Interior: Removal & Installation Hyundai Sonata V рестайлинг

FLOOR CONSOLE REPLACEMENT

Note. When prying with tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 2

Scheme 3

Scheme 4

1. Remove the front seat (See «REPLACEMENT»(ref-286605-S08154556812008060300000) ).
2. After remove the center cover (A).
3. Remove the floor console pad (A).
4. After loosening the console mounting screw, remove the floor console assembly (A).
5. Installation is the reverse of removal.

Scheme 5

Scheme 6

1. Remove the console assembly (See «FLOOR CONSOLE REPLACEMENT»(ref-286589-S18582238702008060300000) ).
2. Remove rear cover (A).
3. After loosening the armrest mounting screw, remove the armrest (A).
4. Installation is the reverse of removal.

Scheme 7

Scheme 8

Scheme 9

1. Remove floor console assembly (See «FLOOR CONSOLE REPLACEMENT»(ref-286589-S18582238702008060300000) ).
2. Remove the center garnish (A).
3. Remove the glove box (See «GLOVE BOX REPLACEMENT»(ref-286589-S30408833402008060300000) ).
4. Remove the center facia upper panel (See «CENTER FACIA PANEL REPLACEMENT»(ref-286589-S33157045932008060300000) ).
5. After loosening the crash pad lower panel mounting screw, then crash pad lower panel (A).
6. Installation is the reverse of removal.

CLUSTER FACIA PANEL REPLACEMENT

Note. When prying with tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 10

Scheme 11

1. Tilt the steering column down.
2. Remove the center garnish (A).
3. After disconnecting the trip sensor connector (A), remove the cluster facia panel (B).
4. Installation is the reverse of removal. NOTE: Make sure the connector is plugged in properly.

Scheme 12

1. After disconnecting the connector (A), remove the center facia panel (B). NOTE: When prying with tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.
2. Installation is the reverse of removal. NOTE: Make sure the connector is plugged in properly.

Scheme 13

Scheme 14

1. Remove the center garnish (See «CLUSTER FACIA PANEL REPLACEMENT»(ref-286589-S21281213062008060300000) ).
2. Loosening the crash pad lower panel mounting screw.
3. After Disconnecting the connector (A), remove lower panel (B).
4. Installation is the reverse of removal.

Scheme 15

Scheme 16

Scheme 17

1. After disconnecting the connector (A), remove the center facia lower panel (B).
2. Loosening the heater control mounting screw, remove heater control unit (C).
3. Installation is the reverse of removal. NOTE: Make sure the connector is plugged in properly.

Scheme 18

Scheme 19

1. Remove the cluster facia panel (See «CLUSTER FACIA PANEL REPLACEMENT»(ref-286589-S21281213062008060300000) ).
2. Loosen the screws.
3. Disconnect the cluster connector (A), then remove the cluster (B).
4. Installation is the reverse of removal. NOTE: Make sure the connector is plugged in properly.

Scheme 20

Scheme 21

1. Remove the center facia panel (See «CENTER FACIA PANEL REPLACEMENT»(ref-286589-S33157045932008060300000) ).
2. Loosen the screws.
3. Disconnect the audio connector (A) and antenna cable (B), then remove the audio assembly (C).
4. Installation is the reverse of removal. NOTE: Make sure the connector is plugged in properly.

Scheme 22

Scheme 23

1. Disconnect the damper (A) from the glove box (B).
2. Disconnect the pin (A), then remove the glove box (B).
3. Installation is the reverse of removal.

COVER REPLACEMENT

Note. When prying with tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 24

Scheme 25

Scheme 26

1. Remove the crash pad side cover (A), crash pad center under cover (B). Crash pad side cover. Front crash pad center under cover, LH Remove the console assembly (See «FLOOR CONSOLE REPLACEMENT»(ref-286589-S18582238702008060300000) ). Front crash pad center under cover, RH Remove the console assembly (See «FLOOR CONSOLE REPLACEMENT»(ref-286589-S18582238702008060300000) ).

