intermittent volume base | ||
| 5 | Fog lamp switch base | 5 | Intermittent time base | ||
| 6 | Front fog lamp switch | 6 | Rear wiper switch | ||
| 7 | 7 | Intermittent rear wiper switch | |||
| 8 | Head lamp low | 8 | Intermittent wiper switch | ||
| 9 | Head lamp high | 9 | Wiper high speed | ||
| 10 | Dimmer switch base | 10 | IGN2 (front washer & wiper) | ||
| 11 | Turn signal left | 11 | Washer switch | ||
| 12 | Turn signal base | 12 | IGN2 (rear wiper & washer) | ||
| 13 | Turn signal right | 13 | Rear washer switch | ||
| 14 | |||||
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws. NOTE: Take care not to damage and scratch the shrouds and its related parts. Take care not to damage the hook when removing the upper and lower shrouds.
- Disconnect the light switch connector (A) and the wiper switch connector (B).
- Remove the wiper switch (A) by pushing the lock pin (B). NOTE: When removing the wiper & washer switch only, release the lock of wiper switch without removing the steering wheel.
- Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-583683-S37145986352013102900000) ")
- Remove the clock spring. (Refer to the " «AIRBAG MODULE»(ref-583692) ")
- Loosen the screws from the multifunction switch assembly (A).
