Power Windows: Other Hyundai Sonata V рестайлинг

FUNCTION OF SAFETY POWER WINDOW

When driver door power window auto-up switch is operated, safety function is activated.

Scheme 2

Scheme 3

Scheme 4

1. Safety function condition When detect the force of 100N during the window rising, window is reversed.
2. Length of window reversing (except holding the auto-up switch) When detect the jamming during the 4mm ~ 250mm from top of the door. --> Window is reversed until 300mm from top of the door. When detect the jamming over the 250mm from top of the door. --> Window is reversed until 50mm from jamming position.
3. Length of window reversing (holding the auto-up switch) When detect the jamming during holding the auto-up switch. --> Window is reversed until 25mm from jamming position. Auto-up function is not available during the 5 seconds from above condition. --> When holding the auto-up switch, window is operated as a manual-up function. (Safety function is not activated.) When holding the auto-up switch after 5 seconds from above condition. --> Window is reverse until 25mm from jamming position.
4. Safety function is not available area Safety function is not available during the 4mm from top of the door.

INITIALIZING METHOD OF THE SAFETY POWER WINDOW

1. Initializing of Battery Connection When the battery is not connected the vehicle over the 5 minutes, safety power window switch need the initializing. Power window operation before initializing Manual-Up/Down function is available Auto-Up function is not available (When holding the auto-up/down switch, window is operated as a manual-up/down.) Initializing method Close the window in window open position, and holding the switch in window full close position over the 0.2 second. (If start the closing the window in window full close position, initializing could be failed.) If initialize the safety power window in jamming status, could occur below conditions. Safety function is not available
2. Initializing of fail safe mode If the window moved by compulsion and motor have a problem, power window switch could be entering the fail safe mode for user' s safety. Power window operation in fail mode Auto/Manual-Down function is available Auto/Manual-Up function is not available (When auto/manual-up is operated, window is rising 20mm and is stopped the moving.)

Scheme 5

Scheme 6

Scheme 7

1. Remove the front door trim panel. (Refer to the «FRONT DOOR»(ref-286607-S30751851552008060300000) )
2. Disconnect the connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 8

1. Remove the rear door trim panel. (Refer to the «REAR DOOR»(ref-286607-S11892231462008060300000) )
2. Disconnect the 2P connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to the «FRONT DOOR»(ref-286607-S30751851552008060300000) )
3. Disconnect the 14P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 14

Scheme 15

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to the «FRONT DOOR»(ref-286607-S30751851552008060300000) )
3. Disconnect the 11P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim panel. (Refer to the «REAR DOOR»(ref-286607-S11892231462008060300000) )
3. Disconnect the 8P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 19

Scheme 20

Scheme 21

1. Disconnect the negative (-) battery terminal.
2. Remove the junction box.
3. Check for continuity between the terminals.
4. There should be continuity between the No.1 in the I/P-G and No. 12 terminal in the I/P-A when power and ground are connected to the No.1 terminal in the I/P-G and No.2 terminal in the I/P-A.
5. There should be no continuity between the No.1 terminal in the I/P-G and No.12 terminal in the I/P-A when power is disconnected.

Scheme 22

Scheme 23

Scheme 24

1. No windows operate from the main switch on the driver's door.
2. Driver's side window does not operate.
3. Passenger's side window does not operate.
