Engine Cylinder Block - Hev: Specifications Hyundai Sonata VI

Mechanical 4 illustrations

Connecting Rod Specifications

ClassMarkInside Diameter
AA51.000 ~ 51.006mm (2.00787 ~ 2.00811in.)
BB51.006 ~ 51.012mm (2.00811 ~ 2.00834in.)
CC51.012 ~ 51.018mm (2.00834 ~ 2.00858in.)

CONNECTING ROD SPECIFICATIONS

Scheme 198

Scheme 198: Crankshaft Pin Identification Mark
Scheme 198: Crankshaft Pin Identification Mark

Note. Conform to read stamping order as shown arrow direction from #1.

Crankshaft Specifications

ClassMarkOutside Diameter Of Pin
I147.966 ~ 47.972mm (1.88842 ~ 1.88866in.)
II247.960 ~ 47.966mm (1.88819 ~ 1.88842in.)
III347.954 ~ 47.960mm (1.88795 ~ 1.88819in.)

CRANKSHAFT SPECIFICATIONS

Scheme 199

Scheme 199: Connecting Rod Bearing Identification Mark
Scheme 199: Connecting Rod Bearing Identification Mark

Connecting Rod Bearing Specifications

ClassMarkThickness Of Bearing
AABlue1.515 ~ 1.518mm (0.05965 ~ 0.05976in.)
ABlack1.512 ~ 1.515mm (0.05953 ~ 0.05965in.)
BNone1.509 ~ 1.512mm (0.05941 ~ 0.05953in.)
CGreen1.506 ~ 1.509mm (0.05929 ~ 0.05941in.)
DYellow1.503 ~ 1.506mm (0.05917 ~ 0.05929in.)

CONNECTING ROD BEARING SPECIFICATIONS

  1. (11) Select a connecting rod bearing using the selection chart.

Cylinder Block Specifications

ClassMarkInside Diameter
AA56.000 ~ 56.006mm (2.20472 ~ 2.20496in.)
BB56.006 ~ 56.012mm (2.20496 ~ 2.20519in.)
CC56.012 ~ 56.018mm (2.20519 ~ 2.20543in.)

CYLINDER BLOCK SPECIFICATIONS

Scheme 200

Scheme 200: Crankshaft Journal Identification Mark
Scheme 200: Crankshaft Journal Identification Mark
CAUTIONConform to read stamping order as shown arrow direction from #1.
ClassMarkOutside Diameter Of Journal
I151.954 ~ 51.960mm (2.04543 ~ 2.04567in.)
II251.948 ~ 51.954mm (2.04519 ~ 2.04543in.)
III351.942 ~ 51.948mm (2.04496 ~ 2.04519in.)

CRANKSHAFT SPECIFICATIONS

Scheme 201

Scheme 201: Crankshaft Bearing Identification Mark
Scheme 201: Crankshaft Bearing Identification Mark

Crankshaft Bearing Specifications

ClassMarkThickness Of Bearing
AABlue2.026 ~ 2.029mm (0.07976 ~ 0.07988in.)
ABlack2.023 ~ 2.026mm (0.07965 ~ 0.07976in.)
BNone2.020 ~ 2.023mm (0.07953 ~ 0.07965in.)
CGreen2.017 ~ 2.020mm (0.07941 ~ 0.7953in.)
DYellow2.014 ~ 2.017mm (0.07929 ~ 0.07941in.)

CRANKSHAFT BEARING SPECIFICATIONS

  1. (8) Select a crankshaft bearing using the selection chart.
