STARTER SPECIFICATIONS
| Application | Specification |
|---|
| Armature Maximum Runout |
| Standard | .002" (.05 mm) |
| Limit | .004" (.10 mm) |
| Brush Length | (1) |
| Commutator Outside Diameter |
| Accent | (2) |
| All Others |
| Standard Diameter | 1.16" (29.4 mm) |
| Wear Limit | 1.12" (28.4 mm) |
| Insulator Depth |
| Accent | (2) |
| All Others |
| Standard Depth | .020" (.50 mm) |
| Wear Limit | .008" (.20 mm) |
| Pinion Gap | .02-.08" (.5-2.0 mm) |
| (1) Bottom of limit line that is stamped into brush. (2) Information is not available from manufacturer. |
| (1) | Bottom of limit line that is stamped into brush. |
| (2) | Information is not available from manufacturer. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Starter Mounting Bolts | 20-25 (27-34) |
Starting System Wiring Diagram (Accent - USA). Scheme 1
Scheme 1: Starting System Wiring Diagram (Accent - USA)
Starting System Wiring Diagram (Accent - Canada). Scheme 2
Scheme 2: Starting System Wiring Diagram (Accent - Canada)
Starting System Wiring Diagram (Elantra). Scheme 3
Scheme 3: Starting System Wiring Diagram (Elantra)
Starting System Wiring Diagram (Sonata - A/T). Scheme 4
Scheme 4: Starting System Wiring Diagram (Sonata - A/T)
Starting System Wiring Diagram (Sonata - M/T). Scheme 5
Scheme 5: Starting System Wiring Diagram (Sonata - M/T)
Starting System Wiring Diagram (Tiburon). Scheme 6
Scheme 6: Starting System Wiring Diagram (Tiburon)
