Hyundai Sonata VIII (2019-2023) Hybrid cooling fan circuit

ACTIVE AIR FLAP ACTUATOR (LOWER) ACTIVE AIR FLAP SENSOR (DOWN LOWER) ACTIVE AIR FLAP SENSOR (UPPER LOWER) BATTERY C/FAN FUSE BATTERY C/FAN RELAY BLK WIRE BLU WIRE BMS BLOWER MOTOR BMS CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM CTRL E/R JUNCTION BLOCK ELECTRONIC WATER PUMP (ENGINE) ELECTRONIC WATER PUMP (HEV) ENGINE C/FAN PUMP, ACTIVE AIR FLAP (LOWER) ENGINE C/FAN PUMP, ACTIVE AIR FLAP (UPPER) EWP 1 FUSE EWP FUSE GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES HPCU ICU JUNCTION BLOCK ICU-E ICU-F LEFT ACTIVE AIR FLAP ACTUATOR (UPPER) LEFT ACTIVE AIR FLAP SENSOR (UPPER) LIN MEMORY PWR ON/START INPUT ORG/ WIRE P-CAN HIGH P-CAN LOW P-CAN LOW BMS-G PCM PNK WIRE PNK/BLK WIRE PWR RED WIRE RED/BLK WIRE RED/ORG WIRE RELAY ENERGIZED RIGHT ACTIVE AIR FLAP ACTUATOR (UPPER) RIGHT ACTIVE AIR FLAP SENSOR (UPPER) SENS DOWN GND SENS GND SENS UP GND SIG SPD BMS-F VDD WHT WIRE YEL WIRE
