Power Windows: Removal & Installation Hyundai Sonata IV

Removal & Installation (Accent)

1. Remove side view mirror inner cover. Remove side view mirror mounting screws, and remove mirror. Remove inside door handle bezel. Remove armrest. Insert a flat screwdriver between trim fasteners and door panel, and pry it loose. Remove door panel and trim seal. Remove outside weatherstrip. Remove carrier plate bolts from regulator channel. Slide window to closed position and secure in place.
2. Remove regulator retaining screws. Disconnect power window motor harness connector. Remove regulator and motor as an assembly. Remove screw attaching power window motor to window regulator. Separate power window motor from window regulator. To install, reverse removal procedure. (Scheme 1)

Removal & Installation (Elantra)

1. Remove side view mirror inner cover. Remove side view mirror mounting screws, and remove mirror. Disconnect remote control connector (electric mirror).
2. Remove screws from inside handle bezel and armrest. Remove door panel retaining screws. Insert a flat screwdriver between trim fasteners and door panel, and pry it loose. Remove door speaker.
3. Disconnect harness connectors at power window main switch, door lock actuator, side view mirror, and trunk lid opener switch. Remove door panel. Remove door speaker and speaker mounting bracket. Remove trim seal and outside weatherstrip. Remove carrier plate bolts from regulator channel. Slide window to closed position and secure in place.
4. Remove regulator retaining screws. Disconnect power window motor harness connector. Remove regulator and motor as an assembly. Remove screw attaching power window motor to window regulator. Separate power window motor from window regulator. To install, reverse removal procedure. (Scheme 1)

Removal & Installation (Sonata)

1. Remove side view mirror inner cover. Remove side view mirror mounting screws, and remove mirror. Disconnect remote control connector (electric mirror).
2. Remove screws from inside handle bezel and armrest. Remove power window main switch and disconnect harness connector. Remove door panel retaining screws. Insert a flat screwdriver between trim fasteners and door panel, and pry it loose. Remove door speaker.
3. Disconnect harness connectors at power window motor, door lock actuator, side view mirror, and trunk lid opener switch. Remove door panel. Remove outside weatherstrip. Remove carrier plate bolts from regulator channel. Slide window to closed position and secure in place.
4. Remove regulator retaining screws. Disconnect power window motor harness connector. Remove regulator and motor as an assembly. Remove screw attaching power window motor to window regulator. Separate power window motor from window regulator. To install, reverse removal procedure. (Scheme 1) Adjust window glass as needed.

Scheme 1

Removal & Installation (Tiburon)

1. Remove inside handle bezel. Remove power window main switch and disconnect harness connector. Remove screws from inside grip handle. Insert a flat screwdriver between trim fasteners and door panel, and pry it loose. Remove door panel and disconnect door lamp connector.
2. Remove carrier plate bolts from regulator channel. Slide window to closed position and secure in place. Remove regulator retaining screws. Disconnect power window motor harness connector. Remove regulator assembly. Remove screw attaching power window motor to window regulator. Separate power window motor from window regulator.
3. To install, reverse removal procedure. (Scheme 1) Adjust window glass as necessary. See «ADJUSTMENTS»(ref-4085-S25190278522000061200000).

Power Window System Wiring Diagram (Accent). Scheme 2

Power Window System Wiring Diagram (Elantra). Scheme 3

Power Window System Wiring Diagram (Sonata). Scheme 4

Power Window System Wiring Diagram (Tiburon). Scheme 5