AIR VENT REPLACEMENT

Note. When prying with a flat-up screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 27

1. Remove the air vent (A) by detaching the clips.
2. Installation is the reverse of removal.

CRASH PAD REPLACEMENT

Note. When prying with tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 28

1. Remove the following items. Front seat (See «REPLACEMENT»(ref-286605-S08154556812008060300000) ). Cluster facia panel, cluster (See «CLUSTER FACIA PANEL REPLACEMENT»(ref-286589-S21281213062008060300000) , «CLUSTER REPLACEMENT»(ref-286589-S37925532482008060300000) ). Audio assembly (See «CLUSTER FACIA PANEL REPLACEMENT»(ref-286589-S21281213062008060300000) , «CLUSTER REPLACEMENT»(ref-286589-S37925532482008060300000) ). Glove box (See «GLOVE BOX REPLACEMENT»(ref-286589-S30408833402008060300000) ). Side cover, center under cover (See «COVER REPLACEMENT»(ref-286589-S38195249572008060300000) ). Front pillar trim (See «FLOOR AND SIDE TRIM»(ref-286589-S26922904462008060300000) ).
2. Disconnect the passenger's air bag connector (A). Loosen the bolt and nut, then remove the crash pad (B).
3. Installation is the reverse of removal. NOTE: Make sure the crash pad fits onto the guide pins correctly. Before tightening the bolts, make sure the crash pad wire harnesses are not pinched. Make sure the connectors are plugged in properly, and the antenna lead is connected properly. Enter the anti-theft code for the radio, then enter the customer's radio station presets.

Scheme 29

1. Remove the trim. NOTE: Put on gloves to protect your hands. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. Take care not to bend or scratch the trim and panels.
2. Installation is the reverse of removal. NOTE: Replace any damage clips.

Scheme 30

1. Remove the trim. NOTE: Put on gloves to protect your hands. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. Take care not to bend or scratch the trim and panels.
2. Installation is the reverse of removal. NOTE: Replace any damage clips.

Scheme 31

1. Remove the trim. NOTE: Put on gloves to protect your hands. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. Take care not to bend or scratch the trim and panels.
2. Installation is the reverse of removal. NOTE: Replace any damage clips.

Scheme 32

1. Remove the trim. NOTE: Put on gloves to protect your hands. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. Take care not to bend or scratch the trim and panels.
2. Installation is the reverse of removal. NOTE: Replace any damage clips.

Scheme 33

REMOVAL

Note. Put on gloves to protect your hands. Use seat covers to avoid damaging any surfaces.

Scheme 34

Scheme 35

Scheme 36

1. Remove the following items. Inside rear view mirror. Sun visors and holders, both side, overhead console, grab handles, both sides. Front pillar trim, both sides. Windshield wiper arms and cowl cover.
2. Remove the windshield glass side molding (A).
3. Pull down the front portion of the headliner. Take care not to bend the headliner excessively, or you may crease or break it.
4. Cut out the sealant using the sealant cutting tool (A) (09861-31100).
5. Remove the windshield (A) carefully using the glass holder (B) (09861-31100).

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Remove the excess sealant from the glass with a window scraper.
2. Remove the excess sealant and foam dam from the body with a knife.
3. Clean the inside of the glass with commercial glass cleaner and a lint-free cloth.
4. Prime an area approximately 20 mm (3/4 inch) wide around the complete primer of the glass.
5. Prime the contact area on the body.
6. Reprime the same area on the inside surface of the glass. CAUTION: Do not permit any primed surface to become contaminated with dirt, water, oil, etc. Do not touch primed surfaces with your hands. Contamination will affect adhesion.
7. Install the self-adhesive foam dam to the body where the original dam had been.
8. Apply the sealant bead to the body just outside the dam. The bead should be slightly higher than the dam.
9. Install molding on the glass.
10. Install the glass into the body making sure the glass rests upon the two spacers at the bottom of the windshield.
11. Press glass firmly into place. CAUTION: Lower both front door windows and leave them in that condition until the vehicle can be put back into service. If the vehicle were completely closed, quickly closing a door could break the seal.
12. Remove excess sealant, if any.
13. Press molding firmly into place.
14. Perform water leak test immediately.
15. Clean the outside of the windshield.
16. Install both of the front pillar trim.
17. Install the inside rearview mirror.
18. Install the cowl top cover with three fasteners.
19. Install both wiper arm assemblies with one nut each.
