A/c Compressor Controls (Manual): Overview Hyundai Tucson I

A/c Compressor 6 illustrations ~202 words

Scheme 1

Scheme 1: COMPONENT LOCATION

DESCRIPTION

The triple switch is a combination of a medium switch as well as conventional low pressure and high pressure switches. The low pressure switch will turn off to stop compressor operation if refrigerant pressure is low. The high pressure switch will turn off to stop compressor operation if refrigerant pressure is too high. The medium switch will turn on at a medium level pressure to determine the A/C system is overheating. It will cool the A/C system by operating the radiator fan and the condenser fan at high speed.

  1. Rating load: Inductive load DC 12V, 10~250mA
  2. Applicable voltage range: DC 8V ~ DC 16V
  3. Applicable temperature range: -30°C ~ 120°C
  4. Applicable refrigerant: R-134a
  5. Insulation resistance: Min. 100 Mohm; at DC 500V
PressureONOFF
High32.0 +/- 2.026.0 +/- 2.0
Low2.3 + 0.25 / -0.292.0 +/- 0.2
Medium18.0 +/- 0.814.0 +/- 1.2

OPERATING CHARACTERISTICS (kg/cm 2 )

Scheme 2

Scheme 2: LOW & HIGH

Scheme 3

Scheme 3: MEDIUM

Scheme 4

Scheme 4: CONNECTOR
Pin No.1234
CircuitHigh & LowHigh & LowMediumMedium

TRIPLE PRESSURE SWITCH PIN NO. DESCRIPTION

Scheme 5

Scheme 5: CIRCUIT DIAGRAM

Scheme 6

Scheme 6: COMPONENT LOCATION

The thermistor will detect the core temperature and interrupt the compressor relay power to prevent evaporator freezing by excessive cooling.

The thermistor will use the thermal negative characteristic.

  1. Rated voltage: DC 12V
  2. Operating voltage: 9V ~ 16V
  3. Reserved temp. range: -40 ~ 90°C
  4. Using temp. range: -30 ~ 85°C
  5. Electric load: ECU
