Esc (Electronic Stability Control) System: Specifications Hyundai Tucson I

Anti-Lock/traction Control 8 illustrations

SPECIFICATIONS

Item	Specification
Operating Voltage	9V~16V
Operating temperature	30°C~75°C
Current consumption	Max. 100mA
Pulse duty	50+/-10%
Pulse width	8°/1 pulse
Voltage(HIGH)	3.0V~4.1V
Voltage(LOW)	1.3V~2.0V
Steering angle velocity	Max 1500°/sec

SPECIFICATIONS

Scheme 55

Scheme 55: CIRCUIT DIAGRAM

Scheme 55: CIRCUIT DIAGRAM

Scheme 56

Scheme 56: OUTPUT CHARACTERISTIC

Scheme 56: OUTPUT CHARACTERISTIC

No.	INPUT		OUTPUT	Steering direction	Remark
1	ST1	L	L	Right
	ST2	L	H	Right
	ST1	L	H	Left
	ST2	L	L	Left
2	ST1	L	L	Left
	ST1	H	L	Left
	ST1	L	H	Right
	ST2	H	H	Right
3	ST1	H	H	Left
	ST2	L	H	Left
	ST1	H	L	Right
	ST2	L	L	Right
4	ST1	H	H	Right
	ST2	H	L	Right
	ST1	H	L	Left
	ST2	H	H	Left

OUTPUT CHARACTERISTIC

Scheme 57

Scheme 57: DESCRIPTION

Scheme 57: DESCRIPTION

The yaw-rate & lateral G sensor is applied for the ESC system.
The yaw-rate is the angular velocity, when a vehicle turns a corner, and the lateral G is the acceleration to move a vehicle out of the way when cornering.

ITEM		SPECIFICATION	REMARK
Operating voltage		4.75 ~ 5.25V
Current consumption		Less than 65mA
Output voltage range		0.5 ~4.5V
Operating temperature		40 ~85°C
Yaw-rate sensor	Measurement range	75 ~ +75°/sec
	Output voltage range	0.5 ~ 4.5V
	Sensitivity	26.67mV(°/sec.)
	Zero rate output	2.5V
	Frequency response	18~22Hz
Lateral G. sensor	Measurement range	1.5 ~ +1.5g
	Output voltage range	0.5 ~ 4.5 V
	Sensitivity	0.136V/g
	Zero rate output	2.5V
	Frequency response	50Hz

SPECIFICATIONS

Scheme 58

Scheme 58: OUTPUT CHARACTERISTIC

Scheme 58: OUTPUT CHARACTERISTIC

Scheme 59

Scheme 59

Scheme 59

Scheme 60

Scheme 60: EXTERNAL DIAGRAM

Scheme 60: EXTERNAL DIAGRAM

Item	Specification	Remark
Supply voltage	4.75V ~ 5.25V
Supply current	Less than 15mA
Operating temperature	40°C ~ 125°C
Measurement pressure range	0 ~ 200bar
Max. pressure limit	350bar
Zero rate output	0.5V
Output range	0.5 ~ 4.4V

SPECIFICATIONS

Scheme 61

Scheme 61: CIRCUIT DIAGRAM

Scheme 61: CIRCUIT DIAGRAM

Scheme 62

Scheme 62: OUTPUT CHARACTERISTIC

Scheme 62: OUTPUT CHARACTERISTIC
