Power Windows Hyundai Santa Fe III

Windows 26 illustrations ~845 words

Scheme 16

Scheme 16: Component Location

Function Of Safety Power Window

When driver door power window auto-up switch is operated, safety function is activated.

Scheme 17

Scheme 17: Function Of Safety Power Window

Scheme 18

Scheme 18

Scheme 19

Scheme 19
  1. Safety function condition When detect the force of 100N (using the 10N/mm spring) during the window rising, window is reversed.
  2. Length of window reversing (except holding the auto-up switch) When detect the jamming during the 4mm ~ 250mm from top of the door. --> Window is reversed until 300mm from top of the door. When detect the jamming over the 250mm from top of the door. --> Window is reversed until 20mm from jamming position.
  3. Length of window reversing (holding the auto-up switch) When detect the jamming during holding the auto-up switch. --> Window is reverse until 25mm from jamming position. Auto-up function is not available during the 5 seconds from above condition. --> When holding the auto-up switch, window is operated as a manual-up function. (Safety function is not activated) When holding the auto-up switch after 5 seconds from above condition. --> Window is reverse until 25mm from jamming position.
  4. Safety function is not available area Safety function is not available during the 4mm from top of the door.

Initializing Method Of The Safety Power Window

  1. Initializing of Battery Connection When the battery power is removed for over 5 minutes, the power window safety switch needs to be re-initialized. Power window operation before initializing Manual-Up/Down function is available Auto-Up function is not available (When holding the auto-up/down switch, window is operated as a manual-up/down.) Initializing method Close the window from a window fully down position, and hold the switch in the windows fully up position for at least 1 second. (if safety power window initialization is attempted with the windows already fully closed, initialization could fail) Initializing the safety power window feature could be unavailable if the window is jammed.
  2. Initializing of fail safe mode If the window will not move while operating the window switch, the motors could be in a fail safe mode. Power window operation in fail mode Auto/Manual-Down function is available Auto/Manual-Up function is not available (When auto/manual-up is operated, window is rising 20mm and is stopped the moving.)

Scheme 20

Scheme 20: Components

Scheme 21

Scheme 21: Circuit Diagram

Scheme 22

Scheme 22: Front Power Window Motor

Scheme 23

Scheme 23

Scheme 24

Scheme 24
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim. Refer to «FRONT DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door) .
  3. Disconnect the connector (A) from the motor. (A: Safety, B: Standard)
  4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.
  5. Connect the terminal No. 2 and No. 3 to battery voltage (12V) and check that the motor operates smoothly when connecting the terminals below.

Scheme 25

Scheme 25: Rear Power Window Motor

Scheme 26

Scheme 26
  1. Disconnect the negative (-) battery terminal.
  2. Remove the rear door trim. Refer to «REAR DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#rear-door) .
  3. Disconnect the connector (A) from the motor.
  4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 27

Scheme 27: Driver Power Window Switch

Scheme 28

Scheme 28: Assist Power Window Switch

Scheme 29

Scheme 29: Rear Power Window Switch

Scheme 30

Scheme 30: Driver Power Window Switch

Scheme 31

Scheme 31

Scheme 32

Scheme 32: Assist Power Window Switch

Scheme 33

Scheme 33

Scheme 34

Scheme 34: Power Window Switch

Scheme 35

Scheme 35: Diagnosis With GDS

Scheme 36

Scheme 36
  1. The BCM can be diagnosed by using the GDS. The BCM communicates with the GDS which then displays inputs and outputs along with codes. It will be able to diagnose defects of power door lock/unlock with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. To diagnose the SJB function, select the vehicle model, BCM and DDM/ADM.
  3. Select "Input/output monitoring", if you will check current data of power door lock system. It provides input/output status of DDM/ADM.
  4. To perform functional test on SJB outputs, select "Actuation Test".

Scheme 37

Scheme 37: Driver Power Window Switch

Scheme 38

Scheme 38
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim. Refer to «FRONT DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door) .
  3. Remove the power window bezel assembly (A) after loosening the mounting screws (12EA).
  4. Remove the power window switch assembly (A) after loosening the mounting screws (6EA).

Scheme 39

Scheme 39: Assist Power Window Switch
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim. Refer to «FRONT DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door) .
  3. Remove the power window switch assembly (A) after loosening the mounting screws (5EA).

Scheme 40

Scheme 40: Rear Power Window Switch

Scheme 41

Scheme 41
  1. Disconnect the negative (-) battery terminal.
  2. Remove the rear door trim. Refer to «REAR DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#rear-door) .
  3. Remove the power window switch assembly (A) after loosening the mounting screws (3EA).
  4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Driver Power Window Switch

  1. Install the power window switch assembly.
  2. Install the front door trim after connect the connector.

Assist Power Window Switch

  1. Install the power window switch assembly.
  2. Install the front door trim after connect the connector.

Rear Power Window Switch

  1. Install the power window switch assembly.
  2. Install the rear door trim after connect the connector.
