# Courtesy lamps circuit, hybrid

# Courtesy lamps circuit, hybrid (1 of 3)

Interior lights — Courtesy lamps circuit, hybrid — Courtesy lamps circuit, hybrid (1 of 3). Hyundai Sonata VIII (2019-2023)
Components on the diagram

    # Courtesy lamps circuit, hybrid (2 of 3)

    Interior lights — Courtesy lamps circuit, hybrid — Courtesy lamps circuit, hybrid (2 of 3). Hyundai Sonata VIII (2019-2023)
    Components on the diagram

      # Courtesy lamps circuit, hybrid (3 of 3)

      Interior lights — Courtesy lamps circuit, hybrid — Courtesy lamps circuit, hybrid (3 of 3). Hyundai Sonata VIII (2019-2023)
      Components on the diagram
