Scheme 25
Scheme 26
Scheme 27
Scheme 28
- Disconnect the negative (-) battery terminal.
- Remove the driver crash pad lower panel. (Refer to the " «CRASH PAD»(ref-424764-S23522138592011100100000) ")
- Remove the steering column upper and lower shrouds. (Refer to the " «CRASH PAD»(ref-424764-S23522138592011100100000) ")
- Remove the wiper switch. (Refer to the «WINDSHIELD WIPER-WASHER SWITCH»(ref-424789-S22559691172011100100000) )
- Remove the ignition switch after disconnecting the ignition switch 6P connector (A)
- Remove the key warning/immobilizer connector (A).
- After loosening the screw, remove the key warning switch and key Illumination (A).
- Pushing lock pin with key ACC.
- Remove the key lock cylinder (A).
INSTALLATION
- Install the key lock cylinder.
- Install the key warning switch and key Illumination.
- Install the key warning/immobilizer connector.
- Connect the ignition switch connector after Install the ignition switch.
- Install the wiper switch.
- Install the steering column shrouds.
- Install the driver crash pad lower panel.
Scheme 29
Scheme 30
Scheme 31
- Disconnect the ignition switch connector (A) and key warning switch connector (B) from the steering column.
- Check for continuity between the terminals.
- If continuity is not specified, replace the switch.
