Cylinder Head Specifications
| Class | Mark | Exhaust No. 1 Inside Diameter Of Cylinder Head Bore |
|---|---|---|
| A | A | 40.000 ~ 40.008mm (1.57480 ~ 1.5751in.) |
| B | B | 40.008 ~ 40.016mm (1.57511 ~ 1.57543in.) |
| C | C | 40.016 ~ 40.021mm (1.57543 ~ 1.57563in.) |
CYLINDER HEAD SPECIFICATIONS
- 2. Select class of camshaft bearing same as class of cylinder head as shown on the table below.
Scheme 129
Exhaust Camshaft Bearing Specifications
| Cylinder Head Bore Class | Bearing Class For Installing (Color) | Thickness Of Bearing |
|---|---|---|
| A (A) | C (Green) | 1.996~2.000mm (0.07858~0.07874in.) |
| B (B) | B (None) | 2.000~2.004mm (0.07874~0.07890in.) |
| C (C) | A (Black) | 2.004~2.008mm (0.07890~0.07905in.) |
EXHAUST CAMSHAFT BEARING SPECIFICATIONS
Oil clearance : 0 ~ 0.032mm (0 ~ 0.00126in.)
